1. Extended
Seoul
Architecture Components
alpaca@vcnc.co.kr

2. Speaker
• (@plazgun)
• Between Android Developer

3. Architecture Components
• Google I/O 2017
Architecture Components - Introduction
Architecture Components - Solving the Lifecycle
Architecture Components - Persistence and Offline
•
• https://developer.android.com/topic/libraries/architecture/
index.html

4. Architecture Components
• Handling Lifecycles
• LiveData
• ViewModel
• Room

5. build.gradle
• allprojects {
repositories {
jcenter()
maven { url 'https://maven.google.com' }
}
}
• compile "android.arch.lifecycle:runtime:1.0.0-alpha3"
compile "android.arch.lifecycle:extensions:1.0.0-alpha3"
annotationProcessor "android.arch.lifecycle:compiler:1.0.0-alpha3"
• compile "android.arch.persistence.room:runtime:1.0.0-alpha3"
annotationProcessor "android.arch.persistence.room:compiler:1.0.0-alpha3"
• compile "android.arch.persistence.room:rxjava2:1.0.0-alpha3"
testCompile "android.arch.persistence.room:testing:1.0.0-alpha3"

6. Handling Lifecycles

7. public class MyActivity extends AppCompatActivity {
private TestListener testListener;
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
testListener = new TestListener();
}
@Override
protected void onStart() {
super.onStart();
testListener.start();
}
@Override
protected void onStop() {
super.onStop();
testListener.stop();
}
}

8. public class MyActivity extends AppCompatActivity {
private TestListener testListener;
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
testListener = new TestListener();
}
@Override
protected void onStart() {
super.onStart();
testListener.start();
}
@Override
protected void onStop() {
super.onStop();
testListener.stop();
}
}
onStart
Override .

9. Lifecycle .

10. Handling Lifecycles
• Lifecycle
• LifecycleOwner
• LifecycleObserver

11. public class MyActivity extends LifecycleActivity {
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_lifecycle);
TestListener testListener = new TestListener(
getLifecycle(),
result -> {
// update UI
});
}
}

12. public class TestListener implements LifecycleObserver {
private Lifecycle lifecycle;
public TestListener(Lifecycle lifecycle, TestCallback callback) {
lifecycle.addObserver(this);
this.lifecycle = lifecycle;
}
@OnLifecycleEvent(Lifecycle.Event.ON_START)
void start() {
// start Event
}
@OnLifecycleEvent(Lifecycle.Event.ON_DESTROY)
void clean() {
lifecycle.removeObserver(this);
}
}

13. public class MyActivity extends CustomActivity {
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
}
}

14. public class LifecycleActivity extends FragmentActivity
implements LifecycleRegistryOwner {
private final LifecycleRegistry mRegistry
= new LifecycleRegistry(this);
@Override
public LifecycleRegistry getLifecycle() {
return mRegistry;
}
}

15. public class MyActivity extends CustomActivity implements LifecycleRegistryOwner {
private final LifecycleRegistry lifecycleRegistry = new LifecycleRegistry(this);
@Override
public LifecycleRegistry getLifecycle() {
return lifecycleRegistry;
}
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_lifecycle);
TestListener testListener = new TestListener(getLifecycle(), state -> {
// update Ui
});
}
}

17. public class MyActivity extends LifecycleActivity {
private TestListener testListener;
@Override
protected void onStart() {
super.onStart();
Utils.checkUserStatus(state -> {
if (state.equals("OK")) {
testListener.start();
}
});
}

18. public class MyActivity extends LifecycleActivity {
private TestListener testListener;
@Override
protected void onStart() {
super.onStart();
// ?
Utils.checkUserStatus(state -> {
if (state.equals("OK")) {
testListener.start();
}
});
}

19. StartCreate Resume Pause Stop Destroy
testListener.stop
Utils.checkStatus testListener.start

20. Activity .

21. public class MyActivity extends LifecycleActivity {
private TestListener testListener;
@Override
protected void onStart() {
super.onStart();
Utils.checkUserStatus(state -> {
if (state.equals("OK") && getLifecycle()
.getCurrentState()
.isAtLeast(Lifecycle.State.STARTED)) {
testListener.start();
}
});
}

22. LiveData

23. LiveData
• Observable Data Holder
• Lifecycle aware
• Automatic subscription management

24. LiveData<String> stateData = new MutableLiveData<>();
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
stateData.observe((LifecycleOwner) this, ((String) result) -> {
// stateData .
});
}
@Override
protected void onStart() {
super.onStart();
stateData.setValue(“Start");
}

25. public class StateChangeLiveData extends MutableLiveData<String> {
@Override
protected void onActive() {
super.onActive();
// Active Observer
// Active: Lifecycle.State STARTED RESUMED
}
@Override
protected void onInactive() {
super.onInactive();
// Active Observer
}
}

26. ViewModel

27. public class MyActivity extends LifecycleActivity {
LiveData<User> userData;
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
userData = userRepository.fetchData();
userData.observe(this, user -> {
// update UI
});
}
}

28. StartCreate Resume Pause Stop Destroy
Rotated
fetchData
StartCreate Resume
fetchData

29. Activity
.

30. ViewModel
The ViewModel class is designed to store
and manage UI-related data so that the
data survives configuration changes such
as screen rotations.
”
“

31. public class UserViewModel extends ViewModel {
}
public class UserViewModel extends AndroidViewModel {
// Application ViewModel
}

32. ViewModel
•
• ActivityContext
• Resource

33. public class MyActivity extends LifecycleActivity {
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.insert_activity);
// ViewModelStore ViewModel .
UserListViewModel viewModel = ViewModelProviders.of(this)
.get(UserListViewModel.class);

34. public class MyActivity extends LifecycleActivity {
@Override
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
ViewModelProviders.of(this).get(UserListViewModel.class)
.getData()
.observe(this, user -> {
//update UI
});
public class UserListViewModel extends ViewModel {
private LiveData<User> userLiveData;
public LiveData<User> getData() {
if (userLiveData == null) {
userLiveData = userRepository.fetchData();
}
return userLiveData;
}
}

35. StartCreate Resume Pause Stop Destroy
Rotated
fetchData
StartCreate Resume
fetchData

36. StartCreate Resume Pause Stop Destroy
Rotated
StartCreate Resume
ViewModel
fetchData
getData getData

37. Room

38. Room
• Sqlite ORM
• Entity
• Dao
• Database

39. id name create_time
@Entity
public class User {
@PrimaryKey(autoGenerate = true)
private Long id;
String name;
@ColumnInfo(name = "created_time")
private long createdTime;
@Ignore
Bitmap profile;
}
Entity

40. DAO
@Dao
public interface UserDao {
@Query("SELECT * FROM user")
List<User> getAll();
@Query("SELECT * FROM user WHERE id IN (:userIds)")
List<User> loadAllByIds(int[] userIds);
@Query("SELECT * FROM user WHERE name LIKE :first LIMIT 1")
User findByName(String first);
@Insert(onConflict = OnConflictStrategy.REPLACE)
void insertAll(User... users);
@Delete
void delete(User user);
@Update
void updateUser(User user);

41. DAO (Rx, LiveData)
@Query("SELECT * FROM user")
LiveData<List<User>> getAllSync();
@Query("SELECT * FROM user WHERE id = :userId")
LiveData<User> fetchUser(String userId);
@Query("SELECT * from user where id = :id LIMIT 1")
Flowable<User> loadUserByIdRx(int id);
@Query("SELECT * FROM user WHERE age > :minAge LIMIT 5")
Cursor loadRawUsersOlderThan(int minAge);

42. Database
@Database(entities = {User.class, Book.class}, version = 1)
public abstract class AppDatabase extends RoomDatabase {
public abstract UserDao userDao();
public abstract BookDao bookDao();
}

43. Entity - Embedded
id name created_time image_id image_width image_height
public class Image {
String id;
Integer width;
Integer height;
}
@Entity
public class User {
@PrimaryKey(autoGenerate = true)
private Long id;
String name;
@Embedded(prefix = "image_")
private Image image;
@ColumnInfo(name = "created_time")
private long createdTime;

44. Entity - TypeConverter
public class User {
@PrimaryKey
private Long id;
@TypeConverters(Converters.class)
private Date date;
public class Converters {
@TypeConverter
public static Date toDate(Long timestamp) {
return timestamp == null ? null :
new Date(timestamp);
}
@TypeConverter
public static Long toTimestamp(Date date) {
return date == null ? null : date.getTime();
}
}

45. Entity - Relation
@Entity(indices = {@Index(value = "id", unique = true)},
foreignKeys = {
@ForeignKey(entity = Book.class,
parentColumns = "id",
childColumns = "bookId",
onDelete = ForeignKey.CASCADE)
})
public class User {
@PrimaryKey(autoGenerate = true)
private Long id;
public Long bookId;
}

46. public class UserDao_Impl implements UserDao {
private final RoomDatabase __db;
private final EntityInsertionAdapter __insertionAdapterOfUser;
private final EntityDeletionOrUpdateAdapter __deletionAdapterOfUser;
private final EntityDeletionOrUpdateAdapter __updateAdapterOfUser;
public UserDao_Impl(RoomDatabase __db) {
this.__db = __db;
this.__insertionAdapterOfUser = new EntityInsertionAdapter<User>(__db) {
@Override
public String createQuery() {
return "INSERT OR REPLACE INTO
`User`(`id`,`name`,`created_time`,`updated_time`,`age`,`bookId`,`image_id`,`image_width`,`image_height`) VALUES
(?,?,?,?,?,?,?,?,?)";
}
@Override
public void bind(SupportSQLiteStatement stmt, User value) {
if (value.getId() == null) {
stmt.bindNull(1);
} else {
stmt.bindLong(1, value.getId());
}
if (value.getName() == null) {
stmt.bindNull(2);
} else {
stmt.bindString(2, value.getName());
}
stmt.bindLong(3, value.getCreatedTime());
if (value.getUpdatedTime() == null) {
stmt.bindNull(4);
} else {
stmt.bindLong(4, value.getUpdatedTime());
}

47. Error
@Query("SELECT * FROM users”)
List<User> getAll();

48. Architecture Components
• Handling Lifecycles
• LiveData
• ViewModel
• Room

49. • RxJava
• greenDAO ( Realm)
• MVP
• Firebase, Retrofit, Dagger, ButterKnife, Fresco, Glide, Mockito …

50. Android Lifecycle Components
vs
ReactiveX

51. public class TestActivity extends RxFragmentActivity {
@Override
protected void onCreate(@Nullable Bundle b) {
super.onCreate(savedInstanceState);
lifecycle()
.filter(e -> e == ActivityEvent.START)
.subscribe(e -> {
// on start
});
}
}
public class TestActivity extends LifecycleActivity
implements LifecycleObserver {
@Override
protected void onCreate(@Nullable Bundle b) {
super.onCreate(savedInstanceState);
getLifecycle().addObserver(this);
}
@OnLifecycleEvent(Lifecycle.Event.ON_START)
void start() {
// on start
}
}
LifecycleOwner RxLifecycle

52. public abstract class RxFragmentActivity
extends FragmentActivity
implements LifecycleProvider<ActivityEvent> {
private final BehaviorSubject<ActivityEvent> lifecycleSubject
= BehaviorSubject.create();
@Override
@NonNull
@CheckResult
public final Observable<ActivityEvent> lifecycle() {
return lifecycleSubject.asObservable();
}
@Override
@CallSuper
protected void onCreate(@Nullable Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
lifecycleSubject.onNext(ActivityEvent.CREATE);
}
@Override
@CallSuper
protected void onStart() {
super.onStart();
lifecycleSubject.onNext(ActivityEvent.START);
}
}
public class LifecycleActivity extends FragmentActivity
implements LifecycleRegistryOwner {
private final LifecycleRegistry mRegistry
= new LifecycleRegistry(this);
@Override
public LifecycleRegistry getLifecycle() {
return mRegistry;
}
}
LifecycleActivity RxFragmentActivity

53. public class TestActivity extends RxFragmentActivity {
@Override
protected void onCreate(@Nullable Bundle b) {
super.onCreate(savedInstanceState);
Flowable<Long> data = getData();
data.compose(RxLifecycle.bindUntilEvent(
lifecycle(), ActivityEvent.DESTROY))
.subscribe(d -> {
// update ui
});
}
}
public class TestActivity extends LifecycleActivity {
@Override
protected void onCreate(@Nullable Bundle b) {
super.onCreate(savedInstanceState);
LiveData<Long> data = getData();
data.observe(this, result -> {
// update ui
});
}
}
LiveData RxFlowable

54. Don’t migrate from RxJava
But be sure that you correctly handle lifecycle.
”
“

55. Room vs greenDAO vs Realm

56. @Entity
public class RoomUser {
@PrimaryKey
private long id;
// getter & setter
}
Room
greenDAO
Realm
@Entity
public class GreenUser {
@Id
private long id;
// getter & setter
}
public class RealmUser extends RealmObject {
@PrimaryKey
private long id;
// getter & setter
}

57. @Entity(tableName = "user")
public class RoomUser {
@ColumnInfo(name = “first_name")
private String firstName;
}
@Entity(nameInDb = "user")
public class GreenUser {
@Property(nameInDb = “first_name")
private String firstName;
}
Room
greenDAO
Realm

58. @Entity(indices = @Index(“address"))
public class RoomUser {
private String address;
@Ignore
private String sessionId;
}
@Entity(indexes = @Index("address DESC"))
public class GreenUser {
private String address;
@Transient
private String sessionId;
}
public class RealmUser extends RealmObject {
@Index
private String address;
@Ignore
private String sessionId;
}
Room
greenDAO
Realm

59. @Dao
public interface RoomUserDao {
@Query("SELECT * FROM RoomUser WHERE id > 10 ORDER BY id DESC”)
List<RoomUser> getUsers();
}
public class GreenUseCase {
public List<GreenUser> getUsers() {
// get DaoSession
return new daoSession.getGreenUserDao().queryBuilder()
.where(GreenUserDao.Properties.Id.gt(10))
.orderDesc(GreenUserDao.Properties.Id)
.list();
}
}
public class RealmUseCase {
public RealmResults<RealmUser> getUsers() {
// get realm instance
return realm.where(RealmUser.class)
.greaterThan("id", 10)
.findAllSorted("id", Sort.DESCENDING);
}
}
Room
greenDAO
Realm

60. public class AndroidUser {
private String userId;
private String groupID;
}
public class AndroidGroup {
private String groupId;
private String groupName;
private List<AndroidUser> roomUser;
}
Relation

61. @Entity
public class RoomGroup {
@PrimaryKey
private long id;
}
@Entity(foreignKeys = @ForeignKey(
entity = RoomGroup.class,
parentColumns = "id",
childColumns = "groupId"))
public class RoomUser {
@PrimaryKey
private long id;
private long groupId;
}
https://developer.android.com/topic/libraries/architecture/room.html#no-object-references
Relation - Room
@Dao
public interface RoomGroupDao {
@Insert(onConflict = OnConflictStrategy.REPLACE)
void insertGroup(RoomGroup group);
@Query("SELECT * FROM RoomGroup WHERE id = :id")
LiveData<RoomGroup> getGroup(long id);
}
@Dao
public interface RoomUserDao {
@Insert(onConflict = OnConflictStrategy.REPLACE)
void insertUsers(List<RoomUser> users);
@Query("SELECT * FROM RoomUser WHERE groupId = :groupId")
LiveData<List<RoomUser>> getUsers(long groupId);
}

62. @Entity
public class GreenGroup {
@Id
private long id;
@ToMany(referencedJoinProperty
= "groupId")
private List<GreenUser> users;
}
@Entity
public class GreenUser {
@Id
private long id;
private long groupId;
}
Relation - greenDAO
public class GreenUseCase {
public void insertGroup(GreenGroup group) {
daoSession.getGreenGroupDao()
.insertOrReplace(group);
daoSession.getGreenUserDao()
.insertOrReplaceInTx(group.getUsers());
}
public GreenGroup getGroup(long groupId) {
return daoSession.getGreenGroupDao()
.queryBuilder()
.where(GreenGroupDao.Properties.Id.eq(groupId))
.build()
.unique();
}
}

63. public class RealmGroup extends RealmObject {
@PrimaryKey
private long id;
RealmList<RealmUser> users;
}
public class RealmUser extends RealmObject {
@PrimaryKey
private long id;
}
Relation - Realm
public class RealmUseCase {
public void insertGroup(RealmGroup group) {
realm.insertOrUpdate(group);
}
public RealmGroup getGroup(long groupId) {
return realm.where(RealmGroup.class)
.equalTo("id", groupId)
.findFirst();
}
}

64. Realm GreenDao Room
Core Native Library SQLite SQLite
Performance Realm Realm
Relation
.
QueryBuilder X
DeepInsert X X
LazyLoading X
Integration Rx Rx, LiveData, Cursor

65. https://youtu.be/FrteWKKVyzI
https://youtu.be/bEKNi1JOrNs
https://youtu.be/MfHsPGQ6bgE
https://developer.android.com/topic/libraries/architecture/index.html
alpaca@vcnc.co.kr

66. • http://engineering.vcnc.co.kr/jobs/
