2. Characterization of vehicle flow for intelligent
transportation systems
People’s Democratic Republic of Algeria
Ministry of Higher Education and Scientific Research
M’Hamed BOUGARA University – Boumerdes
Institute of Electrical and Electronic Engineering
Department of Electronics
MASTER
In Electrical and Electronic Engineering
Option: Telecommunications
Title
Presented by:
•Abdenour BOUAICHA
Supervisor:
Dr. Fatma KEROUH
6. The major categories of ITS?
Intelligent
Transportation
Systems
Advanced Traffic
Management
Systems
Advanced
Travelers
Information
Systems
Commercial
Vehicle
Operation
Advanced Public
Transportation
Systems
Advanced
Vehicle Control
Systems
Advanced Rural
Transportation
Systems
6
Intelligent Transportation
systems
8. Video quality Software
Blur effect Complexity
Bad illumination Execution time
Illumination changing …..
Shadow
Noise
Multiple vehicle occlusion
…..
8
Problems of visual based systems
9. Problems of visual based systems
ITS needs Information
Information requires Data.
Data relies on smart video surveillance.
Fast Robust Reliable
9
10. Intelligent Transportation
Systems
Our purpose?
Why?
• Accumulating the statistics.
Identifying critical flow time periods.
Determining the influence of large vehicles or pedestrians
on vehicular traffic flow.
Knowing the reasons of traffic congestion, road
degradation, and air pollution.
…… 10
Surveillance
camera
Image processing
techniques
Vehicle
detection,
counting,
classification and
speed estimation
11. Proposed vision based ITS
11
-Vehicle detection
and counting.
-Vehicle
Classification.
- Vehicle speed
estimation.
Processing
Preprocessing
Video
15. Proposed vision based ITS
15
Start
The camera is
activated
Preprocessing
The vehicle passing the
ROI
Vehicle detection, counting, classification,
and speed estimation
i++ Yes
No
Yes
End
No
16. Proposed ITS (Detection, counting, and
classification)
16
Proposed idea: Vehicle detected
Vehicle counted
and classified
17. Proposed ITS (Detection and
counting)
17
Start
Read ref
Preprocessing
Camera is
activated
Read rf
Preprocessing
Compute D
D >Th1
&&
D<=Th2
Count++End
Yes
No
Yes
No
19. Proposed ITS (Classification)
19
Start
Read ref
Preprocessing
Camera is
activated
End
CCF++
Vehicle is
detected
Vehicle
is
counted
CCF >=
Th3
Big
Small
No
No
No
No
Yes
Yes
Yes
Yes
21. Proposed ITS (Speed estimation)
21
Start
Camera is
activated
End
Vehicle is
counted in
first ROI
Vehicle is
counted in
second
ROI
COUNT2
COUNT1
COUNT1 !
= COUNT2
Spd++
Calculate the
Speed
Yes Yes
Yes
Yes
No
No
No
No
26. Experiments, Results and
DiscussionsVehicle detection and counting
ROI Video 1 Video 2 Video 3 Video 4
GT OR GT OR GT OR GT OR
ROI 1 13 13 13 13 5 6 4 4
ROI 2 6 6 9 9 9 9 17 14
ROI 3 12 12 8 8 15 14 20 15
ROI 4 13 13 13 13 16 16 22 26
Total 44 44 43 43 45 45 63 59
Accuracy 100% 100% 95.56% 93.65%
Runtime of
one
frames(sec)
0.0702 0.0467 0.1747 0.1713
26
27. Experiments, Results and
Discussions
Vehicle detection and classification
ROI Video 1 Video 2 Video 3 Video 4
S B RS RB S B RS RB S B RS RB S B RS RB
ROI 1 13 0 13 0 8 1 9 0 5 0 5 1 4 0 4 0
ROI 2 5 1 5 1 9 0 9 0 7 2 7 2 15 2 10 4
ROI 3 12 0 12 0 7 1 8 0 15 0 14 0 19 1 12 3
ROI 4 13 0 13 0 10 3 13 0 12 4 7 9 22 0 23 3
Accuracy
rate
100% 88.37% 88.88% 88.88%
Runtime
of one
frame
(sec)
0.0710 0.0463 0.1712 0.1737
2 27
30. Video The task The
running
-time
Percentage
accuracy
Count Class Speed Coun
t
Class
Video 1 Y Y - 0.0782 100% 100%
Video 2 Y Y Y 0.0938 100% 90.91
%
Video 3 Y Y Y 0.1901 95.56
%
88.88
%
Video 4 Y Y Y 0.2031 93.85
%
88.88
%
Total - - - - 97.3% 92.42
%
30
Experiments, Results and Discussions
32. Analyzing the proposed approach
The strengths
Real time
Simple
Robust against to bad and changing illumination
Robust against to the noise
Robust against to the blur effect
Robust against to the occlusion
Simple camera
32
33. The weaknesses
Vehicle passing through portion of ROI.
Fixed camera.
Vehicle congestion.
33
Analyzing the proposed approach
34. Conclusion and perspectives
Introducing the concepts of ITS.
Showing the problems on visual based systems.
Developing a simple and real-time ITS that detects, counts, classifies
and estimates the speed of vehicles.
Proposed ITS relies on selected best ROI which in middle and inside
of the lane with neither small length nor big.
Separating the ROI solved problem of multiple vehicles occlusion.
Using LBP have shown that our system is robust against bad and
changing illumination.
Using adaptive thresholds solve the problem of noise and blur effect.
The percentage accuracy of counting is: 97.3%.
The percentage accuracy of classification is: 92.42%
34
35. Conclusion and perspectives
Perspectives:
-Test the proposed system on long videos that
contains more challenging problems.
-Consider more classes in the classification step
(small, medium, and big vehicles).
-Acquire videos with ground truth to test deeply the
speed estimation part.
-Plan to build android application.
35
