This "Deep Into Prometheus" talk is the second part of our Prometheus & Monitoring series that is heavily built on the content from the Part I "Dip into Prometheus" webinar. It's strongly recommended to watch the Part I recording first is you missed it: https://youtu.be/lvogDmRN-Hs In the "Deep Into Prometheus" meetup, I'm going deep into the Prometheus metrics data model. He will delve into how to design high-quality monitoring metrics and consume that data using PromQL while outlining how to avoid common "gotchas" while doing so.

1. Deep Into P8s

2. hello!
I am Zaar Hai
Staff Cloud Architect at DoiT International
linkedin.com/in/zaar
2

3. Missed Part I?
https://youtu.be/lvogDmRN-Hs
3

4. Let’s focus on Display & Alert
Instrument
Collect
&
Store
Display
&
Alert
4

5. Deep into Metrics
5

6. So we have metrics
2020-07-28T02:32:06Z
http_requests_total{code=200, process=A, path=/foo} 1107
http_requests_total{code=404, process=A, path=/foo} 12
http_requests_total{code=404, process=A, path=/bar} 120
http_requests_total{code=200, process=B, path=/foo} 1005
http_requests_total{code=404, process=B, path=/foo} 8
http_requests_total{code=200, process=B, path=/bar} 172
6
But there are different kinds of those

7. Meet GAUGE
✘ Represents data that can go up and down
✘ Example metrics:
➢ Temperature
➢ Memory usage
➢ Requests in progress
➢ Queue size
7

8. Meet GAUGE
✘ Represents data that can go up and down
✘ Example metrics:
➢ Temperature
➢ Memory usage
➢ Requests in progress
➢ Queue size
8
Better use
counters

9. Where gauges fail?
9
Server 1 : 2rps (avg)
Server 2: 10rps (avg)
Total: 6rps (avg)

10. Where gauges fail mislead
10
Server 1 : 2rps (avg)
Server 2: 10rps (avg)
Total: 6rps (avg)
Server 1 : 4 requests in 2 seconds
Server 2: 10 requests in 1 second
Total: (4+30) / (2+3) = 4.6rps

11. Meet COUNTER
✘ Can only go up
✘ Example: anything related to production / consumption:
➢ Request rate
➢ Error rate
➢ Latency
✘ We only care about deltas over time interval
11

12. Gauge vs Counter
12
✘ Goes up and down
✘ Usable raw values
✘ Non-cumulative*
✘ Goes only UP
✘ We care about Deltas
✘ Cumulative

13. Gauge vs Counter
13
✘ Goes up and down
✘ Usable raw values
✘ Non-cumulative*
✘ Goes only UP
✘ We care about Deltas
✘ Cumulative
Use Counters!

14. The looks of metrics
$ curl localhost:8081/metrics
# HELP process_open_fds Number of open file descriptors.
# TYPE process_open_fds gauge
process_open_fds 9.
# HELP jobs_processed_total Total jobs processed
# TYPE jobs_processed_total counter
jobs_processed_total{cluster="us-east",host="host_a"} 173.0
jobs_processed_total{cluster="us-east",host="host_b"} 203.0
jobs_processed_total{cluster="eu-west",host="host_c"} 190.0
jobs_processed_total{cluster="eu-west",host="host_d"} 169.0
14

15. Make use of Metrics
15

16. Data Viz in a Nutshell
Select Bucket Aggregate
16

17. From Numbers to Graph Dot
17
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
bar{}
1m 2m15s scrape
interval

18. From Numbers to Graph Dot
18
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
bar{}
Select

19. From Numbers to Graph Dot
19
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
bar{}
Select
Bucket

20. From Numbers to Graph Dot
20
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
bar{}
Select
Bucket
Aggregate

21. P8s Instant query
21
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query?time=t4
&query=foo
Instance
vector

22. P8s Instant query
22
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query?time=t4
&query=sum(foo)
sum
bar{}

23. P8s Instant query
23
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query?time=t4
&query=foo[1m]
Range
vector
bar{}

24. Range Instance
P8s Instant query
24
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query?time=t4
&query=avg_over_time(foo[1m])
avgavg
avg avg
bar{}

25. P8s Instant query
25
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query?time=t4
&query=sum(avg_over_time(foo[1m]))
Instance vector
sum
bar{}

26. P8s Range query - rinse/repeat
26
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
foo{t=a}
foo{t=b}
Select
GET /api/v1/query_range?start=t1
&end=t4
&step=60
query=sum(avg_over_time(foo[1m]))
sum sumavg avg
bar{}

27. Practice time
27

28. The looks of metrics
$ curl localhost:8081/metrics
# HELP jobs_in_progress Currently active jobs
# TYPE jobs_in_progress gauge
# HELP jobs_processed_total Total jobs processed
# TYPE jobs_processed_total counter
# HELP request_processing_seconds Time spent processing request
# TYPE request_processing_seconds summary
# HELP errors_total Total errors encountered
# TYPE errors_total counter
28

29. Hairy counters
29

30. Initialize to ZERO
30
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1 -
2 -
3 -
Increase[1m] = 0

31. Initialize to ZERO
31
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1 -
2 -
3 -
Increase[1m] ~= 1

32. Counter resets
32
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
Process restart

33. Counter resets
33
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
“Hoist”
rate() fixes reset “in flight”

34. Jumpy graphs
34
Graph jumps as “now” progresses
source

35. P8s, deltas, and fencing posts
35
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1m 2m15s scrape
interval
1 -
2 -
3 -

36. P8s, deltas, and fencing posts
36
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1m 2m15s scrape
interval
1 -
2 -
3 -
Increase[1m] = 0
Increase[1m] = 0

37. P8s, deltas, and fencing posts
37
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1m 2m15s scrape
interval
1 -
2 -
3 -
Increase[1m] = ?

38. P8s, deltas, and fencing posts
38
t2
t3
t5
t4
t6
t1
t7
t8
t9
t10
bar{}
1m 2m15s scrape
interval
1 -
2 -
3 -
Increase[1m] = 1 / 45 * 60 = 1.33
(over)
extrapolation

39. P8s, deltas, and fencing posts
39
✘ Solutions
➢ xrate fork: https://github.com/free/prometheus
➢ Victoria Metrics: https://github.com/VictoriaMetrics/VictoriaMetrics

40. thanks!
Any questions?
40
