This document summarizes a methodology for estimating corrosion rates on pipelines by comparing data from multiple in-line inspections. It involves three steps: 1) Filtering and adjusting inspection data to account for reporting thresholds and potential biases. 2) Determining average corrosion growth rates between inspections based on filtered populations. 3) Calculating individual corrosion growth rates for defects based on mean depths in surrounding areas. The methodology aims to provide quick yet realistic estimates of corrosion progression to inform pipeline integrity management strategies. A case study demonstrates the robustness of the approach.
