1. The Automated Discovery of Declarative Process
Models
Claudio Di Ciccio
claudio.di.ciccio@wu.ac.at
Humboldt-Universität zu Berlin, 7 December 2016

2. www.wu.ac.at
www.wu.ac.at/infobiz
www.wu.ac.at/infobiz/team/diciccio

3. Control-flow discovery
?
Objective: understanding the
temporal structure that best
describes the process behind
the event log
SEITE 3

4. Knowledge-intensive
Processes
SEITE 4

5. Knowledge-intensive
Processes
SEITE 5

6. Mining flexible processes
SEITE 6

7. Declarative modelling of
processes
 Usage of constraints
 “Open model”
 Declare
 state-of-the-art language
If A is performed,
B must be performed,
no matter if before or afterwards
(responded existence)
Whenever B is performed,
C must be performed afterwards
and B can not be repeated
until C is done
(alternate response)
SEITE 7

8. Workflow Nets
as process models
SEITE 8

9. Imperative v declarative
SEITE 9
SEITE 9

10. Declarative processes
DECLARE

11. Declarative process modelling
 “Open model”
 Specify constraints for
permitted behaviour
 Every execution that
complies with them is
acceptable
 Works best with flexible
processes
 The set of DECLARE
templates is extendible
SEITE 11

12. A fragment of declarative
process model
 If an abstract is submitted, a new paper
had been written or will be written
 After the paper submission, a
confirmation email is sent
 After the paper submission, the paper
will be reviewed;
there can be no review without a
preceding submission
 A paper can be accepted only after it has
been reviewed
 After the rejection, no further
submission follows
 Paper cannot be both accepted and
rejected
SEITE 12
Submit abstract Write new paper
Submit paper
Send
confirmation
email
Submit paper Review paper
Review paper Accept paper
Reject paper Submit paper
Accept paper Reject paper
= activation task
Responded existence(Submit abstract, Write new
paper)
Response(Submit paper, Send confirmation email)
Succession(Submit paper, Review paper)
Precedence(Review paper, Accept paper)
Not succession(Reject paper, Submit paper)
Not co-existence(Accept paper, Reject paper)
Template Tasks

13. A fragment of declarative
process model
SEITE 13
Submit abstract
Write new paper Submit paper
Send
confirmation
email
Review paper Accept paper
Reject paper

14. Declare:
Existence Constraint Templates
Existence(n, A)
Activity A occurs at least n times in the process instance
BCAAC ✓ BCAAAC ✓ BCAC ✗ (for n = 2)
Absence(A)
Activity A does not occur in the process instance
BCC ✓ BCAC ✗
Absence(n+1, A)
Activity A occurs at most n-1 times in the process instance
BCAAC ✗ BCAC ✓ BCC ✓ (for n = 2)
Exactly(n, A)
Activity A occurs exactly n times in the process instance
BCAAC ✓ BCAAAC ✗ BCAC ✗ (for n = 2)
Init(A)
Activity A is the first to occur in each process instance
BCAAC ✗ ACAAAC ✓ BCC ✗
Absence(2, A) ≡ AtMostOne(A)
Existence(1, A) ≡ Participation(A)
SEITE 14

15. Declare:
Relation Constraint Templates
RespondedExistence(A, B)
If A occurs in the process instance, then B occurs as well
CAC ✗ CAACB ✓
BCAC ✓ BCC ✓
SEITE 15

16. Declare:
Relation Constraint Templates
RespondedExistence(A, B)
If A occurs in the process instance, then B occurs as well
CAC ✗ CAACB ✓
BCAC ✓ BCC ✓
Response(A, B)
If A occurs in the process instance, then B occurs after A
BCAAC ✗ CAACB ✓
CAC ✗ BCC ✓
SEITE 16

17. Declare:
Relation Constraint Templates
RespondedExistence(A, B)
If A occurs in the process instance, then B occurs as well
CAC ✗ CAACB ✓
BCAC ✓ BCC ✓
Response(A, B)
If A occurs in the process instance, then B occurs after A
BCAAC ✗ CAACB ✓
CAC ✗ BCC ✓
AlternateResponse(A, B)
Each time A occurs in the process instance, then B occurs
afterwards, before A recurs
BCAAC ✗ CAACB ✗ CACB ✓
CABCA ✗ BCC ✓ CACBBAB ✓
SEITE 17

18. Declare:
Relation Constraint Templates
RespondedExistence(A, B)
If A occurs in the process instance, then B occurs as well
CAC ✗ CAACB ✓
BCAC ✓ BCC ✓
Response(A, B)
If A occurs in the process instance, then B occurs after A
BCAAC ✗ CAACB ✓
CAC ✗ BCC ✓
AlternateResponse(A, B)
Each time A occurs in the process instance, then B occurs
afterwards, before A recurs
BCAAC ✗ CAACB ✗ CACB ✓
CABCA ✗ BCC ✓ CACBBAB ✓
ChainResponse(A, B)
Each time A occurs in the process instance, then B occurs
immediately afterwards
BCAAC ✗ BCAABC ✗ BCABABC ✓
Activation Target

19. Declare:
Relation Constraint Templates
RespondedExistence(B, A)
If B occurs in the process instance, then A occurs as well
CAC ✓ CAACB ✓
BCAC ✓ BCC ✗
Precedence(A, B)
B occurs in the process instance only if preceded by A
BCAAC ✗ CAACB ✓
CAC ✓ BCC ✓
AlternatePrecedence(A, B)
Each time B occurs in the process instance, it is preceded by A
and no other B can recur in between
BCAAC ✗ CAACB ✓ CACB ✓
CABCA ✓ BCC ✗ CACBAB ✓
ChainPrecedence(A, B)
Each time B occurs in the process instance, then B occurs
immediately beforehand
BCAAC ✗ BCAABC ✗ CABABCA ✓
Target Activation

20. Declare:
Relation Constraint Templates
CoExistence(A, B) ≡ Resp’dEx.(A, B) ∧ Resp’dEx.(B, A)
If B occurs in the process instance, then A occurs, and viceversa
CAC ✗ CAACB ✓
BCAC ✓ BCC ✗
Succession(A, B) ≡ Response(A, B) ∧ Precedence(A, B)
A occurs if and only if it is followed by B in the process instance
BCAAC ✗ CAACB ✓
CAC ✗ BCC ✗
AlternateSuccession(A, B) ≡ Alt.Resp.(A, B) ∧ Alt.Prec.(A, B)
A and B occur in the process instance if and only if the latter
follows the former, and they alternate each other in the trace
BCAAC ✗ CAACB ✗ CACB ✓
CABCA ✗ BCC ✗ CACBAB ✓
ChainSuccession(A, B) ≡ ChainResp.(A, B) ∧ ChainPrec.(A, B)
A and B occur in the process instance if and only if the latter
immediately follows the former
BCAAC ✗ BCAABC ✗ CABABC ✓
Activation Target
Target Activation

21. Declare: Negative
Relation Constraint Templates
NotCoExistence(A, B)
A and B never occur together in the process instance
CAC ✓ CAACB ✗
BCAC ✗ BCC ✓
NotSuccession(A, B)
A can never occur before B in the process instance
BCAAC ✓ CAACB ✗
CAC ✓ BCC ✓
NotChainSuccession(A, B)
A and B occur in the process instance if and only if the latter
does not immediately follows the former
BCAAC ✓ BCAABC ✗ CBACBA ✓
Activation Target
Target Activation

22. Subsumption hierarchy
of constraint templates
SEITE 22

23. Declarative processes
Discovery of DECLARE models

24. Constraints mining
?
Objective: understanding the
constraints that best define
the allowed behaviour of the
process behind the event log
SEITE 24

25. Mining declarative processes:
ingredients
“Submit abstract”,
“Submit paper”,
“Accept paper”,
…
SEITE 25
A,
B,
C,
…
Activities Process alphabet

26. Mining declarative processes
RespondedExistence(A, B) ?
RespondedExistence(A, C) ?
…
Response(A, B) ?
Response(A, C) ?
…
SEITE 26
• Support:
fraction of cases fulfilling the constraint
• Confidence:
support scaled by fraction of traces in
which the activation occurs
• Interest factor:
confidence scaled by fraction of traces in
which the target occurs
Support Conf. I.F.

27. Mining declarative processes
RespondedExistence(A, B) ?
RespondedExistence(A, C) ?
…
Response(A, B) ?
Response(A, C) ?
…
SEITE 27
Support Conf. I.F.
• Support:
fraction of cases fulfilling the constraint
• Confidence:
support scaled by fraction of traces in
which the activation occurs
• Interest factor:
confidence scaled by fraction of traces in
which the target occurs

28. Mining declarative processes
RespondedExistence(A, B) 
RespondedExistence(A, C) 
…
Response(A, B) ?
Response(A, C) 
…
SEITE 28
Support Conf. I.F.
• Support:
fraction of cases fulfilling the constraint
• Confidence:
support scaled by fraction of traces in
which the activation occurs
• Interest factor:
confidence scaled by fraction of traces in
which the target occurs

29. Mining declarative processes
RespondedExistence(A, B) 
RespondedExistence(A, C) 
…
Response(A, B) 
Response(A, C) 
…
SEITE 29
Support Conf. I.F.
• Support:
fraction of cases fulfilling the constraint
• Confidence:
support scaled by fraction of traces in
which the activation occurs
• Interest factor:
confidence scaled by fraction of traces in
which the target occurs

30. Constraints mining
An example
SEITE 30
A A B C A B C A C B C D
A C C A B B C B C A C B B D
C C C C C A A B C A A B A A B
A B B B D
C B A B D
A B B D
A A A C A C B D
A B C D
C A B A A C C B B D
B C C D
C A A C C C A A B C B C C B D

31. The role of Support
(event-based)
A A B C A B C A C B C D
A C C A B B C B C A C B B D
C C C C C A A B C A A B A A B
A B B B D
C B A B D
A B B D
A A A C A C B D
A B C D
C A B A A C C B B D
B C C D
C A A C C C A A B C B C C B D
 Support for
 Response(A, B)
 1.0
 Precedence(A, B)
 0.926 (25/27)
 Pruning on the basis of a
support threshold
 E.g., 0.95
 A threshold equal to 1.0
for a constraint means
“always valid in the log”
Activation
Target
Target
Activation
SEITE 31
http://github.com/cdc08x/minerful
Prom Nightly Builds > “Declare MINERful” plug-in

32. The role of Support
(trace-based)
A A B C A B C A C B C D
A C C A B B C B C A C B B D
C C C C C A A B C A A B A A B
A B B B D
C B A B D
A B B D
A A A C A C B D
A B C D
C A B A A C C B B D
B C C D
C A A C C C A A B C B C C B D
 Support for
 Response(A, B)
 1.0
 Precedence(A, B)
 0.818 (9/11)
 Pruning on the basis of a
support threshold
 E.g., 0.95
 A threshold equal to 1.0
for a constraint means
“always valid in the log”
SEITE 32 http://sourceforge.net/projects/prom/files/ProM/6.3

33. Declarative processes
Challenges

34. SEITE 34

35. Objective
SEITE 35

36. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 36

37. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 37
© Granger, NYC, source: https://www.granger.com/

38. Redundancies in discovered
constraints
 E.g.,
 A trace like
A B A B C A B C C
satisfies (w.r.t. A and B):
 RespondedExistence(A, B), RespondedExistence(B, A),
Response(A, B), AlternateResponse(A, B), ChainResponse(A, B),
Precedence(A, B), AlternatePrecedence(A, B), ChainPrecedence(A, B),
CoExistence(A, B), CoExistence(B, A),
Succession(A, B), AlternateSuccession(A, B), ChainSuccession(A, B)
 Among them, the mining algorithm should return only
the most restricting constraint – i.e., ChainSuccession(A, B)
 In order to face this issue, returned constraints
are pruned on the basis of the subsumption
hierarchy of constraints
SEITE 38

39. Pruning redundant constraints
1.0
1.0
1.0
1.01.0
1.0
1.0
1.0
1.0
1.0
1.0
✖
✖
✖
✖
✖
✖✖
✖✖
✖
SEITE 39

40. Pruning redundant constraints
0.8
0.8
0.9
0.90.9
0.9
0.7
0.7
0.9
0.9
0.9
✖ ✖
?
?
✖
✖
✖
?
?
S
u
p
p
o
r
t
✖
✖
✖
✖
SEITE 40

41. Mining declarative processes
RespondedExistence(A, B) 
RespondedExistence(A, C) ?
…
Response(A, B) 
Response(A, C) 
…
SEITE 41
Support Conf. I.F.

42. Mining declarative processes
RespondedExistence(A, B) 
RespondedExistence(A, C) ?
…
Response(A, B) 
Response(A, C) 
…
SEITE 42
Support Conf. I.F.

43. Mining declarative processes
RespondedExistence(A, B) 
RespondedExistence(A, C) 
…
Response(A, B) 
Response(A, C) 
…
SEITE 43
Support Conf. I.F.
http://github.com/cdc08x/minerful
Prom Nightly Builds > “Declare MINERful” plug-in
http://sourceforge.net/projects/prom/files/ProM/6.3

44. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 44

45. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
 Specify templates
Interlude
DECLARE & Regular Expressions
SEITE 45

46. Mining declarative processes
RespondedExistence(A, B)
RespondedExistence(A, C)
and
Response(A, B)
Response(A, C)
and
…
SEITE 46

47. Semantics of Declare:
Regular Expressions
SEITE 47

48. From constraints-based model
to FSA
SEITE 48
[^a]*((a.*b.*)|(b.*a.*))*[^a]* [^a]*(a.*c)*[^a]*

Regular
Expression
Deterministic
Finite
State
Automaton
RespondedExistence(A, B)
RespondedExistence(A, C)
and
Response(A, B)
Response(A, C)
and
…

49. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
Reprise
SEITE 49

50. While mining a real-life log…
SEITE 50

51. Time to challenge the X
SEITE 51


52. The result
SEITE 52

53. The problem
 When support threshold is lower than 100%,
constraints can be valid through most of the log, though being in conflict
 Example: an event log consists of two traces:
1. <A, B, A, B, A, B, C>
2. <A, B, A, B, A, C>
 Support threshold: 0.7
• a is always the first
 Init(A)
• c is always the last
 End(C)
• In 6 cases over 8 (75%), a and c do not directly follow
each other
 NotChainSuccession(A, C)
• In 5 cases over 7 (71.143%), b and c do not directly follow
each other
 NotChainSuccession(B, C)
SEITE 53

54. The problem
 When support threshold is lower than 100%,
constraints can be valid through most of the log, though being in conflict
 Example: an event log consists of two traces:
1. <A, B, A, B, A, B, C>
2. <A, B, A, B, A, C>
 Support threshold: 0.7
• a is always the first
 Init(A)
• c is always the last
 End(C)
• In 6 cases over 8 (75%), a and c do not directly follow
each other
 NotChainSuccession(A, C)
• In 5 cases over 7 (71.143%), a and b do not directly follow
each other
 NotChainSuccession(B, C)
 Question: what can be done right before C?
 inconsistency!
SEITE 54

55. The algorithm to detect
inconsistencies
SEITE 55

Init(a)
Participation(b)
AtMostOne(c)
End(c)
ChainPrecedence(a, b)
…
ChainSuccession(a, b)
Response(a, b)
ChainResponse(b, a)
NotChainSuccession(a, c)
ChainSuccession(b, a)
NotChainSuccession(b, c)
…
…
…
1

56. The algorithm to detect
inconsistencies

Init(a)
Participation(b)
AtMostOne(c)
End(c)
ChainPrecedence(a, b)
…
ChainSuccession(a, b)
Response(a, b)
ChainResponse(b, a)
NotChainSuccession(a, c) 
ChainSuccession(b, a)
NotChainSuccession(b, c)
…
…
…
1
2
SEITE 56 http://github.com/cdc08x/minerful

57. SEITE 57

58. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Increase the expressiveness of discovered
models
SEITE 58
© Granger, NYC, source: https://www.granger.com/

59. The application of the method
to minimise the model
 Rationale:
1. How to find redundancies among constraints?
 Use the automaton-model correspondence
 Same language recognised after the product?
 Main difference with the inconsistency-
checking algorithm
 Constraints having support 100% are checked for
redundancies
 More details in the paper
SEITE 59 http://github.com/cdc08x/minerful

60. The application of the method
to minimise the model
SEITE 60
BPIC 2012

61. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Inspect the imperative counterpart
 Simulate runs
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 61

62. From declarative to imperative
models
SEITE 62
Response(Queued, Accepted)
NotChainSuccession(Queued, Completed)
Response(Queued, Completed)
NotChainSuccession(Queued, Unmatched)
Response(Accepted, Completed)
End(Completed)
NotSuccession(Completed, Unmatched)
AtMostOne(Unmatched)
RespondedExistence(Unmatched, Accepted)
AlternateResponse(Unmatched, Completed)



…

63. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Inspect the imperative counterpart
 Simulate runs
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 63

64. Generation of logs
SEITE 64
http://github.com/cdc08x/minerful
http://github.com/processmining/synthetic-log-generator

65. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Inspect the imperative counterpart
 Simulate runs
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 65

66. Target-Branched Declare
Support for
 Response(A, {B, C})
 1.0
B A A B A B C D
A A D B B A A D C
B A D D A D D A B E
C A B C
D A D B D
A E A C
A A A D B
D A D D B D
A A A D C D
A D D D A C
A A B
E D E B C E E C B E
SEITE 66
Activation
Target
Branching factor = 2

67. Objective
SEITE 67
+ Expressive Power
+ Conciseness

68. Evaluation:
constraints pruning
SEITE 68
BPI Challenge 2012
(0) 6,654,480 (1) 10,676 (2) 1446 (3) 12

69. Evaluation:
performance
SEITE 69
BPI Challenge 2012
(KB) 00:07.274 (Const’s) 25:51.678 (Total) 26:11.380
http://github.com/cdc08x/minerful

70. Make mined models
intelligible
 Prune irrelevant/redundant information
 Detect inconsistencies (yes, it happens)
 Picture what the model tells
 Inspect the imperative counterpart
 Simulate runs
 Increase the expressiveness of discovered
models
 Specify templates
SEITE 70

71. Semantics of Declare:
LTL and LTLf
 Linear Temporal Logic (LTL) initially was a
specification language for the execution of
(endless) concurrent programs (Pnueli, 1977)
 Syntax (let A be a propositional symbol):
 DECLARE was initially based on LTL
SEITE 71
“Until”
“Eventually”“Always”
“Next”

72. Semantics of Declare:
LTL
SEITE 72

73. Declarative process modelling
 “Open model”
 Specify constraints for
permitted behaviour
 Every execution that
complies with them is
acceptable
 Works best with flexible
processes
 The set of DECLARE
templates is extendible
SEITE 73

74. Extendibility of DECLARE:
A clear business impact
SEITE 74
Source: http://businessvalueexchange.com/

75. Semantics of Declare:
LTL and LTLf
 Linear Temporal Logic (LTL) initially was a
specification language for the execution of
(endless) concurrent programs (Pnueli, 1977)
 Syntax (let A be a propositional symbol):
 Interpretation over infinite traces,
i.e., an infinite sequence of consecutive instants of time
 LTLf formulae are meant to be interpreted over
finite traces
“Until”
“Eventually”“Always”
“Next”
SEITE 75

76. Semantics of Declare:
LTLf
SEITE 76

77. Semantics of Declare:
SCIFF
SEITE 77

78. Semantics of Declare:
R/I-nets
SEITE 78

79. Semantics of Declare:
FOL over finite traces
SEITE 79

80. Semantics of Declare:
Regular expressions
SEITE 80

81. More alternatives for DECLARE
spec.: A clear business impact
SEITE 81
Source: http://businessconsultantsnewyork.blogspot.co.at/

82. My long-term objective
 Establish an algebra of constraint templates,
built on a basis of behavioural relations that
are:
 orthogonal to one another (no entailments,
subsumptions…)
 covering multiple trace-based behavioural relations
definition languages by linear composition
 have clear semantics (last but for sure NOT least)
 ...
SEITE 82

83. Further reading
 Presented:
 About MINERful:
 Claudio Di Ciccio, Massimo Mecella: On the Discovery of Declarative Control Flows for Artful Processes. ACM Trans.
Management Inf. Syst. 5(4): 24:1-24:37 (2015)
 Simulation of DECLARE models:
 Claudio Di Ciccio, Mario Luca Bernardi, Marta Cimitile, Fabrizio Maria Maggi: Generating Event Logs Through the
Simulation of Declare Models. EOMAS@CAiSE 2015: 20-36
 Discovery of target-branched DECLARE models:
 Claudio Di Ciccio, Fabrizio Maria Maggi, Jan Mendling: Efficient discovery of Target-Branched Declare constraints. Inf.
Syst. 56: 258-283 (2016)
 Getting rid of redundancies and inconsistencies:
 Claudio Di Ciccio, Fabrizio Maria Maggi, Marco Montali, Jan Mendling: Ensuring Model Consistency in Declarative
Process Discovery. BPM 2015: 144-159
 From DECLARE to Petri nets:
 Johannes Prescher, Claudio Di Ciccio, Jan Mendling: From Declarative Processes to Imperative Models. SIMPDA 2014:
162-173
 More:
 First steps towards data awareness of discovered DECLARE models:
 Stefan Schönig, Claudio Di Ciccio, Fabrizio Maria Maggi, Jan Mendling: Discovery of Multi-perspective Declarative
Process Models. ICSOC 2016: 87-103
 Against the little learnibility of DECLARE:
 Michael Hanser, Claudio Di Ciccio, Jan Mendling: A New Notational Framework for Declarative Process Modeling.
Softwaretechnik-Trends 36(2) (2016)
 Guarantee of the significance of discovered DECLARE models:
 Fabrizio Maria Maggi, Marco Montali, Claudio Di Ciccio, Jan Mendling: Semantical Vacuity Detection in Declarative
Process Mining. BPM 2016: 158-175
SEITE 83
