Case Study For Data Governance Portal
1. Case Study For Data
Governance Portal
Brainvire Infotech Pvt. Ltd
www.brainvire.com
http://www.brainvire.com
2. Client Requirement
http://www.brainvire.com
The website is the Data Governance intranet portal
Data Governance is the practice of bringing clarity around data
and ensuring
Central Tool Supporting the Data Governance Department
Catalogue that holds those data items
Allows all Involved to search the catalogue and browse
Portal also supports the department in processing changes to
data in a controlled and transparent manner
3. http://www.brainvire.com
Client’s Specific Requirements
Portal is centric to Catalogues
Provide visibility around what data is being governed
list all data items under governance
For each data set under governance, a number of information
elements will be captured
There are components, governance roles, quality measures,
access rights, governance type, quality reports, documents and
privacy defined
4. For each catalogue, there are components defined
Defined as primary components, mandatory components or normal
components
Item may create relationship with other catalogue components
Members can view or download data from the portal
Members can subscribe to public catalogue items as an email
Subscribing parties get update of new changes or addition of data
http://www.brainvire.com
5. http://www.brainvire.com
Project Challenges
Data in a Controlled and Transparent manner
Scalability is a key consideration
Site Labels and Static Contents in Desired Language
Ensuring more complex relation between the data and its consistency
Creating versions and reverting version
Transforming and Distributing data
6. Technologies Used
http://www.brainvire.com
Operating System &
Server Management
PHP (Server-side Language) A suitable managed code development
environment for handling the extensive
project.
Red hat Linux Sturdy and stable operating system with high
level functionalities for online development.
MySQL Engine Versatile, low-maintenance database
management system. Cross-platform
compatible database component of the
LAMP platform.
Microsoft Visio Integrated tool best suited for modular
architecture and iterative development of
software.
Zend Studio Versatile web development tool with
exhaustive support for CSS, JavaScript, and
various server-side scripting frameworks.
Subversion (SVN) Ideal application providing stratified storage
and back up of code files.
Symfony Framework Symfony is a full-stack framework, a library
of cohesive classes written in PHP.
8. Planning
http://www.brainvire.com
Database layer containing MySQL Server Database, Tables,
triggers and so on
Data Access layer containing the Data Access DLL responsible for
accessing data from database
Business Layer DLL consisting of all business logic procedures for
modules
Request, Challenges, Profile, Showcase, Offerings, Directories,
Fund, Circle etc
The User Interface Layer, which forms the Graphical User
Interface of the website
9. Architecture
http://www.brainvire.com
User Interface Layer: This will include the page level layer which will be
accessing the other layers beneath to present the data.
Business Specific Layer: This acts as a bridge between the User
Interface layer and database layer. This will contain all the business logic
for the different components involved in the project.
Database Specific Layer: This acts as a bridge between the physical
database and the business logic accessing the data.
Physical Database Layer: This includes My SQL with the tables, views
and stored procedures etc.
10. Development Highlights
http://www.brainvire.com
The design approach was built around PHP 5 and MySQL SERVER 5
User Profiles, company profile, offering, requests,challenge, events, fund
and circle were developed in PHP
Communicate with the relational databases in an object-oriented manner
An intermediary abstraction layer was created for accessing data from the
database
Triggers were used only for complex update and deletion of data
The UI layer was kept free of any business logic with images, applications
and data
Web usability guidelines were strictly followed during development
The site was developed and fully functional within a span of 3 months
