Slides of the talk about OpenStack Bitnami Bootcamp. Feb. 2015

1. “OpenStack”
Alberto Molina Coballes
Teacher at IES Gonzalo Nazareno @alberto_molina
alb.molina@gmail.com

2. Table of Contents
• Infrastructure evolution
• From public to private clouds
• Open Source Cloud Platforms
• Why OpenStack?
• OpenStack architecture and components
• OpenStack in action
• Private cloud administration
• References
• OpenStack Doc: docs.openstack.org
• http://iesgn.github.io/cloud/

3. Infrastructure evolution

4. Traditional infrastructure
• Equipment purchase
• Rack mount
• Physical connection to the network
• “Manual” OS installation and configuration
• Storage provided by NAS or SAN
• Static infrastructure
• Same configurations for years
• Users with no direct access

5. Virtual Machines
• Several VMs on every physical machine
• VMs managed by the hypervisor
• VMs connected through virtual networks
• Without significant changes in storage
• Similar management to traditional infrastructure

6. Cloud Infrastructure
• Machines virtualization
• Network virtualization
• Storage virtualization
• Resource pooling
• Dynamic infrastructure
• Automatic configuration
• The user manages his or her own infrastructure

8. From public to
private clouds

9. The NIST Definition: Essential characteristics
• On demand self-service
• Broad network access
• Resource pooling
• Rapid elasticity
• Measured service

10. The NIST Definition: Deployments models
• Public cloud
• Private Cloud
• Community Cloud
• Hybrid Cloud

11. The NIST Definition: Service model
• Software as a Service (SaaS)
• Platforms as a Service (PaaS)
• Infrastructure as a Service (IaaS)
• Reference
• The NIST Definition of Cloud Computing

12. Source: Kevin Remde: SaaS, PaaS, and IaaS.. Oh my!

13. Why private cloud is needed?
• Public clouds are fine but some points must be
considered carefully:
• Privacy
• Security
• Vendor lock-in
• Control over data
• Customization
• Performance?
• Overall Cost?
• A private or hybrid cloud may be an option to take
into account

14. Infrastructure as a Service
• Public cloud providers: AWS, GCE & Azure. Is there
room for someone else?
• Private Cloud: VMware and Open Source platforms
• In this talk we will focus on IaaS and private cloud,
mainly in an Open Source Cloud Platform called
OpenStack

15. Open Source
Cloud Platforms

16. CloudStack
• Former cloud.com
• Purchased by citrix on 2011
• Donated to Apache Software
Foundation on 2012
• Supports VMware, KVM,
XenServer, XCP and Hyper-V
• Easy to use Web interface
• Compatible with AWS EC2 and S3 APIs

17. Eucalyptus
• Oldest and most mature? Open Source Cloud
platform
• Focus on AWS compatibility
• Licensing issues in the past (Open core?)
• Supports VMware, KVM and Xen
• euca2ools: AWS compatible CLI
• Developed by Eucalyptus Systems
• Eucalyptus Systems purchased by HP in Sept 2014

18. OpenNebula
• Data Center Virtualization Software
• Claim to be a VMware vCloud competitor
• Compatible with AWS EC2 API
• OpenNebula Marketplace
• Developed by OpenNebula Community
• Easier to install and configure?

19. OpenStack
• Next item in detail

20. Why OpenStack?

21. OpenStack
“Openstack is an open-source IaaS cloud computing platform. Its mission is
to provide a flexible solution for both public and private clouds of any size,
and for this matter two basic requirements are considered:
clouds must be simple to implement and massively scalable.”

22. OpenStack releases
Name Release date New components
Austin October 2010 Nova and Swift
Bexar February 2011 Glance
Cactus April 2011
Diablo September 2011
Essex April 2012 Horizon, Keystone
Folsom October 2012 Quantum, Cinder
Grizzly April 2013
Havana October 2013 Neutron, Heat, Ceilometer
Icehouse April 2014 TripleO, Ironic, Trove, Marconi
Juno October 2014 Sahara
Bitergia – The OpenStack Juno release: activity and organizations

23. OpenStack principles
• All of the code for OpenStack is freely available
under the Apache 2.0 license
• Support all Available Hypervisors
• Implement REST APIs and Open Image Format
• Open design process:
• Blueprints
• Public repositories (github)
• Commitment to drive and adopt open standards
• Open community and transparency

24. Source: cloudscaling
Companies Supporting The OpenStack Foundation

25. Why OpenStack?
• We want to manage our own software to provide
IaaS
• Open Source
• Stable project, well supported by companies and
with a promising future
• It has a lot of functionalities
• Works fine on conventional hardware
• Easy to install (ha!)

26. OpenStack architecture
and components

27. OpenStack components
• Core components
• Compute (nova)
• Object Storage (swift)
• Identity (keystone)
• Image (glance)
• Block Storage (cinder)
• Dashboard (horizon)
• Networking (neutron)
• Other components
• DBaaS (trove)
• DNSaaS (designate)
• Orchestration (heat)
• Metering (ceilometer)
• Baremetal (ironic)
• TripleO
• Queue and Notif (zaqar)

28. Randy Bias - 'Vanilla OpenStack' Doesn’t Exist and Never Will
OpenStack components

30. OpenStack in action

31. Basic Concepts
• Image: Preconfigured OS image ready to be launched
• Instance: Virtual machine that runs inside the cloud
• Flavor: Virtual machine specs (RAM, vCPUs, …)
• Fixed IP: IP assigned when instance is launched and
used for communication between instances
• Floating IP: Optional IP used for communication with
networks outside the cloud
• Security group: Firewall rules associated to an
instance

32. OpenStack at IES Gonzalo Nazareno

33. Using OpenStack
• https://albertomolina.wordpress.com/2013/11/20/how-to-
launch-an-instance-on-openstack-i-horizon/
• https://albertomolina.wordpress.com/2013/11/20/how-to-
launch-an-instance-on-openstack-ii-openstack-cli/
• https://albertomolina.wordpress.com/2013/11/20/how-to-
launch-an-instance-on-openstack-iii-python-novaclient-
library/

34. Private cloud administration

35. Enterprise “legacy” applications
• Not fault-tolerant
• Must run on smart hardware
• Typically scales up
• Runs on long-lived machines (virtual or not)
• Redundancy provided by a lower level

36. “Cloud ready” applications
• Fault-tolerant (resilience)
• Typically runs on short-lived machines
• Scale out
• Elasticity
• Smart applications
• Conventional hardware
• Automation
• Agility
• DevOps

37. “Cloud ready” or “legacy” applications?
• Nowadays most of the applications used are not
cloud ready
• IaaS is an evolution of virtualization for legacy
applications (virtualization 2.0)
• Block storage is a SAN equivalent
• Load balancers vs high availability clusters
• Re-architecting legacy applications
Keith Basil - Introduction and Overview of OpenStack for IaaS
Randy Bias - Pets vs. Cattle: The Elastic Cloud Story

38. Cloud administration
• The main purpose of a system administrator is to
keep applications up and running properly and
never lost data
• In this area there are two differents profiles:
• Cloud application system administrator: Deploys and
maintains applications running on the cloud
• Cloud system administrator: Manages the cloud platform

39. Cloud application system administrator
• Common to public or private clouds
• Overall knowledge of cloud resources
• REST APIs, specifically AWS “de facto standard”
• Cloud Orchestration: Cloudformation
• Image Management and transformation
• Instance life cycle
• Object Storage
• Block Storage
• Monitoring
• Automation
• Configuration management

40. Cloud system administrator
• Not for juniors ;)
• Deep knowledge of underlying technologies:
virtualization, networking and storage
• Monitoring
• Automation
• Configuration management

41. Thanks
Alberto Molina Coballes
Teacher at IES Gonzalo Nazareno @alberto_molina
alb.molina@gmail.com
