Real-time Geospatial Aircraft Monitoring Using Apache Kafka
"Capturing geospatial data of aircraft is data intensive due to needing frequent updates for the quickly changing position and velocity data points. A well-tuned real-time system for high throughput and low latency is a must as data is useless to operators if it is just a few seconds behind as they cannot make meaningful real-time decisions otherwise. In addition, the collaboration between operators must also be in real-time. This system, called Raft’s Data Fabric, modernizes this process for the United States Air Force as the communication layer for the systems acting upon real-time geospatial data of all aircraft over the United States airspace. Data Fabric is built with Apache Kafka at its core. It uses KeyCloak for authentication, Open-Policy Agent for authorization, Kafka Streams for stateful processing, database systems (relational, OLAP, and document) for search, WebSockets for visualization integration, and Grafana for observability. From this real-world use case of using real-time technologies, you will walk away knowing how to build end-to-end real-time systems with Apache Kafka at its core. Specifically: * Tuning Apache Kafka for high throughput and low latency for small and larger messages. * Building a WebSocket Kafka consumer for web-based visualization. * Securely fusing and moving real-time data from unsecured to secured environments to provide better decision-making abilities. * Integration with database systems for real-time and historical use cases. * Reasons to consider leveraging OAUTH authorization and Open Policy Agent for authorization for your Kafka Cluster."
Recommended
Recommended
More Related Content
Similar to Real-time Geospatial Aircraft Monitoring Using Apache Kafka
Similar to Real-time Geospatial Aircraft Monitoring Using Apache Kafka (20)
More from HostedbyConfluent
More from HostedbyConfluent (20)
Recently uploaded
Recently uploaded (20)
Real-time Geospatial Aircraft Monitoring Using Apache Kafka
- 1. March 2024 · Kafka Summit London Real-time Geospatial Aircraft Monitoring Using Apache Kafka Bhaarat Sharma – CTO & Co-Founder Raft Neil Buesing – CTO & Co-Founder Kinetic Edge
- 2. March 2024 · Kafka Summit London We bridge the gap between humans and data through radical transparency and our obsession with the mission..
- 4. March 2024 · Kafka Summit London Inspired by: Perishable Insights, Mike Gualtier, Forrester
- 7. March 2024 · Kafka Summit London SQL over Kafka (backed by Pinot)
- 8. March 2024 · Kafka Summit London Fine grained access to dashboard
- 10. March 2024 · Kafka Summit London Architecture - Focus for today
- 13. March 2024 · Kafka Summit London Message Format XML ● XML ⇒ JSON ✔ ● JSON ⇒ XML ✖ consumers expected XML (& valid against XSD schema) ● Additional Challenges ○ marshaling bytes into XML ○ schema validation speed ○ thread safety
- 14. March 2024 · Kafka Summit London Message Format XML ● Custom Serializers - when XML parsing is "read-only" ○ XMLWrapper(byte[] bytes, Document document) ○ wrapper.serialize(xmlWrapper)
- 15. March 2024 · Kafka Summit London Message Format XML ● XOM ○ Slightly better thread safety ○ Faster Implementation ○ Still built on existing Parser technologies ■ so not fully better thread safety
- 16. March 2024 · Kafka Summit London Message Format XML ● XSD Validation ○ Only on incoming or outgoing topics.
- 17. March 2024 · Kafka Summit London Message Format XML ● Staying with XML easier than converting back to XML. ● Optimize Read-Only for speed by compromising on Storage. ● Lessons learned here would apply to other formats; just more obvious with XML.
- 18. March 2024 · Kafka Summit London Throughput and Latency Challenge 2 100k msgs/sec 150+ Sensors Multiple Sensor Fusion Engines Enhanced Search
- 19. March 2024 · Kafka Summit London Configurations - Topics Challenge 2 – Throughput and Latency ● 12 partitions ○ even distribution across availability zones (÷3) ○ even consumer workloads ■ 1/2/3/4/6/12 (6) ● Currently evaluating 24 for some topics ○ also evenly distributed across availability zones (÷3) ○ 1/2/3/4/6/8/12/24 (8) ■ 30->1/2/3/5/6/10/15/30 (7) ■ 36->1/2/3/4/6/9/12/18/36 (9)
- 20. March 2024 · Kafka Summit London Configurations - Producer Challenge 2 – Throughput and Latency ● buffer.size=200_000 ○ or more ● linger.ms=10-50 ○ balance of latency & throughput ● compression.type=lz4 ○ Always test your data against your compression ○ Never compress compressed data
- 21. March 2024 · Kafka Summit London Configurations - Consumer Challenge 2 – Throughput and Latency ● 12 partitions ○ even distribution across availability zones (÷3) ○ even consumer workloads ■ 1/2/3/4/6/12 ● max.partition.fetch.bytes & fetch.max.bytes ○ adding partitions can increase latency (especially if number of consumers isn't increased)
- 22. March 2024 · Kafka Summit London Configurations - Performance Challenge 2 – Throughput and Latency ● Start with the producer ● Then the partitions ● Kafka Streams ○ State Store - Caching (Disable for Latency) ○ Commit Interval (Reduce for Visibility and Latency) ○ Threading - depends on topology & number of containers.
- 24. March 2024 · Kafka Summit London Authentication - Keycloak Challenge 3 – Authentication & Authorization ● OAuth Callback Handler ○ Kafka 3.2.1+ ○ self-signed certificates ... ● Custom Callback Handler ○ error handling considerations ● Librdkafka (Non-Java) ○ Leverage callback handler doing RESTful operation (custom callback)
- 25. March 2024 · Kafka Summit London Authorization – Open Policy Agent Challenge 3 – Authentication & Authorization ● OPA Rego ☞ reminds me of Prolog ● .rego examples consumer_operations = { "TOPIC" : [ "READ", "DESCRIBE" ], "GROUP" : [ "READ", "DESCRIBE" ] } is_consumer_group { user_groups(principal)[_] == topic_consumer_groups(topic_name)[_] } allow_consumer_group { is_group_resource is_consumer_operation startswith(group_name, concat("-", [principal, ""])) }
- 26. March 2024 · Kafka Summit London Pattern of life analysis – Warm Data Challenge 4 Source: ADSB Exchange
- 27. March 2024 · Kafka Summit London Custom Kafka Rest API Challenge 4 – Pattern of Life Analysis ● One of the easiest parts to build ○ Producer ■ linger.ms - major impact - chose wisely ○ Consumer -- not RESTful ☞ Websockets ● One of the easiest mistakes to make - waiting... ○ producer flushing ○ linger.ms ○ Callback vs. Waiting on Future Leverage Framework, e.g. Spring's Deferred Result ● Http Response Codes ○ 200 - OK ○ 201 - Created (try to avoid using this one, but some clients....) ○ 202 - Accepted
- 28. March 2024 · Kafka Summit London Real Time Data – Hot Data Challenge 5 Source: ADSB Exchange
- 29. March 2024 · Kafka Summit London Websocket - Consumer Challenge 5 – Real Time Data – Hot Data ● consumer.subscribe() vs. consumer.assign() ● handling backpressure ● tried Java 21 and Virtual Threads - did not help... ● 2 implementation ○ web-socket consumption drains queue ○ 30 second eviction (independent of consumption) ● garbage collection topic poll() websocket LinkedBlockingQueue push()
- 30. March 2024 · Kafka Summit London Websocket - Consumer Challenge 5 – Real Time Data – Hot Data ● Data Mashing over Websocket ○ XML - not great ○ JSON - better ○ Apache Arrow - best topic poll() websocket LinkedBlockingQueue push() consumer thread thread / websocket
- 32. March 2024 · Kafka Summit London Kafka Streams Challenge 6 – Real Time Data Enrichment ● Avoid initial rekeying (trust but verify), every rekey adds latency. filter((k, v) -> { if (k ≠ v.id()) { log.error("invalid..."); return false; } ● Global Tables / KTables
- 33. March 2024 · Kafka Summit London Kafka Streams Challenge 6 – Real Time Data Enrichment ● Commit Interval ○ 100ms - 5000ms ● Threads ○ Containers vs Stream Threads ● If Scaling down and up (and not using static membership) internal.leave.group.on.close = true ● If Scaling down and up (and static membership + Kafka Streams 3.3+) KafkaStreams.CloseOptions closeOptions = new KafkaStreams.CloseOptions().timeout(SHUTDOWN).leaveGroup(true); streams.close(closeOptions);
