Building a Layer 3 network with Cumulus Linux

•Download as PPTX, PDF•

0 likes•916 views

Learn how Outbrain, the world's leading discovery platform, broke their network and found their way to a disaggregated model. Using Cumulus Linux, they architected an open network built for performance, scalability and automation. To see the full recorded webinar, visit https://cumulusnetworks.com/lp/cumulus-outbrain-webinar/

Technology

Switches, Penguins and
One Bad Cable
Alex Balk

ADI NAVEH
ALEX BALK
ALEX KARASIK
CHEN SHABI
DAFNA FRANK
DORI SHMUEL
GAI RADZI
GERARDO LARACUENTE
GUY MAZUZ
RYAN MCQUILLAN
SHAHAF SAGES
YAFIT MELES
We Are
Core

OUR PURPOSE
OUTBRAIN helps people discover
content that they find interesting.

250 Billion
Content Recommendations
Every Month
½ Billion
People Worldwide
OUTBRAIN
BY THE NUMBERS

AVAILABILITYMANAGEMENT
Two Main Networking Challenges

6 Million
Metrics generated every minute
150 Releases
To production every day
OUTBRAIN
BY THE NUMBERS

SCALE IS ABOUT
TURNING THE LIGHTS ON
Network (gasp!)
was 100% Manual!
• Every change =
risk
• Switching stack
proprietary
• Debugging = fight
or just a hit-n-miss
• Lead time to set-up
new stack
measured in
weeks!
• No way to scale to
the next 10X

New Data Center = Clos Fabric — running BGP end-to-end

Node
Leaf A Leaf B
Spine
NodeNode
SpineSpine
No bonding.
No backbone.
Everything is just a router!

All possible paths to all possible destinations constructed —
hop-by-hop

Node
Leaf A
Spine
NodeNode
SpineSpine
Leaf B
ECMP = “Send it down any available path, they’re all the same”.

SIMPLE
PREDICTABLE
SCALABLE
A Network That is Now

DEVICE
MANAGEMENT
CABLE
MANAGEMENT
SETUP TIME
MONITORING
TESTING

SCALE IS ABOUT
BUILDING THE RIGHT CULTURE

SCALE IS ABOUT
CHOOSING THE RIGHT TOOLS
To bootstrap the new datacenter5 DAYS
99% Of code worked as expected
1 Bad cable...out of 3,000

END SOLUTION MODULES
DRAFT 051116
Thank
You

Hardcore Tech Stuff
Slides shamelessly “borrowed”
from Adi Naveh’s internal tech talk

Traditional Network Topology
Aggregation
Core
Access

Traditional Network Topology
Access
Aggregation
Core
Services
Clients
North-South Traffic

Load Balancers Load Balancers
ISP
Traditional Network Topology in Data Center
Access
Aggregation
Core
Services
North-South Traffic
East-West Traffic

Network operators are slowly but surely embracing L3-based leaf-spine designs. However, either due to legacy applications or certain multi-tenancy requirements, the need for L2 across racks is still present. How do you solve the problem of providing L2 across multiple racks? EVPN is quickly emerging as the best answer to this question. In this episode of our 2-part series on EVPN, we start with a discussion of the use cases, a review of the technologies EVPN competes with, and dive into an evaluation of the pros and cons of each. For a recording of the live event, go to http://go.cumulusnetworks.com/l/32472/2017-09-22/95t27t
