The document discusses several rotogravure printing machines made by GrafFlex and Rotoflex. The machines use modular construction and feature integrated trolley systems that allow for quick job changeovers. Printing speeds range from 200 to 400 meters per minute. The machines can print flexible packaging materials and use unwind and rewind systems along with controls for automatic web tension, register, and speed.

1. ROTOGRAVURE
PRINTING MACHINE

2. ROTOGRAVURE
PRINTING MACHINE (GRAFLEX)

3. A multi-station Rotogravure Printing Machine, with print cylinder
cartridge & flying splice turret unwind, rewind facilities is for the
purpose of printing flexible packaging materials.
-Modular Construction
GRAFLEX is a modular construction machine.Unique feature of
this machine is the special trolley system which contain the ink
tray along with ink circulation system, Doctor blade assembly &
cylinder carrying arrangement, which makes the job change
over matter of minutes.
Seven AC motor integrated digital drive and PC/panel view
controls, Automatic Web Video & Register Control System,
speed upto 350 mtr/min.

4. ROTOGRAVURE ULTIMA
PRINTING MACHINE

5. ROTOFLEX ULTIMA is modular construction machine. Unique
feature of this machine is the special trolley system which
contains the printing cylinder, Ink-tray along with ink-circulation
system, sleeve type impression etc. which makes the job
change over a matter of minutes, speed upto 400 mtr/min.

6. ROTOGRAVURE
PRINTING MACHINE (EXCEL)

7. A multi-station Rotogravure Printing Machine, with excellent
trolley attachment, flying splice turret unwind & rewind facilities,
for the purpose of printing flexible packaging materials.
-Modular Construction
ROTOFLEX EXCEL is a modular construction. Unique feature of this
machine is the special trolley system which contains the ink tray
along with ink circulation & ink applicator system, which makes
the job change over a matter of minutes.
Seven AC motor integrated digital drive and PC/panel view
controls, Automatic Web Video & Register Control System, speed
upto 300 mtr/min.

8. ROTOGRAVURE PRINTING
MACHINE UPRESS (ELS)

9. A multi-station Rotogravure Printing Machine with electronic line
shaft, excellent trolley attachment, Turret unwind and rewind
with auto flying splice facilities, for the purpose of printing flexible
packaging materials
-Modular Construction
ROTOFLEX UPRESS is modular construction machine. Unique
feature of this machine is the special trolley system which
contains the printing cylinder, Ink-tray along with ink-circulation
system, sleeve type impression etc. which makes the job change
over a matter of minutes, speed upto 350 mtr/min.

10. ROTOGRAVURE PRINTING
MACHINE (SUPER)

11. ROTOFLEX SUPER is modular construction machine. Each printing
station is a complete entity by itself. Therefore a station or two
can always be added even at a later stage provided that the
main drive power rating is taken care of right in the beginning.
A printing cylinder can be loaded/unloaded on each print
station through a unique shaftless, pneumatic chucking
arrangement. This technique not only save the changeover time
but also ensure the exact center-to-center locking.
The machine is equipped with seven AC motor integrated digital
drive and PC / panel view controls.
All the four tension zones are equipped with frictionless dance
feed back devices, which ensure very precise actual web
tension control.
The digital drive precision tension control, together with the
automatic length register control equipment and the web
viewing system ensure superb end result. These feature are the
ultimate as far as the gravure press automation is concerned.
Speed upto 300 mtr/min.

12. ROTOGRAVURE PRINTING MACHINE
STANDARD ( ELS)

13. The Machine is equipped with the following :-
Turret Un-wind and Re-wind using air expandable shafts with
auto splicing arrangement.
Integrated Trolley equipped with printing cylinder , Ink
circulation system, etc
Our unique Impression roller design for very- very easy change
over of rubber rollers.
Individual chill roller in each station.
Independent Asynchronous Servo Motors with motion control
drives on each printing station.
Dedicated ARC for user friendly operations and MIS control.

14. ROTOGRAVURE PRINTING
MACHINE (STANDARD)

15. A multi-station Rotogravure Printing Machine, with simplex
unwind & rewind facilities, for the purpose of printing flexible
packaging materials
-Modular Construction
ROTOFLEX STANDARD is modular construction machine. Each
printing station is a complete entity by itself. Therefore a station
or two can always be added even at a later stage provided
that the main drive power rating is taken care of right in the
beginning.
Shafted/selfshaft chucking arrangements, AC motor
integrated digital drive., equipped with tension control device,
Automatic Web Video & Register Control System, speed upto
200 mtr/min
