1. Help please!!
(Include your modified DList.java source code file in your homework solution zip archive)
Using
whatever Java IDE you prefer, create a project and add DList.java and DListTest.java to it (these
files are provided
in the Week 6 Source zip archive). Modify DList to implement a method that removes all
occurrences of a specific
integer from the list. Here is the pseudocode:
Method removeAll(In: Integer pData) Returns Nothing
Define index variable i and initialize i to 0
While i < the size of this Dlist Do
If get(i) equals pData Then
remove(i)
Else
Increment i
End If
End While
End Method removeAll
Next, modify DListTest() to add test case 21 which tests that removeAll() works correctly.
WHat more do i need to provide to get help on this???
Solution
/* DListNode.java */
/**
* A DListNode is a node in a DList (doubly-linked list).
*/
class DListNode {
/**
* item references the item stored in the current node.
* prev references the previous node in the DList.
* next references the next node in the DList.
*
* DO NOT CHANGE THE FOLLOWING FIELD DECLARATIONS.

2. */
public Object item;
protected DListNode prev;
protected DListNode next;
/**
* DListNode() constructor.
* @param i the item to store in the node.
* @param p the node previous to this node.
* @param n the node following this node.
*/
DListNode(Object i, DListNode p, DListNode n) {
item = i;
prev = p;
next = n;
}
}
/* DList.java */
/**
* A DList is a mutable doubly-linked list ADT. Its implementation is
* circularly-linked and employs a sentinel (dummy) node at the head
* of the list.
*
* DO NOT CHANGE ANY METHOD PROTOTYPES IN THIS FILE.
*/
class DList {
/**
* head references the sentinel node.
* size is the number of items in the list. (The sentinel node does not
* store an item.)
*
* DO NOT CHANGE THE FOLLOWING FIELD DECLARATIONS.
*/
protected DListNode head;
protected int size;
/* DList invariants:

3. * 1) head != null.
* 2) For any DListNode x in a DList, x.next != null.
* 3) For any DListNode x in a DList, x.prev != null.
* 4) For any DListNode x in a DList, if x.next == y, then y.prev == x.
* 5) For any DListNode x in a DList, if x.prev == y, then y.next == x.
* 6) size is the number of DListNodes, NOT COUNTING the sentinel,
* that can be accessed from the sentinel (head) by a sequence of
* "next" references.
*/
/**
* newNode() calls the DListNode constructor. Use this class to allocate
* new DListNodes rather than calling the DListNode constructor directly.
* That way, only this method needs to be overridden if a subclass of DList
* wants to use a different kind of node.
* @param item the item to store in the node.
* @param prev the node previous to this node.
* @param next the node following this node.
*/
protected DListNode newNode(Object item, DListNode prev, DListNode next) {
return new DListNode(item, prev, next);
}
/**
* DList() constructor for an empty DList.
*/
public DList() {
// Your solution here.
head = newNode(null, head, head);
head.prev = head;
head.next = head;
size = 0;
}
/**
* isEmpty() returns true if this DList is empty, false otherwise.
* @return true if this DList is empty, false otherwise.
* Performance: runs in O(1) time.
*/

4. public boolean isEmpty() {
return size == 0;
}
/**
* length() returns the length of this DList.
* @return the length of this DList.
* Performance: runs in O(1) time.
*/
public int length() {
return size;
}
/**
* insertFront() inserts an item at the front of this DList.
* @param item is the item to be inserted.
* Performance: runs in O(1) time.
*/
public void insertFront(Object item) {
// Your solution here.
head.next.prev = newNode(item, head, head.next);
head.next = head.next.prev;
size++;
}
/**
* insertBack() inserts an item at the back of this DList.
* @param item is the item to be inserted.
* Performance: runs in O(1) time.
*/
public void insertBack(Object item) {
// Your solution here.
head.prev.next = newNode(item, head.prev, head);
head.prev = head.prev.next;
size++;
}
/**
* front() returns the node at the front of this DList. If the DList is
* empty, return null.

5. *
* Do NOT return the sentinel under any circumstances!
*
* @return the node at the front of this DList.
* Performance: runs in O(1) time.
*/
public DListNode front() {
// Your solution here.
if (isEmpty()) {
return null;
}
return head.next;
}
/**
* back() returns the node at the back of this DList. If the DList is
* empty, return null.
*
* Do NOT return the sentinel under any circumstances!
*
* @return the node at the back of this DList.
* Performance: runs in O(1) time.
*/
public DListNode back() {
// Your solution here.
if (isEmpty()) {
return null;
}
return head.prev;
}
/**
* next() returns the node following "node" in this DList. If "node" is
* null, or "node" is the last node in this DList, return null.
*
* Do NOT return the sentinel under any circumstances!
*
* @param node the node whose successor is sought.

6. * @return the node following "node".
* Performance: runs in O(1) time.
*/
public DListNode next(DListNode node) {
// Your solution here.
if (node == null || node.next == head) {
return null;
}
return node.next;
}
/**
* prev() returns the node prior to "node" in this DList. If "node" is
* null, or "node" is the first node in this DList, return null.
*
* Do NOT return the sentinel under any circumstances!
*
* @param node the node whose predecessor is sought.
* @return the node prior to "node".
* Performance: runs in O(1) time.
*/
public DListNode prev(DListNode node) {
// Your solution here.
if (node == null || node.prev == head) {
return null;
}
return node.prev;
}
/**
* insertAfter() inserts an item in this DList immediately following "node".
* If "node" is null, do nothing.
* @param item the item to be inserted.
* @param node the node to insert the item after.
* Performance: runs in O(1) time.
*/
public void insertAfter(Object item, DListNode node) {
// Your solution here.

7. if (node != null) {
node.next.prev = newNode(item, node, node.next);;
node.next = node.next.prev;
size++;
}
}
/**
* insertBefore() inserts an item in this DList immediately before "node".
* If "node" is null, do nothing.
* @param item the item to be inserted.
* @param node the node to insert the item before.
* Performance: runs in O(1) time.
*/
public void insertBefore(Object item, DListNode node) {
// Your solution here.
if (node != null) {
node.prev.next = newNode(item, node.prev, node);
node.prev = node.prev.next;
size++;
}
}
/**
* remove() removes "node" from this DList. If "node" is null, do nothing.
* Performance: runs in O(1) time.
*/
public void remove(DListNode node) {
// Your solution here.
if (node != null) {
node.prev.next = node.next;
node.next.prev = node.prev;
size--;
}
}
/**
* removeAll() removes "node" from this DList. If "node" is null, do nothing.
* Performance: runs in O(1) time.

8. */
public void removeAll(Object item) {
// Your solution here.
int i=0;
DListNode current = head.next;
while (current != head) {
if (current.item == item ) remove(current);
current = current.next;
}
if (current.item == item) remove(current);
}
/**
* toString() returns a String representation of this DList.
*
* DO NOT CHANGE THIS METHOD.
*
* @return a String representation of this DList.
* Performance: runs in O(n) time, where n is the length of the list.
*/
public String toString() {
String result = "[ ";
DListNode current = head.next;
while (current != head) {
result = result + current.item + " ";
current = current.next;
}
return result + "]";
}
public static void main(String[] argv) {
System.out.println("Testing Constructor");
DList testList = new DList();
System.out.println("Is empty? Should be true: " + testList.isEmpty());
System.out.println("Should be zero length: " + testList.length());
System.out.println("Should be [ ]: " + testList);
System.out.println(" Testing insertFront");

9. testList.insertFront(1);
System.out.println("Is empty? Should be false: " + testList.isEmpty());
System.out.println("Should be one length: " + testList.length());
System.out.println("Should be [ 1 ]: " + testList);
System.out.println(" Testing insertBack");
testList.insertBack(3);
System.out.println("Is empty? Should be false: " + testList.isEmpty());
System.out.println("Should be two length: " + testList.length());
System.out.println("Should be [ 1 3 ]: " + testList);
System.out.println(" Testing front()");
System.out.println("This should print out 1: " + testList.front().item);
System.out.println(" Testing back()");
System.out.println("This should print out 3: " + testList.back().item);
System.out.println(" Testing next method");
testList.insertFront(5);
System.out.println("Should be [ 5 1 3 ]: " + testList);
DListNode testingNode = testList.next(testList.front());
System.out.println("This should print out 1: " + testingNode.item);
testingNode = testList.next(testingNode);
System.out.println("This should print out 3: " + testingNode.item);
System.out.println(" Testing prev method");
testingNode = testList.prev(testingNode);
System.out.println("This should print out 1: " + testingNode.item);
System.out.println(" Testing insertBefore");
testList.insertBefore(10, testingNode);
System.out.println("Should print out [ 5 10 1 3 ]: " + testList);
System.out.println(" Testing insertAfter");
testList.insertAfter(40, testingNode);
System.out.println("Should be [ 5 10 1 40 3 ]: " + testList);
System.out.println(" Removing node");
testList.remove(testingNode);
System.out.println("Should be [ 5 10 40 3 ]: " + testList);
System.out.println(testList.length());
DList l = new DList();
System.out.println(" ###Testing insertFront ### Empty list is" + l);
l.insertFront(9);

10. System.out.println(" Inserting 9 at front. List with 9 is " + l);
l.insertFront(8);
l.insertFront(7);
System.out.println(" Inserting 7, 8 at the front. List with 7, 8, 9 is " + l);
l.insertAfter(6, l.head);
System.out.println(" Inserting 6 after head. nList with 6, 7, 8, 9 is "+l);
l.remove(l.head.next);
System.out.println(" Removed head.next, should return a list of 7, 8, 9. List with 7, 8, 9 is
" + l);
l.insertFront(9);
l.insertFront(8);
System.out.println(" Inserting List 9,8 with 8, 9, 7, 8, 9 is " + l);
l.removeAll(8);
System.out.println(" Removing all 8 from List with 9, 7, 9 is " + l);
}
}
Output refer url : http://ideone.com/Ila9vB
