5. 10 major SHARP manufacturing plants introduced PV systems 9 Sites Installation completed Annual Output : approx. 575MWh KAMEYAMA HIROSHIMA TENRI NARA TOCHIGI KATSURAGI 10 Sites Installation should be completed by 2005 Annual Output : approx. 600MWh Targeting to be Global warming Zero impact company by 2010 Sharp Factory with PV
6. Gunching: 1.9MW Muhlhausen: 6.3MW Minihof: 1.9MW ・ Total size: 10.1MW ・ Location: Bavaria, Germany Photo : by courtesy of Powerlight Corporation Germany
7. ・ 1.7MW Solar Power PlantThe ・ Location : Sonnen Germany ・ installed in November, 2002 [SHARP: PV Modules supply] Germany
9. ・ SIZE: 904 kW ・ PLACE: Oakland California United States
10. ・ 10KW Residential System with 3 Inverters ・ Location : California ・ installed : 2004 Page United States
11. ・ System Size: 4.6MW ・ Location: Prescott, AZ United States
12. 145KW System ・ Central Bank of the Netherlands [SHARP: PV Modules supply] The Netherland
13. ・ 400Kw ・ Location : PAESTUM ( SALERNO ) October 2004 Photo by Juwi /M.Frank 。 Italy
14. 1MW System ・ Location : Mindanao ・ Date: March 2004 [SHARP: PV Modules supply] Philippine
15. School-40kW Telecenter-10kw Village office-10KW Hospital –40kw- Power Center –100kw- Ulan Bator Noyon Soum Mongolia New Energy and Industrial Technology Development Organization International Joint Experimental Study of Photovoltaic Power Generation System
18. [100kW System] ・ Location : Hiroshima Pref. (Mihara filter plant ) ・ Date: February, 2004 ・ Flower of the Sun Japan
19. United States ・ System Size: 904kW ・ Location: Oakland, CA ・ Installation: Aug’2005 ・ System Size: 1.18MW ・ Location: Butte County ・ Installation: Oct’2004 ・ System Size: 588kW ・ Location: South Whether ・ Installation: July’2004 ↑ Roof of carport
20. Solar Panel (Poly Crystal ) NE-080T1J Solar Street light Out Power : 80 W Application : stand-alone photovoltaic system( off-grid) Certificate : JET Approved (IEC61215 Ed2,IEC61730) Weight : 9.0 Kg Dimensions (W x H x D ) : 545 x 1,214 x 35 mm
21. Solar Panel (Poly Crystal ) ND-T060M1 Solar Home System Out Power : 60 W Application : stand-alone photovoltaic system( off-grid) Certificate : JET Approved (IEC61215 Ed2,IEC61730) Weight : 7.5 Kg Dimensions (W x H x D ) : 671 x 787 x 46 mm
22. SPECIFICATION Model name NE-080T1J ND-T060M1 Power(W) 80(+10%-5%) 60W(+15%-5%) Cell Poly 126 ×126(mm) Poly 156.5 ×78.3(mm) Number of cell 36 36 Open circuit voltage (Voc) 21.6V 22.0V Short circuit current (Isc) 5.15A 3.90A Maximum power voltage (Vpm) 17.3V 17.4V Maximum power current (Ipm) 4.63A 3.45A System Voltage (V) 600V 600V Dimension of module 1,214×545×35mm) 787×671×46(mm) Weight 9.0kg 7.5kg Performance standard IEC 61215 Ed2(JET) IEC 61215 Ed2(JET) Safety standard IEC 61730(JET) IEC 61730(JET)
23. 参考・編集ページ Battery AC220V-50Hz AC110V-60Hz DC12V Lamp Radio TV Charge Controller Small Home System Battery AC220V-50Hz AC110V-60Hz DC12V Lamp Radio TV Charge Controller Small Home System
24. SHARP Solar System Group PHOTOVOLTAIC SODIUM STREET LAMP 18 Watt DC for 7 meter Heights GE Sodium Lamp 18 Watt DC Power Electrical Flow
25. SHARP Solar System Group Jayapura Street Lamp 64 unit for realization May 2008 first step and for the 1000 unit next 2010. Tanjung Selor Street Lamp total installation 540 unit for 2010. Finished Order
26. PT SHELTER PRIMA PERKASA Kemang Point Building 3rd floor, suite 306 Jl. Kemang Raya No.3 Jakarta Phone : 021-7182114 Fax : 021-7196163 Contact Person : Crescentia Reenandya (Reena) – 081 551 78 799 Soemadji – 0815 165 2777
Editor's Notes
Well then, let’s take a look at achievement examples by Sharp. This picture shows the example in Sharp Kameyama Factory. We install various kinds of PV including Crystalline, Thin-film and double glass Built-In PV (BiPV) Total output is 5.21MW, and it is the biggest PV installation on the building.
These are the Stand Alone PV system in the developing countries. Dating back to 1986, SHARP has succeeded in installing the 150kW PV system in Thailand. This system is installed as the experimental research project with NEDO (New Energy Development Organization). The photo of lower left is also the installation in the developing countries conducted by another PV company. Photo of lower right is the PV system in Senegal for water supply project . As you can imagine, there are still huge potential demand for solar energy throughout the worlds. Especially in Africa, the demand for small sized PV system for rural electrification is growing and attracting great attention. There are so many people in the world who can’t access electricity. Getting involved in the rural electrification project is really rewarding.
These are examples of a big generation plant. It is an example of the intensive power station which it receives a German kind treatment measure, and was built. Here, I introduce a system of 6.3MW from 1.9MW. It is scale of 10MW by total. An establishment company raises a fund from an individual and a company and attracts its attention as new business model to reduce the profit that I use a kind treatment system of electricity buying up, and to buy electricity did to its elements to each investor. When construction of such a large-scale power station advances, in Europe, the future is expected a strong new energy kind treatment of the government by taking a step.
This is a installation cade in Germany. A 240kW single crystalline PV modules mount on the roof of the soccer stadium.
This is the installation case for residential use in USA. Capacity of this system is 10kW. This is about 3 times of Japanese average size.
