1. BRAIN GATE
TECHNOLOGY
SUBMITTED BY
B.V.SAI SUPRAJA
15471A05E6
III-CSE-C

2. CONTENTS
 INTRODUCTION
 OBJECTIVE
 DEVELOPMENT
 BRAIN COMPUTER INTERFACE
 ANIMAL RESEARCH
 WORKING
 ADVANTAGES
 DISADVANTAGES
 CONCLUSION

3. INTRODUCTION
• Brain gate is an electrode chip which
can be implemented in the brain.
What is Brain gate
Technology?

4. INTRODUCTION(cont.)
 When it is implemented in brain, the electrical signal
exchanged by neurons within the brain.
 Those signals are sent to the brain and it executes
body movement.
 All the signalling process is handled by special
software.
 The signal sends to the computer and then the
computer is controlled by patient.

5. OBJECTIVE
 The goal of the Brain Gate Program is to develop a
fast and reliable connection between the brain of a
severely disabled person and a personal computer.
 The ‘Brain Gate’ device can provide paralysed or
motor-impaired patients a mode of communication
through the translation of thought into direct computer
control.

6. DEVELOPMENT
 Brain Gate Technology by Bio-tech Company Cyber Kinetics in 2008 in
conjunction with the development of Neuroscience at Brown University.
Nicholas Halso

7. BRAIN COMPUTER INTERFACE
 A Brain computer interface called as direct
neural interface or brain machine interface is a
direct communication pathway between
human or animal brain and an external device.
 “BCIs” usually connects the brain(or nervous
system) with a computer system

8. BCI Technology(cont.)
 Based on the communicative pathway BCI
is classified as follows
One way BCIs
Two way BCIs

9. BCI Technology(cont.)
 One way BCI:Computers either accept commands from the brain or send
signals to it(for example, to restore vision)but not both.
 Two way BCI:Brains and external devices can exchange information in
both directions but have yet to be successfully implanted in animals or
humans.
 Brain Computer interface is of three types based on its features and are
 Invasive BCI
 Partially Invasive BCI
 Non Invasive BCI

10. ANIMAL RESEARCH

11. RESEARCH ON ANIMALS
 At first ,rats were implanted with BCI.
 Signals recorded from the cerebral
cortex of rat to operate BCI to
carry out the movement.

12. RESEARCH ON ANIMALS
 Researchers at the University of
Pittsburgh had demonstrate on a
monkey that can feed itself with a robotic
arm simply by using signals from its
brain to carryout the movement.

13. A BOON TO THE PARALYZED -BRAIN
GATE NEURAL INTERFACE SYSTEM:
 Mathew-Nagel the first
person to use the brain-
computer interface to
restore functionality lost
due to paralysis…..

14. WORKING

15. WORKING
 The Brain Gate neural interface device is a
propriety brain-computer interface that consist
of an Inter neural signal sensor and
External processors.
 The sensor consists of a tiny chip containing
100 microscopic electrodes that detect brain
cell electrical activity.
 The chip is implanted on the surface of brain
in the motor cortex area that controls
movement.
 The computers translate brain activity and
create the communication output using
custom decoding software.

16. ADVANTAGES
 Controlling remote devices.
 Making and receiving telephone calls
 Accessing the internet.
 Turn on or off the lights.
 Control robotic arm.
 Watch and control television
 Use the pc
 Locking or unlocking doors
 Motorized wheelchair

17. DISADVANTAGES
 Expensive
 Risky Surgery
 Not wireless yet
 Difficulty in adaptation and learning
 Limitation in information transform rate.
 The latest technology is 20 bits/min.

18. Conclusion
 The invention of Brain gate is such a revolution in medical field . The
remarkable break through offers hope that people who are paralyzed will
one day be able to independently operate artificial limbs ,computers or
wheelchairs.
 The idea of moving robots not by manual control , but by mere “thinking”
(i.e., the brain activity of human subjects) has been a fascinated approach.

19. ANY
QUERIES…
