solar wireless vehicle charging Solar EVSE, such as the equipment procured for the VA, is 100% renewable. These types of charging stations can supplement or create charging hubs at sites that may not have existing electrical capacity. A car would only be able to travel one to three miles for every hour it was charged with solar electricity. This means that for a 300-mile-range electric car, it would take around 90 hours of direct sunshine to fully charge the battery. For many automobiles, this is impracticable.

2. Solar Wireless
Electric Vehicle
Charging System

3. SVSMD’S
SHRI. VATVRUKSHA SWAMI MAHARAJ DEVASTHAN’S
KAI. KALYANRAO (BALASAHEB) INGALE
POLYTECHNIC, AKKALKOT.
-:Team Members:-
Mr. Kumbhar P.P. Enroll No.2012050074
Mr. Ingale P.R. Enroll No.2012050072
Mr. Rathod S.S. Enroll No.2012050065
Ms. Afjalpurkar A.P. Enroll No.2012050059
Under the guidance of,
(Mr. Desai P.B.)
E&TC Department

4. Introduction of our Project
 improve charging station
efficiency
 We investigated the portable
EV charger by reducing
charging time with renewable
energy
 For charging electric vehicles,
the wireless EV charger is the
ideal alternative.

6. Block diagram

7. Hardware Specifications
• ATMEGA Controller
• Battery
• Voltage Sensor
• LCD Display
• Transformer
• Regulator Circuitry
• Transmitter and Receiver Coils
• Vehicle Body
• Wheels
• Switches
• LED’s
• PCB Board
• Resistors
• Capacitors
• Transistors
• Cables and Connectors
• Solar Panel
Software Specifications
• Keil µVision IDE
• MC Programming Language: C
HARDWARE & SOFTWARE REQUIREMENTS

8. Solar Panel Arduino Uno 12V Battery Voltage Sensor
LCD Display 16x2 Transformer Regulator Circuit Coils
Vehicle Body LED’s PCB Board Active & Passive Components Connecting Wires

9. Structure of our Project

10.  Keil Micro Vision software is an integrated
development environment (IDE), which
integrated a text editor to write programs, a
compiler and it will convert your source code
to hex files too.
 Keil development tools for the STM
Microcontroller Architecture support every
level of software developer from the
professional applications engineer to the
student just learning about embedded
software development.
Programming
 We are using embedded C programing
language for programming in
KEIL μVision software

11. Advantages of Electric Vehicle
 Wireless charging of vehicles without any wires
 No external power supply is needed
 Coils integrated into the parking to avoid wear and
tear.
 No fuel required.
 Environmental friendly as they do not emit
pollutants.
 Lower maintenance due to an efficient electric
motor.
 Better Performance.
Disadvantages of Electric Vehicle
 Long charging time – 1-3 hours required for
charging

12. Comparision of Non-EV & EV
# Non Electric Vehicle # Electric Vehicle
Air Pollution.
It run on diesel
Costly.
 No Air Pollution.
 It run on electric battery.
 Less than non electric vehicle.
