1. Distortion techniques
Digital Signal Processing
hakon.kvidal@nmh.no

2. Clipping
Sinuskurve
Klipping
Terskel
Thresold

3. Mirror (Speiling)
Sinuskurve
Speiling- Mirror
Terskel
Thresold

4. Wrap (Bretting)
Sinuskurve
Bretting - Wrap
Terskel
Thresold

5. tanh()-funksjonen
• Signalet multipliseres med en hyperbolsk
tangent
A linear transfer
function
(signal unmodified)
tanh(x*2) transfer
function
tanh(x*4) transfer
function

6. tanh()-funksjonen
Sinuskurve
Sine with tanh distortion, gain = 1
Sine with tanh distortion, gain = 3
Sine with tanh distortion, gain = 7

7. Waveshaping

8. Waveshaping – Lytte eks 1
Vi behandler en sinusbølge følgende funksjon
Example transfer function for
waveshaping, rising sigmoid.
Sine waveshaped with
rising sigmoid shaped
transfer function

9. Waveshaping – Lytte eks 2
Vi behandler en sinusbølge følgende funksjon
Example transfer function for
waveshaping, rising sigmoid plus
4th harmonic sine component.
Sine waveshaped with
sigmoid and 4th
harmonic sine transfer
function

10. Waveshaping – Lytte eks 3
Vi behandler en sinusbølge følgende funksjon
Example transfer function for
waveshaping, arbitrary linear
segments.
Sine waveshaped with
arbitrary linear segment
transfer function
