The document introduces Unisvr's x86 PCC software, designed for private cloud computing on Intel x86 hardware, compatible with Windows 10 and Linux. It outlines the software's major functional modules, including file sharing, video streaming, and real-time IoT applications, while also detailing its deployment in various service territories. The x86 PCC software is set for a beta test by the end of October 2015 as part of a B-to-B-C bundling agreement.

1. 2015/10/6 1
Introduction to “X86 PCC Software”
UniSVR’s Private Cloud Computer Software Products
for x86 Hardware Platform
1003 2015

2. 2015/10/6 2
Intel X86-based Private Cloud Computers Software
for either Windows 10 or Linux
X86 Board with LAN Port
HDD or Other Mass Storage
Windows 10 or Linux
UniSVR’s X86 Private Cloud
Computer Software
Bundled into Products of X86 PCC Partners

3. 2015/10/6 3
Description of X86 PCC Software Products
• Server-class Product.
• Four Product Numbers:
– Including two types of Operating System:
• For Windows (limited to Windows 10, 64 bit )
• For Linux (ubuntu 14.04)
– Including two Service Territories:
• PRC Service Territory
• Global (Except PRC) Service Territory
• For Intel’s X86 CPU-based Hardware Only.
– Atom and above.
– Partners’ own hardware products.
• Rich Functional Software Modules:
– (See the next slide)

4. 2015/10/6 4
Major Functional Modules within UniSVR’s
PCC Software
This the key module to enable PCC to work with UniSVR’s HermesDDS
Service.
HermesComponent8
This is the IO Gateway module, to enable client, at any where to do
manual control of and to read the status of the IO devices.
MIOSS7
This is a file sharing and sharing management modules. Clients can , at
any where, download and upload files to selected folders which are
controlled by AFSS using corresponding App.
AFSS6
This module is to convert audio/video streams to standard video streams
to Web Page or YouTube Live.
Video Streaming5
Notification Generator. This specific type of Action is to send notification
message to designated Clients.
UE/NTG4
Timer Event Generator. The source of event based on timer.UE/TEG3
Event-Action Sequencer. A configurable module to support the
relationship among Events and multiple pre-set Actions.
UE/EAS2
Network Video Recorder supporting only 2 video channels. It is
upgradable by End Users for up to 16 video channels with Upgrade Fee.
UE/NVR1
DescriptionFunctional Modules

5. 2015/10/6 5
Support Multi-User, Real Time IOT
Applications
Local Area Network
Private Cloud Computer
•Private Cloud Storage
•Private Information Exchange
Center
•Network Control Center
•Network Automation Center
•Network Video Center
Client Devices and Client Application Software
Network Edge Device
Android Windows
iOS
Android
Network Edge Device
Gateway
Controller

6. 2015/10/6 6
UniSVR’s UniPCC IOT Solution Framework
IP Networks:
LAN and
Internet
IP Networks:
LAN and
Internet
• Membership
• Client Device
• Client Application Software
Private Cloud Computer
Cloud Service Cloud Gateway
Controllers
Client Side
Network Edge
Devices (NED)
Installed at Users’ Premises

7. 2015/10/6 7
UniPCC “Care Through Share”
Home Solution Application Scenario
The Minimum Configuration
Local Clients
Private Cloud Computer Site
Internet
Elders
For Care
Share
Their
Children
Remote Clients
Using iPhones
At Remote Sites
UniPCC Home Server

8. 2015/10/6 8
“X86 PCC Software”
is the flagship software product
for B-to-B-C bundling agreement
Ready for Beta Test by the End of Oct., 2015
