What does Two Factor Authentication mean? How does it work and how difficult is it to integrate it into your own web application?

2. Who am I?
Norman Soetbeer
Computer Science Student
Game Developer @ InnoGames
Twitter: @TheBattleRattle
Github: BattleRattle

5. John Doe
********
submit
LOGIN
743503
submit
Enter your Code
An authenticator is
connected to your account
Welcome
Hey, John Doe!
You successfully logged in
1 2

6. also known as
TFA, 2FA
Two-Step Authentication
Two-Step Verification (Google)
Two Factor Verification (Dropbox, Twitter)
Login Approvals (Facebook)
Code Generator (Facebook)

7. three factors
consider two (or more)

8. knowledge factor
„something only the user knows“
PIN
password
pattern
„What was the name of your first pet?“

9. possession factor
„something only the user has“
key
smart card
ATM card
mobile phone
hard tokens
USB tokens

10. inherence factor
„something only the user is“
finger print
iris
voice
DNA

11. Automatic Teller Machine
ATM card + PIN
=
„something only the user has“
+
„something only the user knows“

12. requirements for secure factors
strong entropy on secrets

13. requirements for secure factors
high resistance of a tokens to be cloned

14. requirements for secure factors
uniqueness and reliability of biometrics

15. requirements for secure factors
secure transport (tokens, passwords, etc.)

16. requirements for secure factors
additional management:
disable lost tokens
determine steps for password reset
withdraw credentials, if no longer required

17. requirements for secure factors
fraud detection:
monitor failed attempts, lock account

19. what is possible?

20. knowledge factor
PIN?

21. knowledge factor
password?

22. knowledge factor
pattern?
requires javascript / flash, but

23. knowledge factor
„What was the name of your first pet“?
does not fulfill
„something only the user knows“

24. possession factor
key?
difficult to check

25. possession factor
smart card?
requires additional hardware
not usable in web browser (maybe with plugin)
costs (card, card reader, transport of card)

26. possession factor
USB token?
not usable in web browser (maybe with plugin)
costs (token + transfer)

27. possession factor
hard token?
costs (token itself, transport)

28. possession factor
mobile phone?
SMS?
Costs

29. Give us your phone number?

30. possession factor
mobile phone?
voice message?
same as SMS

31. possession factor
mobile phone?
code generator (smart phone)

33. secret key
secret counter value
public serial
new code on key press
(counter increases)

34. HMAC-Based One-Time Password
hash = hmac_sha1(key, counter)
offset = last 4 bits of hash
number = 4 bytes from hash, beginning at offset
pad numbers to given length

35. example
hash = hmac_sha1(„12345“, 1)
20 d4 c6 b0 32 ea 01 da 02 6e
a8 a9 f6 f4 00 41 d0 95 6d 08
offset = last 4 bits of hash
8
number = 4 bytes from hash, beginning at
offset
02 6e a8 a9
pad numbers to given length
40806569

36. usage
serial key counter uid
FOO-BAR-
BAZ
43A7B66
200DD
7 42456
ABCD-
EFGH-IJKL
AF3A77E
8D638
19 87632
MNOP-
QRST-
UVWX
74DA393
55CB6
2 24572
SERIAL
ABCD-EFGH-IJKL
KEY (secret)
AF3A77E8D638
COUNTER (secret)
19
authenticator web application

37. generate a new code
serial key counter uid
FOO-BAR-
BAZ
43A7B66
200DD
7 42456
ABCD-
EFGH-IJKL
AF3A77E
8D638
19 87632
MNOP-
QRST-
UVWX
74DA393
55CB6
2 24572
SERIAL
ABCD-EFGH-IJKL
KEY (secret)
AF3A77E8D638
COUNTER (secret)
20
authenticator web application
830429 830429

38. code was correct
serial key counter uid
FOO-BAR-
BAZ
43A7B66
200DD
7 42456
ABCD-
EFGH-IJKL
AF3A77E
8D638
20 87632
MNOP-
QRST-
UVWX
74DA393
55CB6
2 24572
SERIAL
ABCD-EFGH-IJKL
KEY (secret)
AF3A77E8D638
COUNTER (secret)
20
authenticator web application
830429 830429

39. code was incorrect (e.g. typo)
serial key counter uid
FOO-BAR-
BAZ
43A7B66
200DD
7 42456
ABCD-
EFGH-IJKL
AF3A77E
8D638
19 87632
MNOP-
QRST-
UVWX
74DA393
55CB6
2 24572
SERIAL
ABCD-EFGH-IJKL
KEY (secret)
AF3A77E8D638
COUNTER (secret)
20
authenticator web application
830428 830429

40. code was incorrect (e.g. typo)
serial key counter uid
FOO-BAR-
BAZ
43A7B66
200DD
7 42456
ABCD-
EFGH-IJKL
AF3A77E
8D638
19 87632
MNOP-
QRST-
UVWX
74DA393
55CB6
2 24572
SERIAL
ABCD-EFGH-IJKL
KEY (secret)
AF3A77E8D638
COUNTER (secret)
20
authenticator web application
830428 830429
counters out of sync

41. solution
also check up to 10 upcoming codes
and update counter

43. secret key
internal clock
new code every 30 seconds

44. Time-Based One-Time Password
time_frame = floor (unix_timestamp / time_step)
hash = hmac_sha1(key, time_frame)
offset = last 4 bits of hash
number = 4 bytes from hash, beginning at offset
pad numbers to given length

45. usage
key uid
43A7B66200DD 42456
AF3A77E8D638 87632
74DA39355CB6 24572
KEY (maybe secret)
AF3A77E8D638
UNIX TIMESTAMP
1234567890
authenticator web application
692113 692113
code must be marked as used,
because „one-time password“

46. wrong code
key uid
43A7B66200DD 42456
AF3A77E8D638 87632
74DA39355CB6 24572
KEY (maybe secret)
AF3A77E8D638
UNIX TIMESTAMP
1234567890
authenticator web application
849372 692113
you should lock the account
for current time frame

47. what about delays?
clocks out of sync?

48. simple
just also check one time frame
before and after current one

50. demo time

51. // Check Credentials (Step 1)
$username = $_POST['username'];
$password = $_POST['password'];
$user = getUserByCredentials($username, $password);
if (!$user) {
redirect('/login/');
}
if ($user->hasAuthenticator()) {
$session->set('authenticated', false);
} else {
$session->set('authenticated', true);
}

52. // Check for Authentication
if (!$session->get('authenticated')) {
redirect('/tfa-code/');
}

53. // Check Code (Step 2)
use BattleRattleDoormanAuthenticationGoogleAuthenticator;
// get the code from user input
$code = $_POST['code'];
// get the associated key for the current user
$key = 'ONETIMEPASSWORDS';
$authenticator = new GoogleAuthenticator();
$result = $authenticator->authenticate($key, $code);
if ($result) {
echo 'Welcome, you successfully logged in';
} else {
echo 'Nope, try again';
}

54. installation via composer / packagist
“require”: {
“battlerattle/doorman”: “dev-master”
}

55. questions?

56. thank you
