1. REST made simple with Java
SDC 2008

2. Niklas Gustavsson
niklas@protocol7.com
http://protocol7.com
http://twitter.com/protocol7

3. REST made simple with Java

4. REST?

5. HTTP 1.1

6. Some HTTP history

7. Some HTTP history

8. HTTP done right

10. Principles

11. Principles
Everything is a resource

12. Principles
A resource has an identifier
http://example.com/customers/1453

13. Principles
We transfer representations

14. Principles
All resources expose a uniform interface
GET, POST, PUT, DELETE

15. Principles
Hypermedia as the engine of application state

16. Principles
Client-server, Stateless, Cacheable, Layered

17. Why?

18. Why?
It's easy! Well, it's not

19. Why?
It's what the cool kids use

20. Why?
Web has been successful, copy!

21. Why?
It's what others use

22. Why?
Interoperability on the right level

23. Frameworks, yeay!

24. JAX-RS
(aka JSR-311)

25. Jersey http://jersey.dev.java.net
Restlets http://www.restlet.org
RESTeasy http://www.jboss.org/resteasy
CXF http://cxf.apache.org

26. POJO based
Annotation heavy

27. Resources

28. Code! Show me the code!

29. public class TimeReportService {
private TimeReportDao reportDao;
public TimeReport getReport(String username) {
return reportDao.forUser(username);
}
public void saveReport(TimeReport report) {
reportDao.update(report);
}
...
}

30. Request mapping

31. @Path(quot;reportquot;)
public class TimeReportService {
private TimeReportDao reportDao;
@GET
public TimeReport getReport(String username) {
return reportDao.forUser(username);
}
@PUT
public void saveReport(TimeReport report) {
reportDao.update(report);
}
...
}

33. public class TimeReportApplication extends Application {
@Override
public Set<Class<?>> getClasses() {
Set<Class<?>> resources = new HashSet<Class<?>>();
resources.add(TimeReportService.class);
return resources;
}
}

34. Path parameters and contexts

35. @Path(quot;{username}/reportquot;)
public class TimeReportService {
@GET
public TimeReport getReport(@PathParam(quot;usernamequot;)
String username) {
return reportDao.forUser(username);
}
...
}
http://example.com/niklas/report

36. @GET
public TimeReport getReport(@Context SecurityContext sc) {
if(sc.isSecure()) {
Principal user = sc.getUserPrincipal();
return reportDao.forUser(user.getName());
} else {
... throw error, redirect to login
}
}

37. @GET
public TimeReport getReport(@CookieParam(quot;usernamequot;)
String username) {
return reportDao.forUser(username);
}

39. Any media type is allowed
XML, JSON, text/plain, Binary files, ...

40. Entity providers
MessageBodyReader, MessageBodyWriter

41. Standard Entity providers

43. Writing your own Entity provider

44. BEGIN:VFREEBUSY
DTSTART:20090324T080000Z
DTEND:20090324T170000Z
DTSTAMP:20090316T123136Z
UID:ca668b14ddf589ea8650b0b992eb64a656cdbc7e@google.com
SUMMARY:SDC2009
END:VFREEBUSY

45. @Provider @Produces(quot;text/calendarquot;)
public class TimeReportICalWriter implements
MessageBodyWriter<TimeReport> {
public void writeTo(TimeReport t, Class<?> type, Type
genericType,Annotation[] annotations,MediaType
mediaType,MultivaluedMap<String, Object> httpHeaders,
OutputStream entityStream) {
PrintWriter wr = new PrintWriter(entityStream);
...
for(TimeRange range : t.getRanges()) {
wr.println(quot;BEGIN:VFREEBUSYquot;);
wr.println(quot;DTSTART:quot; + DF.format(range.getStartTime()));
wr.println(quot;DTEND:quot; + DF.format(range.getEndTime()));
wr.println(quot;SUMMARY:quot; + range.getDescription());
wr.println(quot;END:VFREEBUSYquot;);
}
...
}

46. Response, ResponseBuilder

47. Exception
Mapping

48. Deployment

49. JAX-RS limitations

50. JAX-RS limitations
Lifecycle support

51. JAX-RS limitations
Weak support for links, caching, method tunneling

52. JAX-RS limitations
Accept based content negotiation only
http://example.com/report
http://example.com/report.xml
http://example.com/report.cal
http://example.com/report.json

53. JAX-RS limitations
Limited security support

54. JAX-RS limitations
Leaky abstraction

55. Try it out!
And have a look at the alternatives

56. Want more?

57. Questions?
