Download to read offline
![14CONFIDENTIAL
CONSOLIDATED FRAMEWORK
Test data csv-file should be
created/updated before
running consolidated Test case
by executing
ParameterExportByTestCaseID
test method.
Test class
implementationStructure
[TestMethod]
public void MasterTestSuite()
- testCaseData
- <variables to store test data>
...
<Test class>
CNTestCaseBase
+ setup()
reads test data from the
appropriate csv file into and
stores it to local dictionary and
variables of method instance
testCaseData =
CNTestSuiteExten
sions
.LoadTestCaseDa
ta();+ exec()
create and setup test data
needed to TC like create mails,
contacts, meeting, etc.
+ validate()
method that perform validation
steps (after processes execution)
+ cleanup()
clean up environment after TC
execution
Test case
CSV file:
../../../CNAutomation
Project
/TFS.Parameters/
<test case id>.csv
[TestMethod]
<Test
class>()
Start
Create TC…
classes
instances
For each instance
execute setup();
execute exec()
Execute sync- processes
Execute build-model
process,
iisreset
For each instance
execute validate()
End
For each instance
execute cleanup()
[TestClass]
TFSParameterExportByTestCaseID
[TestMethod]
+ ParameterExportByTestCaseID()
Gets test parameters data from TFS for
specified test cases and stores them in
appropriate csv-file](https://image.slidesharecdn.com/consolidatedtcexec-161112065959/85/Example-of-TAF-with-batch-execution-of-test-cases-14-320.jpg)
![16CONFIDENTIAL
CONSOLIDATED FRAMEWORK
Test class
implementation
Structure
[TestMethod]
public void BatchExecution_TestMethod ()
+ ctor <Test class>
Invokes setup()
<Test class>
TestCaseBase
+ setup()
reads test data from the
appropriate csv file into and
stores it to local dictionary and
variables of method instance
[ + Validation1() ]
if required
[ + Validation2() ]
if required
[TestClass]
<Test class>()
Start
Create TC…
classes
instances
Execute
Process 1
End
Implementation 2
For each instance
Exec Validation 1
Execute
Process 2
For each instance
Exec Validation 2
…Execute
Process N
For each instance
Exec Validation N
…[ + ValidationN() ]
if required](https://image.slidesharecdn.com/consolidatedtcexec-161112065959/85/Example-of-TAF-with-batch-execution-of-test-cases-16-320.jpg)
Uploaded byCOMAQA.BY
Example of TAF with batch execution of test cases
The document discusses a consolidated approach to executing test cases that addresses the challenges of long-running processes and significant database modifications, proposing a framework to speed up execution times. It outlines a structured method to manage test data and streamline processes, noting both advantages such as reduced run times, and disadvantages like complexity and difficulty in adapting existing test cases. Future steps include enhancing flexibility in testing workflows and incorporating cleanup methods to improve execution efficiency.
More Related Content
Similar to Example of TAF with batch execution of test cases
Example of TAF with batch execution of test cases
- 1.
- 2. 2CONFIDENTIAL CONSOLIDATED TEST CASEEXECUTION INTRODUCTION
- 3.
- 4. 4CONFIDENTIAL INTRODUTION Takes much time •long-running process (> 5 min) • modify database significantly Integration processes
- 5.
- 6.
- 7.
- 8.
- 9. 9CONFIDENTIAL Testcase Arrangement test data (create e-mail) Syncprocesses (Set data in DB) Build- model Verify data REAL EXAMPLE Testcase Arrangement test data (create e-mail) Sync processes (Set data in DB) Build- model Verify data … Testcase Arrangement test data (create e-mail) Sync processes (Set data in DB) Build- model Verify data many times with unique test data
- 10. 10CONFIDENTIAL REAL EXAMPLE Could weuse parallelization? (setup scope of environments and run TCs on each) No. • We are unable to run build-model against one server • Only one process must run at the same time • Therefore we need setup whole environment on each VM • It takes about 20 minutes (some installation scripts execution require • So no sense • Moreover we don’t have so much free VMs
- 11. 11CONFIDENTIAL REAL EXAMPLE Execution timeof 1 test case: 10–15 minutes Number of test cases: 70 Total running time: 875 minutes (14.5 hours)
- 12. 12CONFIDENTIAL SOLUTION Sync processes (Set datain DB) 0 Build- model Testcase Arrangement test data (create e-mail) Testcase Arrangement test data (create e-mail) … Testcase Arrangement test data (create e-mail) Testcase Verify data Testcase Verify data … Testcase Verify data
- 13.
- 14. 14CONFIDENTIAL CONSOLIDATED FRAMEWORK Test datacsv-file should be created/updated before running consolidated Test case by executing ParameterExportByTestCaseID test method. Test class implementationStructure [TestMethod] public void MasterTestSuite() - testCaseData - <variables to store test data> ... <Test class> CNTestCaseBase + setup() reads test data from the appropriate csv file into and stores it to local dictionary and variables of method instance testCaseData = CNTestSuiteExten sions .LoadTestCaseDa ta();+ exec() create and setup test data needed to TC like create mails, contacts, meeting, etc. + validate() method that perform validation steps (after processes execution) + cleanup() clean up environment after TC execution Test case CSV file: ../../../CNAutomation Project /TFS.Parameters/ <test case id>.csv [TestMethod] <Test class>() Start Create TC… classes instances For each instance execute setup(); execute exec() Execute sync- processes Execute build-model process, iisreset For each instance execute validate() End For each instance execute cleanup() [TestClass] TFSParameterExportByTestCaseID [TestMethod] + ParameterExportByTestCaseID() Gets test parameters data from TFS for specified test cases and stores them in appropriate csv-file
- 15.
- 16. 16CONFIDENTIAL CONSOLIDATED FRAMEWORK Test class implementation Structure [TestMethod] publicvoid BatchExecution_TestMethod () + ctor <Test class> Invokes setup() <Test class> TestCaseBase + setup() reads test data from the appropriate csv file into and stores it to local dictionary and variables of method instance [ + Validation1() ] if required [ + Validation2() ] if required [TestClass] <Test class>() Start Create TC… classes instances Execute Process 1 End Implementation 2 For each instance Exec Validation 1 Execute Process 2 For each instance Exec Validation 2 …Execute Process N For each instance Exec Validation N …[ + ValidationN() ] if required
- 17. 17CONFIDENTIAL PROS AND CONS AdvantagesDisadvantages significantly reduced TC run time complex test case structure able to manage execution order test data should be unique test data is read from local CSV huge test log difficult to add new methods MS test methods like Class/Test initialize or cleanup are not executed hard to adopt existing TCs to consolidated approach
- 18.
- 19. 19CONFIDENTIAL 1. Make testcase more flexible • ability to change testing workflow process by managing pool of executable methods 2. Add execution of ClassInitialize, TestInitialize, ClassCleanup, TestCleanup accordingly NEXT STEP
