Sales Kit for Raider PSU

1. P O W E R S U P P L Y
P O W E R S U P P L Y
450/550/650/750W
Sales Kit
V2.2012.04.19

2. P O W E R S U P P L Y
• Market need 80PLUS Bronze models, we will
get more Market share.
• Customers prefer Single Rail design (demands
on Middle-Range VGA card)
• Raider series covers wide-range watts with
high C/P ratio

3. Product Position P O W E R S U P P L Y
 Gamers
High-End  Hardware Enthusiasts
 Overclockers
RAIDER 650/750
• Segment - Mainstream
• Target - Active/DIY user/Gamer
• Positioning - High C/P, Support
Mainstream Multi-GPU
 DIY market
RAIDER Series  Active user
650/750  Gamers
RAIDER 450/550
• Segment - Entry Level
• Target - Gamer/ DIY user
RAIDER Series • Positioning - High C/P
450/550
 SI market
Entry Level  Office PC
 Gamers

4. Best Choose P O W E R S U P P L Y
Best choice in performance
• SATA ARRAY CABLE, EASY INSTALLATION
• +12V SINGLE RAIL DESIGN
• NOISE < 19 DBA AT 50% LOADING
• MUTLIPLE PCI-E 6+2 PIN CONNECTORS FOR ALL
MAINSTREAM VGA CARD

5. FSP MIA ICTM P O W E R S U P P L Y
FSP MIA ICTM Technology (Multiple Intelligence Ability)
• FSP’s own Patented Design
• Active-Clamp Topology with MIA IC + POST SR
• Eco-Friendly Design
1) Reliability & High Compatibility
2) High Efficiency - Zero Current Switching Technique
3) Max Protection - OVP, OCP, SCP, OPP, UVP
Application No. 100109686

6. Feature P O W E R S U P P L Y
+12V Single Rail Design
- Designed for power-intensive VGA cards.
- Provides strong power to any overloading condition.
SATA Array Cable
- 50mm intervals for 4 SATA device installation
- Optimized the airflow in case
- No-hassle with case side panel

7. Feature P O W E R S U P P L Y
POSR SR (Post Synchronous Rectifier)
Optimized the 3.3V/5V/12V start-up setting, with ZCS
PFC benefits, it may avoid the switching loss and
strengthen the efficiency significantly.
Multiple PCI-E Connectors
PCI-E 6+2 pin Connectors for all kinds of Graphic
Cards

8. Cable Distribution P O W E R S U P P L Y
20+4 PIN 4+4 PIN 6+2 PIN SATA MOLEX FLOPPY
450W 1 1 2 5 3 1
550W 1 1 2 6 3 1
650W 1 1 2 6 3 1
750W 1 1 4 9 3 1
1) 60cm EPS12V 4+4P, Good Wiring for Tower Case
2) 450W/550W/650W = 2 x PCI-E 6+2pin
750W = 4x PCI-E 6+2pin

9. Specifications P O W E R S U P P L Y
RA450
RA550
RA650
RA750

10. Feature P O W E R S U P P L Y
 +12V Single Rail Design
 SATA Array Cable
 120mm Quiet Fan, 20% Loading < 18dBA, 50% Loading < 19dBA,
100% Loading < 25dBA
 All series come with PCI-E 6+2 Pin connectors
 FSP MIA ICTM inside
 80PLUS Bronze Certificated, efficiency > 85%
 Complies with ATX 12V 2.31 & EPS 12V 2.92 version
 Active PFC, power factor ≥ 99%
 Complete Protections: OCP, OVP, OPP, SCP, UVP
 Full Safety Approved: TUV / CE / UL / FCC / BSMI /
GOST / C-tick / CCC

11. Color Box P O W E R S U P P L Y
• Raider series come with 450W/550W/650W/750W
• All kinds of wattage have uniqueness color

12. Key Vision P O W E R S U P P L Y
Retailer LOGO

13. Supplementary materials P O W E R S U P P L Y
• NVIDIA VGA :
VGA Maximum Graphics Minimum System Power Supplementary Power
Card Power Requirement Connectors
Geforce GTX590 365W 700W 2 x 8pin
Geforce GTX580 244W 600W 6 + 8pin
Geforce GTX570 219W 550W 2 x 6pin
Geforce GTX560 150W 450W 2 x 6pin
Geforce GTX560Ti 210W 550W 2 x 6pin
Geforce GTX550Ti 116W 400W 6pin
Geforce GTX545 GDDR5 105W Non
Geforce GTX545 GDDR3 70W Non
Geforce GT520 29W 300W Non
Geforce GT530 50W Non
Geforce GT510 25W Non
Source from NVIDIA Official Website

14. Supplementary materials P O W E R S U P P L Y
VGA Maximum Graphics Minimum System Power Supplementary
Card Power Requirement Power Connectors
Geforce GTX480 600W 6+8pin
Geforce GTX470 550W 2 x 6pin
Geforce GTX465 550W 2 x 6pin
Geforce GTX460 150W 450W 2 x 6pin
Geforce GTX450 106W 400W 6 pin
Geforce GTX440 65W 300W Non
Geforce GTX430 49W 300W Non
Geforce GTX405 25W Non
Geforce GTX405 Non
Geforce 210 300W Non
Geforce 8400GS Non
Source from NVIDIA Official Website

15. Supplementary materials P O W E R S U P P L Y
• ATI VGA Source from AMD Official Website
VGA Maximum Graphics Card Minimum System Power Supplementary
Power Requirement Power Connectors
HD 7970 75+150W 500W 6 + 8pin
HD 7950 75+150W 600W 6 + 8pin
HD 7770 75W 500W 6pin
HD 7750 75W 500W 6pin
HD 6990 150W 750W 8pin X 2
HD 6970 75+150W 550W 6 + 8pin
HD 6950 75W 500W 6pin X 2
HD 6870 75W 500W 6pin X 2
HD 6850 500W 6pin X 2
HD 6790 75W 500W 6pin X 2
HD 6770 75W 450W 6pin
HD 6750 75W 450W 6pin
HD 6670 non 400W Non
HD 6570 non 400W Non
HD 6450 non 400W Non

16. Supplementary materials P O W E R S U P P L Y
VGA Maximum Graphics Card Minimum System Power Supplementary
Power Requirement Power Connectors
HD 5970 75+150W 650W 6 + 8pin
HD 5870 Eyefinity 6 75+150W 600W 6 + 8pin
HD 5870 75W 500W 6pin X 2
HD 5850 75W 500W 6pin X 2
HD 5830 75W 500W 6pin X 2
HD 5770 75W 450W 6pin
HD 5750 75W 450W 6pin
HD 5670 non 400W non
HD 5570 non 400W non
HD 5550 non 400W non
HD 5450 non 400W non
Source from AMD Official Website

17. P O W E R S U P P L Y
T h a n k Yo u !
