1. The Rust Programming Language
Patrick Walton
All Hands Winter 2011

2. Overview
• What is Rust?
• How has the Rust design evolved over the past year?
• How far have we come in implementation?
• What are we going to use Rust for?

3. What is Rust?
use std;
import std::{ int, vec };
fn main(grades : [str]) {
let results = vec::map({ |s|
if int::parse(s) >= 70 { “Pass” }
else { “Fail” }
}, grades);
log results;
}

4. What is Rust?
• Rust is a new systems programming language designed for
safety, concurrency, and speed.
• It was originally conceived by Graydon Hoare and is now
developed by a team in Mozilla Research and the community.

5. What is Rust? — Safety
• Rust has no null pointers. The typical replacement for a
nullable pointer is std::option<T>.
• Rust is memory-safe, outside of designated unsafe blocks,
which can be easily audited.
• Rust features typestate, an analysis that allows the compiler to
track predicates that you define.

6. What is Rust?—Typestate
• Typestate isn’t new—it’s in Java!
public static void main() {
String s;
if (new Date().getHours() < 12)
s = “Good morning!”
System.out.println(s); // Error: s may be uninitialized
}

7. What is Rust?—Typestate
• The same initialization checking takes place in Rust through the
typestate system and the so-called init predicate. Each value
must hold the init predicate (i.e. be initialized) before use.
fn main() {
let s : str;
if date::localtime(date::now()).hours < 12u {
s = “Good morning!”
}
log s; // Error: predicate ‘init’ does not hold
}

8. What is Rust?—Typestate
• Beyond this, Rust allows you to define your own predicates.
• Functions can demand that certain predicates be true before
calling them is allowed.You can also use values with predicates
as first-class types, such as int|prime.
• You use the check statement to make the Rust compiler
aware of assertions that you’re performing. The assertion is
checked at runtime, and the program aborts if the assertion
fails.

9. What is Rust?—Typestate
• Suppose we have these declarations:
pred in_range(array : [int], start : uint, end : uint) {
start < end && end < vec::len(array)
}
fn slice(array : [int], start : uint, end : uint)
-> [int] : in_range(array, start, end) { ... }

10. What is Rust?—Typestate
• Then we can’t call slice in the normal way:
fn main() {
let v = [ 1, 2, 3, 4, 5 ];
log v.slice(2, 3); // error: predicate
//‘in_range(v, 2, 3)’ does
// not hold
}

11. What is Rust?—Typestate
• But we can if we use a check statement:
fn main() {
let v = [ 1, 2, 3, 4, 5 ];
check in_range(v, 2, 3);
log v.slice(2, 3); // OK
}

12. What is Rust?—Typestate
• Why is this useful?
• The Rust compiler remembers the assertions that you’ve
performed, so that you don’t have to perform them
repeatedly.
• With typestate, assertions are in the function signature,
which helps make functions self-documenting.

13. What is Rust?—Concurrency
• Rust is designed for concurrency on a large scale, following
the principles of Erlang.
• You can spawn thousands of tasks in the same process.
• Under the hood, the Rust scheduler spawns one or two OS
threads per CPU and schedules your tasks appropriately.

14. What is Rust?—Concurrency
fn do_something_expensive() -> bigint {
ret factorial(99999999);
}
fn main() {
let task = spawn(do_something_expensive);
log join(task);
}

15. What is Rust?—Concurrency
• While they’re running, tasks can communicate via channels
and ports.
• Ports and channels are typed; e.g. port<int>,
chan<dom_node>.
• Ports are the receiving endpoint; channels are the sending
endpoint. Mnemonic: bodies of water.
• Multiple channels can go to the same port.

16. What is Rust?—Concurrency
fn something_expensive(ch : chan<bignum>) {
send(ch, factorial(99999999));
}
fn main() {
let p = port();
spawn(bind something_expensive(chan(p)));
log recv(p);
}

17. What is Rust?—Concurrency
• Rust ensures that there is no shared state.
• There is no need for mutex locks, condition variables, atomic
operations, or concurrent garbage collection.
• All unique pointers (~) are allocated in a shared heap and
move from task to task by simply copying a pointer.
• All boxed pointers (@) are allocated in task-local heaps and
never move.

18. What is Rust?—Concurrency
• We enforce these concurrency-related invariants through our
type system.
• Unique pointers (denoted by ~) are the only pointers that
can be sent.
• Once you send a unique pointer, you lose access to it.
• This is enforced through typestate; the unique pointer, once
moved, loses its init predicate.

19. What is Rust?—Speed
• We use the LLVM compiler infrastructure, which is used by
the Clang C++ compiler, for the self-hosted compiler.
• We benefit from all of LLVM’s optimization passes.

20. What is Rust?—Speed
• We strive for predictable runtime performance with a
minimum of overhead.
• Performance should be comparable to idiomatic C++; that is,
C++ with use of the STL and avoiding highly unsafe
constructs.
• We also have an unsafe sublanguage that allows direct pointer
manipulation. It’s restricted to blocks and functions marked
unsafe.

21. What is Rust?—Speed
• We support three type layers to make memory management
simple and fast.
• Interior types (denoted with no sigil) are stored on the stack.
• Unique types (denoted with ~) have ownership semantics. When
the pointer goes out of scope, the object it’s pointing to is
destroyed.
• Boxed types (denoted with @) are garbage-collected. Multiple
boxes can point to the same data.

22. What is Rust?—Speed
• All together:
fn main() {
let a = ~3; // Unique pointer to number
let b = a; // Copies a
let c = @3; // Box of number
let d = c; // c & d point to the same value
} // a and b destroyed; c and d will be GC’d

23. Language changes
• A year ago, we announced Rust at the Mozilla Summit.
• Since then, we’ve made a large number of changes to the
language syntax and semantics.
• Writing the Rust compiler in Rust helped us to quickly find
and fix the painful areas of the language.

24. Language changes—Syntax
• One year ago:
fn f(&option.t[str] s) {
auto r;
alt (s) {
case (some(?ss)) { r = rec(x=123, y=ss); }
case (none) { fail; }
}
}

25. Language changes—Syntax
• Today:
fn f(s : option::t<str>) {
let r = alt s {
some(ss) { { x: 123, y: ss } }
none. { fail }
};
}

26. Language changes—Syntax
• Small changes:
• We’ve removed parentheses around if, alt, while, etc.
• Pattern matching syntax has been tweaked. Switch
statements (alt) no longer require case.
• Types now go after variable bindings: let int x is now
written let x : int.

27. Language changes—Closures
• Instead of simply supporting a bind form, we now essentially
have full-featured closures.
• Closures are written as Ruby-style blocks:
vec::eachi([ 1, 2, 3 ], { |x, i| // Parameters
log “Element #“, i, “ is “, x;
});

28. Language changes—Sharing
• When Rust was initially designed, only immutable data
structures could be sent over channels, like Erlang.
• But we still needed copying to avoid global garbage collection.
• What we really need is to avoid sharing, not immutability.
• The immutability restriction is now the ownership restriction—
you can only send data you own, and after you send it you
lose that ownership.

29. Language changes—Macros
• One year ago, macros were more like compiler plugins—they
were DLLs loaded by the rustc compiler that could
manipulate its internal code representation.
• These kinds of macros are still supported, but we wanted
macros to be usable by people other than compiler hackers.
• So now we have macro-by-example, which are pattern-
matching macros like those of Scheme.

30. Current status
How far are we from achieving our goals of safety, concurrency,
and speed?

31. Current status—Safety
• We have a type-safe, memory-safe language with a self-hosted
compiler.
• We have hundreds of unit tests and a testing framework.
• We’re missing garbage collection and stack unwinding.
• The compiler isn’t yet production-quality. Crashes are
uncommon but still happen.

32. Current status—Concurrency
• We have a working concurrency system that operates
similarly to Erlang and Grand Central Dispatch.
• Thousands of simultaneous tasks are supported.
• We’re currently missing growable stacks (to prevent address
space exhaustion), unique pointers and closures (for fast data
sharing), and OS process isolation.

33. Current status—Speed
• Our compiler benefits from LLVM’s optimizations and highly-
tuned code generation.
• On simple numeric kernels, we generally perform well.
• We’re currently slower than we’d like to be on generic code
(type-passing), memory management (too much copying), and
cross-crate calls (no inlining).

34. Roadmap
• A tentative roadmap:
• Rust 0.1 (soon!): Garbage collection/cycle collection; stack
unwinding; unique pointers; unique closures; stack growth.
• Future: Rewritten backend; cross-crate function inlining;
improved LLVM garbage collection; iterators; fleshed-out
standard libraries; package management.

35. Project Servo
Or: “So why are we doing this?”

36. Servo Project
• Rust is a critical piece of the Servo project, which is a project
to develop a parallel browser engine.
• We don’t know how, or whether, we will ship this engine to
end users at the moment; it’s very much a research project. It
might be a new product, become a part of Gecko/Firefox, or
remain purely a research platform.
• Nevertheless, we want our code to be production quality.

37. Servo Project—Architecture
Web content dom.js Servo engine Platform APIs
HTML + JavaScript JavaScript Rust C++

38. Servo Project—Architecture
• Servo is not planned to feature a cross-language component
model.
• Instead, all JavaScript–Rust communication is performed via
the Rust message passing system.
• The single-threaded parts of the browser will run in
JavaScript and communicate asynchronously with the highly
parallel Servo engine written in Rust.

39. Servo Project—Components
• These components are planned to be written in Rust:
• A parallel HTML/JavaScript/SVG/CSS parser.
• A layout engine that performs parallel layout, including CSS
selector matching, box reflows, etc.

40. Servo Project—Components
• These components are planned to remain in C++ for the first
few iteration:
• The SpiderMonkey JavaScript engine.
• The graphics rendering engine “Azure”.

41. Servo Project—Components
• These components will be written in JavaScript and HTML:
• The DOM will be dom.js, in order to avoid the problems of
XPCOM (cross-language cycles, SpiderMonkey optimization
hazards, etc.)
• The UI will be all HTML and JavaScript.

42. Servo Project—Getting Involved
• We’re still in the early stages of development, but you can
help!
• dom.js is actively being worked on and we’d love to have your
help: http://github.com/andreasgal/dom.js
• If you have ideas along the lines of “what I would do if I could
start over from scratch”, particularly if you’re a platform
hacker, we’d like to know!

43. Thanks
• The Rust team
• Brian Anderson (brson)
• Tim Chevalier (tjc)
• Marijn Haverbeke (marijn)
• Dave Herman (dherman, @littlecalculist)
• Graydon Hoare (graydon, @graydon_moz)

44. Thanks
• And the Rust interns:
• Roy Frostig (froystig)
• Eric Holk (eholk, @theinedibleholk)
• Lindsey Kuper (lkuper, @lindsey)
• Paul Stansifer (pauls, @paulstansifer)
• Michael Sullivan (sully)

45. Questions?
@rustlang
irc.mozilla.org #rust
http://github.com/graydon/rust
