This document provides information about Precise Implant Systems Ltd., a dental implant manufacturer. It summarizes the company's profile, products, and key features. The company manufactures four types of implants - PSI Precise Spiral Implant, PST Precise Spiral Top, PSS Precise Spiral Standard, and PHI Precise Helical Implant. The implants are made of titanium alloy and feature a nano-mesh surface coating that promotes osseointegration. The document describes the features and intended benefits of each implant type. It also outlines the surgical drills, instruments, prosthetics and abutments available from the company.

1. PSS PST
PHI
PSI
Catalog 2015
Precise Implant Systems Ltd.
P.O.B 45469
Tel-Aviv 6145401
ISRAEL
info@precise-is.com
www.precise-is.com
Ref.7042Ver.2.01

4. 3
Table of content:
Company Profile 4
Nano-Mesh Surface 5
Surgical Kit 6
Tapered and Cylindrical Implants 7
The advantages 8
PSI - Precise Spiral Implant 9-12
PST- Precise Spiral Top Implant 13-16
PSS - Precise Spiral Standard Implant 17-20
PHI - Precise Helical Implant 21-24
Drills and Surgical Instruments 25-30
Prosthetics and Abutments 31-35

5. ■ Company profile
We are the same but much better!
4
Precise company believes in making dental implants by redefining
precision in the process of manufacturing, marketing and service.
We combine this new level of precision with simplicity and quality control
together with state of the art scientific knowledge, to achieve vast
improvements over existing implants.
The partners in Precise have more than 30 years of experience as leading
developers and marketers of implants and prosthetic parts, with proven
sales of more than a million implants by other brands.
Precision
In Precise, we focus on making precision implantology. The products that
we manufacture are of the highest quality, and they provide easy-to-use
solutions. We strive for total customer satisfaction by producing the
ultimate kit that addresses any clinical need.
Science
Precise is based on the principle of science by nature. This principle is
carried out to its practical applications, which reflect our solution-driven
technological innovations.
High Standards
Precise is committed to the highest level of accuracy and quality control to
produce the best possible implants. The company's products comply with
all the requirements of medical devices and are CE approved (0473) .
Product Range
Precise manufactures four types of dental implants and a variety of
prosthetic parts, as well as extremely accurate, Internal-Hex, "one platform
for all diameters" components, which enable the dentist to maintain
a minimal inventory of prosthetic parts.
Our products are designed for maximum Bone-to-Implant-Contact (BIC),
maximum initial stability, safe and easy insertion and high aesthetics.

6. ■ Precise Nano-MeshSurface
Our implants are treated with a state-of-the art process and
high purity surface that promotes bone growth and
accelerating osseointegration.
An advance process consisting of particles blasting that
dramatically increases the macro face area followed by dual
thermal acid etching that farther increases the micro face area
into a final 3D micro structure that enables and promotes the
osseointegration.
The Nano-Mesh surface provides hydrophilic properties to the
implants and thus encourages and supports the blood clot
theory that effects the bone growth.
Precise Nano-Mesh characteristics are:
■ Hybrid macro and micro surface structure
■ High oxide layer
■ Excellent bio-compatibility surface
■ Faster Bone-to-Implant-Contact (BIC)
■ High wettability characteristics
5
■ Precise Implants
The geometry and features of our family of dental implants,
along with our meticulous manufacturing process, result in
implants that ensure maximum precision, smooth insertion and
a more comfortable, natural healing process for the patient.
The implant family uses classic implant design and surface
treatments, and an intermediate micro-thread, to achieve larger
bone-to-implant surface area contact.
Precise Implants are made of biocompatible, extremely strong
Ti-6Al-4V ELI medical-grade Titanium alloy. Features such as
flutes cut at the apex and a tapered body shape render the
implant self drilling and self tapping. These make the implant
insertion process as streamlined as possible, resulting in firmer
contact with the bone.
■ PSI Precise Spiral Implant
■ PST Precise Spiral Top
■ PSS Precise Spiral Standard
■ PHI Precise Helical Implant

7. ■ Surgical Drills
Precise’s surgical drills are available in variety of diameters and
are made of surgical stainless steel. The drills are color coded for
easy diameter identification and laser-marked on depth grooves
for easy reference during surgery.
■ Precise Prosthetics
Precise’s diverse prosthetic array provides implant professionals
in the dental industry with comprehensive solutions for all the
common dental restorative procedures.
The meticulously designed prosthetic system features straight,
angled and casting abutments, as well as ball attachments in
various lengths, permitting versatile restoration with narrow
implants. Our unique single restoration platform enables the use
of any abutment of any implant diameter.
■ Surgical Instruments
Our surgical kit is comprised of essential surgical
instrumentation for implantation procedures
■ Surgical Kit
The Precise surgical kit consists of basic
surgical instrumentation for carrying out all
implantation procedures.
Autoclaveble kit, user-friendly and simple
to use, with optimal and
convenient tool arrangement.
■ Ergonomically-designed box
■ Compact and light to carry
■ Shock-resistant plastic compounds compatible for over
■ 1000 autoclave sterilization cycles
■ Carefully arranged and sectioned tray to accommodate
■ instruments in separate compartments
■ Individual silicon fixtures that hold instruments
■ and prevent movement during transport, even if the kit
■ is turned upside down
■ Ware resistant and easy to clean laser-etched markings
■ Dimensions: 19 cm x 14 cm x 6.9 cm
Materials:
■ Box: Large - Radel R polyphenylsulfone resin
Small - Stainless Steel
■ Tool fixtures: Autoclavable medical-grade silicon
■ Bath: Stainless Steel
Four different working positions with non-skid tray
6
P-SKP
94069Ref.
P-SKS
94068Ref.
Large Kit Small Kit

8. 7
■ PSI
Precise Spiral Implant
With its science, design and
quality control, the PSI implant
introduces a whole new level
of stability, comfort and bone
completion. This is why we
can proudly assert that Precise
applies the principle of
science by nature, carrying out
its technological innovation to
practical solutions.
■ Cylindrical Implants
■ PHI
Precise Helical Implant
Our classical, mainstream, implant is an indispensable element of every implant system available in the
market. The PHI promotes bone condensing and creates overall stability. It is ideal for hard bone but suitable
for common cases too.
■ Tapered Implants
The tapered implants are the heart of the implant world. The implants are ideal for soft bone of types III and IV.
Moreover, in special cases they may be used also in hard bone* of type I and II.
■ PST
Precise Spiral Top
Based on PSI’s characteristics
and advantages, the PST
implant is at the top of the
dental implant world today in
terms of aesthetics, due to it's
concave coronal portion
design.
■ PSS
Precise Spiral Standard
Enhanced variation of
common standard spiral
implant with superior
finishing, which greatly
outperforms competing
products.
* This does not constitute a recommendation for the dentist on how to use these implants.

9. The advantages of using Precise’s tapered implants:
■ These implants enable penetration into locations with thicker
diameter and in soft tissue and softer bones (bone types III
and IV)
■ The narrow tapered implant is suitable for cases of limited
bone width and it prevents damage to the anatomical
structure
■ The implants enable reasonable alteration of the implantation
direction during the implant procedure
■ These implants are ideal for immediate implantation as well as
for immediate loading
■ They can be indicated for any condition, bone type and
surgical protocol
■ They promote bone condensing and provide enhanced
primary stability
■ The threads in the coronal portion are thicker trapezoid, in
the middle portion are thinner square and in the apical
portion, where the borders are straight, the threads are
sharper and V-shaped
To summarize, the advantages mentioned herein constitute
implants that enable easy insertion even to narrow locations
with high primary stability, prevent damage to the anatomical
structure and are self tapping.
The clinical advantages:
Our implants allow better bone condensing and offer high
primary stability and minimum bone loss, thus reducing trauma.
They can be implanted in areas with narrow ridges and narrow
location, preventing damage to adjacent teeth. They can be
precisely controlled during the implantation through the
insertion pathway, meaning that their angle can be changed
during the procedure to reduce the perforation in the lingual
and buccal cortex and finally sited in the desired location.
The implants' enhanced stability is achieved even with small
bone mass and in soft bone areas – necessary in many clinical
cases. This is the result of the special implant body, thread
design and the apical portion.
■ PSI ■ PSS ■ PST ■ PHI
8

10. With its science, design and
quality control, this implant
introduces a whole new level of
stability, comfort and bone
completion. This is why we can
proudly assert that Precise
applies the principle of science
by nature, carrying out its
technological innovation to
practical solutions.
■ PSI
Precise Spiral Implant
PSI

11. 10
The next generation of the
tapered implants!
The PSI implant has a complex, new
variable threads design that enlarged
from the apex toward the coronal
portion. This structure features two
tunnels that provide better fixation to
the bone by at least 30% compared to
implants with standard thread design.
The variable fixation channels enable
much easier insertion toward the top, to
achieve the excellent stabilization
familiar to anyone working with tapered
implants.
Internal Hex connection
The connection is extremely precise,
being the platform for all diameters that
enables a simple restoration process.
Coronal Portion
Surface is rough towards the coronal
portion of the implant, reducing bone
resorption and reducing crestal stress for
better load distribution.
The most coronal portion is treated with
acid etched only.
Coronal portion with two micro rings
will reduce pressure on the cortical bone
on one hand and on the other will allow
maximum bone volume around the
most coronal portion thus will enable
minimum bone absorption as possible.
Implant Body
Tapered body design allows easy and
smooth insertion to the osteotomy, bone
condensing and thus will provide high
initial stability.
Implant Threads
Are double-threaded (2x2.4mm) for
efficient implantation. The variable threads
in the coronal portion are thicker
trapezoid, in the middle apical portion
thinner square and in the apical portion
V-shaped to enable fast insertion, bone
condensing and self tapping. Additional
increasing thread between the main
threads increases the macro and therefore
micro surface area thus providing higher
bone level that will improve the long term
stability.
Apical Portion
The apical portion has narrow, deep and
sharp apical starting threads that enable
dual entrance, self tapping and self drilling,
as well as easy bone penetration to
prevent damage to the anatomical
structure and provide high stability.
■ PSI
Precise Spiral Implant

12. 11
■ PSI
PSI 3.75
Dia.
L
Ref.
D1
D2
D3
3.75mm
10.0mm
91007
3.85
2.95
3.60
3.75mm
11.5mm
91008
3.85
2.95
3.60
3.75mm
13.0mm
91009
3.85
2.95
3.60
3.75mm
16.0mm
91010
3.85
2.95
3.60
3.75mm
8.0mm
91006
3.85
2.95
3.60
PSI 4.2
Dia.
L
Ref.
D1
D2
D3
4.2mm
10.0mm
91012
4.20
3.00
3.85
4.2mm
11.5mm
91013
4.20
3.00
3.85
4.2mm
13.0mm
91014
4.20
3.00
3.85
4.2mm
16.0mm
91015
4.20
3.00
3.85
4.2mm
8.0mm
91011
4.20
3.00
3.85
PSI 5.0
Dia.
L
Ref.
D1
D2
D3
5.0mm
10.0mm
91017
5.00
3.70
3.85
5.0mm
11.5mm
91018
5.00
3.70
3.85
5.0mm
13.0mm
91019
5.00
3.70
3.85
5.0mm
16.0mm
91020
5.00
3.70
3.85
5.0mm
8.0mm
91016
5.00
3.70
3.85
PSI 3.3
Dia.
L
Ref.
D1
D2
D3
3.3mm
8.0mm
91001
3.70
2.95
3.50
3.3mm
10.0mm
91002
3.70
2.95
3.50
3.3mm
11.5mm
91003
3.70
2.95
3.50
3.3mm
13.0mm
91004
3.70
2.95
3.50
3.3mm
16.0mm
91005
3.70
2.95
3.50

13. 12
■ PSI
Precise Spiral Implant
SoftBone
HardBone
SoftBone
HardBone
SoftBone
HardBone
SoftBone
HardBone
O 2.0
O 2.8
O 3.2
O 3.65
O 4.0
O 4.5
O 4.8
O 5.0O 4.2O 3.75O 3.3
The recommended drill protocol, with drill depth and diameter, in
the above table, is based on the accumulated experience of many
dentists.
Nevertheless, in cases where bone density deviates from the
average, necessary adjustments should be made, relying on the
experience of the dentist carrying out the procedure.
Please note that in cases of soft bone, the drilling diameter is
smaller than the implant’s diameter, and generally the harder the
bone, the larger the drilling diameter should be.
Legend:
Drill according to
implant length
Drill through cortical
bone only in case of
hard bone
RecommendedDrillProtocol

14. PST
Based on PSI’s characteristics
and advantages, this implant
is at the top of the dental
implant world today in terms
of aesthetics, due to its
coronal portion design.
■ PST
Precise Spiral Top

15. 14
Topnotch Aesthetics and
Stabilization
This new and advanced generation of
implants is distinguished by the design
of its coronal portion and the differential
fixation channels.
The design provides much better
fixation to the bone, allows easy
insertion and higher stabilization and
offers greater aesthetics.
The PST implants are available in two
diameters only – 4.2mm and 5mm,
matching standard abutments.
Internal Hex Connection
The connection is extremely precise,
being the single platform for all
diameters that enables a simple
restoration process.
Coronal Portion
Surface is rough towards the top of the
implant, reducing bone resorption and
crestal stress for better load
distribution. Concave design with three
micro rings. The concave design will
reduce pressure on the cortical bone
on one hand and on the other will
allow maximum bone volume around
the most coronal portion thus will
enable minimum bone absorption as
possible.
Implant Body
Tapered body design allows easy and
smooth insertion to the osteotomy,
bone condensing and thus will provide
high initial stability.
Implant Threads
Are double-threaded (2x2.4mm) for
efficient implantation. The threads in the
coronal portion are thicker trapezoid, in
the middle portion thinner square and in
the apical portion V-shaped to enable fast
insertion, bone condensing and self
tapping. Additional increasing thread
between the main threads increases the
macro and therefore micro surface area
thus providing higher bone level that will
improve the long term stability.
Apical Portion
The apical portion has narrow, deep and
sharp apical starting threads that enable
dual entrance, self tapping and self
drilling, as well as easy bone penetration
to prevent damage to the anatomical
structure and provide high stability.
■ PST
Precise Spiral Top

16. 15
PST 4.2
PST 5.0
■ PST
The PST implant is available in two diameters
O 4.2mm and O 5mm
4.2mm
10.0mm
91076
4.20
3.00
3.50
3.90
5.0mm
10.0mm
91081
5.00
3.70
3.85
4.70
4.2mm
11.5mm
91077
4.20
3.00
3.50
3.90
5.0mm
11.5mm
91082
5.00
3.70
3.85
4.70
4.2mm
13.0mm
91078
4.20
3.00
3.50
3.90
5.0mm
13.0mm
91083
5.00
3.70
3.85
4.70
4.2mm
16.0mm
91079
4.20
3.00
3.50
3.90
5.0mm
16.0mm
91084
5.00
3.70
3.85
4.70
4.2mm
8.0mm
91075
4.20
3.00
3.50
3.90
5.0mm
8.0mm
91080
5.00
3.70
3.85
4.70
Dia.
L
Ref.
D1
D2
D3
D4
Dia.
L
Ref.
D1
D2
D3
D4

17. 16
■ PST
Precise Spiral Top
SoftBone
HardBone
SoftBone
HardBone
O 2.0
O 2.8
O 3.2
O 3.65
O 4.0
O 4.5
O 4.8
O 5.0O 4.2
The recommended drill protocol, with drill depth and diameter, in
the above table, is based on the accumulated experience of many
dentists.
Nevertheless, in cases where bone density deviates from the
average, necessary adjustments should be made, relying on the
experience of the dentist carrying out the procedure.
Please note that in cases of soft bone, the drilling diameter is
smaller than the implant’s diameter, and generally the harder the
bone, the larger the drilling diameter should be.
Legend:
Drill according to
implant length
Drill through cortical
bone only in case of
hard bone
RecommendedDrillProtocol

18. ■ PSS
Precise Spiral Standard
An improved iteration of the
standard spiral tapered implant
with superior finishing, which
greatly outperforms competing
products.
PSS

19. 18
Simple & Precise
The geometry and features of our PSS
dental implant family, along with our
meticulous manufacturing process,
result in implants that ensure maximum
precision, smooth insertion during the
procedure and a more comfortable,
natural healing process for the patient.
The PSS family employs classic implant
design and surface treatments to
achieve a larger bone-to-implant surface
area contact.
Internal Hex Connection
The connection is a high-precision
structure that creates the perfect
implant-abutment connection and
results in a simple restoration process.
Coronal Portion
Surface is rough towards the coronal
portion of the implant, reducing bone
resorption and reducing crestal stress for
better load distribution.
The most coronal portion is treated with
acid etched only.
Coronal portion with two micro rings
design will reduce pressure on the
cortical bone on one hand and on the
other will allow maximum bone volume
around the most coronal portion thus
will enable minimum bone absorption
as possible.
Implant Body
Tapered body, to achieve better bone
condensing, higher initial stability and
easy insertion.
Implant Threads
Are double-threaded (2x2.4mm) for
efficient implantation. The threads in the
coronal portion are thicker trapezoid, in the
middle portion thinner square and in the
apical portion V-shaped to enable fast
insertion, bone condensing and self
tapping.
Apical Portion
The apical portion has narrow, deep and
sharp apical starting threads that enable
dual entrance, self tapping and self drilling,
as well as easy bone penetration to prevent
damage to the anatomical structure and
provide high stability.
■ PSS
Precise Spiral Standard

20. 19
■ PSS
PSS 3.3
PSS 3.75
PSS 4.2
PSS 5.0
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3
3.3mm
10.0mm
91051
3.70
2.95
3.50
3.75mm
10.0mm
91056
3.85
2.95
3.60
4.2mm
10.0mm
91061
4.20
3.00
3.85
5.0mm
10.0mm
91066
5.00
3.70
3.85
3.3mm
11.5mm
91052
3.70
2.95
3.50
3.75mm
11.5mm
91057
3.85
2.95
3.60
4.2mm
11.5mm
91062
4.20
3.00
3.85
5.0mm
11.5mm
91067
5.00
3.70
3.85
3.3mm
13.0mm
91053
3.70
2.95
3.50
3.75mm
13.0mm
91058
3.85
2.95
3.60
4.2mm
13.0mm
91063
4.20
3.00
3.85
5.0mm
13.0mm
91068
5.00
3.70
3.85
3.3mm
16.0mm
91054
3.70
2.95
3.50
3.75mm
16.0mm
91059
3.85
2.95
3.60
4.2mm
16.0mm
91064
4.20
3.00
3.85
5.0mm
16.0mm
91069
5.00
3.70
3.85
3.3mm
8.0mm
91050
3.70
2.95
3.50
3.75mm
8.0mm
91055
3.85
2.95
3.60
4.2mm
8.0mm
91060
4.20
3.00
3.85
5.0mm
8.0mm
91065
5.00
3.70
3.85

21. 20
■ PSS
Precise Spiral Standard
SoftBone
HardBone
SoftBone
HardBone
SoftBone
HardBone
SoftBone
HardBone
O 2.0
O 2.8
O 3.2
O 3.65
O 4.0
O 4.5
O 4.8
O 5.0O 4.2O 3.75O 3.3
The recommended drill protocol, with drill depth and diameter, in
the above table, is based on the accumulated experience of many
dentists.
Nevertheless, in cases where bone density deviates from the
average, necessary adjustments should be made, relying on the
experience of the dentist carrying out the procedure.
Please note that in cases of soft bone, the drilling diameter is
smaller than the implant’s diameter, and generally the harder the
bone, the larger the drilling diameter should be.
Legend:
Drill according to
implant length
Drill through cortical
bone only in case of
hard bone
RecommendedDrillProtocol

22. Our classical, mainstream,
implant is an indispensable
element of every implant system
available in the market. The PHI
promotes bone condensing and
creates overall stability, it is ideal
for hard bone but suitable for
common cases too, and it
enables small changes in the
implantation direction.
■ PHI
Precise Helical Implant
PHI

23. 22
Classical Mainstream Implant
Promotes bone condensing and creates ■
overall stability.
Ideal for hard bone but can be used in
common cases as well.
Enables small changes in the implantation
direction.
These advantages ensure easy insertion,
excellent stability, self drilling and self
tapping.
Internal Hex Connection
The connection has one platform for all
diameters with the perfect
implant-abutment connection for easy
restoration process.
Coronal Portion
Surface is rough towards the coronal
portion of the implant, reducing bone
resorption and reducing crestal stress for
better load distribution.
The most coronal portion is treated with
acid etched only.
Coronal portion with two micro rings will
reduce pressure on the cortical bone on
one hand and on the other will allow
maximum bone volume around the most
coronal portion thus will enable minimum
bone absorption as possible.
Implant Body
Conventional cylindrical design to perfectly
fit hard bone and therefore provide as
possible homogeneous pressure on the
hard bone.
Implant Threads
Double-threads (2x1.2mm) design with
small pitch provide high surface area and
thus providing potential higher BIC.
The variable thread design is very
moderate to fit the hard bone thus enable
primary stabilization, easy insertion, bone
condensing, self-drilling and self-tapping
as much as possible.
Apical Portion
The apical portion has sharp apical threads
with straight apical outlines. It is self
tapping and self drilling, enabling easy
penetration thereby preventing damage
to the anatomical structure.
■ PHI
Precise Helical Implant

24. 23
■ PHI
PHI 3.75
PHI 3.3
PHI 4.2
PHI 5.0
3.3mm
16.0mm
91029
3.70
2.60
3.60
3.75mm
16.0mm
91034
3.75
3.00
3.60
4.2mm
16.0mm
91039
4.20
3.00
3.85
5.0mm
16.0mm
91044
5.00
4.00
3.85
3.3mm
13.0mm
91028
3.70
2.60
3.60
3.75mm
13.0mm
91033
3.75
3.00
3.60
4.2mm
13.0mm
91038
4.20
3.00
3.85
5.0mm
13.0mm
91043
5.00
4.00
3.85
3.3mm
11.5mm
91027
3.70
2.60
3.60
3.75mm
11.5mm
91032
3.75
3.00
3.60
4.2mm
11.5mm
91037
4.20
3.00
3.85
5.0mm
11.5mm
91042
5.00
4.00
3.85
3.3mm
10.0mm
91026
3.70
2.60
3.60
3.75mm
10.0mm
91031
3.75
3.00
3.60
4.2mm
10.0mm
91036
4.20
3.00
3.85
5.0mm
10.0mm
91041
5.00
4.00
3.85
3.3mm
8.0mm
91025
3.70
2.60
3.60
3.75mm
8.0mm
91030
3.75
3.00
3.60
4.2mm
8.0mm
91035
4.20
3.00
3.85
5.0mm
8.0mm
91040
5.00
4.00
3.85
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3
Dia.
L
Ref.
D1
D2
D3

25. 24
■ PHI
Precise Helical Implant
HardBone
SoftBone
HardBone
SoftBone
HardBone
SoftBone
HardBone
O 2.0
O 2.8
O 3.2
O 3.65
O 4.0
O 4.5
O 4.8
SoftBone
O 5.0O 4.2O 3.75O 3.3
The recommended drill protocol, with drill depth and diameter, in
the above table, is based on the accumulated experience of many
dentists.
Nevertheless, in cases where bone density deviates from the
average, necessary adjustments should be made, relying on the
experience of the dentist carrying out the procedure.
Please note that in cases of soft bone, the drilling diameter is
smaller than the implant’s diameter, and generally the harder the
bone, the larger the drilling diameter should be.
RecommendedDrillProtocol
Legend:
Drill according to
implant length
Drill through cortical
bone only in case of
hard bone

26. Drills
&
Surgical
Instruments

27. Ref.
D
P-DRLS 4.0
94070
4.0 mm
Ref.
D
P-DRLS 3.65
94019
3.65 mm
Ref.
D
P-DRLS 4.5
94021
4.5 mm
Ref.
D
P-DRLS 4.8
94059
4.8 mm
26
■ Surgical Drills
Precise’s surgical drills are made
of surgical stainless steel, color
coded and bare laser marking
for easy diameter identification
and depth grooves.
Ref.
D
P-RB 2.3
94040
2.3 mm
Ref.
D
P-RB 3.1
94041
3.1 mm
Ref.
D
P-RB 4.0
94042
4.0 mm
Ref.
D
P-DRLS 2
94016
2.0 mm
Ref.
D
P-DRLS 2.8
94017
2.8 mm
Ref.
D
P-DRLS 3.2
94018
3.2 mm
Standard
Surgical Drill
External Irrigation
(Stainless steel)
Round Bur
(Stainless steel)

28. 27
■ Other Drills
Ref.
D
P-DRLSS 2
94022
2.0 mm
Ref.
D
P-DRLSS 2.8
94023
2.8 mm
Ref.
D
P-DRLSS 3.2
94024
3.2 mm
Ref.
D
P-DRLSS 4.0
94026
4.0 mm
Ref.
D
P-DRLSS 3.65
94025
3.65 mm
Ref.
D
P-DRLSS 4.5
94027
4.5 mm
Ref.
D
P-DRLSS 4.8
94061
4.8 mm
Short
Surgical Drill
External Irrigation
(Stainless steel)
Ref.
P-MDRL 01
94062
Marking drill
Ref.
P-DRLE
94038
Extension drill
Ref.
P-CTS 3
94039
Countersink
Ref.
P-CTS 5
94066
Countersink
D=3.75x4.2
D=5.0x6.0

29. ■ Implant Insertion Drivers
P-SRDH L
94003Ref.
Internal
Hex Insertion Drivers
(stainless steel)
P-SRDH
94028Ref.
P- IHM 04
94046
2.5mm
18mm
P- IHM 03
94045
2.5/1.25mm
18mm
P-IHML 01
94043
2.5/1.25mm
25mm
Ref.
Hex
L
Internal Hex
Contra Angle Drivers
(stainless steel)
Internal hex motor mount
P- IHML 02
94044
2.5mm
25mm
P-RAT Ref. 94001Ratchet Wrench
P-TRAT Ref. 94002
Torque / Ratchet
Wrench 10-45 Ncm
P-SSD Ref. 94053Screw Driver
28
■ Surgical Instruments
25mm
25mm
18mm
18mm
2.5mm
2.5mm
2.5mm
2.5mm
2.5mm
1.25mm
2.5mm
1.25mm

30. Ref. Ref. Ref. Ref. Ref.
29
■ Prosthetics Insertion Drivers
■ Parallel and Depth Guides
■ Implant Depth Measuring
Hex Driver
P-SRD L (long)
94048
Hex Driver
P-SRD
94032
Manual Screw Driver
P-HSRD L (long)
94030
Screw Driver
P-HSRD
94031
Contra Angle Motor Mount
P-CAD 05
94047
P-DM 01
94049Ref.
Depth Guide
16mm
P-DM 02
94050Ref.
Depth Guide
10mm
P-PDM
94051Ref.
Parallel
Guide
16mm.
10mm.
1mm.
1.9mm.
3.0mm.
3.0mm.
1.9mm.
1mm.
Ref.
P-DP 01
94033
1.25mm
1.25mm
1.25mm
1.25mm
1.25mm O2.1mm
O1.9mm
7.0mm
16mm13mm
10mm 11.5mm
8mm
1.9mm
2.7mm

31. ■ Impression Transfer
30
Ref. Ref. Ref.Ref.
Ref.Ref.
Ref.Ref.
Short Closed Tray Transfer
P-TCT 02
92251
Closed Tray Transfer
P-TCT 01
92250
Screw for Open/Close Tray
P-TRS 02
93004
Long Screw for Open Tray
P-TRS 01
93003
Wide Platform 5.0 Implant Analog
P-ANL 02
92256
Implant Analog
P-ANL 01
92255
Short Open Tray Transfer
P-TOT 02
92253
Open Tray Transfer
P-TOT 01
92252
■ Implant Analog

32. Prosthetics
&
Abutments

33. 32
P-HC 20
92220
4.6mm
2.0mm
P-HC 30
92221
4.6mm
3.0mm
P-HC 40
92222
4.6mm
4.0mm
P-HC 50
92223
4.6mm
5.0mm
P-HC 60
92224
4.6mm
6.0mm
P-HC 70
92225
4.6mm
7.0mm
Standard
Form
Healing
Abutment
P-HCN 20
92226
3.85mm
2.0mm
Ref.
D
H
Ref.
P-HCN 30
92227
3.85mm
3.0mm
P-HCN 40
92228
3.85mm
4.0mm
P-HCN 50
92229
3.85mm
5.0mm
P-HCN 60
92230
3.85mm
6.0mm
P-HCN 70
92231
3.85mm
7.0mm
Narrow
Form
Healing
Abutment
■ Healing abutments
Implant Cover Screw
P-CVS
93002
Ref.
D
H

34. 33
■ Prosthetic Abutments
Titanium
Straight
Abutments
Titanium
Straight
Anatomic
Abutments
Titanium
Straight
Abutments
Abutment Screw
P-ABTS 0002
92004
8.50mm
4.50mm
1.00mm
Ref.
H
D
A
P-ABTS 0003
92005
9.50mm
4.50mm
2.00mm
P-ABTS 0004
92006
10.5mm
4.50mm
3.00mm
P-ABTS 0005
92007
11.5mm
4.50mm
4.00mm
Ref.
H
D
A
Ref.
H
D
A
B
AA
D
D
H
H
P-ABT 0011
92031
11.5mm
4.50mm
0.80mm
P-ABT 0008
92030
8.50mm
4.50mm
0.80mm
D
A
H
P-ABTA 0015
92017
11.5mm
4.90mm
3.00mm
4.00mm
P-ABTA 0014
92016
10.5mm
4.90mm
2.00mm
3.00mm
P-ABTA 0013
92015
9.5mm
4.90mm
1.00mm
2.00mm
P-ABTA 0012
92014
8.5mm
4.90mm
0.00mm
1.00mm
P-COS
93001
B
Ref.
Implant Interface
Implant Interface
Implant Interface

35. 34
■ Prosthetic Abutments
A
15°
D
H
A
D
15°
B
H
Titanium
150 Angular
Abutments
Titanium
150 Angular
Anatomic
Abutments
Ref.
H
D
A
Ref.
H
D
A
B
P-ABT 1502
92011
7.50mm
4.50mm
1.30mm
P-ABT 1504
92013
11.5mm
4.50mm
1.30mm
P-ABT 1503
92012
9.50mm
4.50mm
1.30mm
A
P-ABTA 1514
92029
12.5mm
5.10mm
4.00mm
5.00mm
P-ABTA 1513
92023
11.5mm
5.10mm
3.00mm
4.00mm
P-ABTA 1512
92022
10.5mm
5.10mm
2.00mm
3.00mm
P-ABTA 1511
92021
9.50mm
5.10mm
1.00mm
2.00mm
P-ABT 2504
92010
11.5mm
4.50mm
1.3mm
0.30mm
P-ABT 2503
92009
9.50mm
4.50mm
1.3mm
0.30mm
P-ABT 2502
92008
7.00mm
4.50mm
1.3mm
0.30mm
Ref.
H
D
A
B
A
25°
Implant Interface
D
B
H
Titanium
250 Angular
Abutments
Implant Interface
Implant Interface

36. ■ Plastic Casting
P-PAB 02
92233Ref.
■ Nylon Caps & Metal House
P-PAB 01
92232 Ref.
P-BA 0.5
92258
0.5
Ref.
D
Straight
Ball
Attachments
P-BA 2
92259
2.0
P-BA 3
92260
3.0
P-HSB
92236Ref. Ref. Ref.
P-CFB 01
92234
P-CFBT 02
92235
P-BA 4
92261
4.0
P-BA 5
92262
5.0
P-BA 6
92263
6.0
■ Prosthetics-Overdenture
D
A
B
H
Titanium
250 Angular
Anatomic
Abutments
Ref.
H
D
A
B
P-ABTA 2514
92028
12.5mm
5.10mm
4.00mm
5.00mm
P-ABTA 2513
92020
11.5mm
5.10mm
3.00mm
4.00mm
P-ABTA 2512
92019
10.5mm
5.10mm
2.00mm
3.00mm
P-ABTA 2511
92018
9.50mm
5.10mm
1.00mm
2.00mm
Stainless Steel
Housing
Nylon Cap Nylon Cap
With Titanium
35
A
25°
■ Prosthetic Abutments
Implant Interface

37. 36
