1. DATA SHEET
SMARTFINGER EMBEDDED DEVELOPMENT & EVALUATION KITS
SMARTFINGER EMBEDDED DEVELOPMENT KITS SMARTFINGER EVALUATION KIT
IDEX SmartFinger Film Sensor supports many types of controllers and The SmartFinger Evaluation kit (Part# IX-EVAL-01) consists of a Demo
development kits. The IDEX development kits consist of an IDEX Unit, a USB cable and PC Software (including drivers). The Demo Unit
development board, the SmartFinger Film sensor plug-on module, a is connected to the PC using USB 2.0 High Speed.
controller development board and an RS232 module.
In addition IDEX delivers pre-compiled software libraries for any Cortex-
M3 based microcontroller. The libraries are free of any I/O or OS
related code in order to maximize their applicability and portability.
The following controllers/kits are supported:
Part No. Description
IX-EDK-ST-F107 STM32F107 dev. kit
IX-EDK-ST-F103 STM32F103 dev. kit
IX-EDK-AT-SAM3S ATMEL SAM3S dev. kit
IX-EDK-AT-SAM7S ATMEL SAM7S dev. kit
IX-EDK-NXP-LPC NXP LPCXpresso LPC1768/69 dev. kit
IX-EDK-FS-K60 Freescale Kinetis TWR-K60N512 dev. kit
The picture below shows the STM32 development kit.
Together with the PC Software this unit can demonstrate the
capabilities of the IDEX SmartFinger Film Fingerprint Sensor and the
Image Reconstruction (IR) and Enrolment & Matching (E&M)
algorithms.
The Demo Unit is equipped with a SmartFinger Film Fingerprint sensor
for capturing the fingerprint, and the Raw Image data is transferred to
the PC via USB, where the IR and E&M algorithms are executed. The
PC Software can run on Windows XP, Windows Vista and Windows 7
(32/64 bit).
About IDEX ASA
nsure individuals a safe, secure, and
user-friendly use of personal ID. IDEX has developed the award-winning SmartFinger® Film technology platform including the patented fingerprint imaging principle,
sensing scheme and chip design combined with core software algorithms for imaging and authentication.
IDEX develops and supplies the patented SmartFinger® Film fingerprint sensor technology and software algorithms which enables on device enrollment, template
storage and verification within the very same module. SmartFinger® Film is extremely thin and flexible and can be customized for a variety of applications such as One
Time Password devices, Smartcards, ID cards, access control devices and biometric tokens.
The SmartFinger® technology is available to customers under an intellectual property (IP) licensing scheme or as SmartFinger® Film sensor assemblies for integration
into customer products. IDEX ASA (ticker IDEX) is listed at the Oslo Axess market place on the Oslo Stock Exchange.
