The document discusses link aggregation according to the IEEE 802.3ad standard. It describes how link aggregation can be used to increase bandwidth and availability by combining multiple network links into a single logical link. It outlines the types of link aggregation configurations including switch-to-switch, switch-to-station, and station-to-station connections. It also summarizes the goals of the IEEE 802.3ad standard and considerations for implementing link aggregation such as addressing, frame distribution, and SysKonnect's software solution for link aggregation on Windows 2000.
