1. Introduction to the
Ruby Object Model

2. Ruby is an object
oriented language

3. Primitives
182376
“hello, world”
[1, 2, 3]
Objects
String: “x”
object_id: 2817249
#length, #upcase, #..
Object
@name = “Peter”
@age = 30
object_id: 2132452
Array: [., .]
object_id: 2132452
#next, #size, #..

4. An Object
@name = “Peter”
@age = 30
#name=(name)
#name
#age=(age)
#age
Data
Methods
class: User
object_id: 2132452

5. In Ruby: everything (well, almost
everything) is an object:
• Classes
• “Primitive types”
• Modules (will be explained later on)
• Procs

6. ‘a’.upcase # => ‘A’
‘a’.class # => String

7. 10.class # => Fixnum

8. class Fixnum
def +(other)
42
end
end
10 + 10 # => 42 (!)

9. Fixnum.class # => Class
Class.class # => Class

10. my_class = Class.new
my_obj = my_class.new

11. The “Ruby Object Model”

12. How Objects Are
Represented Internally

13. struct RObject {
struct RBasic basic;
long numiv;
VALUE *ivptr;
struct st_table *iv_index_tbl;
};
Number of
instance variables
Instance variables array
@name = “Fred”
@age = 23
Essentially a hash of
{ name -> index into ivptr }

14. struct RBasic {
VALUE flags;
VALUE klass;
};
Stores information like
whether the object is
frozen, tainted or others
Reference to
whatever the class
of the object is

15. An object has:
• Klass (parent class)
• Flags (frozen? tainted? etc.)
• Instance variables
• Nothing else.

16. How Classes Are
Represented Internally

17. struct RClass {
struct RBasic basic;
rb_classext_t *ptr;
struct st_table *m_tbl;
struct st_table *iv_index_tbl;
};
struct rb_classext_struct {
VALUE super;
struct st_table *iv_tbl;
struct st_table *const_tbl;
};
Additional class
info
Methods
Instance
variables
Reference
to superclass
Instance
variables
Constants

18. struct RClass {
VALUE flags;
VALUE klass;
VALUE super;
struct st_table *iv_tbl;
struct st_table *const_tbl;
struct st_table *m_tbl;
struct st_table *iv_index_tbl;
};
Reference
to superclass
Instance
variables
Constants
Methods
Instance
variables

19. class Oban < Scotch
AGE = 14
@tasty = true
def tasty
Oban.instance_variable_get("@tasty")
end
end

20. class Oban < Scotch
AGE = 14
@tasty = true
def tasty
Oban.instance_variable_get("@tasty")
end
end
basic.klass Class
ptr->super Scotch
iv_tbl { “@tasty” => true }
const_tbl { “AGE” = 14 }
m_tbl { “tasty” => … }

21. Enough with the C
code!

22. RObject and RClass
flags
RObject
class reference
instance variables
@age = 10
@name = “Peter”
flags
RClass
class reference
instance variables
methods table
reference to ‘superclass’
constants table
These three are extra to classes

23. class User
def name=(name)
@name = name
end
def name
@name
end
end

24. User (RClass)
class reference
class instance variables
methods table
#name=
#name
reference to ‘superclass’
Class (RClass)
class reference
Object (RClass)
class reference

25. class User
def name=(name)
@name = name
end
def name
@name
end
end
me = User.new

26. User (RClass)
methods table
#name=
#name
RObject
class reference
instance variables

27. User (RClass)
methods table
#name=
#name
RObject
class reference
instance variables
@name => “Peter Cooper”
me.name = “Peter Cooper”

28. class User
def status
:admin
end
end

29. User (RClass)
methods table
#name=
#name
#status
RObject
class reference
instance variables
@name => “Peter Cooper”

30. me = User.new
you = User.new
def me.age
30
end
me.age # => ?
you.age # => ?

31. me = User.new
you = User.new
def me.age
30
end
me.age # => 30
you.age # => NoMethodError

32. User (RClass)
methods table
#name=
#name
RObject
Me
class reference
RObject
You
class reference
.. but where does
me.age go?

33. User (RClass)
methods table
#name=
#name
RObject
Me
class reference
methods table
#age
RObject
You
class reference
*me (RClass)
singleton class

34. RObject
Me
class reference
RObject
You
class reference
*me (RClass)
methods table
#age
superclass
User (RClass)
methods table
#name=
#name

35. me.class # => User

36. “Class Methods”

37. class User
def self.plural_name
“users”
end
end
User.plural_name # => “users”
me.plural_name # => NoMethodError
you.plural_name # => NoMethodError

38. User (RClass)
superclass
methods table
#name=
#name
klass
Class (RClass)
*User (RClass)
methods table
#plural_name
klass
Object (RClass)

39. User (RClass)
superclass
methods table
#name=
#name
klass
Object (RClass) Conclusion:
All methods in Ruby
instance methods!
Class (RClass)
are actually
*User (RClass)
methods table
#plural_name
klass

40. Modules
“Collection of methods
and constants”

41. module MyModule
PI = 3.141592
def some_method
puts "Hello, world!"
end
end
MyModule::PI # => 3.141592 (yay!)
MyModule.some_method # => NoMethodError (eh!?)

42. class User
include MyModule
end
Using modules as “mixins"
me.some_method # => “Hello, world!”

43. class User
include MyModule
end
Using modules as “mixins"
“Mixing in” functionality
into an existing class
me.some_method # => “Hello, world!”

44. Using modules as function grouping in a
namespace (helper/utility classes)
module MyModule
def self.some_method
puts “Hello, world!”
end
end
MyModule.some_method # => “Hello, world!”

45. Math.cos(10)

46. module NamingMethods
def name=(name)
@name = name
end
def name
@name
end
end
class User
include NamingMethods
end
me = User.new
me.name = “Fred”
p me.name

47. module NamingMethods
def name=(name)
@name = name
end
def name
@name
end
end
Can anybody guess
what’s going on
behind the scenes?
class User
include NamingMethods
end
me = User.new
me.name = “Fred”
p me.name

48. User (RClass)
superclass
methods table
#name=
#name
Object (RClass)
NamingMethods (RModule)
methods table
#name=
#name
#hello

49. superclass
User (RClass)
superclass
methods table
#name=
#name
Object (RClass)
NamingMethods (RModule)
methods table
#name=
#name
#hello
NamingMethods (IClass)
methods table

50. “extend” vs “include”

51. module ClassMethods
def hello
42
end
end
class User
extend ClassMethods
end
p User.hello # => 42

52. module SingletonMethods
def hello
42
end
end
str = “hello”
str.extend SingletonMethods
p str.hello # => 42

53. module MyFunctionality
def instance_meth
puts “I’m an instance method”
end
def self.included(klass)
klass.extend ClassMethods
end
module ClassMethods
def class_meth
puts “I’m a class method”
end
end
end
class MyClass
include MyFunctionality
end
p MyClass.class_meth # => “I’m a class method”
p MyClass.new.instance_meth # => “I’m an instance method”

54. superclass
MyClass (RClass)
superclass
Object (RClass)
MyFunctionality (RModule)
methods table
#instance_meth
(IClass)
methods table
klass
*(IClass)
superclass
methods table
MyFunctionality::ClassMethods
methods table
#class_meth
(RModule)
