Architecting Applications on Amazon Web Services with Node.js In this talk we will learn about how to build applications on AWS that leverage some of the most commonly used service offerings including EC2, Lambda, VPC, S3, API Gateway, IAM, CloudFront, DynamoDB and Cognito.

1. Architecting Applications on
Amazon Web Services with Node.js

2. Speaker: Henry Fougere
Current Role:
Director, Tech Lead, Software Engineering & Delivery
Experience:
15+ Years Full Stack Developer
5 Years Using AWS
When I’m not doing technology stuff, I enjoy:
Marathon Running
Photography
Graphic Design
Tennis, Soccer
Longs walks on the beach

3. What are we building today???

4. VPC - Virtual Private Cloud
10.0.0.0/26
Start: 10.0.0.0
2^ (32-26) = 2^ 6 = 64
End: 10.0.0.63
Internet Gateway: communication between
instances in VPC and the Internet
horizontally scaled, redundant, highly available
- Default VPC has an Internet Gateway
- 1 IGW per VPC
- VPC spans all availability zones
Route Tables: contain a set of rules called routes
that determine where traffic is directed
- restricted to 1 availability zone

5. VPC
(cont.)

6. VPC - Virtual Private Cloud

7. ● Fully managed NoSQL database service
● Provides fast and predictable performance
● Don't have to worry about hardware provisioning, setup and configuration, replication, software
patching, or cluster scaling
● Core components: Tables, Items, and Attributes
● Partition key – A simple primary key
● Partition key and sort key – Referred to as a composite primary key
DynamoDB

8. DynamoDB

9. ● First service launched by Amazon back in 2006
● S3 is used to store and retrieve any amount of data at any time
● Can be integrated with other services such as Lambda and CloudFront.
● Amazon S3 objects can range in size from a minimum of 0 bytes to a maximum of 5 terabytes.
● The largest object that can be uploaded in a single PUT is 5 gigabytes.
● There are three highly durable storage classes:
○ Amazon S3 Standard for general-purpose storage of frequently accessed data
○ Amazon S3 Standard - Infrequent Access for long-lived, but less frequently accessed data
○ Amazon Glacier for long-term archive.
S3 (Simple Storage Service)

10. S3 (Simple Storage Service)

11. ● Amazon CloudFront is a global content delivery network (CDN) service
● Deep Integration with key AWS Services such as Amazon S3, AWS Lambda and API Gateway
● Securely delivers data, videos, applications, and APIs to your viewers with low latency and high
transfer speeds.
● Optimized for low latency and high data transfer speeds.
CloudFront (CDN)

12. CloudFront (CDN)

13. ● Securely control access to AWS services and resources
● Create and manage users and groups
● Use permissions to allow and deny access to AWS resources.
● IAM is a feature of your AWS account offered at no additional charge.
● You will be charged only for use of other AWS services by your users.
IAM - Identity and Access Management

14. IAM - Identity and Access Management

15. ● Run code without provisioning or managing servers.
● You pay only for time your code is running.
● Run code for any type of application or backend service - all with zero administration.
● Takes care of everything required to run and scale your code with high availability.
● Set up your code to automatically trigger from other AWS services or call it directly from any web or
mobile app.
Lambda

16. Lambda

17. ● Run code without provisioning or managing servers.
● You pay only for time your code is running.
● Run code for any type of application or backend service - all with zero administration.
● Takes care of everything required to run and scale your code with high availability.
● Set up your code to automatically trigger from other AWS services or call it directly from any web or
mobile app.
API Gateway

18. API Gateway

19. ● Add user sign-up and sign-in to your mobile and web apps
● Federate identities and provide secure access to AWS resources
● Store and sync across devices
Cognito Identity

20. Cognito Identity

21. ● Secure, resizable compute capacity in the cloud.
● Configure capacity with minimal friction.
● Reduces time required to obtain and boot new server instances to minutes
● Quickly scale capacity up and down, as computing requirements change.
● Pay only for capacity that you actually use.
EC2 - Elastic Compute Cloud

22. EC2 - Elastic Compute Cloud

23. Cloud Computing Tips...
● Be sure to deprovision resources as needed.
● Grant Least Privilege
● Lock Away Account Access Keys, and Passwords. Don’t not share them by any means
● Create Individual IAM Users
● Use Groups to Assign Permissions to IAM Users
● Configure a Strong Password Policy
● Rotate Credentials Regularly
● Remove Unnecessary Credentials
● Monitor Activity in Your AWS Account

24. Thank You!
Henry Fougere
hfougere@yahoo.com
