Throttle valve control module, checking
Vehicles with engine code AEG (80-pin Engine Control Module -ECM-)
Vehicles with engine code AVH, AZG (121-pin
Engine Control Module -ECM-), see VEHICLES WITH ENGINE CODE AVH, AZG (121 -PIN ENGINE
CONTROL MODULE -ECM-).
Function
Components of throttle valve control module (J338):
l Closed Throttle Position (CTP) Switch -F60-
l Throttle Position (TP) sensor -G69-
l Throttle Position (TP) Sensor -G88-
l Throttle Position (TP) Actuator -V60-
If the complete throttle valve control module is current-less (e.g. connector disconnected) the throttle valve
moves into a particular, specified mechanical position, which signals an increased idle speed with an engine at
operating temperature.
If only the Throttle Position (TP) Actuator -V60- is current-less, the throttle valve also moves into the specified
mechanical position (emergency running gap), however, since Closed Throttle Position (CTP) Switch -F60- can
still be recognized, an "almost normal" is reached via the respective ignition angle retardation.
If the Engine Control Module (ECM) detects a malfunction at Throttle Position (TP) Sensor - G69-, Throttle
Position (TP) Actuator -V60- is switched current -less by the Engine Control Module (ECM) and the throttle
valve moves into the specified mechanical position (emergency running gap) again.
Recommended special tools and equipment
l VAG1526 multimeter or VAG1715 multimeter
l VAG1594 connector test kit
l Wiring diagram
Test requirements
l The respective fuses of Motronic Engine Control Module (ECM) -J220- must be OK.
NOTE: Use only gold-plated terminals when servicing terminals in harness connector
of throttle valve control module.
NOTE: Terminal assignment at throttle control unit is different in vehicles with and
without cruise control. Characteristic: Steering column switch with operating
unit for cruise control.
2003 Volkswagen Jetta GLI
1999-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) - 2.0L Generic Scan Tool (Engine Code AEG, AVH,
AZG)
AZG)
viernes, 24 de marzo de 2023 19:18:56 Page 1 © 2011 Mitchell Repair Information Company, LLC.

Fig. 29: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.
l Battery voltage must be at least 11.5 volts.
l All electrical consumers like, for example, lights and rear window heating must be switched off.
l Parking brake must be engaged or else daylight driving lights will be switched on.
l If vehicle is equipped with an A/C system, it must be switched off.
l Ground (GND) connections between engine and chassis must be OK.
l Throttle valve must not be damaged or dirty.
l Throttle valve must be in Closed Throttle Position (CTP).
NOTE: Fuse holder is behind access panel at far left end of dash.
AZG)

l Adjustment of accelerator pedal cable must be OK.
l Coolant temperature must be at least 80 °C. See DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES ; PID 5, Coolant temperature.
Test sequence
¡ Disconnect the 8 -pin connector at the throttle valve control module.
Check resistance
¡ Measure resistance of Throttle Position (TP) Actuator -V60- between the following terminals.
Vehicles with cruise control: Terminal 7 +8
Specified value: 3...200 ohms
Vehicles without cruise control: Terminal 1 +2
Specified value: 3...200 ohms
AZG)

Fig. 30: Identifying TP Actuator Terminals (Engine Code AEG)
If specified value is not obtained:
¡ Replace Throttle Valve Control Module -J338-, see item 13.
¡ Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .
¡ Generate readiness code, see READINESS CODE, GENERATING .
If specified value is obtained:
¡ Check voltage supply of throttle valve control module and wiring to control module, see CHECKING
AZG)

VOLTAGE SUPPLY AND WIRING TO CONTROL MODULE.
If voltage supply and wires are OK:
¡ Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
MODULE (ECM).
Checking voltage supply and wiring to control module
¡ Connect multimeter to the following connector terminals for voltage measurement.
Vehicles with cruise control: Terminal 2 + 5
¡ Switch ignition on. Specified value: at least 4.5 V
¡ Switch ignition off.
AZG)

Fig. 31: Identifying Throttle Valve Control Module Harness Connector Terminals (Engine Code
AEG)
¡ Connect multimeter to the following connector terminals for voltage measurement:
AZG)

Vehicles with cruise control: Terminal 2 +6
¡ Connect test box to control module wiring harness. See CONNECT TEST BOX FOR WIRING
TEST .
AZG)

Fig. 32: Identifying Throttle Valve Control Module Harness Connector Terminals (Engine Code
AEG)
¡ Check wires between test box and 8-pin connector for open circuit according to wiring diagram.
AZG)

¡ Vehicles with cruise control:
Terminal 1+socket 74
Terminal 4 + socket 75
Wire resistance: max: 1.5 ohms
AZG)

Fig. 33: Identifying Throttle Valve Control Module Harness Connector Terminals (Engine
Code AEG)
Vehicles without cruise control:
AZG)

¡ Also check wires for short circuit to each other, to vehicle Ground (GND) and to B+.Specified value:
INFINITY ohms
If no malfunctions are found in wires:
¡ Check voltage supply of Engine Control Module (ECM), see VOLTAGE SUPPLY FOR ENGINE
CONTROL MODULE (ECM), CHECKING.
DIAGNOSTIC DATA .
Vehicles with engine code AVH, AZG (121 -pin Engine Control Module -ECM-)
Function
The throttle valve activation occurs via an electric motor (throttle drive) in the throttle valve control module. It
is activated by the Engine Control Module (ECM) according to specifications of the two sensors, Throttle
Position (TP) Sensor -G79- and Sensor 2 for accelerator pedal position - G185-. See 20 FUEL SUPPLY ,
function of the E -gas system.
Components of throttle valve control module - J338-:
l Throttle drive (power accelerator actuation) - G186-
l Angle sensor -1- for throttle drive (power accelerator actuation) -G187-
l Angle sensor -2- for throttle drive (power accelerator actuation) -G188-
l Wiring diagram
Test requirements
AZG)

Fig. 34: Identifying Fuse
l Battery voltage must be at least 11.5 volts.
l All electrical consumers like, for example, lights and rear window heating must be switched off.
l If vehicle is equipped with an A/C system, it must be switched off.
l Ground (GND) connections between engine and chassis must be OK.
l Throttle valve must not be damaged or dirty.
l Coolant temperature must be at least 80 °C. See DIAGNOSTIC MODE 1: CHECK MEASURED
NOTE: Fuse holder is located behind access panel at far left end of dash.
AZG)

VALUES ; PID 5, Coolant temperature.
Function test
¡ Connect diagnostic tester. See CONNECT DIAGNOSTIC TESTER .
¡ Switch ignition on.
¡ Under address word 33, select "Diagnostic mode 1: Checking measured values."
¡ Select the measuring value "PID 17: Throttle valve position (absolute)."
¡ Check specified value of throttle valve position (absolute) at idle stop.
PID 17: THROTTLE VALVE POSITION (ABSOLUTE): AT IDLE STOP
¡ Slowly depress accelerator pedal up to Wide Open Throttle (WOT) stop while observing the percentage
display. The percentage display must increase uniformly.
¡ Check specified value of throttle valve position (absolute) at Wide Open Throttle (WOT) stop.
PID 17: THROTTLE VALVE POSITION (ABSOLUTE): AT WOT STOP
¡ End diagnosis and switch ignition off.
If specified values are not obtained:
Check resistance
TEST .
¡ Measure resistance of Throttle drive (power accelerator actuation) -G186- between test box sockets
117+118.
Specified value: 1,0...5,0 ohms
¡ Replace Throttle Valve Control Module -J338-, see item 13.
DIAGNOSTIC DATA .
PID Diagnostic text Specified value:
17: Throttle valve position (absolute)
l Idle stop 12,0...16,0 %
17: Throttle valve position (absolute)
l Wide Open Throttle
(WOT) stop
84,0...88,0 %
AZG)

¡ Check voltage supply of throttle valve control module and wiring to control module, see CHECKING
VOLTAGE SUPPLY AND WIRING TO CONTROL MODULE.
¡ Check Throttle Position (TP) Sensor -G79- and Sensor 2 for accelerator pedal position -G185-. See 20
FUEL SUPPLY .
If voltage supply and wires are OK:
MODULE (ECM).
Checking voltage supply and wiring to control module
l Connector connected at Engine Control Module (ECM).
¡ Disconnect 6-pin connector -2- at the throttle valve control module -1-.
AZG)

Fig. 35: Disconnecting Throttle Valve Control Module 6-Pin Connector (Engine Code AVH, AZG)
¡ Connect multimeter to connector terminals 2 + 6 for voltage measurement.
AZG)

AZG)

Fig. 36: Connecting Multimeter To Throttle Valve Control Module Connector Terminals 2 + 6 For
Voltage Measurement (Engine Code AVH, AZG)
TEST .
¡ Check wires between test box and 6-pin connector for open circuit according to wiring diagram:
AZG)

Fig. 37: Identifying Throttle Valve Control Module 6-Pin Harness Connector Terminals (Engine
Code AVH, AZG)
¡ Also check wires for short circuit to each other, to vehicle Ground (GND) and to B+. Specified value:
INFINITY ohms
¡ Check voltage supply of Engine Control Module (ECM), see VOLTAGE SUPPLY FOR ENGINE
CONTROL MODULE (ECM), CHECKING.
DIAGNOSTIC DATA .
AZG)

Engine Coolant Temperature (ECT) sensor, checking
l Wiring diagram
Test requirements
l For vehicles with automatic transmission, selector lever must be in position -P- or -N-.
l Engine must be cold.
NOTE: Use only gold-plated terminals when servicing terminals in harness connector
of sensor.
AZG)

Function test, vehicles with engine code AEG
Function test, vehicles with engine code AVH, AZG, see FUNCTION TEST, VEHICLES WITH ENGINE
CODE AVH, AZG.
AZG)

¡ Select the measuring value "PID 05: Coolant temperature".
¡ Check specified value of coolant temperature:
PID 05: COOLANT TEMPERATURE (ENGINE CODE AEG)
¡ Continue test according to the following table:
PID 05: COOLANT TEMPERATURE: DIAGNOSIS
¡ Start engine and let run at idle. The temperature should climb uniformly
Continuation of test if indication is approx. - 46.5 °C:
¡ Disconnect 4-pin connector from Engine Coolant Temperature (ECT) sensor -G62- with Engine Coolant
Temperature (ECT) sensor -G2- (arrow)
05: Coolant temperature approx. coolant temperature
Indicated(1) Cause Continue testing
approx. - 46.5 °C Open circuit or short circuit to
B+
See CONTINUATION OF TEST
IF INDICATION IS APPROX. -
46.5 °C:
approx. 141.0 °C Short circuit to Ground (GND) See CHECKING WIRING
(1) If a temperature is indicated which differs greatly from ambient temperature of sensor, check sensor
wires for contact resistance.
NOTE: l The temperature increases in increments of 1.0 °C.
l If the engine shows problems in certain temperature ranges and if the
temperature does not climb uniformly, the temperature signal is
intermittent and the sensor should be replaced.
AZG)

Fig. 39: Disconnecting ECT Sensor 4-Pin Connector
Vehicles with old connector shape
¡ Bridge terminals 1 + 3 of connector using the respective adapter cables and observe the indication on
display.
AZG)

Fig. 40: Identifying ECT Sensor Harness Connector Terminals (Old Connector Shape)
Vehicles with newer connector shape
display.
AZG)

Fig. 41: Identifying ECT Sensor Harness Connector Terminals (Newer Connector Shape)
Continuation for all connector shapes
If indication jumps to approx. 141.0 °C:
¡ Replace Engine Coolant Temperature (ECT) Sensor -G62- with Engine Coolant Temperature (ECT)
Sensor -G2-, see item 13.
DIAGNOSTIC DATA .
AZG)

If indication remains at approx. -46.5 °C:
¡ Check wires according to wiring diagram, see CHECKING WIRING.
Continuation of test if indication is approx. 141.0 °C:
Fig. 42: Disconnecting 4-Pin Connector From Engine Coolant Temperature (ECT) Sensor
If indication jumps to approx. -46.5 °C:
AZG)

DIAGNOSTIC DATA .
If indication remains at approx. 141.0 °C:
Checking wiring
TEST .
Vehicles with older connector shape
AZG)

Fig. 43: Identifying ECT Sensor Harness Connector Terminals (Old Connector Shape)
AZG)

Fig. 44: Identifying ECT Sensor Harness Connector Terminals (Newer Connector Shape)
INFINITY ohms
AZG)

Vehicles with older connector shape
¡ Perform a resistance measurement at Engine Coolant Temperature (ECT) Sensor -G62- terminal 1
(Ground -GND-) and 3 (signal).
Fig. 45: Identifying Engine Coolant Temperature (ECT) Sensor Terminals 1 And 3 (Old Connector
Shape)
¡ Measure resistance at Engine Coolant Temperature (ECT) sensor -G62-, terminals C (signal) and D
(Ground -GND-).
AZG)

Fig. 46: Identifying Engine Coolant Temperature (ECT) Sensor Terminals (Newer Connector
Shape)
Range A displays resistance values for the temperature range of 0 to 50 °C, range B displays resistance values
for the temperature range of 50 to 100 °C.
AZG)

Fig. 47: ECT Sensor Temperature Versus Resistance Range Graph
Read-out examples:
l 30 °C is in range A and corresponds to a resistance of 1.5 to 2.0 kohms
l 80 °C is in range B and corresponds to a resistance of 275 to 375ohms
DIAGNOSTIC DATA .
AZG)

If no malfunctions are detected in the wires and the resistance values are OK:
MODULE (ECM).
Function test, vehicles with engine code AVH, AZG
¡ Select the measuring value "PID 05: Coolant temperature".
¡ Check specified value of coolant temperature:
PID 05: COOLANT TEMPERATURE (ENGINE CODE AVH, AZG)
PID 05: COOLANT TEMPERATURE DIAGNOSIS
¡ Start engine and let run at idle. The temperature should climb uniformly
Continuation of test if indication is approx. - 40.0 °C:
05: Coolant temperature approx. coolant
temperature
approx. - 40.0 °C Open circuit or short circuit to
B+
40.0 °C:
approx. 140.0 °C Short circuit to Ground (GND) See CONTINUATION OF TEST
IF INDICATION IS APPROX.
140.0 °C:
(1) If a temperature is indicated which differs greatly from ambient temperature of sensor, check sensor
wires for contact resistance.
NOTE: l The temperature increases in increments of 1.0 °C.
l If the engine shows problems in certain temperature ranges and if the
temperature does not climb uniformly, the temperature signal is
intermittent and the sensor should be replaced.
AZG)

Fig. 48: Disconnecting 4-Pin Connector From Engine Coolant Temperature (ECT) Sensor (Engine
Code AVH, AZG)
display.
AZG)

Fig. 49: Identifying ECT Sensor Harness Connector Terminals (Engine Code AVH, AZG)
If indication jumps to approx. 140.0 °C:
¡ Replace Engine Coolant Temperature (ECT) sensor (G62).
DIAGNOSTIC DATA .
If indication remains at approx. -40.0 °C:
AZG)

Continuation of test if indication is approx. 140.0 °C:
Fig. 50: Disconnecting 4-Pin Connector From Engine Coolant Temperature (ECT) Sensor (Engine
Code AVH, AZG)
If indication jumps to approx. -40.0 °C:
¡ Replace Engine Coolant Temperature (ECT) sensor (G62).
AZG)

DIAGNOSTIC DATA .
If indication remains at approx. 140.0 °C:
Checking wiring
TEST .
AZG)

Fig. 51: Identifying ECT Sensor 4-Pin Harness Connector Terminals (Engine Code AVH,
AZG)
INFINITY ohms
¡ Measure resistance at Engine Coolant Temperature (ECT) sensor -G62-, terminals C (signal) and D
(Ground -GND-).
AZG)

Fig. 52: Identifying Temperature (ECT) Sensor Terminals (Engine Code AVH, AZG)
Range A displays resistance values for the temperature range of 0 to 50 °C, range B displays resistance values
for the temperature range of 50 to 100 °C.
AZG)

Fig. 53: ECT Sensor Temperature Versus Resistance Range Graph
Read-out examples:
l 30 °C is in range A and corresponds to a resistance of 1.5 to 2.0 k ohms
¡ Replace Engine Coolant Temperature (ECT) sensor -G62-.
DIAGNOSTIC DATA .
AZG)

MODULE (ECM).
Intake Air Temperature (IAT) sensor, checking
l Wiring diagram
l Chilling spray (commercially available)
Test requirements
l For vehicles with automatic transmission, selector lever must be in position -P- or -N-.
NOTE: The Intake Air Temperature (IAT) sensor -G42- is a component of the Mass Air
Flow (MAF) sensor -G70- and cannot be replaced individually.
AZG)

Function test
¡ Select the measuring value "PID 15: Intake air temperature".
¡ Check specified value of intake air temperature:
AZG)

PID 15: INTAKE AIR TEMPERATURE
PID 15: INTAKE AIR TEMPERATURE DIAGNOSIS
¡ Remove intake air hose between Mass Air Flow (MAF) sensor and throttle valve control module, see
item 2.
¡ Remember the intake air temperature value.
¡ Spray the sensor (arrow) with commercially available chilling spray and watch the temperature value. The
temperature should decrease.
15: Intake Air Temperature (IAT) approx. ambient temperature
approx. -40 °C
or
approx. -46 °C
Open circuit or short circuit to
B+
40 OR -46 °C:
approx. 140 °C Short circuit to Ground (GND) See CONTINUATION OF TEST
IF INDICATION IS APPROX.
140 °C:
(1) If a temperature is indicated which is below the ambient temperature of sensor, first check sensor
wires for contact resistance. Note that while the vehicle is standing still the sensor might warm up
due to radiant heat.
AZG)

AZG)

Fig. 55: Identifying IAT Sensor
If the intake air temperature does not drop:
¡ Replace Mass Air Flow (MAF) Sensor -G70-, see item 3.
DIAGNOSTIC DATA .
Continuation of test if indication is approx. -40 or -46 °C:
¡ Disconnect 5-pin connector from Mass Air Flow (MAF) sensor - G70- with Intake Air Temperature
(IAT) sensor -G42- (arrow).
AZG)

Fig. 56: Disconnecting 5-Pin Connector From Mass Air Flow (MAF) Sensor
¡ Bridge terminals 1 + 3 of connector using the respective adapter cables while observing the indication on
display.
AZG)

Fig. 57: Bridging Terminals 1 + 3 of MAF Sensor Harness Connector
If indication jumps to approx. 140 °C:
DIAGNOSTIC DATA .
AZG)

If indication remains at approx. -40 or -46 °C:
Continuation of test if indication is approx. 140 °C:
¡ Disconnect 5-pin connector from Mass Air Flow (MAF) sensor - G70- with Intake Air Temperature
(IAT) sensor -G42- (arrow).
Fig. 58: Disconnecting 5-Pin Connector From Mass Air Flow (MAF) Sensor
If indication jumps to approx. -40 or -46 °C:
AZG)

¡ Replace Mass Air Flow (MAF) Sensor -G70-, see item 3
DIAGNOSTIC DATA .
If indication remains at approx. 140 °C:
Checking wiring
TEST .
Vehicles with engine code AEG
AZG)

Fig. 59: Identifying MAF Sensor 5-Pin Harness Connector Terminals (Engine Code AEG)
Vehicles with engine code AVH, AZG
AZG)

Fig. 60: Identifying MAF Sensor 5-Pin Harness Connector Terminals (Engine Code AVH,
AZG)
Continuation for all vehicles
¡ Also check wires for short circuit to each other, to vehicle Ground (GND) and to B+.Specified value:
If no malfunctions are found in wire:
¡ Measure resistance at Intake Air Temperature (IAT) sensor -G42-, terminals 1 (signal) and 3 (Ground -
GND-).
AZG)

Fig. 61: Measuring Resistance At Intake Air Temperature (IAT) Sensor
Range A displays resistance values for the temperature range of 0..0.50 °C, range B displays resistance values
for the temperature range of 50..0.100 °C.
AZG)

Fig. 62: IAT Sensor Temperature Versus Resistance Range Graph
Read-out examples:
l 30 °C is in range A and corresponds to a resistance of 1.5 to 2.0 kohms
DIAGNOSTIC DATA .
AZG)

MODULE (ECM).
AZG)

P0221.pdf

More Related Content

What's hot

Similar to P0221.pdf

More from jose cuellar

Recently uploaded

P0221.pdf
