This document outlines a revised methodology for estimating ground water resources in India. It notes that ground water has become an important source of water for irrigation, domestic, and industrial uses. The previous methodology from 1984 provided the basis for ground water assessment and development in the country. However, experience over the past decade highlighted the need to update the methodology. The revised methodology incorporates several changes compared to the 1984 approach, including using watershed as the assessment unit in hard rock areas, separating command and non-command areas, and assessing recharge separately for monsoon and non-monsoon seasons. The report recommends the revised methodology be used by states to realistically reassess ground water resources.
