This document discusses using Nginx as a web server and content accelerator. It provides two examples of how to configure Nginx for acceleration. The first example shows configuring Nginx with PHP-FCGI to accelerate PHP content. The second example demonstrates configuring Nginx to proxy requests to an Apache server running PHP in the backend. Additional sections cover using Nginx as a cache, examples of caching configurations, and provisioning cache nodes across multiple servers.

1. 2012-10-25
Caché acelerador de contenido
Derechos reservados © 2012 Sandino Araico Sánchez
<sandino@1101.mx>
Se permite ilimitadamente el uso, copia, redistribución con o sin
modificaciones siempre y cuando se mantenga el aviso de
derecho de autor y se anoten al final de la presentación todas las
modificaciones que se llevan a cabo conservando la historia de
las modificaciones que hagan las demás personas e indicando la
fecha de cada modificación y el nombre de la persona que la
llevó a cabo.
Thursday, October 25, 2012

2. Netcraft web server survey
Fuente: netcraft.com
Thursday, October 25, 2012

3. Servidores de páginas
Apache
Nginx
Cherokee
Lighttpd
Tomcat
Thursday, October 25, 2012

4. Aceleración
Primer ejemplo
Nginx
Cherokee
php-fcgi
php-fpm
Thursday, October 25, 2012

5. Aceleración
Primer ejemplo
server {
listen 192.168.182.170:80;
server_name hhh.example.com example.com;
access_log /var/log/nginx/example/hhh.access.log main;
error_log /var/log/nginx/example/hhh.error.log;
root /var/www/example/hhh/public_html;
location / {
index index.php index.html;
if (!-e $request_filename) {
rewrite ^(.*)$ /index.php?q=$1 last;
break;
}
}
location ^~ ^/nota/ {
rewrite ^(.*)$ /index.php?q=$1 last;
break;
}
Thursday, October 25, 2012

6. Aceleración
Primer ejemplo
location ~* ^.+.(jpg|jpeg|gif|png|ico|js|css)$ {
#access_log off;
expires 30d;
}
location ~ "^/([0-9]+)$" {
rewrite ^/([0-9]+)$ /index.php?q=/node/$1 last;
}
location ~ .php$ {
fastcgi_pass 127.0.218.170:8000;
fastcgi_index index.php;
fastcgi_read_timeout 300;
fastcgi_param SCRIPT_FILENAME /var/www/example/
hhh/public_html$fastcgi_script_name;
include /etc/nginx/fastcgi.conf;
}
}
Thursday, October 25, 2012

7. Aceleración
Segundo ejemplo
Nginx
Cherokee
Apache en el puerto 8080
PHP en el Apache
Thursday, October 25, 2012

8. Aceleración
Segundo ejemplo
upstream indio {
server 127.0.0.1:8880;
}
upstream hosting {
server 192.168.182.226:80;
}
server {
listen 200.57.34.35:80 default_server ;
listen [2607:f0d0:1002:f2:200:57:34:35]:80
default_server ;
server_name example.com www.example.com ;
root /var/www/example.com/www/web ;
access_log /var/log/nginx/example.access.log main;
access_log /var/log/nginx/everyone.log main;
error_log /var/log/nginx/example.error.log ;
#charset ISO-8859-1;
Thursday, October 25, 2012

9. Aceleración
Segundo ejemplo
location / {
index index.php index.html;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-FORWARDED_PROTO https;
proxy_set_header Host $http_host;
proxy_redirect off;
if (!-e $request_filename) {
proxy_pass http://hosting;
break;
}
}
Thursday, October 25, 2012

10. Aceleración
Segundo ejemplo
location ~ .php {
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-FORWARDED_PROTO https;
proxy_set_header Host $http_host;
proxy_redirect off;
proxy_pass http://hosting;
break;
}
}
Thursday, October 25, 2012

11. Servidores de caché
Squid
Varnish
Nginx
Cherokee
Thursday, October 25, 2012

12. Caché
Primer ejemplo
user nginx;
worker_processes 1;
worker_rlimit_nofile 250000;
events {
worker_connections 65536;
}
! proxy_cache_path /data/nginx/cache levels=1:2 keys_zone=STATIC:16m
inactive=24h max_size=15g;
! proxy_temp_path ! /data/nginx/tmp ;! !
! open_file_cache max=10000 inactive=200s;
! open_file_cache_valid 300s;
! open_file_cache_min_uses 5;
! open_file_cache_errors on;
Thursday, October 25, 2012

13. Caché
Primer ejemplo
log_format accounting
'$msec $time_local '
'| $remote_addr '
'| $status '
'| $bytes_sent '
'| $request_time '
'| $pipe '
'| $upstream_cache_status '
'| $upstream_status '
'| $upstream_response_time '
'| $host '
'| $uri '
'| $query_string ' ;
Thursday, October 25, 2012

14. Caché
Primer ejemplo
1351186862.566 25/Oct/2012:12:41:02 -0500 | 69.93.147.213 | 200 | 569 | 0.000 | . |
HIT | - | - | gpl.la | / | -
1351186867.326 25/Oct/2012:12:41:07 -0500 | 69.93.147.213 | 301 | 425 | 0.000 | . | - |
- | - | gpl.la | /gran/peda/linuxera/ | -
1351186869.260 25/Oct/2012:12:41:09 -0500 | 69.93.147.213 | 200 | 10476 | 0.000 | . |
HIT | - | - | gpl.la | /gran/peda/linuxera/main.php | -
1351186869.380 25/Oct/2012:12:41:09 -0500 | 69.93.147.213 | 404 | 464 | 0.120 | . |
MISS | 404 | 0.054 | gpl.la | /favicon.ico | -
1351186872.651 25/Oct/2012:12:41:12 -0500 | 69.93.147.213 | 200 | 3314 | 0.000 | . |
HIT | - | - | gpl.la | /gran/peda/linuxera/modules/core/data/gallery.css | -
1351186873.198 25/Oct/2012:12:41:13 -0500 | 201.158.247.57 | 301 | 407 | 0.000 | . | -
| - | - | enli.org.mx | / | -
1351186876.225 25/Oct/2012:12:41:16 -0500 | 69.93.147.213 | 200 | 838 | 0.000 | . |
HIT | - | - | gpl.la | /gran/peda/linuxera/modules/albumselect/dtree.css | -
Thursday, October 25, 2012

15. Caché
Primer ejemplo
upstream local ! ! { server 127.0.0.1:8080; }
upstream mendozaaaa ! server 200.57.34.35:80;
{
server 200.57.34.45:80; } #c.w.h
upstream mozillamexico ! { server 200.57.34.35:80;
server 200.57.34.45:80; } #c.w.h
upstream enli! ! ! { server 200.57.34.35:80;
server 200.57.34.45:80; } #c.w.h
Thursday, October 25, 2012

16. Caché
Primer ejemplo
server {
! listen 80;
! server_name ! www.enli.org.mx ;
! access_log /var/log/nginx/accounting.log accounting;
! error_log /var/log/nginx/error.log;
! location / {
! ! include /etc/nginx/proxy-common.conf ;
! ! proxy_pass http:/ /enli;
! ! break;
! }
! location = /programa.html {
! ! include /etc/nginx/proxy-micro.conf ;
! ! expires 60;
! ! proxy_pass http:/ /enli;
! ! break;
! }
Thursday, October 25, 2012

17. Caché
Primer ejemplo
! location ~ .php {
! ! include /etc/nginx/proxy-micro.conf ;
! ! proxy_pass http:/ /enli;
! ! expires 60;
! ! break;
! }
! location ~* .(jpg|jpeg|gif|png|ico|css|js|ico)$ {
! ! include /etc/nginx/proxy-common.conf ;
! ! proxy_ignore_headers "Expires" "Cache-Control" "Set-Cookie" ;
! ! proxy_pass http:/ /enli;
! ! break;
! }
! include /etc/nginx/common-attack.conf;
}
Thursday, October 25, 2012

18. Caché
proxy-common
! ! proxy_set_header X-Real-IP $remote_addr;
! ! proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
! ! proxy_set_header Host $http_host;
! ! proxy_redirect off;
proxy_cache STATIC;
proxy_cache_valid 1d;
proxy_cache_use_stale error timeout invalid_header updating
http_500 http_502 http_503 http_504;
! ! proxy_buffering on;
! ! proxy_buffer_size 8k;
! ! proxy_buffers 8 8k;
! ! proxy_busy_buffers_size 16k;
Thursday, October 25, 2012

19. Caché
proxy-micro
! ! proxy_set_header X-Real-IP $remote_addr;
! ! proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
! ! proxy_set_header Host $http_host;
! ! proxy_redirect off;
proxy_cache STATIC;
proxy_cache_valid 15;
proxy_cache_valid 200 5;
proxy_cache_use_stale error timeout invalid_header updating
http_500 http_502 http_503 http_504;
! ! proxy_buffering on;
! ! proxy_buffer_size 8k;
! ! proxy_buffers 8 8k;
! ! proxy_busy_buffers_size 16k;
Thursday, October 25, 2012

20. Caché
CDN por DNS
;$TTL 86400! 1 day
;
$TTL 3600! ; 1 hour
$ORIGIN enli.org.mx.
;@!! A! 200.57.34.35!; hosting
;www!CNAME! @! ! ;
@! ! A! 50.30.46.179 ; raicilla
www! ! ! CNAME! a.cdn.1-1-0-1.net.
origen!! CNAME! b.w.h.srvr.mx.
Thursday, October 25, 2012

21. Caché
Primer ejemplo
server {
! listen 80;
! server_name ! enli.org.mx ;
! access_log /var/log/nginx/accounting.log accounting;
! location / {
! ! rewrite ^/(.*)$ http:/ /www.$server_name/$1 permanent;
! }
! include /etc/nginx/common-attack.conf;
}
Thursday, October 25, 2012

22. Caché
CDN por DNS Round Robin
;$TTL 3600! ; 1 hour
$TTL 300! 5 min
;
$ORIGIN cdn.1-1-0-1.net.
;A
;a! ! A! 50.30.46.179 ; raicilla
;a! ! A! 99.90.100.1 ; Nodo A
a! ! A! 99.90.100.2 ; Nodo D
;a! ! A! 200.57.48.12 ; Nodo C
;a! ! A! 200.57.48.13 ; Nodo E
a! ! A! 74.86.74.194 ; Nodo F
Thursday, October 25, 2012

23. Caché
Provisionamiento de nodos
for i in `cat hosts | sed “s/#.*$/ ` ; do
/”
ssh $i < scripts/install-key
./scripts/install-node $i
done
./sync-nginx-all
Thursday, October 25, 2012

24. Caché
sync-nginx-all
RSYNC_PARAMS='-vacH --progress '
for i in `cat ./hosts | sed 's/#.*$/ ; do
/'`
! echo "===> rsync to: $i"
! rsync $RSYNC_PARAMS ./etc/nginx/*conf root@$i:/etc/nginx/
! rsync $RSYNC_PARAMS --delete ./etc/nginx/vhosts/ root@$i:/etc/nginx/vhosts/
! ssh root@$i service nginx reload
done
Thursday, October 25, 2012

25. Caché
common-attack.conf
#Apache .htaccess
location ~ /.ht {
! deny all;
}
## Only allow these request methods ##
if ($request_method !~ ^(GET|HEAD|POST)$ ) {
return 444;
}
## Do not accept DELETE, SEARCH and other methods ##
#Directory trasversal ../../../../../
! if ($query_string ~ ../../../../../ ) {
! ! return 404;
! }
! return 404;
}
Thursday, October 25, 2012

26. Referencias
http://wiki.nginx.org/HttpProxyModule
Sandino Araico Sánchez
<sandino@1101.mx>
@KBrown #mendozaaaa
