Red Hat provided tools useful for debugging applications running in OpenShift.

1. CONFIDENTIAL Designator
OpenShift Application
Debugging Tools for
Developers
Michael Greenberg
Red Hat - Cloud Consultant
1

2. CONFIDENTIAL Designator
Agenda
2
● Pitfalls when Debugging and Testing for OpenShift
● Options for Application Development on/for OpenShift
● Debugging remote applications using off-the-shelf tools
● Red Hat OpenShift IDE plugins:
○ Eclipse Plugin
○ IntelliJ IDEA Connector
○ Microsoft Visual Studio Code Extension Pack
● Red Hat CodeReady Studio
● Moving Forward

3. CONFIDENTIAL Designator
Classic Host Based Development
3
-Cucumber
-JUnit
-Mockito
Trusted code
repos
-Jira
-Trello
ISSUES
DEV
ENV
UNIT
TEST
Trusted artifact
and image repos
Dev Host
-SonarQube
-Fortify
-AtomicScan
-Blackduck
-Twistlock
-Sysdig
-Dynatrace
CI SYSTEM
CODE
QUAL
SEC
SCAN
INT
TEST
UAT
PROD
OPENSHIFT KUBERNETES PLATFORM
-Arquillian
-JUnit

4. CONFIDENTIAL Designator
Development vs. Production
for Microservice Applications
4
Development performed on a desktop Production is run on OpenShift.

5. CONFIDENTIAL Designator
Runtime Differences Between Dev Host and Cluster
5
● Monitoring
● Logging
● Certificate management
● Credentials
● Scaling (load based)
● Security
● Network
● Storage

6. CONFIDENTIAL Designator
Where Should Developers Debug and Test?
6
● IDE debug on local host
● IDE debug in Docker container(s) on local host
● IDE debug using Minishift/All-In-One on local host
● IDE debug on OpenShift cluster
● Develop & Debug using Red Hat OpenShift CodeReady Workspaces

7. CONFIDENTIAL Designator
Extending Debugging to Pods
7
-Cucumber
-JUnit
-Mockito
-SonarQube
-Fortify
-AtomicScan
-Blackduck
-Twistlock
Trusted code
repos
-Sysdig
-Dynatrace
-Jira
-Trello
CI SYSTEM
ISSUES
DEV
ENV
UNIT
TEST
CODE
QUAL
SEC
SCAN
INT
TEST
UAT
PROD
Trusted artifact
and image repos
OPENSHIFT KUBERNETES PLATFORM
-Arquillian
-JUnit
Dev Host

8. CONFIDENTIAL Designator
Debugging Remote
Applications Using
Off-The-Shelf Tools
8

9. CONFIDENTIAL Designator
Debugging Java on a Remote Server/Container
9
# Run Java in Debug Mode on the remote server:
$ java -Xdebug -Xrunjdwp:transport=dt_socket,address=8000,server=y,suspend=y
# Optionally Connect to a Remote Server using Port Forwarding
$ ssh -L 8000:localhost:8000 root@<remoteserver>
# Connect your debugger
$ jdb -attach localhost:8000 -sourcepath ~/dev/remote/src/main/java/
# Port Forwarding to a Pod/Container
# oc/kubectl port-forward <pod> 8000:8000

10. CONFIDENTIAL Designator
Red Hat OpenShift Eclipse
Plugin
10

11. CONFIDENTIAL Designator
Eclipse Plugin for OpenShift Installation
11

12. CONFIDENTIAL Designator
Eclipse Plugin Welcome to Red Hat
12

13. CONFIDENTIAL Designator
Red Hat OpenShift Connector
for IntelliJ IDEA
13

14. CONFIDENTIAL Designator
IntelliJ OpenShift Connector Installation
14
Manually download:
- odo v0.0.20
Debugging requires
manual port forwarding.

15. CONFIDENTIAL Designator
Red Hat OpenShift
Extension for Microsoft
Visual Studio Code
15

16. CONFIDENTIAL Designator
Visual Studio Code OpenShift Extension Pack Installation
16
Download:
- oc
- odo
via IDE.
Debugging requires
manual port forwarding.

17. CONFIDENTIAL Designator
Red Hat CodeReady Studio
17

18. CONFIDENTIAL Designator
RedHat CodeReady Studio
18
https://developers.redhat.com/products/codeready-studio/download
Install using:
java -jar codereadystudio-<installername>.jar

19. CONFIDENTIAL Designator
Moving Forward
19

20. CONFIDENTIAL Designator
Red Hat CodeReady Workspaces
20
● Centralized developer environments
● Container-based workspaces
● Source code protection
● Pre-built or custom stacks
● Enterprise integration (SSO, LDAP, AD)
● Browser-based IDE
