The addition of Kubernetes support to Docker Enterprise Platform presents deployments with interesting new abstractions for application connectivity. Users and Operators are often challenged with rationalizing how pod networking (with CNI plugins like Calico or Flannel), Services (via kube-proxy) and Ingress work in concert to enable application connectivity within and outside a cluster. Similarly, given the dynamic and transient nature of containerized microservice workloads, how to leverage scalable and declarative approaches like network policies to express segmentation and security primitives. This session provides an illustrative walkthrough of these core concepts by going through common deployment architectures providing design, operations, and scale considerations based on experience from numerous production deployments. The session will also showcase how to complement application and operations workflows with policy-driven business, compliance and security controls typically required in enterprise production deployments.

1. Demystifying Application Connectivity
with Kubernetes in the Docker Platform
Session #154945

2. Dir. Solution Architecture,Tigera
@worldhopper
Karthik Prabhakar
Solution Architect, Docker
@nicolakabar
Nicola Kabar

3. Quick Poll #1
Who is designing a Kubernetes Container
Platform ?

4. Quick Poll #2
Who is intimidated by Kubernetes
Networking?

5. ...Then This Session is for You!
● Networking Design Considerations
● Calico CNI + Basics of K8S Networking
● Docker EE + Calico Integration Overview
● Application Deployment with Docker EE
● Takeaways
● Q&A

6. •Heterogeneous Infrastructure
•Diverse Application Portfolio
•Zero-Trust Security
Design Considerations

7. Let’s Start with K8S Connectivity Basics

8. Kubernetes Connectivity Concepts
Pod Networking
(CNI)
Ingress
Services
(Kube-proxy)
Network
Policy
Kube-DNS

9. Worker Nodes
UCP Manager/ K8s Master
Manager Nodes
Pod Creation: Kubelet
Node
apiserver scheduler
controller-
manager
Etcd
kubelet
Node
Pod
Node

10. Worker Nodes
UCP Manager/ K8s Master
Manager Nodes
Pod Network: Calico/CNI
apiserver scheduler
controller-
manager
Etcd
kubelet
Calico/CNI
Calico/IPAM

11. Worker Nodes
UCP Manager/ K8s Master
Manager Nodes
Pod Network: Calico/Node
apiserver scheduler
controller-
manager
Etcd
kubelet
Calico/CNI
Calico/IPAM
Calico/Node Calico/Node
Calico/CNI
Calico/IPAM
kubelet

12. Worker Nodes
UCP Manager/ K8s Master
Manager Nodes
Kubernetes Services: Kube-proxy
apiserver scheduler
controller-
manager
Etcd
kubelet
Calico/CNI
Calico/IPAM
Calico/Node Calico/Node
kube-proxy kube-proxy
Calico/CNI
Calico/IPAM
kubelet
> Cluster IP
> Node Port
> Load Balancer

13. UCP Manager/ K8s Master
Manager Nodes
Kubernetes Services: Ingress
apiserver scheduler
controller-
manager
Etcd
Worker NodesIngress Nodes
pod
svc
A
service-a.example.com

14. Worker Nodes
UCP Manager/ K8s Master
Manager Nodes
Network Policy
apiserver scheduler
controller-
manager
Etcd
kubelet
Calico/CNI
Calico/IPAM
Calico/Node Calico/Node
kube-proxy kube-proxy
Calico/CNI
Calico/IPAM
kubelet

15. Secure networking for the cloud-native era
Open source, maintained by Tigera with hundreds of
third party contributors
Batteries-included Container networking for Docker EE
Kubernetes
> Scalable, distributed control plane
> Policy-driven network security
> No overlay required
> Integratedwith all major cloud platforms
> Widely deployed, proven at scale
TIGERA CALICO: WHY IT’S AWESOME

16. Docker Enterprise Edition 2.0 + Calico
Architecture Overview

17. Node
UCP Manager
Manager Nodes
Load Balancer (ucp.example.com)
Node Node
Node
UCP
worker
Worker Nodes
Node
UCP
worker
Node
UCP
worker
Node
DTR worker
DTR Nodes
Load Balancer (dtr.example.com)
Node
DTR worker
Node
DTR worker
DTR Storage (Azure Storage, NFS, etc.)
Logging Monitoring
Image storage
External CALDAP/AD
Add-ons
UCP Manager UCP Manager
Docker Enterprise Edition Overview
Load Balancer (app.example.com)

18. UCP Manager/ K8s Master
Manager Nodes
Worker Nodes
Docker Enterprise Edition 2.0 Calico Integration
kubelet
k8s-apiserver
calico-node
Appl Pod A
kubelet
UCP / k8s Worker A
kube-proxy
kube-dns
k8s-scheduler
calico-node
kube-proxy
calico-node
App Pod B
kubelet kube-proxy
UCP / k8s Worker B
Pod IP Connectivity
Peering
Native Host Routing
calico-kube-controller
k8s-controller
eth0 eth0

19. UCP Manager/
K8s Master
Manager Nodes
Load Balancer (ucp.example.com)
Node
UCP/K8S
worker
Worker Nodes
Node
UCP/K8S
worker
Node
UCP/K8S
worker
UCP Manager/
K8s Master
UCP Manager/
K8s Master
Calico Node Calico Node Calico Node
Calico Node Calico NodeCalico Node
App Pods App Pods App Pods
Demo 1: Docker EE + Calico Overview

20. UCP Manager/
K8s Master
Manager Nodes
Load Balancer (ucp.example.com)
Node
UCP/K8S
worker
Worker Nodes
Node
UCP/K8S
worker
Node
UCP/K8S
worker
UCP Manager/
K8s Master
UCP Manager/
K8s Master
Calico Node Calico Node Calico Node
Calico Node Calico NodeCalico Node
Client Pod Frontend Pod Backend Pod
Node
UCP/K8S
worker
Node
UCP/K8S
worker
Calico Node Calico Node
NGINXNGINX
Demo 2: Let’s Deploy a Sample Application
Ingress Nodes
Client Service
UI Service
Frontend Service Backend Service

21. Let’s revisit our
Design Considerations.

22. Heterogeneous Infrastructure
➔No Underlay Dependency = No Lock-In
➔Simple Zero-Touch Provisioning
➔Any Infrastructure, Any Cloud
◆On-Prem ( VM, Bare)
◆Cloud ( AWS, Azure, GCP)
◆Hybrid

23. Connectivity Concept Out-of-the-Box Solution with Docker EE 2.0
Pod - Pod Calico CNI
Services ClusterIP
NodePort
LoadBalancer
Ingress NGINX Ingress Controller
DNS kube-dns
K8s Network Policy Calico
Diverse Application Portfolio
* Tigera CNX builds on Calico with enterprise security features: Hierarchical Policies, Policy RBAC, DevSecOps tools (Audit, Alerting, Compliance), etc.

24. Zero-Trust Security
•Declarative policy-driven isolation
•Fine-grained access control
•Dynamic, in lock step with Kubernetes
ComplianceStage/tier
separation
Tenant/namespace
isolation
Micro-
segmentation

25. Takeaway
Docker Enterprise Edition 2.0 seamlessly integrates Calico as
the default CNI providing choice of using native K8S
connectivity abstractions on any infrastructure all while
enforcing a dynamic policy-based microsegmentation.

26. Thank you! Questions?
Try Docker EE + Calico: trial.docker.com
community.docker.com
slack.projectcalico.org
@docker @projectcalico @tigeraio
