This document discusses Calico Docker+IPAM and provides examples of how to: 1. Create a Calico IP pool 2. Create a Docker network using the IP pool 3. Create a container using a specific IP address from the pool It also describes the 'calicoctl ipam release' command to release an IP address that was previously assigned to an endpoint.

1. Calico Docker+IPAM
Rajesh Kumar

2. 2
IPAM
Wit h t he r elease of Docker 1.10, suppor t has been
added t o allow user s t o select a specif ic I P
address when creat ing a cont ainer. I n or der t o use
t his f eat ure, Docker requir es t hat you specif y t he
- - subnet par amet er when running
docker network create.
Calico r equires t hat t he passed - - subnet value be
t he same CI DR as an exist ing Calico I P pool.

3. 3
Example
1. Creat e Calico I P pool
cat <<EOF | calicoct l creat e -f -
- apiVer sion: v1
kind: ipPool
met adat a:
cidr : 192.0.2.0/ 24
EOF

4. 4
Example
2. Creat e a Docker net wor k using t he I P pool
docker net work creat e --driver calico --ipam-
driver calico-ipam --subnet =192.0.2.0/ 24
my_net
3.Creat e a cont ainer using a specif ic I P
addr ess f r om t he pool
docker r un --net my_net --name my_workload
--ip 192.0.2.100 -t id busybox

5. 5
Example
4. Verif y t hat t he I P address was assigned t o t he
cont ainer
docker inspect -f ' {{range
.Net wor kSet t ings.Net works}}{{.I PAddr ess}}
{{end}}' my_wor kload

6. 6
calicoctl ipam commands
This command allows you t o release an I P address
t hat had been pr eviously assigned t o an endpoint .
When an I P addr ess is r eleased, it becomes
available f or assignment t o any endpoint .
Not e t hat t his does not r emove t he I P f r om any
exist ing endpoint s t hat may be using it , so we
gener ally recommend you use t his command t o
clean up addr esses f rom endpoint s t hat wer e not
cleanly removed f rom Calico.

7. 7
calicoctl ipam commands
This command can be r un on any Calico node.
Command synt ax:
calicoct l ipam r elease <I P>
<I P>: I P addr ess t o r elease.

8. 8
calicoctl ipam commands
Examples:
$ calicoct l ipam r elease 192.168.1.1
Addr ess successf ully released
$ calicoct l ipam r elease
f d80:24e2:f 998:72d6::1
Addr ess successf ully released
