Building low latency apps with a
serverless architecture and
in-memory data
Darin Briskman | April 2018
briskman@amazon.com

2. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Things with
purpose

3. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Non-Relational Powers New Architectures

4. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Traditional application characteristics
HR Payroll
CRM ERP
…
Users 100s-1000s
Data volume GB-TB
Locality HQ
Performance Seconds
Request Rate Tens of thousands
Access Internal servers, PCs
Scale Up
Economics Pay up front
Developer Access days/weeks/months

5. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Cloud application characteristics
Key-valueRelational Document Graph
;
Users 1M+
Data volume TB-PB-EB
Locality Global
Performance Milliseconds-Microseconds
Request Rate Millions
Access Mobile, IoT, Devices
Scale Up-Out-In
Economics Pay as you go
Developer access Instant API access

6. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Database characteristics
Referential integrity with
strong consistency,
transactions, and
hardened scale
GraphKey-value Document
;
Relational
Low-latency, key-based
queries with high
throughput and fast
ingestion of data
Indexing and storing
documents with support
for query on any property
Creating and navigating
relations between data
easily and quickly
Complex query support
via SQL
Simple query methods
with filters
Simple query with filters,
projections, and
aggregates
Easily express queries in
terms of relations

7. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Polyglot persistence
Different data technologies for different data needs
• Within an application
• Across an organization
• Spanning multiple organizations
Loose coupling sets you free
• Services communicate through queues
• Non-relational databases make excellent queues

8. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
The New De-Normal

9. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Different approaches for highly connected data
Purpose-built for a business process
Purpose-built to answer questions about
relationships

10. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon DynamoDB
F a s t a n d f l e x i b l e N o S Q L d a t a b a s e s e r v i c e f o r a n y s c a l e
Fast, consistent performanceHighly scalable Fully managed Business critical
reliability
Consistent single-digit millisecond
latency; DAX in-memory
performance reduces response
times to microseconds
Auto-scaling to hundreds of
terabytes of data that serve
millions of requests per second
Automatic provisioning,
infrastructure
management, scaling,
and configuration with
zero downtime
Data is replicated across
fault tolerant availability
zones, with fine-grained
access control

11. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
VPC
Endpoints
April 2017
Auto
Scaling
June 2017
DynamoDB
Accelerator (DAX)
April 2017
Time to
Live (TTL)
February 2017
GlobalTables
(GA)
N E W !
On-demand
Backup (GA)
N E W !
Amazon DynamoDB
D e l i v e r i n g o n c u s t o m e r n e e d s
Encryption at rest
(Coming Soon)
N E W !

12. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
DynamoDB Global Tables ( G A )
F i r s t f u l l y m a n a g e d , m u l t i - m a s t e r, m u l t i - r e g i o n d a t a b a s e
Build high performance, globally distributed applications
Low latency reads and writes to locally available tables
Disaster proof with multi-region redundancy
Easy to set up and no application re-writes required
Globally dispersed users
Replica (N. America)
Replica (Europe)
Replica (Asia)
Global App
Global Table

13. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon DynamoDB – Backup and Restore
F i r s t N o S Q L d a t a b a s e t o a u t o m a t e o n - d e m a n d a n d c o n t i n u o u s
b a c k u p s
Point in time restore for
short-term retention and
data corruption protection
(coming soon)
Back up hundreds of TB
instantaneously with NO
performance impact
On-demand backups
for long-term data
archival and
compliance (GA)

14. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon DynamoDB
E n c r y p t i o n @ r e s t ( c o m i n g s o o n )
Server-side
encryption
Supports
compliance
certifications
No application
code rewrites

15. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon Elasticsearch Service
L o g a n a l y t i c s , c l i c k s t r e a m a n a l y t i c s , f u l l - t e x t s e a r c h
Easy to Use
Fully managed.
Single click topologies.
Open & Integrated
Elasticsearch APIs &
Kibana. AWS Integrated.
Secure
VPC. IAM.
Scalable & Available
100 Nodes. 150 TB.
Multi-AZ.

16. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon Elasticsearch Service: What’s
new
100 nodes
150TB
February 2017
VPC
Slow Logs
October 2017April 2017
Elasticsearch 5
January 2017
1 Petabyte
I3 Instances
(coming soon)
N E W !
Encryption at rest
(coming soon)
N E W !
Elasticsearch 6
(coming soon)
N E W !
C4, M4, R4
1.5TB Storage

17. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon ElastiCache
Extreme Performance
Secure & hardened Easily scalable
Highly available &
reliable
In-memory data store and
cache using optimized
stack to deliver sub-
millisecond response times
VPC for cluster isolation,
encryption at rest/transit,
and HIPAA compliance
Read scaling with
replicas. Write and
memory scaling with
sharding. Non disruptive
scaling
Multi-AZ with automatic
failover
Managed, in-memory data store service
Redis or Memcached to power real-time apps with sub-millisecond latency

18. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Memcached
1.4.34
April 2017
Online cluster
resizing
Redis Cluster aware
backup/restore
March 2017
HIPAA
Eligibility
N E W !
Amazon ElastiCache
D e l i v e r i n g o n c u s t o m e r n e e d s
Encryption In
Transit,At Rest, and
RedisAUTH
N E W ! N E W !
Redis test
failover
April 2017

19. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Highly connected data
Social News Feed Restaurant Recommendations Retail Fraud Detection

20. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Too expensive
Difficult to maintain high
availability
Difficult to scale
Limited support for open
standards
$
Existing Graph DatabasesRelational Databases
Inefficient graph processingUnnatural for querying
graph
Rigid schema inflexible for
changing graphs
Challenges building apps with highly connected
data

21. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon Neptune
F u l l y m a n a g e d g r a p h d a t a b a s e
(public preview today)
Fast & Scalable Reliable Open
Store billions of
relationships and
query with
milliseconds latency
Six replicas of your data
across three AZs with full
backup and restore
Build powerful queries
easily with Gremlin and
SPARQL
SupportsApache
TinkerPop &W3C RDF
graph models
Gremlin
SPARQL
Easy

22. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Request rate
High Low
Latency
Low High
Structure
Low
High
Data volume
Low High
Amazon
RDS
Amazon S3
Amazon
Glacier
Amazon
CloudSearch and
Amazon Elasticsearch
Service
Amazon
DynamoDB
Amazon
ElastiCache
and Amazon
DynamoDB
Accelerator
(DAX)
HDFS

23. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Powerful
~200 commands + Lua scripting
In-memory data structure server
Utility data structures
Strings, lists, hashes, sets, sorted
sets, bitmaps, and HyperLogLogs
Simple
Atomic operations
supports transactions
Ridiculously fast!
<1 ms latency for most commands
Highly available
replication
Persistence
Open source
What is Redis?

24. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Caching
Clients
Amazon
ElastiCache
Redis
Amazon
DynamoDB
Elastic Load
Balancing
Amazon
EC2
Amazon
RDS
write-through
reads/
writes
DDB streams
mysql.lambda_async
reads/
writes
Amazon
S3
reads/writes
Object data
Unstructured data
Relational data

25. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Caching NoSQL
Amazon
EC2 reads/
writes
reads
MongoDB
Cluster
Cassandra
Cluster
 Smaller NoSQL DB clusters needed = lower costs
 Faster data retrieval = better performance
Elasticsearch
Cluster
Clients

26. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon
EC2
reads/
writes
Amazon
ElastiCache
Redis
reads
MongoDB
Cluster
DBObject doc = collection.findOne();
Cache serialized DBObject in Redis (good)
Cache rows in Redis hash (faster/more efficient)
Cassandra
Cluster
Amazon
ElastiCache
Redis
Amazon
EC2
reads/
writes
reads
ResultSet rs = session.execute(stmt);
Cache serialized ResultSet in Redis (good)
Cache rows in Redis hash (faster/more efficient)
 Smaller NoSQL DB clusters needed = lower costs
 Faster data retrieval = better performance
Caching NoSQL databases with Amazon ElastiCache

27. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon
Kinesis
Analytics
Amazon
Kinesis
Streams
Amazon
Kinesis
Streams
Amazon
ElastiCache
(Redis)
cleansed
stream
Streaming data enrichment/processing
Datasources
raw
stream
Subscribers
AWS Lambda function 1
Continualdata
filtering/enrichment
Real-time
pub/sub
AWS Lambda function 2

28. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Big data architectures using Redis
Amazon Kinesis
DataSources
AWS Lambda
Apache Storm
on EMR
Spark Streaming
on Amazon EMR
Amazon
Kinesis app
Amazon
EC2
AWS IoT
Amazon
ElastiCache
Collect
Store
Process
Amazon
S3
Apache Kafka
AWS
Lambda
Custom
app
Spark on
Amazon
EMR
Analyze

29. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Rules Engine
Amazon
ElastiCache
Redis
AWS
Lambda
Direct integration
LambdaSNS SQS
S3 KinesisDDB
AWS
IoT devices
AWS
IoT
Sensor store
IoT powered by ElastiCache

30. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Mobile apps powered by ElastiCache
Amazon API
Gateway
AWS
Lambda
Amazon
ElastiCache
Redis
GEOADD
GEORADIUS
Search points of interest
Update points of interest
https://aws.amazon.com/blogs/database/amazon-elasticache-utilizing-redis-geospatial-capabilities/
Amazon
DynamoDB
DDB streams
Amazon
EC2

31. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Ad tech powered by ElastiCache
Clients
Advertisers
https://aws.amazon.com/caching/database-caching/
Ad network
Ad slot
Consumer
Ad slot
publishers
Ad placement
(websites/apps)
Amazon
ElastiCache
Redis
<40 ms
Clickstream
(shopping
events)
User visits page Publisher
places ad slot
for auction
Ad network
calls for bidsBidders respond
with bids
Winners bid
ad displayed

32. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Chat apps powered by ElastiCache
https://aws.amazon.com/blogs/database/amazon-elasticache-utilizing-redis-geospatial-capabilities/
Clients
Chat apps
Application Load
Balancer
WebSockets
Amazon
ElastiCache
Redis
PubSub Server
persistent
connections
Elastic
Beanstalk
SUBSCRIBE chat_channel:114
PUBLISH chat_channel:114 "Hello all"
>> ["message", "chat_channel:114", "Hello all"]
UNSUBSCRIBE chat_channel:114

33. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
• Very popular for gaming apps that need
uniqueness and ordering
• Easy with Redis sorted sets
ZADD "leaderboard" 1201 "Gollum”
ZADD "leaderboard" 963 "Sauron"
ZADD "leaderboard" 1092 "Bilbo"
ZADD "leaderboard" 1383 "Frodo”
ZREVRANGE "leaderboard" 0 -1
1) "Frodo"
2) "Gollum"
3) "Bilbo"
4) "Sauron”
ZREVRANK "leaderboard" "Sauron"
(integer) 3
Gaming—real-time leaderboards

34. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Ex: throttling requests to anAPI
uses Redis counters
ELB
Externally
facing API
Reference: http://redis.io/commands/INCR
FUNCTION LIMIT_API_CALL(APIaccesskey)
limit = HGET(APIaccesskey, “limit”)
time = CURRENT_UNIX_TIME()
keyname = APIaccesskey + ":” + time
count = GET(keyname)
IF current != NULL && count > limit THEN
ERROR ”API request limit exceeded"
ELSE
MULTI
INCR(keyname)
EXPIRE(keyname,10)
EXEC
PERFORM_API_CALL()
END
Rate limiting

35. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Amazon
ElastiCache
µs is the new ms

36. © 2018, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Thank you!
… and thanks to our sponsors!
