Smart Shipment Box is a project about home automation. that designed to facilitate the user to takes or keeps an item. the box can be controlled by smartphone via bluetooth.

1. I N S T R U M E N T A T I O N
SMART SHIPMENT BOX
( H o m e A u t o m a t i o n )

2. INTRODUCTION

3. LET US TO INTRODUCE OURSELVES!
FATHAN FARIZA RACCHEL RIYANTO
“Life is a Chance” “Your Life Depends of What
You Choose”

4. RESULT THE PROJ ECT
Smart Shipment Box – Home Automation

5. SMART
SHIPMENT BOX
6
1
2
5 3
4
LOOKING FOR IDEA OF PROJECT
LOOKING FOR SOURCE
TUTORIAL
LOOKING FOR TOOLS AND
MATERIAL
UPLOAD VIDEO, UPLOAD
SLIDE, AND MAKE REPORT
CREATE THE VIDEO AND
POWER POINT SLIDE
BUILD THE PROJECT
STEPS

6. in contemporary times most people always want instant, fast, and
not boring to meet their needs. one of them in terms of taking an
item. when a person is too lazy to move because he was tired or too
lazy while he wanted to take items such as bottles, food, or anything
else. it requires the sender of an item that can be controlled from a
distance. therefore we make SMART TECHNOLOGY SHIPMENT
BOX that can be controlled with a smartphone-based microcontroller
arduino uno.
T H E
B A C K G R O U N D
O F P R O J E C T

7. The purpose in the making of this project is to allow students :
1. Knowing and Understanding the function each components
2. Knowing the work principles the components
3. Can assemble and make the circuit to the microcontroller.
4. Can create programs to run the project created.
P U R P O S E T H E
P R O J E C T

8. R E F E R E N C E I D E A
1. Arduino Project Tutorial 09 - RC Car Control via Bluetooth (with Smartphone)
Links : https://www.youtube.com/watch?v=AkxwExdnXAE&t=14s

9. M O D I F I C A T I O N I D E A
From that video using smartphone to control the RC Car by Bluetooth. We modificate it
and create a box as body of RC Car. The function of that box is for keep and delivery an
item such as water bottle, food, and else.

10. Smart Shipment Box
“Delivery Your Thing as Fast as Wink”
Easy FunFast

11. COMPONENTS

12. A R D U I N O U N O
Arduino/Genuino Uno is a microcontroller board based on the ATmega328P. It has 14 digital input/output pins (of
which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz quartz crystal, a USB connection, a power
jack, an ICSP header and a reset button
Microcontroller

13. L 2 9 3 D M O T O R S H I E L D
The function of Motor Shield is to drive DC and servo.

14. B L U E T O O T H M O D U L E
The function of bluetooth module to link a device to another device
Model HC-05

15. M O T O R D C
Motor DC is one of motor that using DC Voltage as source energy. with gives different voltage
to both terminal. will rotate direct current, but if the polarity excanged the direct rotation will
change too.

16. B A T T E R Y 1 . 5 V
Battery is supply to give energy
4 Pieces

17. W I R E S
Wire is an item to connect between pins.
10 Wires

18. W I R I N G
Wiring for Smart Shipment Box

19. 1
2
3
4
Installing Arduino Program
Can be downloaded from www.arduino.cc
Decide the Board and Port
Click Tools Tab - Board – Choose Arduino UNO
Click Tools Tab – Port – Choose the connected port
Add the Library
The L293D Motor Shield has a library. Move the library
to folder library in Arduino folder
Wiring
Compose the circuit of the project
♦ ♦ ♦
STAGE OF WORK

20. 5
6
7
8
Coding
Type the coding, then compile, and last
upload it.
Design the Body Project
The used material is Acrylic 2mm.
Sketch, Cut, and Build it up
Decorate
Decorate the body project so looks nice
Testing
Testing the project whether work or not.
♦ ♦ ♦
STAGE OF WORK

21. C O D I N G

22. S m a r t p h o n e A p p l i c a t i o n

23. T e s t i n g S t e p s
Turn On
Switch
Put or Take
an Item
Open
Application
Trying the
controller
Connect
Bluetooth
Turn OFF
swith
Supply from battery
enter to system.
LED from Motor
Shield turn on.
LED from Bluetooth
turn on.
You can put inside
the item to box, or
take the item from
the box
Open application
“ARDUINO ROBOT”
on smartphone
Click forward to
move the project
forward.
Click bacward to
move the project
backward.
Click Right to move
the project to right
Click Left to move
the project to left
Choose the
bluetooth tab on
application
If you have finish
playing that smart
shipment box, turn
off the switch so the
project is off and
can’t be controlled.

24. T H A N K Y O U !
F o r A t t e n t i o n
A n y Q u e s t i o n
