12. 12TABS CRITERIA
Choosing an Accessible UI Framework
FOCUS INDICATION
ARIA
KEYBOARD INTERACTION
COLOR CONTRAST
13. 13TABS KEYBOARD INTERACTION
Choosing an Accessible UI Framework
LEFT/ UP FOR PREVIOUS TAB
ARROW KEYS SHOULD CYCLE
TAB KEY FOCUSES ACTIVE TAB
RIGHT/ DOWN FOR NEXT TAB
20. 20FORMS SOLUTION
Choosing an Accessible UI Framework
GROUP RELATED FIELDS WITH
FIELDSET/ LEGEND
EXPLICITLY ASSOCIATE LABELS
WITH INPUTS
CONVEY ERROR STATE AND
DESCRIPTION
24. 23TABS SOLUTION
Choosing an Accessible UI Framework
LEFT/ UP FOR PREVIOUS TAB
ARROW KEYS SHOULD CYCLE
TAB KEY FOCUSES ACTIVE TAB
RIGHT/ DOWN FOR NEXT TAB
27. 27DIALOG SOLUTION
Choosing an Accessible UI Framework
FOCUS SHOULD RETURN TO TRIGGER
CYCLE FOCUS WITHIN DIALOG
ROLE=“DIALOG”, ARIA-HIDDEN,
ARIA-DESCRIBEDBY
How many of you are are actively looking for a framework?
How many of you didn’t make it to Karl Groves and Billy Gregory’s presentation?
How many of you didn’t know Karl Groves and Billy Gregory were presenting at this same time?
I will turn around and count to 10, if you want to leave I will not count it against you…
For those of you here, thank you. You could have chosen to sleep in, or any other presentation, but I am glad you are here.
INTRODUCTIONS
Evaluating UI frameworks and libraries for your latest web development project is no easy task.
Each decision maker has their own set of criteria based on their past experience and overall project or task at hand.
Some common criteria factors are:
ease of use, architecture, opinionated vs non-opinionated, customization, large community, open source, popularity, visual design, 3rd party modules, file size, MV* patterns, etc. Though determining this criteria is not covered in this discussion you need to ask yourself: Where does accessibility rank on your list of things to evaluate?
Using one of these UI frameworks and libraries for your web project makes for rapid and easy development, so picking the right framework or library for your next web development project can have a serious impact on your ability to deliver on time and ensure future maintainability.
Unfortunately, the speed and ease at which these frameworks allow you to develop often means that accessibility can easily be overlooked and taken for granted.
NEXT SLIDE: How do you know the one you choose is accessible?
How? We will go over some basic checks, a starting off point, on what to look for.
It is not my intention to bash any of these frameworks. Building a framework is hard and takes a lot of work.
I am extremely appreciative of these frameworks for the time and effort they have put in in order to make the development of my projects easier.
Does the framework document a11y intentions?
Do code examples exhibit a11y best practices?
Proper labels/ descriptions: Is semantic meaning being conveyed?
Keyboard navigation: Can a user perform tasks without the use of a mouse? Is focus indication defined, can a user know where they are at all times?
Color Contrast: Is the CSS styles of each framework/ theme good for low-vision users? Minimum 4.5:1
If ARIA is needed, are the right roles, states, and properties being used?
We will be using WAI-ARIA 1.0 Authoring Practices as our guide for widgets, i.e tab and dialog.
Google Chrome Accessibility Developer Tools for inspection
Google ChromeVox as screenreader
Angular Doc:
ngAria with code examples (aria-checked not updated?)
Common a11y patterns
Additional Resources
Good info!
Bootstrap Doc
Foundation Doc
Copied from Bootstrap?
JQM Doc:
Slim, mentions accessibly hiding menus
Forms are everywhere!
Extremely easy to get right, extremely easy to get wrong!
Just good, semantic form markup!
Error validation is usually customized, so some aria will be needed.
Visit Angular FORMS
Test keyboard and focus indication
Test via chrome a11y tools, check label associations, check color contrast of validation
ChromeVOX: CONTROL + COMMAND + A + A
Check if error state is always read out loud
Bootstrap forms
Note about using labels for accessibility, Good documentation for a11y
Forms are CSS only, meaning validation state should be handled manually via JS. No grouping, except for disabled groups of fields
Foundation Forms
"Note about labels and accessibility
switches and range use custom elements, switches require strange, markup”
Focus indication does not pass color contrast
No grouping
JQM
Passed all except color contrast for default (blue/ white theme)
Uses native form elements ensuring accessibility will always be supported even though highly stylized
A “tabbed” interface that allows dynamic switching of content
Tab to tabs
Arrow keys?
Focus indicaition
Use a11y dev tools to check aria-roles
Additional key combinations, CTRL + UP/ PAGE UP/DOWN are mentioned but might conflict with browser interactions, ie switching browser tabs.
They are also somewhat Windows keyboard-centric
List of tabs has a role=“tablist”
Tabs have role=“tab”, property aria-controls with id of of content, and communicate selected state via aria-selected
Content containers have role=“tabpanel”
Visit Bootsrap tabs
focus indication and color contrast is good
Keyboard nav is not there
Aria is ok
Check with chromevox CONTROL + COMMAND + A + A
Angular Tabs
No focus indication on selected item
Tab to control and left/ right arrows ok
Not cyclical, no up/down. Navigation does not activate tab, must press enter
Aria is ok
JQM: PERFECT! Keyboard nav, color contrast, aria all perfect
Foundation:
No focus indication makes keyboard nav useless
Tab to control and left/ right arrows ok
Not cyclical, no up/down. Navigation does not activate tab, must press enter
Aria is ok
Overlay that either prompts user for a response or presents additional information
Initial focus should go to either the first focusable element or the dialog container
TAB/ SHIFT-TAB should cycle through focusable elements, never leaving the panel
ESC should close the panel and return focus to the triggering element
ENTER should submit form, if available but care is needed if other elements inside the dialog use ENTER.
Role=dialog
Simple dialogs like alerts/ confirmations should use role=“alertdialog”
Dialog is labelled by either aria-label or aria-labelledby
Additional aria seen later for better use
Foundation Dialog
Docs already note this is not accessible
Tab not restricted to panel
Focus does not return to trigger
Esc and click outside does close dialog
Invalid markup, no aria
Check with Chromevox
Angular Dialog
Focus indication ok, keyboard , Tab not restricted to panel
Focus does not return to trigger
Esc and click outside does close dialog
JQM: Good aria, tab not restriced to keyboard, focus not on trigger, esc and click outside to close
Bootstrap: Tabs restricted, but there is shift-tab keyboard trap. Escape closes dialog
So now we see that there are some things lacking in order to make the use of frameworks in our application more accessible.
What are some of the things we can do?
Again, forms are extremely easy to get right, and just as easy to get wrong.
AFTER, show Angular FORM Code
Add fieldset
Explicitly associated labels with inputs
Used fieldset with visually hidden css
Color contrast of error messages changed
Uses live-region to express error messages, but aria-descibedby might better in addition
Just add js after after bootstrap
Add ARIA roles like tablist, presentation, and tab for tabs UL, LI.
Add tabIndex, aria-expanded, aria-selected, aria-controls for tab.
Add ARIA roles of tabPanel, tabIndex, aria-hidden, and aria-labelledBy for tabPanel.
Add keydown event listener for the tab to work with keyboard.
Dynamically flip tabIndex, aria-selected, and aria-expanded for tab when it is activated and add aria-hidden to hide the previously visible tab.
Wrap body content in container in order to maintain aria-hidden when panel is open
Role=“dialog”
Aria-describedby=“dialog-title”
Aria-hidden
Tabindex=0
Move close trigger to logical order, after title
Change close trigger to button
Close trigger being read as “multiplication”. Add aria-hidden and visually hidden text “close dialog”
Focus close button upon opening
Focus trigger upon closing
Show code for tab cycle
Angular – Marcy Sutton: undoubtedly biased, but Angular Material has some of the best accessibility support around for being a new framework.
Angular 1.x had ngAria as a module, Angular 2.0 will essentially have ngAria built-in.
Material Design won’t release components until a11y is built-in.
Material Design enforces text alternatives via warnings in the console.
Even better, a11y plugin for Protractor (e2e testing for Angular) that uses either Chrome Accessibility Developer Tools or Tenon.io by Karl Groves.
Foundation – Brandon, Foundation Lead – Rafi, Customer Advocate:
Next version of Foundation for web, v6, is being built from the ground up with a11y as a focus.
No component will make build unless it passes a11y.
Fixing docs, keyboard, and color contrast
Bootstrap - Patrick Lauke
V4 is a complete overhaul, with simplification and refactoring of most existing CSS/JS components
Working hard trying to get Paypal a11y plugin back in
Patrick will be overseeing/ triaging all new features/ pull requests
Mostly volunteer basis
This is it. We looked at some popular frameworks, some common interactions and patterns, used a basic checklist to evaluate and came up with some solutions.
So what did we learn?
Frameworks are hard to get completely accessible, implementations can vary.
Ultimately, you need to do what is best for your users. Frameworks should give you the proper tools to do so.
Share the knowledge, be an advocate.
All the frameworks I tallked to said they greatly welcome any contributions/ pull requests to help with a11y. Open source is a community effort.
