DevOps for IBM Commerce
Michael D. Elder
IBM Distinguished Engineer
Chief Developer, UrbanCode
mdelder@us.ibm.com
@mdelder

2© 2016 IBM Corporation
Please Note
2
• IBM’s statements regarding its plans, directions, and intent are subject to change or withdrawal
without notice at IBM’s sole discretion.
• Information regarding potential future products is intended to outline our general product direction
and it should not be relied on in making a purchasing decision.
• The information mentioned regarding potential future products is not a commitment,
promise, or legal obligation to deliver any material, code or functionality. Information about
potential future products may not be incorporated into any contract.
• The development, release, and timing of any future features or functionality described for our
products remains at our sole discretion.
• Performance is based on measurements and projections using standard IBM benchmarks in a
controlled environment. The actual throughput or performance that any user will experience will
vary depending upon many factors, including considerations such as the amount of
multiprogramming in the user’s job stream, the I/O configuration, the storage configuration, and
the workload processed. Therefore, no assurance can be given that an individual user will achieve
results similar to those stated here.

• What problems do DevOps release methods solve?
• How can you shift your culture to an Enterprise view of
DevOps?
• Principles and techniques of DevOps from Architecture to
Automated Deployments to Version Control
Agenda
IBM Confidential

Failures due to
inconsistent dev and
production
environments
Bottlenecks trying to
deliver more frequent
releases to meet
market demands
Complex, manual,
processes for release
lack repeatability and
speed
Poor visibility into
dependencies across
releases, resources, and
teams
Software delivery challenges
Daily
Build
Monthly
Delivery
Who did
this last
time?
Dave…
Dave’s not
here man…
Dev
Prod

High performing teams adopt DevOps
Reference: 2013State ofDevOps Report by PuppetLabs

About philosophy
Culture of continual
experimentation and
learning
• Production like environments
• Fully automated deployments
• Accelerated delivery cycles
Build – Measure - Learn
“Success is not delivering a
feature; success is learning
how to solve the customer’s
problem.”

7© 2016 IBM Corporation 7
IBM Bluemix Garage Method
Practices
Processes or actions you & your
team perform to achieve an
outcome.
Tracks
A selectedset of practices,tools,
and toolchains tocreateacloud
nativeorcloudenabled solution
Toolchain
Complementary & compatible tools
that when used together create a
flexible solution
Experts & Experiences
ListentoourExperts tolearnhow
wetransformedourbusiness
Combines industry best practices for Design
Thinking, Lean Startup, Agile Development,
DevOps, and Cloud to build and deliver
innovative solutions.
https://www.ibm.com/devops/method

8© 2016 IBM Corporation © IBM
Corporation
New content added weekly

9© 2016 IBM Corporation © IBM
Corporation
Linkage to
Bluemix Garage
and Lab Services
Method Website – global deployment
Usage analytics
Linkage to Online tools and tutorials
Linkage to Tool Chains for tracks
User Login and profile management
- Tailored views by user
Method personalization & customization
eLearning & certifications
Innovative & new “Method-as-a-Service”
With consulting
services
Self service
Common/Shared:
Method Content
Practices & Tracks
As a large enterprise, how do I get 2,000 developers doing DevOps on Cloud?
Garage Method for DevOps Transformation @ Enterprise Scale

Accelerate Innovation
ivDeliverCodeThink Run
Systems of engagement
Systems of Record
Enterprise
Applications
Production
Most enterprises need a combination of DevOps patterns
10
API
Catalog
Operational Excellence
ivDeliverCodeThink Run Production
Shared
Services
Digital
Applications
• Coordinating different
teams working at different
speeds
• Balancing between agility,
stability, and risk
• Decouple across API
boundary, but manage
release process with
consistent approach

Expectations of Continuous Delivery
User Experience Today Emerging
Primary Workload Type Systems of Record
(Transactional)
Systems of Engagement (+ Record)
Big Data, Analytics, Mobile/Social Channels
Delivery Model Planned Incremental(DevOps)
Development and Operations Team Sizes 100s and costly 10s with built-in DevOps automation
Release Frequency Months to years Days to weeks, based on business opportunity
Integration Frequency Weeks Continuous
Infrastructure Deployment Days Minutes
Time to Value Planned Opportunistic
Operational Model Systems management Built into application, recovery-oriented, continuous availability
Service Sourcing Develop Consume and assemble (public and private)
Feedback Loop Periodic Continuous interaction with clients

Increase the operational awareness of your software earlier in the
development process.
What does DevOps mean to me?
How do you do that?
§ Architecture
§ Automated Testing
§ Automated Deployments
§ Production-Like Environments
§ Automated Release Promotion Process
§ Version control of all software, automation, and configuration
Why do this?
Because faster feedback loops enable rapid evolution of ideas and
therefore faster iterations of your software
Shift Left

“Cool factor” .. seen as pushing to the “next big thing” in our industry
Better communication between those who createand those who operate
(same people in some cases)
Reduced fear of breaking the build/deployment/environment
Fail fast before you “fail all”
Heavy focus on experimentation and learning
Improve the speed of your feedback loop to enable rapid evolution of ideas
What are the characteristics of teams who practice DevOps?

§ Architecture
§ Version control of all software, automation, and
configuration
About our next topics

About your architecture
• Architecture should support DevOps principles such as staged
roll out, operational insights, and scriptability
• Each resource provides some very practical advice for building
systems which are focused on reliability and feedback loops
Experiment!: Website
conversion rate
optimization with A/B
and multivariate testing
Release It!: Design and
Deploy Production-Ready
Software

Common components in Commerce configurations
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Swim Lane 1
Swim Lane 2
www
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Commerce
Data
Content
Mgmt
System
Commerce
Data
Content
Mgmt
System

Common managed artifacts in Commerce configurations
www
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Commerce
Data
Content
Mgmt
System
.sql
.sql
Business
Content
.war
.ear
partial .ear
.xml
httpd.conf
iPhone7 microsite
.war

Common managed artifacts in Commerce configurations
www
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Commerce
Data
Content
Mgmt
System
.sql
.sql
Business
Content
.war
.ear
partial .ear
.xml
httpd.conf
iPhone7 microsite
.war
Snapshot of Related
Assets to be
delivered as a single
unit of deployment

Updates & Rollbacks in Production
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Swim Lane 1
Swim Lane 2
www
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Commerce
Data
Content
Mgmt
System
Commerce
Data
Content
Mgmt
System
Apply
Updates

Automated testing is critical for automated feedback
• This is THE HARDEST part of the whole experience
• NO ONE is great at this, so don’t get discouraged
• Facebook’s process for code review include stats on how
many tests are consistently broken to decide whether the test
failures are noteworthy
• Continuously improve your coverage, flexibility, and discipline
• Consider all aspects of testing:
• Programmatic API (JUnit)
• REST API (HTTPUnit, REST Fuse)
• Web UI (Selenium)
• Behavior driven testing (Cucumber)
• Performance testing (Apache JMeter)
• Security testing (Rational AppScan & IBM QRadar)

Embedding unit tests in your classes directly
• Promoted approach by
Netflix to reduce friction and
introduces limited additional
bytes relative to third party
libraries
• Makes it easy to write
commands, the UnitTest
becomes the test harness
and verification
• Always testSuccess() and
testFailure() use cases to
ensure expected behavior
import static org.junit.Assert.assertEquals;
import static org.junit.Assert.assertNotNull;
public class OSDeployEnvironmentCommand extends
OSAbstractOrchestrationCommand<Response> {
public static class UnitTest {
@Test
public void testSuccess() throws InterruptedException,
ExecutionException, JSONException {
…
Future<Response> request =
new OSDeployEnvironmentCommand(…)
.queue();
Response response = request.get();
assertNotNull(response);
assertEquals(HttpStatus.SC_OK,
response.getStatus());
}
}

Testing Your Deployed Application – REST API
• We have used REST Fuse
which is an Eclipse project
• Captures REST calls as
annotations, freeing up
your test method to just
verify behavior
• Requires a little “hoop
jumping” for testing a
series of calls (e.g. POST ..
PUT .. GET)
import static
com.eclipsesource.restfuse.Assert.assertCreated;
import ...restfuse.annotation.Authentication;
import ...restfuse.annotation.HttpTest;
import ...restfuse.MediaType;
@HttpTest (method =
com.eclipsesource.restfuse.Method.POST,
contentMethod="getBlueprintRequestBody",
authentications = {
@Authentication( type = BASIC,
user = "{keystoneUser}",
password = "{keystonePassword}") },
path = "/rest/blueprint",
type = MediaType.APPLICATION_JSON
)
public void testCreateBlueprintOK() throws Exception {
assertCreated(response);
}

Behavior Driven Development & Testing
• Captures natural language
statements using “Given”,
“When”, “Then” clauses
• Each line is matched to a
snippet of code based on
regular expression
• Complete code statements
are executed to validate
behavior
• Bridge between business
goals and technical details
Scenario: Success – Upload client directory
Given I provide valid credentials to the api client
And I want to use the api client to make requests
When I upload the directory ”data/sample-app” with the client
Then the files returned matches the upload directory ”data/sample-app"

Testing Your Deployed Application – Web UI
• Selenium is the only
“apparent” choice that
we’ve come across that’s
effective
• Couples automated test to
some details of your web UI
and must be kept in sync
• We’ve developed a few best
practices around location
elements for maximum
flexibility, could publish this
if there’s interest
public class EditorsPage extends UCDPPage {
…
@FindBy(id = "new-blueprint-button")
private WebElement newButton;
…
public void createFile(String name, String id,
String[] values) {
newButton.click();
util().waitForElementPresentAndVisible(
By.className("new-file-dialog"));
WebElement widget =
util().findElement(
By.className("new-file-dialog"));
Dialog dialog =
Widget.init(this, widget, Dialog.class);
dialog.setValues(values, true, true);
dialog.clickPrimaryButton();
…
}
…
}

Automated deployments
• Visibility and automated control of your application deployment process
• Manage application
components and versions
• Manage configurations
across all environments
• Offer secure ‘self-service’
capabilities
• Increase transparency
• Ensure governance and compliancy

IBM UrbanCode for Continuous Delivery
Drive down cost
Reduce amount of manual labor, resource wait-time,andrework by
eliminating errors & providingself-serviceenvironments
Speed time to market
Increase frequency of softwaredelivery throughautomated, repeatable
deploymentprocesses across development, test and production
Reduce risk
Robust configurationmanagement, coordinatedreleaseprocesses, audits,
and traceability
Enabling clients to continuously deliver applications with high quality and low risk
IBM UrbanCode Build is a continuous integrationandbuildmanagement server optimized
for the enterprise,designed tomake it easy to scaletheconfigurationand managementof
build infrastructureandseamlessly plugin to development, testingand release tooling.
IBM UrbanCode Deploy enables hybridcloudby automatingthe deployment of
applications, databases, configurations and containers into development, test and production
on prem or in the cloud, helping todrive downcost,speed time to market with reducedrisk.
With full-stack environment management and deployment automation,users to design,
deploy and updatefull-stack environments for multiple clouds, including Bluemix, Softlayer,
AWS, Azure, and virtualizedenvironments.
IBM UrbanCode Release is an intelligent collaboration releasemanagement solutionthat
replaces error-pronemanual spreadsheets andstreamlines releaseactivitiesfor application
and infrastructure changes.

Application model
Reliably capture application content and configuration
settings with versioning and traceability

Application environments
Define where components are deployed and capture configuration
settings per deployment environment for an application

Define automated processes for each application component
Each component defines a series of steps, backed by
plugin tasks or custom scripts, to deploy it

Production-Like Environments
Possibly one of the most important principles of DevOps
Shift left any operational concerns that lead to
differences from DEV to PROD
https://hub.docker.com/u/ibmcom/#

Deployment of Applications across Environments
Applications are
managed for
deployment
Components
from the app
Specific versions of
the Components’
artifacts are
deployed
Compliancy keeps track
of whether the actual
versions matches the
expected
Each Component
knows its relevant
deployment
processes
Compare versions across
environments and define
Snapshots of known working
sets of Components
View
deployment
requests against
the environment
https://developer.ibm.com/urbancode/
Automated Release Promotion Process

Inventory over time

Configuration Management - Snapshots
Creating a Snapshot
Component Versions
1
1
2
2
3
3
321Web
Mid. Code
DB
Snapshot
3
2
1
Mid. Config 1 2 3 3
Snapshot Deployment
ENVSnapshot
3
2
1
WEB HOST
MID HOST
DB HOST
2
1
1
3
2
X
3 3 1
Contents of environments that pass tests
• contain deployable version and configuration
Deployments are based on deltas
They provide Automation, Audit, and Visibility

Version applications with Snapshots
Capture tested component versions and configuration
settings as a snapshot that is promoted to other
environments for better visibility and control

Updates & Rollbacks in Production
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Swim Lane 1
Swim Lane 2
www
Management
Center
IBM
Commerce
WebSphere
ND
Static
Content
Schema
changes may
be harder to
rollback
App logic changes
just rollback to a
known good version
or snapshot
Commerce
Data
Content
Mgmt
System
Commerce
Data
Content
Mgmt
System
Snapshot of Assets

Promotion Lifecylces
• Some changes such as
application logic will follow a
complete cycle from DEV to
PROD
• Other content-based changes
may only flow from Stage to
PROD
• All system changes should
flow through a consistent,
automated process with
appropriate approvals in
place
App Logic & Behavior
(Example: Updates per week or per month)
Content-based changes to Database
(Example: Nightly updates)

About version control
§ All application source code and
configuration should be version
controlled
§ All of your automation scripts,
configuration files, tests, etc
should also version controlled
§ UrbanCode Deploy
automatically understands
versions of components from
your build process, but also
versions all changes to
configuration properties and
automation processes

Code review should be part of your versioning process
§ Define and enforce coding
standards early in the
process
§ Automate deployment to
production-like systems as
part of automatic verification
§ Each commit should run
automated testing and code
coverage, and the toolchain
should enforce compliance
before merging or promoting
changes

§ Architecture
§ Version control of all software, automation, and
configuration
About this deck
mdelder@us.ibm.com http://linkedin.com/in/mdelder @mdelder

41© 2016 IBM Corporation41
© Copyright IBM Corporation 2013. All rights reserved. The information contained in these materials is provided for informational purposes only, and is provided AS IS without warranty of any kind, express or
implied. IBM shall not be responsible for any damages arising out of the use of, or otherwise related to, these materials. Nothing contained in these materials is intended to, nor shall have the effect of, creating
any warranties or representations from IBM or its suppliers or licensors, or altering the terms and conditions of the applicable license agreement governing the use of IBM software. References in these materials
to IBM products, programs, or services do not imply that they will be available in all countries in which IBM operates. Product release dates and/or capabilities referenced in these materials may change at any
time at IBM’s sole discretion based on market opportunities or other factors, and are not intended to be a commitment to future product or feature availability in any way. IBM, the IBM logo, Rational, the
Rational logo, Telelogic, the Telelogic logo, and other IBM products and services are trademarks of the International Business Machines Corporation, in the United States, other countries or both. Other company,
product, or service names may be trademarks or service marks of others.
www.ibm.com/software

DevOps for IBM Commerce

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to DevOps for IBM Commerce

Similar to DevOps for IBM Commerce (20)

More from Michael Elder

More from Michael Elder (14)

Recently uploaded

Recently uploaded (20)

DevOps for IBM Commerce
