Isometric perspective is a type of technical drawing that represents a 3D object in a single view using three receding planes that project at the same angle onto the drawing plane, allowing the object's dimensions to be clearly seen from one viewpoint. The isometric system uses three planes (XOY, YOZ, ZOX) that form a trihedral and project at the same angle to the drawing surface, giving the isometric view. One can transition from an orthographic projection system to the isometric view by taking the front, left side, and plan views and projecting them together at a uniform angle.

1. ISOMETRIC PERSPECTIVE

2. In general, perspectives aim to represent three-
dimensional objects in a single view or projection, allowing
us to clearly see how the object is in reality.

3. ISOMETRIC PERSPECTIVE
Z
This system is composed
of three planes forming a
trihedral (XOY, YOZ and
ZOX), which is
projected, forming the o
same angle, onto the
drawing plane. This gives Y X
us the isometric
perspective.

4. How to pass from ortographic system to isometric
Z
Front view Left side view
Plan view o
X
Y
iew
tv
Fro n

7. ISOMETRIC PERSPECTIVE
