Session four
1. http://www.bized.co.uk
Session 4
Prepared by
Alaa Salah Shehata
Mahmoud A. M. Abd El Latif
Mohamed Mohamed Tala’t
Mohamed Salah Mahmoud
Version 02 – October 2011
Copyright 2006 – Biz/ed
4. Session 4
http://www.bized.co.uk
Data Operators Concatenation
Used to merge two operands together using the concatenation operator (&).
This result is an array in which length is the sum of lengths of both operands.
C <= A & B A B
C
4
Copyright 2006 – Biz/ed
6. Session 4
http://www.bized.co.uk
Data Operators Concatenation
A7 A0
Shift Right Register:
A <= „0‟ & A(7 downto 1);
0
A7 A1
A7 A0
Shift Left Register:
A <= A(6 downto 0) & „0‟ ;
0
A6 A0
6
Copyright 2006 – Biz/ed
7. Session 4
http://www.bized.co.uk
Data Operators Concatenation
A7 A0
Shift Right Register:
A <= A(7) & A(7 downto 1);
A7 A7 A1
we use this shifting when we need to keep
the sign in our vector and not losing it.
A7 A7 A7 A2
7
Copyright 2006 – Biz/ed
9. Session 4
http://www.bized.co.uk
Data Operators Concatenation
A7 A0
Rotate Right Register:
A <= A(0)& A(7 downto 1);
A0 A7 A1
A7 A0
Shift Left Register:
A <= A(6 downto 0) & A(7);
A6 A0 A7
9
Copyright 2006 – Biz/ed
10. Session 4
http://www.bized.co.uk
Data Operators Aggregate
Provides an easy way of assigning objects of composite types
The aggregate assigns values to a selected elements of an array or a record.
Example 20
Signal data_bus : std_logic_vector(15 downto 0);
data_bus <= (15 downto 8 => '0' , others => '1');
“0000000011111111”
data_bus <= (1 | 4 | 7 => '1', 2 | 3 => '0', others => 'Z');
“ZZZZZZZZ1ZZ1001Z”
data_bus <= (others => ‘Z'); -- fill data_bus with ones
“ZZZZZZZZZZZZZZZZ”
10
Copyright 2006 – Biz/ed
14. Session 4
http://www.bized.co.uk
Attributes Attribute Return value
Attributes allow returning information about entities , architectures ,
types , signals Count’left 0
„left, „right, „high, „length, ‟range, „event, … States’left Idle
Word’left 15
Note
Pronounce the apostrophe as “tick “ Count’right 127
States’right Write
Example Word’right 0
Type count is integer range 0 to 127 ; Count’high 127
States’high Write
Type states is ( idle , decision , read , write ) ;
Word’high 15
Type word is array ( 15 downto 0 ) of std_logic ;
Count’low 0
Note
States’low Idle
As we know if we need to ask about the rising edge of the clk we Word’low 0
can say
if rising_sdge(clk) then Count’length 128
States’length 4
by using attributes we also can ask about the clk with other formula Word’length 16
that says
if (clk’event and clk = ‘1’) then
14
Copyright 2006 – Biz/ed
15. Session 4
http://www.bized.co.uk
• General example on Attributes
Example
21
15
Copyright 2006 – Biz/ed
16. Session 4
http://www.bized.co.uk
ARCHITECTURE examp OF attrs IS
Type myInt is range 0 to 15; Type states is (red, yellow, green);
Type word is array (15 downto 0) of std_logic;
Signal count: integer; signal mySig: myInt;
signal state : states;
BEGIN
process
begin
mySig <= myInt'left; count <= word'left; state <= states'left;
wait for 10 ns;
mySig <= myInt'right; count <= word'right; state <= states'right;
wait for 10 ns;
mySig <= myInt'low; count <= word'low; state <= states'low;
wait for 10 ns;
mySig <= myInt'high; count <= word'high; state <= states'high;
wait for 10 ns;
count <= word'length;
wait;
end process;
END ARCHITECTURE examp;
16
Copyright 2006 – Biz/ed
18. Session 4
http://www.bized.co.uk
As clock is found in your design..
the output registered (saved) and appeared next clk cycle
18
Copyright 2006 – Biz/ed
24. Session 4
http://www.bized.co.uk
Download Session 4 material
Session 4.pdf
Labs4.txt
Ask for the material through mail
start.courses@gmail.com
Facebook group
start.group@groups.facebook.com
24
Copyright 2006 – Biz/ed
