Kubernetes at Datadog Scale - Ara Pulido
- 1. Kubernetes at Datadog scale Ara Pulido @arapulido
- 4. 17 major releases since 2015 +80k commits +2k contributors
- 5. Kubernetes popularity past 5 years
- 6. Kubernetes popularity past 5 years
- 7. Kubernetes v.s Mariah Carey
- 8. ● 2 years full time Kubernetes ● CKA; part of the team that created CKAD ● Writing apps for Kubernetes ● User of Kubernetes (15-25 nodes) ● Amateur youtuber (really!) https://dtdg.co/k8s_es My journey with Kubernetes
- 11. Dozens of clusters +1K nodes / cluster Multi-cloud
- 12. Survey: number of nodes / cluster Source: https://github.com/MagalixCorp/kubernetes-autoscale-survey
- 13. Let’s talk about the elephant in the room
- 15. POD NETWORKING DNS SERVICE NETWORKING Kubernetes networking 101
- 16. Pod 172.17.0.2 Pod 172.17.0.3 GET EVERY POD A UNIQUE IP MAKE SURE EVERY POD CAN TALK TO ANY OTHER POD IN THE CLUSTER Pod networking
- 17. Client 172.17.0.6 Pod 172.17.0.4 Pod 172.17.0.5 Service 10.107.122.52 kube-proxy Service networking
- 19. Pod networking
- 20. Pod 172.17.0.2 Pod 172.17.0.3 GET EVERY POD A UNIQUE IP MAKE SURE EVERY POD CAN TALK TO ANY OTHER POD IN THE CLUSTER
- 21. Pod 172.17.0.2 Pod 172.17.0.3 CNI Container Network Interface
- 23. Pod 10.244.2.1 10.244.1.0/24 10.244.0.0/16 10.244.2.0/24 10.244.0.0/16 cni0 flannel0 cni0 flannel0 Pod 10.244.1.1 Overlays (flannel, weavenet) I WAS HERE 192.168.0.1 192.168.0.2
- 25. 10.244.1.0/24 dev cni0 proto kernel scope link src 10.244.1.0 10.244.0.0/16 dev flannel proto kernel scope link src 10.244.1.1 Overlays Src: 192.168.0.1 Dst: 192.168.0.2 Src: 10.244.1.1 Dst: 10.244.2.1 Pod 10.244.2.1 10.244.1.0/24 10.244.0.0/16 10.244.2.0/24 10.244.0.0/16 cni0 flannel0 cni0 flannel0 Pod 10.244.1.1 192.168.0.1 192.168.0.2
- 26. Pod 10.244.162.131/32 10.244.143.129/32calixxxx calixxxx Pod 10.244.162.131 192.168.0.1 192.168.0.2 BGP BGP BGP (Calico) 10.244.143.129
- 27. 10.244.162.131 dev cali12d4a061371 scope link 10.244.143.129 via 192.168.0.2 dev eth0 Calico (BGP) 10.244.143.129 dev cali12d4bf881 scope link 10.244.162.131 via 192.168.0.1 dev eth0 Pod 10.244.162.131/32 10.244.143.129/32calixxxx calixxxx Pod 10.244.162.131 192.168.0.1 192.168.0.2 BGP BGP 10.244.143.129
- 28. Direct Pod Routing (EKS, Lyft) Pod 10.0.0.3 Pod 10.0.0.4 SDN
- 29. Direct Pod Routing (EKS, Lyft) Pod 10.0.0.3 Pod 10.0.0.4 SDN DATADOG
- 30. Direct Pod Routing (EKS, Lyft) Pod 10.0.0.3 Pod 10.0.0.4 SDN
- 31. Be ready to become an “expert” in the CNI plugin of your choice (yay!!)
- 34. Client 172.17.0.6 Pod 1 172.17.0.4 Pod 2 172.17.0.5 Iptables 10.107.122.52 kube-proxy API Watch svc, endpoints iptables mode (default)
- 35. Client 172.17.0.6 Pod 1 172.17.0.4 Pod 2 172.17.0.5 Iptables 10.107.122.52 kube-proxy API Watch svc, endpoints iptables mode (default) I WAS HERE
- 36. Client 172.17.0.6 Pod 1 172.17.0.4 Pod 2 172.17.0.5 Iptables 10.107.122.52 kube-proxy API Watch svc, endpoints iptables mode (default)
- 37. Chain KUBE-SERVICES (2 references) KUBE-SVC-4N57TFCL4MD7ZTDA tcp -- anywhere 10.107.122.52 /* default/nginx: cluster IP */ tcp dpt:www Chain KUBE-SVC-4N57TFCL4MD7ZTDA (1 references) target prot opt source destination KUBE-SEP-UZXILYFQQ2IZUWN5 all -- anywhere anywhere statistic mode random probability 0.50000000000 KUBE-SEP-43IWXJI557JKCKCF all -- anywhere anywhere Chain KUBE-SEP-43IWXJI557JKCKCF (1 references) target prot opt source destination KUBE-MARK-MASQ all -- 172.17.0.5 anywhere DNAT tcp -- anywhere anywhere tcp to:172.17.0.5:80 iptables mode (default)
- 38. GROWS LINEARLY WITH PODS AND SERVICES THERE IS NO ROOM FOR MORE FEATURES FOR EVERY CHANGE, THE WHOLE TABLE NEEDS TO BE RESYNC iptables mode (default)
- 39. IPVS mode GA SINCE 1.11
- 40. GA SINCE 1.11 IPVS mode DATADOG
- 41. ATOMIC CHANGES (NO NEED TO RESYNC EVERY RULE) O(1) COMPLEXITY DIFFERENT LOAD BALANCING ALGORITHMS (RR, LEAST CONN, etc.) ipvsadm -ln --tcp-service 10.107.122.52:80 Prot LocalAddress:Port Scheduler Flags -> RemoteAddress:Port Forward Weight ActiveConn InActConn TCP 10.107.122.52:80 rr -> 172.17.0.4:80 Masq 1 0 37 -> 172.17.0.5:80 Masq 1 0 44 GA SINCE 1.11 IPVS mode
- 42. Source: https://www.projectcalico.org/comparing-kube-proxy-modes-iptables-or-ipvs/ iptables v.s. IPVS
- 43. Source: https://www.projectcalico.org/comparing-kube-proxy-modes-iptables-or-ipvs/ iptables v.s. IPVS
- 44. Many large deployments are already moving to IPVS and newer solutions are being developed (eBPF based)
- 45. DNS
- 49. ` Client DNS Cache CoreDNS DNS Local Cache
- 50. ` Client DNS Cache CoreDNS DNS Local Cache DATADOG
- 51. ` Client DNS Cache CoreDNS DNS Local Cache
- 52. NodeLocal DNSCache is now part of Kubernetes (Beta 1.15)
- 53. Take aways
- 54. The bad
- 55. KUBERNETES IS FLEXIBLE FOR DEVS, STILL COMPLEX FOR OPS YOU WILL HIT BUGS CNI PLUGINS WORK *VERY* DIFFERENTLY. LEARN YOURS.
- 56. The good
- 57. THE ECOSYSTEM PICKS UP QUICKLY DEVELOPMENT EXPERIENCE DOESN’T CHANGE (MUCH) CHANGES DON’T HAVE TO HAPPEN FOR ALL WORKLOADS DIRECTLY
- 59. Thank you! Ara Pulido @arapulido WE ARE HIRING
