19. In Context Pattern 1
• Image Based Placeholders allow you to
dynamically generate an image to use for
rendering in the editor.
• Easy to retrofit to your existing macros.
https://developer.atlassian.com/display/CONFDEV/Providing+an+Image+as+a+Macro+Placeholder+in+the+Editor
20. In Context Pattern 1
• Image Based Placeholders allow you to
dynamically generate an image to use for
rendering in the editor.
• Easy to retrofit to your existing macros.
https://developer.atlassian.com/display/CONFDEV/Providing+an+Image+as+a+Macro+Placeholder+in+the+Editor
21. In Context Pattern 2
Your macro augments or modifies the properties
of images.
22. In Context Pattern 2
Your macro augments or modifies the properties
of images.
Instead of using a macro, add this functionality to
the Image Property Dialog.
25. In Context Pattern 2
• Allows you to extend the Image Property
Dialog
• Use it when your macro modifies the
properties of images and you wish for
more seamless integration with the editor.
https://developer.atlassian.com/display/CONFDEV/Extending+the+Image+Properties+Dialog
27. In Context Pattern 3
Your macro generates a link when rendered.
Extend the Link Browser Dialog to add the
functionality here, instead of using a macro.
30. In Context Pattern 3
• Useful for complex links, or links that
require a lot of parameters.
• Useful for links that have some
administration setup
• Simplifies the user experience.
https://developer.atlassian.com/display/CONFDEV/Extending+the+Confluence+Insert+Link+Dialog
31. In Context Pattern 4
You would like to capture data a user pastes into
the Confluence editor, to better represent it.
32. In Context Pattern 4
You would like to capture data a user pastes into
the Confluence editor, to better represent it.
Extend the editor autoconvert to convert userpasted data into any editor content you like.
33. In Context Pattern 4
• Register a paste handler
• Can convert to images or arbitrary wiki
content, not just macros!
34. In Context Pattern 4
• Register a paste handler
• Can convert to images or arbitrary wiki
content, not just macros!
https://developer.atlassian.com/display/CONFDEV/Extending+Autoconvert
35. In Context Pattern
Use Case
Plugin
Point
Macro generates an image
Image Based
Placeholder
Macro modifies images
Extend the Image
Dialog
Macro create a link
Extend the Link
Dialog
Capture user-pasted
content
Extend
Autoconvert
More Info
https://developer.atlassian.com/display/CONFDEV/Providing+an+Image+as
+a+Macro+Placeholder+in+the+Editor
https://developer.atlassian.com/display/CONFDEV/Extending+the+Image
+Properties+Dialog
https://developer.atlassian.com/display/CONFDEV/Extending+the
+Confluence+Insert+Link+Dialog
https://developer.atlassian.com/display/CONFDEV/Extending+Autoconvert
37. You’re Too Big Pattern
Your macro has too many parameters, or you wish
to provide a custom user experience.
38. You’re Too Big Pattern
Your macro has too many parameters, or you wish
to provide a custom user experience.
Write a custom editor dialog for your macro.
42. You’re Too Big Pattern
Easy to do!
AJS.bind(“init.rte”, function() {
AJS.MacroBrowser.setMacroJsOverride(“myMacro”, {
opener: function(macro) {
// Dialog drawing code goes here...
}
}
}
43. You’re Too Big Pattern
• Use AJS.MacroBrowser.setMacroJsOverride
to override the editor functionality for a macro &
display your own dialog.
• Do this when you have too many parameters, or you
want a custom editor experience.
https://developer.atlassian.com/display/AUI/Dialog
44. You’re Too Big Pattern
• Use AJS.MacroBrowser.setMacroJsOverride
to override the editor functionality for a macro &
display your own dialog.
• Do this when you have too many parameters, or you
want a custom editor experience.
https://developer.atlassian.com/display/AUI/Dialog
55. The 90% Pattern 2
Your macro has many required parameters, trying
to cater to every eventuality.
56. The 90% Pattern 2
Your macro has many required parameters, trying
to cater to every eventuality.
Think about the parameters you’re making required!
58. The 90% Pattern 2
Think about required parameters!
• These will cause the macro edit dialog to
always be displayed
• Is the field actually required, or could you
set a sensible default for it?
• Using sensible defaults can lead to a
smoother user experience
63. Notification Pattern 1
You have configuration needed to be done by an
administrator.
Create an Administration Task Item so that admins
can track and complete the config.
65. Notification Pattern 1
Add a web-item to the
system.admin.tasks/general section
<web-item key="plugin-admin-task"
section="system.admin.tasks/general"
weight="150">
<label key="plugin.admin.task.title"/>
<description key="plugin.admin.task.description"/>
<link id="configure-mail">/admin/mail/viewmailservers.action</link>
<condition class="com.atlassian.examples.DefaultMailServerExistsCondition"
invert="true"/>
</web-item>
atlassian-plugin.xml
66. Notification Pattern 1
• Ensure your addon is correctly configured
by creating an administrator task for it
• Admin tasks display in the Confluence
Administration page.
• The can be checked off as completed by
administrators
https://developer.atlassian.com/display/CONFDEV/Creating+an+Admin+Task
67. Notification Pattern 2
You want to keep your users informed of what’s
new when they install your plugin.
68. Notification Pattern 2
You want to keep your users informed of what’s
new when they install your plugin.
Configure a post-install-url for your plugin.
71. Notification Pattern 2
• Specifies a page that appears after
installation, or update
• Keep administrators up to date with the
latest features of your addon
• Only appears when installed via Atlassian
Marketplace
https://developer.atlassian.com/display/UPM/Plugin+Metadata+Files+used+by+UPM+and+Marketplace
