2. Kiril Georgiev played 360 people simultaneously in Sofia, Bulgaria.
His final score was 284 wins, 70 draws and 6 losses.
• Multiple protocol support (HTTP, HTTPS, WebSocket, IMAP, POP3, SMTP)
• SSL termination (TLSv1.1/TLSv1.2/SSL/SNI/PFS/PCI-DSS and OCSP Stapling)
• HTTP video streaming using MP4/FLV/HDS/HLS
• Caching static & dynamic content
• Content compression
• Header manipulation
• Request filtering
• Extended monitoring and logging
• Upgrades without downtime using live binaries
• Graceful restart with non-stop request processing
• Complete reverse proxy and load balancer
3. $ sudo yum install epel-release
$ sudo yum install epel-release
$ sudo yum -y install nginx
$ nginx -h
nginx version: nginx/1.0.15
Usage: nginx [-?hvVtq] [-s signal] [-c filename] [-p prefix] [-g directives]
Options:
-?,-h : this help
-v : show version and exit
-V : show version and configure options then exit
-t : test configuration and exit
-q : suppress non-error messages during configuration testing
-s signal : send signal to a master process: stop, quit, reopen, reload
-p prefix : set prefix path (default: /usr/share/nginx/)
-c filename : set configuration file (default: /etc/nginx/nginx.conf)
-g directives : set global directives out of configuration file
$ sudo nginx
NGINX 설치
(직접 컴파일 해야 하는 경우는 http://nginx.org/en/docs/configure.html)
INSTALL NGINX
6. WORKER
PROCESS
MASTER PROCESS
WORKER
PROCESS
WORKER
PROCESS
WORKER
PROCESS
root 32475 1 0 13:36 ? 00:00:00 nginx: master process /usr/sbin/nginx
nginx 32476 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32477 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32479 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32480 32475 0 13:36 ? 00:00:00 _ nginx: worker process
worker_processes 4;
events {
worker_connections 2048;
}
( Total worker connections : 4 x 2048 )
PROCESSES
7. WORKER
PROCESS
MASTER PROCESS
WORKER
PROCESS
WORKER
PROCESS
WORKER
PROCESS
root 32475 1 0 13:36 ? 00:00:00 nginx: master process /usr/sbin/nginx
nginx 32476 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32477 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32479 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32480 32475 0 13:36 ? 00:00:00 _ nginx: worker process
nginx 32481 32475 0 13:36 ? 00:00:00 _ nginx: cache manager process
nginx 32482 32475 0 13:36 ? 00:00:00 _ nginx: cache loader process
CACHE
MANAGER
CACHE
LOADER
PROCESSES
8. TERM, INT fast shutdown
QUIT graceful shutdown
HUP
changing configuration, keeping up
with a changed time zone (only for
FreeBSD and Linux), starting new
worker processes with a new
configuration, graceful shutdown of
old worker processes
USR1 re-opening log files
USR2 upgrading an executable file
WINCH graceful shutdown of worker processes
$ sudo nginx -s [OPTION]
stop — fast shutdown
quit — graceful shutdown
reload — reloading the configuration file
reopen — reopening the log files
$ sudo kill -HUP `cat /var/run/nginx.pid` $ sudo nginx -s reload
SIGNALS
9. PID PPID USER %CPU VSZ WCHAN COMMAND
33126 1 root 0.0 1148 pause nginx: master process
33127 33126 nobody 0.0 1380 kqread nginx: worker process (nginx)
33128 33126 nobody 0.0 1364 kqread nginx: worker process (nginx)
33129 33126 nobody 0.0 1364 kqread nginx: worker process (nginx)
33130 33126 nobody 0.0 1364 kqread nginx: worker process (nginx)
PID PPID USER %CPU VSZ WCHAN COMMAND
33126 1 root 0.0 1164 pause nginx: master process
33130 33126 nobody 0.0 1380 kqread nginx: worker process is
shutting down (nginx)
33135 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33136 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33137 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33138 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
PID PPID USER %CPU VSZ WCHAN COMMAND
33126 1 root 0.0 1164 pause nginx: master process
33135 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33136 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33137 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
33138 33126 nobody 0.0 1368 kqread nginx: worker process (nginx)
BEFORE RELOAD
AFTER RELOAD
RELOADING
RELOAD NEW CONFIGURATION WITH NO DOWNTIME
12. Worker Process
worker_processes 2;
events {
worker_connections 65536;
use epoll;
multi_accept on;
}
/etc/nginx/nginx.conf
1
2
3
4
worker_process 는 Event Looping Single Thread 로 일반적으로 CPU Core 수에 맞게 설정한다.
또는, worker_processes auto; 하여 자동으로 Core 수에 맞게 실행되도록 할 수 있다.
$ grep ^processor /proc/cpuinfo | wc -l
Core 수 확인은 아래와 같이 함.
1
3 epoll 방식은 Kernel 에 의존하여 file descriptor 중 변화가 있는(이벤트 감지) 신호를 받아 처리
하는 방식으로 대용량 트래픽 처리에 적합하다.
2
worker process 별로 최대 연결할 수 있는 수이며, $ ulimit -n 로 file descriptor 수를 확인하
여 같거자 작은 값으로 설정해야 한다.
worker_connections =
inbound 연결수 + 연결 대기 수 + outbound 수(proxy 대상인 upstream servers)
4 work process 가 동시에 file descriptor 를 처리 할 수 있도록 하는 옵션이다.
13. HTTP section
http {
keepalive_timeout 65;
keepalive_requests 100000;
sendfile on;
tcp_nopush on;
tcp_nodelay on;
}
/etc/nginx/nginx.conf
1
2
3
4
1
4
keepalive_timeout 은 TCP 연결 timeout (default: 75s) 이다.
keepalive_requests 는 하나의 Connection 에서 처리 할 수 있는 최대 request 수 (default :
100) 이다.
2
3
tcp_nopush on 은 sendfile on 일때만 동작하며, 소켓 옵션 중 TCP_CORK 를 사용하여 HTTP
Header 를 하나의 소켓으로 전송한다.
sendfile (default : off) 을 on 하게 되면, 이미지나 비디오 같은 static 파일을 multi
thread 로 보내도록 한다. 주로 이미지를 전송하게 되는 경우 사용한다.
tcp_nopush on 과 함께 사용하며, Client 로 부터의 ACK 를 최소화 하여 지연을 줄이는 방식이다.
14. HTTP section
http {
client_body_buffer_size 128k;
client_max_body_size 10m;
client_header_buffer_size 1k;
}
/etc/nginx/nginx.conf
1
2
1 client_body_buffer_size (Default 8k(32Bit) / 16k(64Bit)) 는 POST 로 전송되는
payload 사이즈이며 일반적으로 128k 가 적당하다. 초과 할 경우 temp 파일이 생성되어 속도 저하
가 발생한다.
client_max_body_size (Default: 1m) 는 최대 사이즈이며 초과 할 경우 413 (Request
Entity Too Large)를 반환한다.
2
client_header_buffer_size (default : 1k) header 사이즈며 대부분 1k 면 충분하다.
하지만 Cookie 가 상당히 많은 경우는 이를 조정할 필요가 있다. on 하게 되면, 이미지나 비디오
같은 static 파일을 multi thread 로 보내도록 한다. 주로 이미지를 전송하게 되는 경우 사용한
다.
15. Kernel Network Configuration
net.core.somaxconn = 65536
net.ipv4.tcp_max_tw_buckets = 1440000
/etc/sysctl.conf
1
2
1 net.core.somaxconn 는 socket max connection을 의미하며, 커널이 최대 연결 가능한 소
캣 수이다. 일반적으로 $ ulimit -n 에서 나오는 File Descriptor 와 일치 시킨다.
현재 설정 값은 $ cat /proc/sys/net/core/somaxconn 로 확인이 가능하다.
2 net.ipv4.tcp_max_tw_buckets 는 동시에 발생하는 timewait socket 수의 최대 값을 지정
하는 것으로, 이를 초과 하면 socket 을 제거 된다.
현재 설정 값은 $ cat cat /proc/sys/net/ipv4/tcp_max_tw_buckets 로 확인이 가능하다.
16. Compression
http {
server {
gzip on;
gzip_min_length 1000;
gzip_types: text/html text/javascript text/plain text/xml application/xml;
gzip_disable "MSIE [1-6].”;
}
}
/etc/nginx/nginx.conf
gzip on (default: off) 으로 응답 결과를 압축하도록 설정한다.
gzip_min_length (default: 20) 로 응답 사이즈의 최소값을 지정한다. 단위는 bytes.
gzip_types (default: text/html) 으로 MIME 타입을 지정하고 해당하는 MIME 타입인 경우에만 압축하도록 한다.
gzip_disable 요청 해더의 “User-Agent” 가 지정한 경우와 일치하는 경우 압축하지 않도록 한다.
