1. Deploying and Monitoring Windows Azure Application Wely Lau (wely@ncs.com.sg) Microsoft MVP, Windows Azure Solutions Architect, NCS Blog : http://wely-lau.net

2. Microsoft Cloud Day Wely Lau Windows Azure MVP / Solutions Architect, NCS Pte Ltd Deploying and Monitoring Windows Azure Application Wely is the first Windows Azure MVP in Southeast Asia. In NCS, he focuses on Cloud Computing, specifically on Windows Azure Platform. Performing cloud consultancy, architecting cloud solution, designing cloud framework, and delivering cloud training are his day-to-day activities. This session learn how we can deploy application to Windows Azure ,install program on Windows Azure, and how do we monitor our application on Windows Azure.

3. Agenda Basic Concept Deploying Upgrading Monitoring Start-up Task Q & A

4. Understanding Packaging and Config Windows Azure Services are described by two important artifacts: Service Definition (*.csdef) Service Configuration (*.cscfg) Your code is zipped and packaged with definition (*.cspkg) Encrypted(Zipped(Code + *.csdef)) == *.cspkg Windows Azure consumes just (*.cspkg + *.cscfg)

5. Service Definition Contains metadata needed by the Windows Azure environment to understand the requirements of your application. Describes the shape of your Windows Azure Service Defines Roles, Ports, Certificates, Configuration Settings, Startup Tasks, IIS Configuration, and more… Can only be changed by upgrades or new deployments

6. Service Configuration Sets values for the configuration settings defined in the service definition file and specifies the number of instances to run for each role. Supplies Runtime Values (Scale, Config Settings, Certificates to use, VHD, etc.) Can be updated any time through Portal or API

7. Fault and Upgrade Domains Fault Domains Represent groups of resources anticipated to fail together i.e. Same rack, same server Fabric spreads instances across fault domains Default of 2 Upgrade Domains Represents groups of resources that will be upgraded together Specified by upgradeDomainCountin ServiceDefinition Default of 5 Fabric splits Upgrade Domains across Fault Domains and Across Roles

8. Fault and Upgrade Domains Visualized Fault Domain Fault Domain Rack Rack U/G Domain #1 U/G Domain #2 U/G Domain #1 U/G Domain #2 Web Role Web Role VM VM VM VM Worker Role Worker Role VM VM VM VM

9. Deployment Environments Two Environments to choose from Nearly Identical… <servicename>.cloudapp.net <deploymentID>.cloudapp.net VIP Swap between them

10. Agenda Basic Concept Deploying Upgrading Monitoring Start-up Task Q & A

11. Various Techniques Deploying to the Cloud Windows Azure Portal Visual Studio 2010 Windows Azure Service Management Cmdlets

14. Connect to your service account

15. Publish inside of VS2010

17. http://archive.msdn.microsoft.com/azurecmdlets

18. Wraps Management REST API and Diagnostics API

19. Enables building of sophisticated deployment scripts

21. Agenda Basic Concept Deploying Upgrading Monitoring Start-up Task Q & A

22. Upgrading Windows Azure Application Deployment Consideration Downtime tolerance VIP Address Cost Various options Delete & Recreate In Place Upgrade Web Deploy VIP Swap DNS Swap* Sometimes you MUST delete a deployment Changes in endpoints, VM size, and binding Try to minimize by specifying what you might need in advance

23. Delete & Recreate Down time between deployments You can change almost everything in your app 1 X your instance cost New VIP Hosted Service Deployment v2 Deployment v1 Web Role Web Role Worker Role Worker Role VM VM VM VM VM VM VM VM

24. In Place Upgrade Reuses existing VMs (Preserves VM state i.e. local cache data) Can update a single role 1 X your instance cost Cannot change the service definition size, endpoints, roles, etc. Utilizing Upgrade Domain to avoid downtime

25. In Place Upgrade Rack Rack Web Role Web Role Load Balancer: #1 #2 #1 #2 VM VM Prod VM VM Worker Role Worker Role VM VM VM VM

26. Web Deploy Newly built-in in SDK 1.4.1 Quickly push incremental changes Caveats: Only applicable for single instance web role Changes made will not be persistence Development and testing purpose, not production!

27. VIP swap Easier to undo Requires 2 identical environments Cannot update endpoints 2 X your instance cost Happen very fast Typically within 1 mins Hosted Service Deployment v1 Worker Role Web Role VM VM Load Balancer: VM VM Prod Prod Deployment v2 Stage Stage Web Role Worker Role VM VM VM VM

28. DNS Swap Use DNS as another layer of abstraction Requires your own domain name 2 X your instance cost Updating the domain record is not immediate New VIP DNS: whatever.com Hosted Service (foo.cloudapp.net) Hosted Service (bar.cloudapp.net) Deployment Deployment Web Role Worker Role Web Role Worker Role VM VM VM VM VM VM VM VM

29. Web Deploy VIP Swap demo

30. Agenda Basic Concept Deploying Upgrading Monitoring Start-up Task Q & A

32. Performance measurement

33. Troubleshooting and debugging

34. Capacity planning

35. Traffic analysis (users, views, peak times)

36. Billing & Auditing

37. Challenges in the Cloud

38. Many instances

39. Local storage is not persistence

40. They move around

41. Massive amount of data

42. Can’t remote desktop in

44. IIS Logs, Crash Dumps, FREB Logs

45. Arbitrary log files

46. Performance Counters

47. Event Logs

48. Debug/Trace statements

49. Infrastructure events

50. MonAgentHost.exe is started automatically by default.

51. Listener wired up in app/web.config

53. Diagnostic Monitor Starts

54. Monitor is configured

55. Imperatively at Start time

56. Remotely any time

57. Monitor buffers data locally

58. User can set a quota (FIFO)

59. User initiates transfer to storage

60. Scheduled or On Demand

61. Where to store?Role Local directory storage Diagnostic Monitor

62. Sample Results

63. Visualizing the data

64. Diagnostics Considerations Volume of Data Storage Standard costs apply for transactions, storage & bandwidth Reaction Time $ Cost Monitoring 5 Performance Counters every 5 seconds for 100 instances costs > $260 US dollar per month

65. Remote Desktop

66. Remote Desktop Role 2 Role 1 IN_0 IN_0 IN_1 Port 3389 LB IN_1 IN_2 Remote Forwarder Internal Port 3389

67. Remote Desktop to Windows Azure Installing Program on Windows Azure demo

68. Agenda Basic Concept Deploying Upgrading Monitoring Start-up Task Q & A

70. Scenarios: Perform short, unattended setups on role startup. E.g.

71. COM Component

72. Registry Key

73. Configuring a Windows Server Role, such as IIS

74. Installation Startup.cmd start /w pkgmgr /iu:IIS-ASP REG ADD "HKEY_LOCAL_MACHINEOFTWAREicrosoftctive Setupnstalled ComponentsA509B1A7-37EF-4b3f-8CFC-}" /v "IsInstalled" /t REG_DWORD /d 0 /f winrar-x64-40b7.exe /s

76. Background – System does not wait for the task to exit

79. http://msdn.microsoft.com/en-us/wazplatformtrainingcourse.aspx

80. Building, deploying, and managing Windows Azure Applications

81. http://channel9.msdn.com/Events/PDC/PDC10/CS03

82. Deploying, Troubleshooting, Managing and Monitoring Applications on Windows Azure

83. http://www.msteched.com/2010/Europe/COS324

84. Windows Azure CmdLet

85. http://archive.msdn.microsoft.com/azurecmdlets

86. Remote Desktop to Windows Azure

87. http://tinyurl.com/azure-remote-desktop

88. Custom Domain Name in Windows Azure

90. Thank you! Wely Lau (wely@ncs.com.sg) Microsoft MVP, Windows Azure Solutions Architect, NCS Blog : http://wely-lau.net
