1. Sanjivani Rural Education Society’s
Sanjivani College of Engineering, Kopargaon-423 603
(An Autonomous Institute, Affiliated to Savitribai Phule Pune University, Pune)
NACC ‘A’ Grade Accredited, ISO 9001:2015 Certified
Department of Computer Engineering
(NBA Accredited)
Prof. S.A.Shivarkar
Assistant Professor
Contact No.8275032712
Email- shivarkarsandipcomp@sanjivani.org.in
Subject- Data Mining and Warehousing (CO314)
Unit –II: Data Pre-Processing
2. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 2
Data Pre-processing
Introduction to Data Pre-processing, Data Cleaning: Missing
values,
Noisy data; Data integration: Correlation analysis; transformation:
Min-max normalization, z-score normalization and decimal
scaling;
Data reduction: Data Cube Aggregation, Attribute Subset
Selection,
Sampling; and Data Discretization: Binning, Histogram Analysis.
3. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 3
Data Quality
Today’s real-world databases are highly susceptible to noisy, missing, and inconsistent
data due to their typically huge size (often several gigabytes or more) and their likely
origin from multiple, heterogenous sources.
Low-quality data will lead to low-quality mining results.
“How can the data be preprocessed in order to help improve the quality of the data
and, consequently, of the mining results?
How can the data be preprocessed so as to improve the efficiency and ease of the
mining process?”
4. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 4
Why Data Pre-Prpocessing
Data in the Real World Is Dirty: Lots of potentially incorrect data, e.g., instrument faulty, human or
computer error, transmission error
incomplete: lacking attribute values, lacking certain attributes of interest, or containing only aggregate data
e.g., Occupation=“ ” (missing data)
noisy: containing noise, errors, or outliers
e.g., Salary=“−10” (an error)
inconsistent: containing discrepancies in codes or names, e.g.,
Age=“42”, Birthday=“03/07/2010”
Was rating “1, 2, 3”, now rating “A, B, C”
discrepancy between duplicate records
Intentional (e.g., disguised missing data)
Jan. 1 as everyone’s birthday?
5. Incomplete data may come from
“Not applicable” data value when collected
Different considerations between the time when the data was collected and when it is analyzed.
Human/hardware/software problems
Noisy data (incorrect values) may come from
Faulty data collection instruments Human or computer error at data entry Errors in data transmission
Inconsistent data may come from
Different data sources
Functional dependency violation (e.g., modify some linked data)
Duplicate records also need data cleaning
5
Why Is Data Dirty?
6. 6
Why Is Data Preprocessing Important?
“No quality data, no quality mining results!”
Quality decisions must be based on quality data
•e.g., duplicate or missing data may cause incorrect or even misleading
statistics.
Data warehouse needs consistent integration of quality data Data
extraction, cleaning, and transformation comprises the majority of the
work of building a data warehouse
7. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 7
Data Pre-Prepocessing
There are several data preprocessing techniques:
1. Data cleaning can be applied to remove noise and correct inconsistencies in data. Data
integration merges data from multiple sources into a coherent data store such as a data
warehouse.
2. Data reduction can reduce data size by, for instance, aggregating, eliminating redundant
features, or clustering.
3. Data transformations (e.g., normalization) may be applied, where data are scaled to fall within a
smaller range like 0.0 to 1.0. This can improve the accuracy and efficiency of mining algorithms
involving distance measurements.
These techniques are not mutually exclusive; they may work together. For example, data
cleaning can involve transformations to correct wrong data, such as by transforming all entries
for a date field to a common format.
8. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 8
Data Quality: Why Preprocess the Data?
Measures for data quality: A multidimensional view
Accuracy: correct or wrong, accurate or not
Completeness: not recorded, unavailable, …
Consistency: some modified but some not, dangling, …
Timeliness: timely update?
Believability: how trustable the data are correct?
Interpretability: how easily the data can be understood?
9. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 9
Data Quality: Why Preprocess the Data?
Measures for data quality: A multidimensional view
Accuracy: correct or wrong, accurate or not
Completeness: not recorded, unavailable, …
Consistency: some modified but some not, dangling, …
Timeliness: timely update?
Believability: how trustable the data are correct?
Interpretability: how easily the data can be understood?
10. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 10
Major Tasks in Data Preprocessing?
Data cleaning
Fill in missing values, smooth noisy data, identify or remove outliers, and resolve
inconsistencies
Data integration
Integration of multiple databases, data cubes, or files
Data reduction
Dimensionality reduction
Numerosity reduction
Data compression
Data transformation and data discretization
Normalization
Concept hierarchy generation
11. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 11
Major Tasks in Data Preprocessing?
Data cleaning
Fill in missing values, smooth noisy data, identify or remove outliers, and resolve
inconsistencies
Data integration
Integration of multiple databases, data cubes, or files
Data transformation
Normalization and aggregation
Data reduction
Obtains reduced representation in volume but produces the same or similar analytical results
Data discretization
Part of data reduction but with particular importance, especially for numerical data
12. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 12
Major Tasks in Data Preprocessing?
13. 13
Incomplete (Missing) Data
Data is not always available
E.g., many tuples have no recorded value for several attributes, such as customer income
in sales data
Missing data may be due to
equipment malfunction
inconsistent with other recorded data and thus deleted
data not entered due to misunderstanding
certain data may not be considered important at the time of entry
not register history or changes of the data
Missing data may need to be inferred
14. 14
How to Handle Missing Data?
Ignore the tuple: usually done when class label is missing (when doing
classification)—not effective when the % of missing values per attribute varies
considerably
Fill in the missing value manually: tedious + infeasible?
Fill in it automatically with
a global constant : e.g., “unknown”, a new class?!
the attribute mean
the attribute mean for all samples belonging to the same class: smarter
the most probable value: inference-based such as Bayesian formula or decision tree
15. 15
Noisy Data
Noise: random error or variance in a measured variable
Incorrect attribute values may be due to
faulty data collection instruments
data entry problems
data transmission problems
technology limitation
inconsistency in naming convention
Other data problems which require data cleaning
duplicate records
incomplete data
inconsistent data
16. 16
How to Handle Noisy Data?
Binning
first sort data and partition into (equal-frequency) bins then one can smooth by
bin means, smooth by bin median, smooth by bin boundaries, etc.
Regression
smooth by fitting the data into regression functions
Clustering
detect and remove outliers
Combined computer and human inspection
detect suspicious values and check by human (e.g., deal with possible outliers)
17. 17
Simple Discretization Methods: Binning
Equal-width (distance) partitioning
Divides the range into N intervals of equal size: uniform grid
if A and B are the lowest and highest values of the attribute, the width of intervals will be:
W = (B –A)/N.
The most straightforward, but outliers may dominate presentation Skewed data is not handled well
Equal-depth (frequency) partitioning
Divides the range into N intervals, each containing approximately same number of samples
Good data scaling
Managing categorical attributes can be tricky
18. 18
Simple Discretization Methods: Binning cont…
Equal-width (distance) partitioning
Sorted data for price (in dollars): 4, 8, 9, 15, 21, 21, 24, 25, 26, 28, 29, 34
Partition into equal-frequency (equi-depth) bins:
- Bin 1: 4, 8, 9, 15
- Bin 2: 21, 21, 24, 25
- Bin 3: 26, 28, 29, 34
Smoothing by bin means:
- Bin 1: 9, 9, 9, 9
- Bin 2: 23, 23, 23, 23
- Bin 3: 29, 29, 29, 29
Smoothing by bin boundaries:
- Bin 1: 4, 4, 4, 15
- Bin 2: 21, 21, 25, 25
- Bin 3: 26, 26, 26, 34
21. Correlation Analysis (Numerical Data)
Correlation coefficient (also called ) Pearson’s product moment coefficient)
n σA and σB n σA and σB
( A A')( B B')
( AB ) n AB
rA,B
where n is the number of tuples,
Where
n is the number of tuples
A’ and B’ are the respective means of A and B
σAand σB are the respective standard deviation of A and B
Σ(AB) is the sum of the AB cross-product.
If rA,B > 0, A and B are positively correlated (A’s values increase as B’s).
The higher, the stronger correlation.
rA,B = 0: independent;
rA,B < 0: negatively correlated
September 6, 2016 Data Mining: Concepts and Techniques 21
22. Correlation Analysis (Categorical Data)
• Χ2 (chi-square) test
2
(Observed Expected )2
Expected
• The larger the Χ2 value, the more likely the variables are related
• The cells that contribute the most to the Χ2 value are those
whose actual count is very different from the expected count
• Correlation does not imply causality
– # of hospitals and # of car-theft in a city are correlated
– Both are causally linked to the third variable: population
23. Chi-Square Calculation: An Example
Play chess Not play chess Sum (row)
Like science fiction 250(90) 200(360) 450
Not like science fiction 50(210) 1000(840) 1050
Sum(col.) 300 1200 1500
• Χ2 (chi-square) calculation (numbers in parenthesis are expected
counts calculated based on the data distribution in the two
categories)
• It shows that like_science_fiction and play_chess are correlated
• in the group
507.93
September 6, 2016 Data Mining: Concepts and Techniques 23
2
(250 90)2
(50 210)2
(200 360)2
(1000 840)2
90 210 360 840
25. Cluster Analysis
• It shows that like_science_fiction and play_chess are correlated
in the group
507.93
25
26. Data integration
507.93
26
Data integration:
Combines data from multiple sources into a coherent store
Schema integration: e.g., A.cust-id B.cust-#
Integrate metadata from different sources
Entity identification problem:
Identify real world entities from multiple data sources, e.g., Bill Clinton = William Clinton
Detecting and resolving data value conflicts
For the same real world entity, attribute values from different sources are different
Possible reasons: different representations, different scales, e.g., metric vs. British units
27. Handling Redundancy in Data Integration
Redundant data occur often when integration of multiple databases
Object identification: The same attribute or object may have different names
in different databases
Derivable data: One attribute may be a “derived” attribute in another table, e.g.,
annual revenue
Redundant attributes may be able to be detected by
correlation analysis
Careful integration of the data from multiple sources may help reduce/avoid
redundancies and inconsistencies
28. Data Transformation
38
Smoothing: remove noise from data
Aggregation: summarization, data cube construction Generalization:
concept hierarchy climbing
Normalization: scaled to fall within a small, specified range
min-max normalization
z-score normalization
normalization by decimal scaling
Attribute/feature construction
New attributes constructed from the given ones
29. Data Transformation: Normalization
Then $73,000 is mapped to
98,00012,000
(new_ maxA new_ minA) new_ minA
v'
A
– Ex. Let μ = 54,000, σ = 16,000. Then
• Normalization by decimal scaling
v' Where j is the smallest integer such that Max(|ν’|) < 1
16,000
Min-max normalization: to [new_minA, new_maxA]
Ex. Let income range $12,000 to $98,000 normalized to [0.0, 1.0]. Then $73,000 is
mapped to
Z-score normalization (μ: mean, σ: standard deviation):
Ex. Let μ = 54,000, σ = 16,000. Then
Normalization by decimal scaling
A
A
A
A
A
A
min
new
min
new
max
new
min
max
min
v
v _
)
_
_
(
'
A
A
v
v
'
j
v
v
10
' Where j is the smallest integer such that Max(|ν’|) < 1
716
.
0
0
)
0
0
.
1
(
000
,
12
000
,
98
000
,
12
600
,
73
225
.
1
000
,
16
000
,
54
600
,
73
30. E.g.
Name Salary Experience in years Position
X1 100000 10 2
X2 78000 7 4
X3 32000 5 8
X4 55000 6 7
X5 92000 8 3
X6 120000 15 1
X7 65750 7 5
Data Transformation: Normalization
31. Example of Decision Tree Induction
Initial attribute set:
{A1, A2, A3, A4, A5, A6}
A4 ?
A1? A6?
Class 1 Class 2 Class 1 Class 2
>
>
Reduced attribute set: {A1, A4,A6}
33. Divide data into buckets and store
average (sum) for each bucket
Partitioning rules:
Data Reduction: Histograms Analysis
4
0
3
5
represents)
0
1
0
Equal-width: equal bucket range Equal-
frequency (or equal-depth)
V-optimal: with the least histogram variance
(weighted sum of the original values that each
bucket represents)
MaxDiff: set bucket boundary between each
pair for pairs the β–1 largest differences
1
0
0
0
0
3
3
3
0
0
0
0 5
0
0
0
0 7
0
0
0
0 9
0
0
0
0
34. DEPARTMENT OF COMPUTER ENGINEERING, Sanjivani COE, Kopargaon 34
Reference
Han, Jiawei Kamber, Micheline Pei and Jian, “Data Mining: Concepts and
Techniques”,Elsevier Publishers, ISBN:9780123814791, 9780123814807.
https://onlinecourses.nptel.ac.in/noc24_cs22
