The document discusses APC NetShelter rack enclosures and open frame racks for server and networking applications. It describes the NetShelter SX rack enclosures which provide cooling, power distribution, cable management and environmental monitoring. It guarantees equipment compatibility and is certified for use with InfraStruXure architecture. It also describes the NetShelter WX wall-mounted enclosures and NetShelter 2-post and 4-post open frame racks.
The document discusses outdoor wireless network engineering, including access network examples like university campus coverage and high-density outdoor plazas, as well as mesh network examples. It covers topics like bridging versus routing approaches, design best practices, and installation considerations. Specific case studies are presented on extending a university campus network outdoors and providing high-density wireless access in an outdoor plaza setting.
Kali Linux Installation - VMware
Kali Linux is an advanced Penetration Testing and Security Auditing Linux distribution.
Preinstalled with numerous penetration-testing programs.
The document discusses wide area network (WAN) technologies and Cisco's Enterprise Composite Model (ECNM) for integrated WAN services. It aims to describe how ECNM provides services across an enterprise network, identify key WAN concepts, and determine the appropriate WAN technologies to match ECNM practices with enterprise requirements. Specific topics covered include WAN definitions and functions, stages of business growth and their network needs, problems with traditional network models, Cisco enterprise architectures, WAN protocols and switching, and factors for selecting WAN connections.
VirtualBox allows users to install multiple guest operating systems on a single machine. The document outlines the steps to install VirtualBox and then install Ubuntu 13.04 as a guest OS. It describes downloading and installing VirtualBox, creating a virtual machine, configuring settings like memory and storage, and then walking through the Ubuntu installation process by selecting options and components. The summary provides a high-level overview of the key steps involved in setting up Ubuntu as a virtual machine on VirtualBox.
TIA-942 is a data center design standard that provides guidelines for key areas like spaces, cabling, electrical systems, cooling, and tier classifications. It defines five functional space areas and recommends separating them where possible. The standard also covers best practices for racks and cabinets, structured cabling layouts, electrical considerations, and choosing appropriate cooling based on calculated heat loads. It establishes a four-tier system for classifying data centers based on resilience and capacity of mechanical, electrical, and plumbing systems. Proper implementation of TIA-942 helps standardize designs and allows facilities to be reliably compared.
** Edureka Certification Training: https://www.edureka.co **
This Edureka "VMware Tutorial for Beginners” video will give you a thorough and insightful overview of Virtualization and help you understand other related terms that revolve around VMware and Virtualization. Following are the offering of this video:
1. What is VMware?
2. What is Virtualization?
3. Types Of Virtualization
4. What Is Hypervisor?
5. Hypervisor Types
6. Demo- Creating a VM using VMware Workstation Player
Have you ever dreamed to have an "MKSYSB like" solution to quickly backup/restore your Linux on Power ?
If the answer is YES, the opensource solution named Relax and Recover (ReaR) may be for you.
Come to this session to learn more about how to implement and the capabilities of this solution through presentation and live demonstration.
The document discusses outdoor wireless network engineering, including access network examples like university campus coverage and high-density outdoor plazas, as well as mesh network examples. It covers topics like bridging versus routing approaches, design best practices, and installation considerations. Specific case studies are presented on extending a university campus network outdoors and providing high-density wireless access in an outdoor plaza setting.
Kali Linux Installation - VMware
Kali Linux is an advanced Penetration Testing and Security Auditing Linux distribution.
Preinstalled with numerous penetration-testing programs.
The document discusses wide area network (WAN) technologies and Cisco's Enterprise Composite Model (ECNM) for integrated WAN services. It aims to describe how ECNM provides services across an enterprise network, identify key WAN concepts, and determine the appropriate WAN technologies to match ECNM practices with enterprise requirements. Specific topics covered include WAN definitions and functions, stages of business growth and their network needs, problems with traditional network models, Cisco enterprise architectures, WAN protocols and switching, and factors for selecting WAN connections.
VirtualBox allows users to install multiple guest operating systems on a single machine. The document outlines the steps to install VirtualBox and then install Ubuntu 13.04 as a guest OS. It describes downloading and installing VirtualBox, creating a virtual machine, configuring settings like memory and storage, and then walking through the Ubuntu installation process by selecting options and components. The summary provides a high-level overview of the key steps involved in setting up Ubuntu as a virtual machine on VirtualBox.
TIA-942 is a data center design standard that provides guidelines for key areas like spaces, cabling, electrical systems, cooling, and tier classifications. It defines five functional space areas and recommends separating them where possible. The standard also covers best practices for racks and cabinets, structured cabling layouts, electrical considerations, and choosing appropriate cooling based on calculated heat loads. It establishes a four-tier system for classifying data centers based on resilience and capacity of mechanical, electrical, and plumbing systems. Proper implementation of TIA-942 helps standardize designs and allows facilities to be reliably compared.
** Edureka Certification Training: https://www.edureka.co **
This Edureka "VMware Tutorial for Beginners” video will give you a thorough and insightful overview of Virtualization and help you understand other related terms that revolve around VMware and Virtualization. Following are the offering of this video:
1. What is VMware?
2. What is Virtualization?
3. Types Of Virtualization
4. What Is Hypervisor?
5. Hypervisor Types
6. Demo- Creating a VM using VMware Workstation Player
Have you ever dreamed to have an "MKSYSB like" solution to quickly backup/restore your Linux on Power ?
If the answer is YES, the opensource solution named Relax and Recover (ReaR) may be for you.
Come to this session to learn more about how to implement and the capabilities of this solution through presentation and live demonstration.
The document provides step-by-step instructions for performing a password recovery on a Cisco 2960X switch. It explains that to begin, the mode button must be held for 30-40 seconds during power up until "USB Console INIT" appears. Then the flash_init and dir flash: commands allow renaming the config.text file. Reloading the switch ignores the startup config and allows changing passwords before copying the renamed file back.
This document discusses virtual machine creation and management topics including vNetwork, vStorage, vMotion, DRS, and high availability (HA). It covers virtual machine hardware configuration, the files that make up a virtual machine, VMware Tools, and virtual machine power options. It also summarizes storage protocols, thin and thick provisioning, methods for migrating virtual machines, and how vMotion and DRS work. Finally, it discusses HA features like protection at different availability levels, using NIC teaming or additional networks for redundancy, and how the HA cluster architecture functions with a master and slave agents.
Virtualization allows multiple operating systems and applications to run on the same physical server at the same time. This increases hardware utilization and flexibility while reducing IT costs. VMware virtualization solutions can reduce energy costs by 80% through server consolidation and powering down unused servers without affecting applications or users. Virtualization makes hardware resources independent of operating systems and applications, treating them as single unified units that can be more easily deployed, maintained, and supported.
This document provides an overview of server virtualization and its benefits for Madison Plains Local School District. It discusses how virtualization can help lower costs by consolidating servers and improving hardware utilization. Specific benefits mentioned include reducing the number of physical servers needed, lowering power consumption, gaining hardware independence for virtual machines, and isolating virtual machines for improved security. The document also shows how most applications see performance on par with physical machines when run virtually. It promotes developing a plan that assesses the current infrastructure and provides a roadmap for virtualizing servers.
This document provides an overview of VMware Cloud Foundation on Dell VxRail. It discusses the key benefits of the solution such as simplified operations through automation, a modern hybrid cloud platform, and choice of financial consumption models. It covers various technical aspects of the solution including workload domains, deployment options, lifecycle management, networking and security considerations, and integration with Tanzu for modern applications. Sections are included on initial deployment, day 2 operations, networking topology, host configuration, and the Tanzu framework.
Data Center Floor Design - Your Layout Can Save of Kill Your PUE & Cooling Ef...Maria Demitras
Implementing data center best practices and using CFD models allowed Great Lakes to suggest a data center layout that would improve PUE and efficiency. Jason Hallenbeck, DCDC, explains the concepts behind how data center floor design can save or kill your PUE and cooling efficiency—as found in this proposal. Find Jason presenting at the BICSI Fall Conference on September 14th at 1:30 pm.
Are you new to Nutanix? Jump into this introductory product session to learn the fundamentals of Nutanix Enterprise Cloud software and its key capabilities. A couple Nutanix experts will demonstrate how Nutanix delivers a complete cloud “stack” with the server, storage virtualization and network resources to run any application. Learn the basics of hyperconverged infrastructure, and understand how to deploy Nutanix in your datacenter or branch/remote office.
MAAS & Ubuntu Core: OCP Tech Day, Facebook Menlo Park, Aug 30thChristian "kiko" Reis
An overview of MAAS, a flexible bare-metal provisioning system that manages DHCP, DNS and PXE services, drives chassis and BMCs, and deploys of CentOS, RHEL, Ubuntu, Windows and more. Presented at the latest OCP Tech Day on August 30th 2016.
Nutanix NEXT on Tour - Maarssen, Netherlands NEXTtour
The document provides an agenda for a Nutanix .NEXT event, including keynote speeches on Nutanix products and use cases from HERO and OGD. It discusses Nutanix adoption in Europe, the benefits of hyperconverged infrastructure, and Nutanix products like Acropolis and Prism. Later presentations will provide overviews of Nutanix deployments at HERO and OGD, focusing on simplified management and improved performance.
In this presentation, we will be sharing a collection of several vital configuration tips and tricks which are widely implemented across mid-size to large enterprise WLAN. Our primary focus would be on Security as well as Performance characteristics of Aruba WLAN networks. Check out the webinar recording where this presentation was used: https://community.arubanetworks.com/t5/Wireless-Access/Airheads-Technical-Webinar-Recording-Slides-Aruba-OS/m-p/277294
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
This document provides an agenda for a presentation on HP Blade technology. The agenda includes introductions to HP Blade chassis, onboard administrators, Virtual Connect Flex-10 modules, Cisco modules, system management tools, different types of Aurora servers, storage servers, and cluster configuration. It also discusses NTP server configuration, questions, and demonstrations of HP Blade hardware components and management modules.
This presentation will show how ArubaOS architecture has evolved and been modernized towards the ever growing Virtual Machine world to give mobile workers the best possible experience that is evolving into a key component of the Aruba Mobile First platform. Check out the webinar recording where this presentation was used. https://community.arubanetworks.com/t5/Wireless-Access/Airheads-Technical-Webinar-Recording-Slides-ArubaOS-8-0/m-p/278668
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
VMware es un software de virtualización que permite simular sistemas operativos y hardware en máquinas virtuales que pueden ejecutarse en cualquier computadora. Ofrece versiones gratuitas como VMware Player, Server y ESXi, así como versiones comerciales como ESX Server, diseñado para la virtualización de servidores. Mientras que las versiones gratuitas tienen limitaciones, las versiones comerciales ofrecen funciones avanzadas sin restricciones.
The document discusses best practices for monitoring and maintaining a data center. It covers topics such as the role of the network operations center (NOC) in monitoring equipment health and responding to issues, the importance of in-band and out-of-band monitoring, using SNMP to monitor resources, ensuring physical and logical security, approved cleaning procedures and supplies, and guidelines for safely cleaning different areas of the data center like equipment surfaces, floors, and above-ceiling spaces.
This document provides instructions for promoting a Windows Server 2012 machine to a domain controller. It outlines the key steps which are:
1. Configure the server's network settings to use a static IP on the same subnet as the existing domain controllers.
2. Install the Active Directory Domain Services role using the Server Manager tool.
3. Select the option to add the domain controller to an existing domain and provide credentials for the enterprise administrator.
4. Complete the promotion process by defining DNS and global catalog roles, site, and directory services restoration mode password.
In this presentation, e will discuss AirWave 10, a new software build that lets us streamline code, add performance, clustering. Check out the webinar recording where this presentation was used: http://community.arubanetworks.com/t5/Network-Management/Technical-Webinar-Introduction-to-AirWave-10/td-p/454762
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
Modul Free One Day Workshop Implementing Cisco IP Routing and Switched NetworksI Putu Hariyadi
Dokumen tersebut memberikan penjelasan tentang Cisco Internetwork Operating System (IOS) dan konfigurasi dasar pada router Cisco. Secara singkat, dokumen tersebut menjelaskan:
1. Pengenalan Cisco IOS sebagai sistem operasi router Cisco dan cara mengakses mode command line melalui koneksi console atau remote.
2. Cara mengkonfigurasi hostname, password, banner, dan interface pada router Cisco.
3. Penjelasan tentang static route dan default route serta cara mengkonfigurasinya pada router.
That\'s why NetApp and Cisco have collaborated to create FlexPod™ for VMware. FlexPod consists of networking, storage, and infrastructure software components.
Putting the Flexpod inside an Elliptical container makes FlexPod a pre-validated data center solution built on a flexible, shared infrastructure that can scale easily, be optimized for a variety of mixed application and workloads.
The document describes Elliptical Mobile Solutions' micro-modular data center products. It discusses the advantages of EMS products over traditional and modular data centers, including 50-80% lower capital costs and 40-65% lower operating costs. It then provides details on EMS's product line, which includes mobile and relocatable enclosure models like SPEAR, RASER, and C3-SPEAR that offer scalable, high-density computing in a compact format.
The document provides step-by-step instructions for performing a password recovery on a Cisco 2960X switch. It explains that to begin, the mode button must be held for 30-40 seconds during power up until "USB Console INIT" appears. Then the flash_init and dir flash: commands allow renaming the config.text file. Reloading the switch ignores the startup config and allows changing passwords before copying the renamed file back.
This document discusses virtual machine creation and management topics including vNetwork, vStorage, vMotion, DRS, and high availability (HA). It covers virtual machine hardware configuration, the files that make up a virtual machine, VMware Tools, and virtual machine power options. It also summarizes storage protocols, thin and thick provisioning, methods for migrating virtual machines, and how vMotion and DRS work. Finally, it discusses HA features like protection at different availability levels, using NIC teaming or additional networks for redundancy, and how the HA cluster architecture functions with a master and slave agents.
Virtualization allows multiple operating systems and applications to run on the same physical server at the same time. This increases hardware utilization and flexibility while reducing IT costs. VMware virtualization solutions can reduce energy costs by 80% through server consolidation and powering down unused servers without affecting applications or users. Virtualization makes hardware resources independent of operating systems and applications, treating them as single unified units that can be more easily deployed, maintained, and supported.
This document provides an overview of server virtualization and its benefits for Madison Plains Local School District. It discusses how virtualization can help lower costs by consolidating servers and improving hardware utilization. Specific benefits mentioned include reducing the number of physical servers needed, lowering power consumption, gaining hardware independence for virtual machines, and isolating virtual machines for improved security. The document also shows how most applications see performance on par with physical machines when run virtually. It promotes developing a plan that assesses the current infrastructure and provides a roadmap for virtualizing servers.
This document provides an overview of VMware Cloud Foundation on Dell VxRail. It discusses the key benefits of the solution such as simplified operations through automation, a modern hybrid cloud platform, and choice of financial consumption models. It covers various technical aspects of the solution including workload domains, deployment options, lifecycle management, networking and security considerations, and integration with Tanzu for modern applications. Sections are included on initial deployment, day 2 operations, networking topology, host configuration, and the Tanzu framework.
Data Center Floor Design - Your Layout Can Save of Kill Your PUE & Cooling Ef...Maria Demitras
Implementing data center best practices and using CFD models allowed Great Lakes to suggest a data center layout that would improve PUE and efficiency. Jason Hallenbeck, DCDC, explains the concepts behind how data center floor design can save or kill your PUE and cooling efficiency—as found in this proposal. Find Jason presenting at the BICSI Fall Conference on September 14th at 1:30 pm.
Are you new to Nutanix? Jump into this introductory product session to learn the fundamentals of Nutanix Enterprise Cloud software and its key capabilities. A couple Nutanix experts will demonstrate how Nutanix delivers a complete cloud “stack” with the server, storage virtualization and network resources to run any application. Learn the basics of hyperconverged infrastructure, and understand how to deploy Nutanix in your datacenter or branch/remote office.
MAAS & Ubuntu Core: OCP Tech Day, Facebook Menlo Park, Aug 30thChristian "kiko" Reis
An overview of MAAS, a flexible bare-metal provisioning system that manages DHCP, DNS and PXE services, drives chassis and BMCs, and deploys of CentOS, RHEL, Ubuntu, Windows and more. Presented at the latest OCP Tech Day on August 30th 2016.
Nutanix NEXT on Tour - Maarssen, Netherlands NEXTtour
The document provides an agenda for a Nutanix .NEXT event, including keynote speeches on Nutanix products and use cases from HERO and OGD. It discusses Nutanix adoption in Europe, the benefits of hyperconverged infrastructure, and Nutanix products like Acropolis and Prism. Later presentations will provide overviews of Nutanix deployments at HERO and OGD, focusing on simplified management and improved performance.
In this presentation, we will be sharing a collection of several vital configuration tips and tricks which are widely implemented across mid-size to large enterprise WLAN. Our primary focus would be on Security as well as Performance characteristics of Aruba WLAN networks. Check out the webinar recording where this presentation was used: https://community.arubanetworks.com/t5/Wireless-Access/Airheads-Technical-Webinar-Recording-Slides-Aruba-OS/m-p/277294
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
This document provides an agenda for a presentation on HP Blade technology. The agenda includes introductions to HP Blade chassis, onboard administrators, Virtual Connect Flex-10 modules, Cisco modules, system management tools, different types of Aurora servers, storage servers, and cluster configuration. It also discusses NTP server configuration, questions, and demonstrations of HP Blade hardware components and management modules.
This presentation will show how ArubaOS architecture has evolved and been modernized towards the ever growing Virtual Machine world to give mobile workers the best possible experience that is evolving into a key component of the Aruba Mobile First platform. Check out the webinar recording where this presentation was used. https://community.arubanetworks.com/t5/Wireless-Access/Airheads-Technical-Webinar-Recording-Slides-ArubaOS-8-0/m-p/278668
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
VMware es un software de virtualización que permite simular sistemas operativos y hardware en máquinas virtuales que pueden ejecutarse en cualquier computadora. Ofrece versiones gratuitas como VMware Player, Server y ESXi, así como versiones comerciales como ESX Server, diseñado para la virtualización de servidores. Mientras que las versiones gratuitas tienen limitaciones, las versiones comerciales ofrecen funciones avanzadas sin restricciones.
The document discusses best practices for monitoring and maintaining a data center. It covers topics such as the role of the network operations center (NOC) in monitoring equipment health and responding to issues, the importance of in-band and out-of-band monitoring, using SNMP to monitor resources, ensuring physical and logical security, approved cleaning procedures and supplies, and guidelines for safely cleaning different areas of the data center like equipment surfaces, floors, and above-ceiling spaces.
This document provides instructions for promoting a Windows Server 2012 machine to a domain controller. It outlines the key steps which are:
1. Configure the server's network settings to use a static IP on the same subnet as the existing domain controllers.
2. Install the Active Directory Domain Services role using the Server Manager tool.
3. Select the option to add the domain controller to an existing domain and provide credentials for the enterprise administrator.
4. Complete the promotion process by defining DNS and global catalog roles, site, and directory services restoration mode password.
In this presentation, e will discuss AirWave 10, a new software build that lets us streamline code, add performance, clustering. Check out the webinar recording where this presentation was used: http://community.arubanetworks.com/t5/Network-Management/Technical-Webinar-Introduction-to-AirWave-10/td-p/454762
Register for the upcoming webinars: https://community.arubanetworks.com/t5/Training-Certification-Career/EMEA-Airheads-Webinars-Jul-Dec-2017/td-p/271908
Modul Free One Day Workshop Implementing Cisco IP Routing and Switched NetworksI Putu Hariyadi
Dokumen tersebut memberikan penjelasan tentang Cisco Internetwork Operating System (IOS) dan konfigurasi dasar pada router Cisco. Secara singkat, dokumen tersebut menjelaskan:
1. Pengenalan Cisco IOS sebagai sistem operasi router Cisco dan cara mengakses mode command line melalui koneksi console atau remote.
2. Cara mengkonfigurasi hostname, password, banner, dan interface pada router Cisco.
3. Penjelasan tentang static route dan default route serta cara mengkonfigurasinya pada router.
That\'s why NetApp and Cisco have collaborated to create FlexPod™ for VMware. FlexPod consists of networking, storage, and infrastructure software components.
Putting the Flexpod inside an Elliptical container makes FlexPod a pre-validated data center solution built on a flexible, shared infrastructure that can scale easily, be optimized for a variety of mixed application and workloads.
The document describes Elliptical Mobile Solutions' micro-modular data center products. It discusses the advantages of EMS products over traditional and modular data centers, including 50-80% lower capital costs and 40-65% lower operating costs. It then provides details on EMS's product line, which includes mobile and relocatable enclosure models like SPEAR, RASER, and C3-SPEAR that offer scalable, high-density computing in a compact format.
The N3K-C31108TC-V is a Cisco Nexus 31108TC-V switch that provides 48 10GBASE-T ports, 6 QSFP28 ports, and up to 2.16 Tbps of switching capacity. It is a 1RU fixed form factor switch that supports line-rate L2 and L3 switching, VXLAN routing, 16 MB of shared buffering, and high availability features. The switch has redundant power and fans and is designed for use in data centers and cloud computing environments.
Manage power consumption, cooling delivery, and temperature set points at a rack level
Reduce your cooling and electrical costs by up to 50%
Reduce the costs to plan, build, and implement your new facility by up to 80%
Grow horizontally—from 1 to 100 units—without disrupting existing operations?
Can be installed or Re-Located anywhere with the only requirements being power and network connectivity
Provide a complete turnkey solution within weeks vs. years.
The document is a datasheet for the Cisco Nexus 3100-V N3K-C31108PC-V switch. It provides specifications for the switch such as its physical dimensions, port configuration of 48 SFP and 6 QSFP28 ports, switching capacity of 2.16 Tbps, and features including line-rate Layer 2 and 3 switching, VXLAN routing, high availability, and extensive management capabilities through the NX-OS operating system.
The document discusses racks and accessories from Multimedia Connect. It summarizes 3 lines of racks: Essential for low density cabling with load capacity up to 500kg, Technic for technical room cabling with load capacity up to 800kg, and Server for data centers with load capacity up to 1000kg. It also outlines accessories like fans, panels, and bases that are compatible across all rack lines.
This document provides information about the Cisco ASR 9000 Series Router Ethernet Linecard A9K-2X100GE-TR, including how to purchase it from Launch 3 Telecom. Launch 3 Telecom offers this Cisco product along with warranty, shipping, payment and additional services like repairs. The document also includes a data sheet detailing the technical specifications and features of the Cisco ASR 9000 Series Route Switch Processor.
1. APC and Datacentre UK are partnering to provide scalable and customizable data center solutions using APC's InfraStruXure architecture for integrated power, cooling, and management.
2. InfraStruXure allows customers to select standardized components to create a solution tailored to their needs, providing reliability and predictability while being customized.
3. APC's full product portfolio includes UPS systems, PDUs, cooling solutions, racks, and remote monitoring software to address all customer imperatives around controlling costs, adapting to change, maximizing uptime, and easy maintenance.
The document provides information about the Cisco ASR 9000 Series Route Switch Processor (RSP). It describes the RSP as a scalable, low-power platform designed for Carrier Ethernet and service provider networks. Key details include its distributed forwarding and control planes for high performance, modular design for scalability and fault isolation, and built-in redundancy features. The document also provides specifications for the RSP hardware, supported line cards, environmental operating conditions, and power requirements.
The Cisco Aironet 3600 Series access point delivers up to three times more wireless coverage than competitors for mobile devices. It supports 4x4 MIMO and three spatial streams for reliable high-speed connections at greater distances from the access point. The modular platform also provides investment protection and can be expanded to support upcoming 802.11ac clients with 1.3Gbps speeds or add security and spectrum monitoring features.
Introduction of Orissa Wicomm corporate profile and products.
Representing Narada Liithium-ion and Lead Acid Battery products and solution. Lightning Protection and Site Access Monitoring & Control Solution
The document describes a containerized power distribution center (PDC) solution designed and constructed by Eaton for an oil and gas company in NSW, Australia. The PDC solution utilizes Eaton's Power Xpert CX and UX equipment and was fully assembled, tested, and transported in a self-contained switchroom structure weighing 69.5 tons. The solution provides safe and reliable electrical power distribution for the company's gas storage and supply operations through extensive safety features and testing of the equipment.
The Cisco Aironet 3602E-Q-K9 is an 802.11n wireless access point that delivers up to three times more wireless coverage than competing solutions. It supports 4x4 MIMO and three spatial streams to sustain reliable connections at higher speeds further from the access point. The modular platform also offers future expansion options to support newer standards like 802.11ac. It has external antenna connectors and dimensions of 8.7 x 8.7 x 2.11 inches. The access point has features such as 450 Mbps data rates and beamforming capabilities.
The Cisco Aironet 3600 Series access point delivers up to three times more wireless coverage than competitors for mobile devices. It supports 4x4 MIMO and three spatial streams for reliable high-speed connections at 450 Mbps from further away. The modular platform also provides investment protection and can be expanded to support upcoming 802.11ac clients at 1.3 Gbps speeds or add security and spectrum monitoring features. The AIR-CAP3602E-S-K9 is an external antenna 802.11n access point that operates on 2.4 GHz and 5 GHz channels with a maximum data rate of 450 Mbps. It has dimensions of 8.7 x 8.7 x 2.11 inches and weighs
The document provides specifications for the Cisco 1941 router series, including the Cisco 1941 and 1941W models. It describes the key features such as integrated services, services on demand through software licensing, and high performance. Product specifications include memory, ports, power options, dimensions, and environmental specifications. Basic ordering information and sources are also listed.
Juniper round table switching and product overviewKappa Data
The document discusses Juniper Networks' switching solutions for campus and branch networks. It highlights key benefits of Juniper switching such as simplicity, performance, high availability, and the Junos operating system. It provides an overview of Juniper's switching portfolio including the EX, QFX, and EX9200 product lines. It also discusses technologies like Virtual Chassis that provide benefits like simplified management, resiliency, and investment protection. Finally, it outlines Juniper's approach to campus network transformation through automation, security, and cloud-based management.
This document compares Elliptical Mobile Solutions' R.A.S.E.R. product to traditional shipping container data centers. R.A.S.E.R. can deploy 1680 blade servers in a standard 40-foot shipping container, offering higher density and lower costs than a traditional data center build. It provides up to 50% savings on electricity usage and 75% reduction in floor area needs compared to traditional raised floor data centers.
The Cisco Aironet 3600 Series access point delivers up to three times more wireless coverage than competitors for mobile devices. It supports 4x4 MIMO and three spatial streams for reliable high-speed connections at greater distances. The modular platform offers investment protection and can be expanded to support upcoming 802.11ac clients with 1.3Gbps speeds or add security and spectrum monitoring features. The AIR-CAP3602E-R-K9 is an external antenna 802.11n access point that operates on 2.4GHz and 5GHz channels with a maximum throughput of 450Mbps. It has 10/100/1000 Ethernet and console ports and dimensions of 8.7x8.7x2.
The Cisco Aironet 3600 Series access point delivers up to three times more wireless coverage than competitors for mobile devices. It supports 4x4 MIMO and three spatial streams for reliable high-speed connections at longer ranges. The modular platform offers future expansion options to support newer standards like 802.11ac and additional security and monitoring features. It has external antenna ports and dimensions of 8.7 x 8.7 x 2.11 inches. The access point supports a range of operating channels and data rates up to 450 Mbps in the 5GHz band.
1. RACK ENCLOSURES AND OPEN FRAME RACKS FOR SERVER
AND NETWORKING APPLICATIONS IN IT ENVIRONMENTS
Rack Systems
2. “Fits Like a Glove” NetShelter®
SX
Guaranteed Compatibility
Whether you are designing
a wiring closet or the largest
data center, or just looking for
the most flexible rack solution,
APC NetShelter®
SX rack enclosures provide a secure and ven-
dor-neutral environment for your IT equipment.
APC is committed to ensuring that your rack-mount equip-
ment will fit into NetShelter SX enclosures. APC guarantees
that all 19” EIA-310-D compliant equipment will physically fit
into NetShelter SX enclosures with the mounting hardware
provided by the original equipment manufacturer (OEM),
APC, a third party vendor, or any combination thereof or your
money back.*
X-Certified
NetShelter®
SX rack enclosures and accessories are X-certified,
meaning they are tested and certified for use with InfraStruXure™
architecture. InfraStruXure is on-demand architecture for power,
cooling and environmental management. An effective solution
to Network-critical Physical Infrastructure (NCPI), InfraStruXure
is the industry’s only integrated architecture robust enough to
effectively maintain highly available and manageable networks.
Look for the words (X-CERTIFIED) and the“Fits like a glove” icon
throughout this brochure to determine which racks and accesso-
ries are compatible with APC InfraStruXure architecture.
*See www.apc.com for more details.
Every product carrying this mark has been tested and certified
for use with InfraStruXure™ architecture. Before you buy, check
for the “X” to guarantee product compatibility.
COMPATIBILITYGUARANTEED
ENCLOSURES
NetShelter®
SX 2
Enclosures providing cooling, power
distribution, cable management, and
environmental monitoring for
applications in IT environments.
NetShelter®
WX 6
Wall-mounted rack enclosures for
networking applications in IT
environments
OPEN FRAME RACKS
NetShelter®
2 Post Rack 7
2 Post racks for networking
applications in IT environments
NetShelter®
4 Post Rack 7
4 post racks with advanced power
distribution and cable management
features for server, networking, and
telecom applications in secure IT
environments
ACCESSORIES
Enclosure and Rack Accessories 8
Power distribution, cooling, and cable
management accessories, shelving,
grounding, keyboards, keyboard drawers,
LCD monitors, KVM switches, security
devices, stabilization accessories required
for a complete rack solution
Cooling 8
Rack Power Distribution 9
Cable Management 10
Rack Keyboard Monitor Mouse 11
Keyboards and drawers 11
KVM switches 11
Rack Mounting Hardware 11
Rack Security Devices 12
Shelving 12
Stabilization 12
Troughs and Ladders 12
Security and Environmental 14
Accessories Compatibility Chart 16
TABLE OF CONTENTS
3. O
nce concerned with environmental design at the
room-level, consulting engineers now direct
their attention to power distribution, cooling,
and cable management at the rack level. The
driving force behind this shift is technology
compaction, as today’s IT equipment is designed
with efficient rack-mounting capabilities to maximize the
utilization of valuable floor space.
The ideal rack enclosure maximizes flexibility with a
progressive, non-proprietary feature-set as well as an
extensive line of scalable accessory products to address
current needs and adapt to future technology trends. APC
NetShelter®
rack systems provide the most progressive
feature-set available in a vendor-neutral rack environment
while allowing the user the flexibility to quickly adapt to
emerging trends. Available in a variety of heights and
widths, NetShelter racks and enclosures support applica-
tions ranging from branch offices and wiring closets to
enterprise data centers. With an extensive line of lead-
ing-edge power distribution, cooling and cable manage-
ment accessories, APC offers the most comprehensive
rack solutions to protect the critical components of the
IT environment.
InfraStruXure™
Supports
Dynamic Systems
Environment at Microsoft
Technology Center
“We change configurations
in our data center on
a weekly basis. The
InfraStruXure™
system
with its ability to balance
loads as we swap servers,
battery modules and
power modules, helps
to make these changes
worry-free.”
Chuck McCann
Technical Director
Microsoft Technology Center
– Boston
4. 2 For more information about APC’s Availability Solutions, visit www.apc.com
NetShelter®
SX
Enclosures providing cooling, power distribution, cable management,
and environmental monitoring for applications in IT environments.
NetShelter®
SX is APC’s next generation rack enclosure solution influ-
enced by 10 years of customer feedback addressing current IT market
trends for high-density server and networking applications. With a
strong focus on cooling, power distribution, cable management and
environmental monitoring, the NetShelter SX provides a reliable rack-
mounting environment for mission-critical equipment.
NETSHELTER®
SX
NetShelter®
SX Product Design Benefits
Scalable
Cooling Options
Enhanced door ventilation
with scalable cooling
options for high-density
applications
Cable Management
Integrated features and options
for horizontal and vertical routing
of high-density cabling
Environmental & Security
Integrate environmental & security
solutions for protection against
physical threats
Rack Power
Distribution
Toolless 0U mounting for
rack PDUs
5. For more information about APC’s Availability Solutions, visit www.apc.com 3
NETSHELTER®
SX
Every product carrying
this mark has been tested
and certified for use with
InfraStruXure™
architecture.
Before you buy, check
for the “X” to guarantee
product compatibility.
Compatibility
• Door ventilation exceeds 919 in2
(5933 cm2
)
• Captive adjustment of Vertical Mounting Rails
[fig 3a]
• Fits-Like-A-Glove guaranteed compatibility
Convenience
• Toolless installation and removal of roof
(fig 3b)
• Rapid adjustment of leveling feet (fig 3c)
• Toolless PDU mounting provisions
• Numbered U positions (fig 3d)
• Light-weight, half-height side panels
• Toolless cable management options
• 42U models roll through 2 meter doorways
• Cable openings for overhead or underfloor
applications
Safety
• Integrated grounding
• UBC Zone 4 stabilization provisions
Protection
• Lockable doors and side panels
• Door access monitoring
• Static weight load rating of 3,000 lbs
Serviceability
• Quick release doors
• Quick release side panels (fig 3e)
• Split rear doors
Adaptability
• Reversible doors
• Scalable cooling options
• Seamless integration of environmental monitoring
devices
• External baying for easy deployment in rows
(fig 3f)
NetShelter®
SX Features and Benefits
[fig 3a]
[fig 3b]
[fig 3c]
[fig 3d] [fig 3e] [fig 3f]
6. 4 For more information about APC’s Availability Solutions, visit www.apc.com
NETSHELTER®
SX
AR3100
Net Weight 275.20 lbs (125.09 kg)
Net Height 78.40 inches (1991 mm)
Net Width 23.62 inches (600 mm)
Net Depth 42.13 inches (1070 mm)
Shipping Weight 318.00 lbs (144.55 kg)
Shipping Height 83.40 inches (2118 mm)
Shipping Width 35.38 inches (899 mm)
Shipping Depth 48.00 inches (1219 mm)
Weight Capacity (static load) 3000 lbs (1363.6 kg)
Weight Capacity (dynamic load) 2250 lbs (1022.7 kg)
NetShelter®
SX 42U×600mm (W) Enclosure
Black 42U×600 Enclosure:
AR3100
NetShelter SX 42U×750mm (W) Enclosure
Black wide enclosure:
AR3150 AR3150
Net Weight 343.10 lbs (155.95 kg)
Net Height 78.40 inches (199.1 cm)
Net Width 29.53 inches (75.0 cm)
Net Depth 42.13 inches (107.0 cm)
Shipping Weight 370.00 lbs (168.18 kg)
Shipping Height 87.25 inches (221.6 cm)
Shipping Width 35.25 inches (89.5 cm)
Shipping Depth 48.00 inches (121.9 cm)
Weight Capacity (static load) 3000 lbs (1363.6 kg)
Weight Capacity (dynamic load) 2250 lbs (1022.7 kg)
NetShelter®
SX 48U×600mm (W) Enclosure
Black 48U×600mm Enclosure:
AR3107
AR3107
Net Weight 304.10 lbs (138.23 kg)
Net Height 88.90 inches (2258 mm)
Net Width 23.62 inches (600 mm)
Net Depth 42.13 inches (1070 mm)
Shipping Weight 346.90 lbs (157.68 kg)
Shipping Height 93.90 inches (2385 mm)
Shipping Width 35.38 inches (899 mm)
Shipping Depth 48.00 inches (1219 mm)
Weight Capacity (static load) 3000 lbs (1363.6 kg)
Weight Capacity (dynamic load) 2250 lbs (1022.7 kg)
7. For more information about APC’s Availability Solutions, visit www.apc.com 5
NETSHELTER®
SX/VX
Black 25U×600mm Enclosure:
AR2105BLK
NetShelter®
VX 25U×600mm (W) Enclosure
AR2105BLK
Net Weight 255.00 lbs (115.91 kg)
Net Height 51.70 inches (1313 mm)
Net Width 23.50 inches (597 mm)
Net Depth 42.20 inches (1072 mm)
Shipping Weight 301.00 lbs (136.82 kg)
Shipping Height 57.30 inches (1455 mm)
Shipping Width 29.50 inches (749 mm)
Shipping Depth 47.50 inches (1207 mm
Weight Capacity (static load) 2000 lbs (909.1 kg)
Weight Capacity (dynamic load) 2000 lbs (909.1 kg)
Black 42U×600mm Enclosure:
AR2144BLK/AR2145BLK
NetShelter®
VX 42U×600mm (W) Seismic Enclosure
AR2144BLK
Net Weight 518.00 lbs (235.45 kg)
Net Height 81.50 inches (2070 mm)
Net Width 23.50 inches (597 mm)
Net Depth 42.20 inches (1072 mm)
Shipping Weight 556.00 lbs (252.73 kg)
Shipping Height 87.00 inches (2210 mm)
Shipping Width 29.50 inches (749 mm)
Shipping Depth 47.50 inches (1207 mm)
Weight Capacity (static load) 2000 lbs (909.1 kg)
Weight Capacity (dynamic load) 2000 lbs (909.1 kg)
Black 48U×750mm Enclosure
AR3157
NetShelter SX 48U×750mm (W) Enclosure
AR3157
Net Weight 372.00 lbs (169.09 kg)
Net Height 88.90 inches (2258 mm)
Net Width 29.53 inches (750 mm)
Net Depth 42.13 inches (1070 mm)
Shipping Weight 405.00 lbs (184.09 kg)
Shipping Height 94.50 inches (2400 mm)
Shipping Width 35.25 inches (895 mm)
Shipping Depth 48.00 inches (1219 mm)
Weight Capacity (static load) 3000 lbs (1363.6 kg)
Weight Capacity (dynamic load) 2250 lbs (1022.7 kg)
8. Black13U Enclosure with glass front
door:
AR100
NetShelter®
WX
Wall-mounted rack enclosures for networking applications
in IT environments
NetShelter®
WX Enclosures are specifically designed for network-
ing professionals to securely store and wire 19" EIA compatible
equipment such as hubs, routers, concentrators and patch pan-
els. Typical applications include small hub and LAN applications
within wiring closets and computer rooms with floor space con-
straints. The NetShelter®
Wall-Mount Enclosure mounts directly
to building walls without occupying valuable or unavailable floor
space. Rubber feet are provided with the enclosure for those
applications that require floor mounting.
Convenience
• Wall-mountable
• Multi-purpose mounting rails
• Adjustable front rail
• Integrated cable access holes
• Labeled U positions
• Unit symmetry allows left or right
hand door swing operation
Availability
• Ventilation front doors and
side panels
Serviceability
• Quick release doors
Protection
• Lockable doors
6 For more information about APC’s Availability Solutions, visit www.apc.com
NETSHELTER®
WX
AR100
Net Weight 94.00 lbs (42.73 kg)
Net Height 25.75 inches (65.41 cm)
Net Width 23.00 inches (58.42 cm)
Net Depth 24.50 inches (62.23 cm)
Shipping Weight 115.00 lbs (52.27kg)
Shipping Height 33.00 inches (83.82 cm)
Shipping Width 27.00 inches (68.58 cm)
Shipping Depth 30.50 inches (77.47 cm)
Weight Capacity (static load) 100.00 lbs (45.36 kg)
NetShelter®
WX Wall-Mount Enclosure 13U Vented Door
Black13U Enclosure with vented door:
AR100HD
AR100HD
NetShelter®
WX Wall-Mount Enclosure 13U Glass Door
Net Weight 94.00 lbs (42.73 kg)
Net Height 25.75 inches (65.41 cm)
Net Width 23.00 inches (58.42 cm)
Net Depth 24.50 inches (62.23 cm)
Shipping Weight 115.00 lbs (52.27 kg)
Shipping Height 33.00 inches (83.82 cm)
Shipping Width 27.00 inches (68.58 cm)
Shipping Depth 30.50 inches (77.47 cm)
Weight Capacity (static load) 100.00 lbs (45.36 kg)
9. For more information about APC’s Availability Solutions, visit www.apc.com 7
NETSHELTER®
SXNETSHELTER®
2- AND 4 POST OPEN FRAME RACKS
2 Post racks for networking applications in IT environments
The NetShelter®
2 Post Rack offers a quality solution for the economical
installation of rack-mountable networking equipment. The 2 Post Rack
offers cost conscious customers a simple solution for rack mounting
network equipment in a secure managed environment including data
centers, wiring closets and co-location facilities. Each NetShelter®
2-Post
Rack is made with high grade aluminum extrusions and offers a gener-
ous 45U (78.75" or 200cm) of equipment mounting space in a 7 foot high
design. The self-squaring design makes assembly quick and easy and
requires only one person to fully assemble each unit.
2 Post rack features
• 6061-T6 Structural grade aluminum:
High quality aluminum ensures
product durability
• Self squaring design: Allows for fast
and easy installation
NetShelter®
2 Post Open Frame Racks
2-Post Rack with
Aluminum finish:
AR200
2-Post Rack with
black finish:
AR201
AR200, AR201
Net Weight 26.00 lbs (11.82 kg)
Net Height 83.50 inches (212.09 cm)
Net Width 20.20 inches (51.31 cm)
Net Depth 14.80 inches (37.59 cm)
Shipping Weight 30.00 lbs (13.64 kg)
Shipping Height 86.00 inches (218.44 cm)
Weight Capacity (static load) 750.00 lbs (340.19 kg)
4 post racks with advanced power distribution and cable
management features for server, networking, and telecom
applications in secure IT environments.
APC 4 Post Open Frame Racks provide simple, low cost mounting
means for rack-mount equipment in IT environments. Ideal for rack-
mount servers, networking, and telecom equipment where security
at the individual rack level is not required, open frame racks provide
unobstructed airflow and fast, easy access to installed equipment.
Provisions for vertically mounting APC Rack PDUs in the rear com-
bined with options for easily routing, organizing, and storing large
bundles of cables make APC 4 Post Open Frame Rack solutions the
best alternative on the market.
4 post rack features
• Numbered U positions
• Optimized width
• Reversible stabilization plates
NetShelter®
4 Post Open Frame Racks
Net Weight 92.00 lbs (41.82 kg)
Net Height 80.90 inches (205.49 cm)
Net Width 20.60 inches (52.32 cm)
Net Depth 29.50 inches (74.93 cm)
Shipping Weight 102.00 lbs (46.36 kg)
Shipping Height 82.00 inches (208.28 cm)
Shipping Width 10.00 inches (25.40 cm)
Shipping Depth 7.40 inches (18.80 cm)
Weight Capacity (static load) 1000.00 lbs (453.59 kg)
AR203, AR204
(X-CERTIFIED)
4 Post 43U Rack with
Square Mounting Holes: AR203
4 Post 43U Rack with #12-24
Threaded Mounting Holes: AR204
10. 8 For more information about APC’s Availability Solutions, visit www.apc.com
To determine which cooling accessories are compatible
with specific models of NetShelter enclosures and racks,
check the Accessory Compatibility Chart on page 16–17.
Rack Air Distribution Unit
Air distribution for power dense enclosures and
low pressure areas
The Rack Air Distribution Unit is a 2U
fan unit that works with an existing
precision air conditioning system
to deliver cool air to the equipment
contained in a rack enclosure. The
Rack Air Distribution Unit connects
into the raised floor and pulls supply air directly into the enclosure.
This prevents the conditioned air from mixing with warmer room
air before reaching the equipment. The Rack Air Distribution Unit
minimizes temperature differences between the top and bottom of the enclosure.
It also prevents hot exhaust air from recirculating to the inlet of the enclosure.
The product is recommended for rack enclosures with loads greater than 1.5kW
and can provide airflow for loads up to 3.0kW. It is also ideal for enclosures in
raised floor environments where underfloor air distribution is inadequate.
ACF001 (115VAC, 60HZ)
ACF002 (230VAC, 50HZ)
ACF003 (100VAC, 50/60HZ)
Densely packed enclosures can overheat IT equipment and cause
downtime. High density enclosures create an environment where
traditional air distribution methods are not effective.
The Air Removal Unit captures exhaust heat, ducting it to the
return air plenum and eliminating hot spots. Through automatic
fan speed adjustment based on temperature or power
consumption, a desired temperature can be set and fans will
self-adjust for optimal energy efficiency. The Rack Air Removal
Unit can cool up to a 7.5 kW rack and provide fan redundancy
up to 5.0 kW, as well as provide power redundancy through dual
corded input. This space saving product mounts to the back of the
enclosure – requiring zero U space.
ACF400 (100–240V 50/60HZ for NetShelter SX 600mm Wide Rack)
ACF402 (100–240V 50/60HZfor NetShelter SX 750mm Wide Rack)
ACF126 (ARU Ducting Kit for 24” Ceiling Tiles)
ACF127 (ARU Ducting Kit for 600mm Ceiling Tiles)
ACF122 ARU DOOR GRILLE KIT
Rack Air Removal Unit
Heat removal for high density
enclosures
ACCESSORIES: COOLING
FAN TRAYS
Roof Fan Tray (120, 208, 230 VAC) Black
ACF501(115 VAC, 600mm), ACF502 (208–230 VAC,
600mm), ACF503 (115 VAC, 750mm), and ACF504
(208 – 230 VAC, 750mm). (X-CERTIFIED)
Occupies 0U of rack space, Integrated cable
access holes, promotes bottom to top airflow.
Includes Installation Guide, mounting hardware.
Wall-Mount Fan Tray 120, 230 VAC Black
AR8206BLK (120 VAC), AR8207BLK (230 VAC)
Occupies 1U of rack space, promotes bottom
to top airflow. Includes Installation Guide,
Qty 1–IEC to NEMA 5–15P Power Cord (120V),
IEC to IEC 320 Power (230V) Cord; Qty 2–Fans.
Wall-Mount Ventilation Plate
AR8355
Ventilated. Includes Installation Guide.
Rack Side Air Distribution Unit
Air distribution for networking equipment with side to side airflow.
Housing equipment with side to side airflow
creates many challenges for IT and
facility managers, particularly in
regards to cooling. Because most
enclosures are designed for a front
to back airflow pattern, it is difficult
to maintain ideal operating temperatures on side to side
airflow equipment. The Rack Side Air Distribution Unit allows for greater security
and organization by allowing racks to be placed adjacent to one another without
impeding airflow.
The Rack Side Air Distribution Unit is a 2U rack mountable air distribution
product for networking equipment or servers with side to side airflow. It pulls in
conditioned air from the front of the rack and distributes it to the side air intake
of the networking equipment. This extends equipment life by providing proper
inlet temperatures.
This product is recommended for one or more networking products that are
stacked consecutively in a rack. Rack Side Air Distribution Units may be
placed above and/or below the networking equipment. Airflow pattern is user
configurable via an interchangeable air turning vane.
ACF201BLK (115VAC, 60HZ)
ACF202BLK 208/230VAC, 50/60HZ
11. For more information about APC’s Availability Solutions, visit www.apc.com 9
Basic Rack PDUs
Power distribution for
rack-mount equipment
APC offers a wide variety
of Basic Rack Power
Distribution Units (PDUs),
which allow users to
distribute power outlets to rack-mount equipment. Horizontal and vertical units
are available as well as a variety of power inputs and outputs to fit most power
environments. APC now offers Basic Rack PDUs that mount vertically, without
tools in the rear channel of a NetShelter®
SX. The Basic Rack PDU family
contains solutions that support up to 14.4kW of load.
Switched Rack PDUs
Power distribution that remotely controls power
to individual outlets and monitors the aggregate
power consumption
APC’s Switched Rack Power Distribution Units (PDUs) are
premium solutions to many of the power management problems
seen in today’s IT environments. Some of the problems are
unauthorized use of power outlets, locked-up equipment, in-rush
current, overloaded circuits, and the need of remote access to
power outlets in the rack. Users can access, configure, and
control the Switched Rack PDUs through Web, SNMP, or Telnet
Interfaces. The Basic Rack PDU family contains solutions that
support up to 12.5kW of load.
Metered Rack PDUs
Power distribution units that monitor the aggregate
power consumption of connected equipment
APC's Metered Rack Power Distribution Units (PDUs) provide power
distribution as well as equip on-site installers with the ability to
monitor the aggregate current draw as equipment is connected to
the unit. These Metered Rack PDUs also have alarm thresholds that
when exceeded provide alarms to alert users of potential problems.
These features help eliminate the possibility of an overloaded circuit.
Units listed below include installation guide, rack mounting brackets,
toolless mounting kit, and user manual. The Basic Rack PDU family
contains solutions that support up to 14.4kW of load.
ACCESSORIES: RACK POWER DISTRIBUTION
BLANKING PANELS
1U Modular Toolless Blanking Panels
AR8136BLK (Qty 10)/AR8136BLK200 (Qty 200)
(X-CERTIFIED)
Modular 1U plastic blanking panels allow quick
and easy installation in any EIA-310-D compliant
square hole mounting rail rack or enclosure, toolless
mounting.
Blanking Panel Kit (1U, 2U, 4U, 8U)
AR8101BLK (Black) (X-CERTIFIED)
Metal blanking panels are designed for use in
vertical rails with threaded holes. They promote
proper airflow, preventing air recirculation by
occupying unused rack space. Their use will
improve the efficiency of cooling within the
enclosure. Includes mounting hardware.
Qty 1 each: 1U, 2U, 4U and 8U Panel.
1U Blanking Panel Kit (Qty 2)
AR8108BLK (X-CERTIFIED)
Metal blanking panels are designed for use in
vertical rails with threaded holes. They promote
proper airflow, preventing air recirculation by
occupying unused rack space. Their use will
improve the efficiency of cooling within the
enclosure. Includes mounting hardware Qty
2–1U Panels.
12. 10 For more information about APC’s Availability Solutions, visit www.apc.com
Cable Management
As the number of IT components
within each rack enclosure
continues to increase, so do the
number of power and data cables.
Traditionally, overhead cable trays
and under-floor cabling systems limit
flexibility and adaptability. Under-
floor plenum material is costly and
resource-intensive to install, and
under-floor branch circuits can
negatively effect air distribution.
Recognizing these challenges, APC responded with a comprehensive selection of
optional components that allows users to pick the ideal cable management solution for
their particular IT environment. Accessories such as shielded power cable troughs and
data partitions create self-contained cabling, eliminating the need to use space under
a raised floor and permitting better organization in non-raised floor environments.
To determine which accessories are compatible with
specific models of NetShelter enclosures and racks,
check the Accessory Compatibility Chart on page 16-17.
ACCESSORIES: CABLE MANAGEMENT
VERTICAL CABLE MANAGEMENT
Cable Management Rings
AR8113A (X-CERTIFIED)
Facilitates side/vertical cable management. Organizes
data and power cables. Includes Mounting hardware,
Velcro Mounting Straps.
NetShelter®
SX Wide Cable Ring Set
AR7707 (X-CERTIFIED)
Deep cable management rings to facilitate vertical cable
management in typically networking environments.
NetShelter SX 42U/48U Vertical PDU
Mount and Cable Organizer
AR7502/AR7572 (X-CERTIFIED)
Cable management accessory to help eliminate cable
stress and maintain a neat, organized cable layout
within an enclosure or a rack.
Cable Containment Brackets for NetShelter SX
AR7702 (X-CERTIFIED)
Cable management accessory to help eliminate cable
stress and maintain a neat, organized cable layout
within an enclosure or a rack.
Cable Tree for NetShelter SX
AR7505 (X-CERTIFIED)
Cable management accessory to facilitate rear cable
management within an enclosure or a rack. Helps to
eliminate cable stress and maintain a neat, organized cable
layout. Works in both 42U and 48U racks.
Vertical Cable Organizer for NetShelter 0U Channel
AR8442 (X-CERTIFIED)
Toolless, vertical cable management accessory that
allows for quick installation and takes up zero U of
space within the rack. It helps to eliminate cable
stress and organize the cable layout within the rear
channels of the NetShelter® enclosure.
HORIZONTAL CABLE MANAGEMENT
Side Channel Cable Trough
AR8008BLK/AR8016ABLK (X-CERTIFIED)
Adjustable mounting depth, facilitates side
cable management, tool-less mounting. Includes
Installation Guide, Velcro Mounting Straps.
Cable Management Arm
AR8129 (X-CERTIFIED)
Organizes data and power cables. Includes
Installation Guide, Mounting hardware, Velcro
Mounting Straps.
NetShelter SX Wide Mounting Rail
Brush Strips
AR7706 (X-CERTIFIED)
Promotes proper airflow through the rack while
allowing cables to be passed from the front to the
rear of the rack.
1U and 2U Horizontal Cable Organizer
AR8425A, AR8426A (X-CERTIFIED)
Facilitates front cable management. Integrated front
cable hoops. Occupies 1U of rack space. Includes
Installation Guide, Mounting hardware.
2U Patch Cord Organizer Black
AR8427A (X-CERTIFIED)
Facilitates front cable management. Integrated front
cable hoops. Occupies 2U of rack space. Includes
Installation Guide, Mounting hardware.
1U Cable Pass-Thru w/Brush Strip Black
AR8429 (X-CERTIFIED)
Includes Mounting hardware.
2U Horizontal Cable Organizer w/ Pass-Thru
AR8428 (X-CERTIFIED)
Facilitates front cable managent while allowing
cables to pass through to rear appliances. Occupies
2U of rack space.
13. RACK LCD MONITOR KEYBOARD MOUSE
Rack LCD
AP5015 (15-inch LCD Monitor) (X-CERTIFIED)
AP5017 (17-inch LCD Monitor) (X-CERTIFIED)
Integrated keyboard, 15” or 17” monitor, and mouse;
occupies 1U of rack space; allows for rear mounting
of 1U device; integrated touchpad pointing device; power
tilt sensor; PS/2 terminations; standard VGA connector;
low cooling requirements; slide rails; quick release tabs;
On-Screen Display (OSD) adjustments; includes cable
management arm and rack-mount brackets.
KEYBOARDS AND DRAWERS
17" Keyboard Drawer
AR8126ABLK (X-CERTIFIED)
4 Post Mounting. Accommodates 17 inch
keyboards. Adjustable mounting depth. Allows for
rear mounting of 1U device. Integrated wrist rest.
Includes Installation Guide, mounting hardware.
19" Rotating Keyboard Drawer
AR8127BLK (X-CERTIFIED)
4 Post Mounting. Adjustable mounting depth.
Designed for standard desktop keyboards.
Occupies 2U of rack space. Includes Cable
Management Clips, Installation Guide, mounting
hardware, mouse pad, wrist rest.
17" Keyboard
AR8250BLK (Black) (X-CERTIFIED)
104 key keyboard, 2 mouse buttons, integrated
number pad, integrated touchpad pointing device,
mechanical keyswitches, PS/2 terminations.
Includes User Manual.
11For more information about APC’s Availability Solutions, visit www.apc.com
ACCESSORIES
RACK MOUNTING HARDWARE
# 10-32 Hardware Kit
AR8005 (X-CERTIFIED)
Additional hardware for mounting equipment.
Qty 36 #10–32 caged nuts.
M6 Hardware Kit
AR8100 (X-CERTIFIED)
M6 hardware for mounting equipment in 600mm wide
enclosures. Qty 32 sets of M6 caged nuts and nylon
washers and slot/Philips screws
Recessed Rail Kits for NetShelter®
SX
AR7503, AR7504, AR7508, and AR7578
Enables users to mount networking and server equipment
in the same rack or enclosure. Includes: Installation Guide,
Mounting Hardware, Rack mounting hardware
Equipment Support Rails for 600mm
Wide Enclosure.
AR8006A
The Equipment Support Rails will support any non-Rack
Mount piece of equipment that measures 16.75” (43cm) to
17.7” (45cm) wide and has a maximum weight of 200 lbs/
91kg. The Support Rails attach to the side mounting holes
of the vertical mounting rails.
NetShelter SX HP Adapter Kit – L Class/RP54XX
Series
AR8013A
This adapter kit allow HP’s L Class/RP54xx Series
servers to be installed in the NetShelter®
SX Enclosure.
This kit is configured for the installation of one server
Includes: Installation Guide, Mounting Hardware
RACK KVM
16-Port IP KVM Switch
AP5405
Enterprise-class KVM solution for managing Windows,
Sun and Linux/UNIX servers; supports connections
to PS/2, Sun and USB; integrated Microsoft Remote
Desktop Protocol (RDP) functionality; CAT5- or
6-based cabling, supporting distances of up to
500 ft (153 meters); occupies only 1U of rack space;
server-based authentication support for RADIUS,
TACACS+, LDAP, NTLM, Kerberos, and Active
Directory, user access lists per port and user
access logging; centralized management through
cascading with support for up to 1024 servers.
16-Port CAT5 KVM Switch
AP5401
Enterprise-class KVM solution for managing
Windows, Sun and Linux/UNIX servers; supports
connections to PS/2, Sun and USB; CAT5- or
6-based cabling, supporting distances of up to
500 ft (153 meters); occupies only 1U of rack space;
server-based authentication support for RADIUS,
TACACS+, LDAP, NTLM, Kerberos, and Active
Directory, user access lists per port and user access
logging; centralized management through cascading
with support for up to 1024 servers.
8- and 16-Port Analog KVM Switches
AP5201 and AP5202
Multi-platform support (PS/2, USB, or SUN); firmware
upgradeable; hot pluggable; read-only user option;
desktop placement or 1U rack-mount; on-screen
display (OSD) capability; scanning capabilities; daisy-
chain compatible units and manage up to 512 servers
14. ACCESSORIES
12 For more information about APC’s Availability Solutions, visit www.apc.com
To determine which accessories are compatible with
specific models of NetShelter enclosures and racks,
check the Accessory Compatibility Chart on page 16–17.
For more information about APC’s Availability Solutions, visit www.apc.com
ACCESSORIES
RACK MOUNTING HARDWARE
NetShelter
®
SX HP Adapter Kit –
N Class/RP7400
AR8014A
This adapter kit allow HP’s N Class/RP7400
server to be installed in the NetShelter
®
SX Enclosure. This kit is configured for the
installation of one server. Includes: Installation
Guide, Mounting Hardware
RACK SECURITY DEVICES
Door Switch Kit
AP9513 (X-CERTIFIED)
Advanced security, interior and exterior
mounting capabilities. Includes User Manual.
Combination Lock Handles (Qty2)
AR8132A (X-CERTIFIED)
Master key override, Three digit thumbwheel
combination, User configurable combination
STABILIZATION
NetShelter SX Bolt-Down Kit
AR7701
Bolt-down brackets for UBC Zone-4 Seismic
anchoring options in row applications. Includes:
Installation Guide, Mounting Hardware
NetShelter SX 600mm/750mm Stabilizer Plate
AR7700
Stabilization plates to prevent tip-over in stand-alone
rack applications. Includes: Front stabilizing plate,
Installation Guide, Mounting Hardware
SHELVING
Fixed Shelf 50lbs/22.7kg
AR8105BLK (Black) (X-CERTIFIED)
Occupies 2U of rack space, ventilated, cantilever
(2 post) mount. Includes Installation Guide, mounting
hardware.
Fixed Shelf 250lbs/114kg
AR8122BLK (Black) (X-CERTIFIED)
Occupies 1U of rack space, 4 post mounting, adjustable
mounting depth, ventilated. Includes Installation Guide,
Mounting hardware.
Sliding Shelf 100lbs/45.5kg
AR8123BLK (Black) (X-CERTIFIED)
Occupies 1U of rack space, 4 post mounting, adjustable
mounting depth, ventilated. Includes
friction pads, Installation Guide, Mounting hardware,
User Manual.
Sliding Shelf 200lbs/91kg
AR8128BLK (Black) (X-CERTIFIED)
4 post mounting, adjustable mounting depth, full
extension. Occupies 1U of rack space.
Includes Installation Guide, Mounting hardware,
Qty 4–Retaining clips.
TROUGHS AND LADDERS
PDU Shielding Trough 600mm wide Black
AR8160ABLK, AR8160ABLKSEISMIC (X-CERTIFIED)
Facilitates overhead power distribution. Protective
grounding provisions. Toolless mounting. Includes
Installation Guide, Qty 1–8 inch/20cm grounding strap.
NetShelter Shielding Trough 600mm wide
AR8161ABLK, AR8161ABLKSEISMIC (X-CERTIFIED)
Facilitates overhead power distribution. Protective
grounding provisions. Toolless mounting. Includes
Installation Guide, Qty 1–8 inch/20cm grounding strap.
Shielding Partition Solid 600mm
wide Black
AR8162ABLK, AR8162ABLKSEISMIC (X-CERTIFIED)
Facilitates overhead cable management. Protective
grounding provisions, toolless mounting. Includes
Installation Guide, Qty 1–8 inch/20cm grounding strap.
15. For more information about APC’s Availability Solutions, visit www.apc.com 13
ACCESSORIESACCESSORIES
TROUGHS AND LADDERS
Shielding Trough Cover 600mm wide
AR8174BLK (X-CERTIFIED)
Shielding Trough Cover 750mm wide
AR8175BLK (X-CERTIFIED)
750mm Wide Trough Brackets
AR8176BLK (X-CERTIFIED)
750mm Wide Partition Brackets
AR8177BLK (X-CERTIFIED)
PDU Shielding Trough 750mm Wide Black
AR8178BLK (X-CERTIFIED)
Facilitates overhead power distribution. Protective
grounding provisions. Tool-less mounting. Includes
Installation Guide, Qty 1– 8 inch/20cm grounding strap.
Ladder Attach Bracket 2 Post Rack
AR8460
Allows cable ladders to attach to 2-post racks, running
parallel and perpendicular to a row of racks. This
increases agility by providing solutions for environments
with layout challenges
Ladder Corner Clamp Kit
AR8461
These brackets allow ladders to be connected at
90-degree angles to address unique layouts or cable
management needs.
Ladder Angle Clamp Kit
AR8462
These brackets are adjustable to allow the connection
of ladders that are going up a rise between racks and/or
enclosures of different heights.
Ladder Stacking Kit
AR8463
This allows for the vertical stacking of one row of
ladders to separate data and power lines running to and
from racks. APC recommends that the ladders only be
stacked two high.
Ladder Wall Termination Kit 6” & 12” Wide
AR8465
A solution for those applications in which a ladder must
terminate at a wall rather than at another rack
or enclosure.
TROUGHS AND LADDERS
Shielding Partition Pass-through 600mm wide
Black
AR8163ABLK, AR8163ABLKSEISMIC (X-CERTIFIED)
Cable pass-through. Facilitates overhead cable
management. Protective grounding provisions.
Toolless mounting. Includes Installation Guide,
Qty 1–8 inch/20cm grounding strap.
Data Cable Ladder 6" (15cm) with Bracket Kit
AR8164ABLK (X-CERTIFIED) , AR8164AKIT
(ladder alone)
Power Cable Ladder 12" (30cm)
with Bracket Kit
AR8165ABLK (X-CERTIFIED), AR8165AKIT (ladder alone)
APC Ladder Bracket Kit
AR8166ABLK (X-CERTIFIED)
Shielding Trough End Cap Black
AR8167BLK (X-CERTIFIED)
ISX Type A Ladder Brackets
AR8168BLK (X-CERTIFIED)
Installation Guide, Qty 1–8 inch/20cm grounding strap.
APC Ladder Clamp Kit
AR8169 (X-CERTIFIED)
Ladder clamps allow two cable ladders to be connected
end-to-end, extending the cable run.
NetShelter®
Shielding Trough 750mm wide Black
AR8171BLK (X-CERTIFIED)
Facilitates overhead power distribution. Protective grounding
provisions. Toolless mounting. Includes Installation Guide,
Qty 1–8 inch/20cm grounding strap.
Shielding Partition Solid 750mm wide Black
AR8172BLK (X-CERTIFIED)
Facilitates overhead cable management. Protective
grounding provisions. Tool-less mounting. Includes
Installation Guide, Qty 1–8 inch/20cm grounding strap.
Shielding Partition Pass-through
750mm wide Black
AR8173BLK (X-CERTIFIED)
Cable pass-through. Facilitates overhead cable
management. Protective grounding provisions.
Toolless mounting. Includes Installation Guide,
Qty 1–8 inch/20cm grounding strap.
16. SECURITY AND ENVIRONMENTAL
14 For more information about APC’s Availability Solutions, visit www.apc.com
NetBotz®
monitoring appliances
connect to existing IP networks
allowing for easy deployment.
Sensors and cameras may be
attached to provide additional
monitoring capabilities.
Centralized management allows all
aspects of the NetBotz appliances
to be monitored and managed.
NetBotz 500
Centralized
Management Server
NetBotz 420
Sensor Pod
NetBotz 320
NetBotz 500
Camera Pod
Sensor Pod
Temperature sensor Fluid sensor
IP Network
Keeping the racks and enclosures
in your data center safe and
secure should incorporate more
than the latest digital security
solutions. Physical security and
environmental monitoring are key
to protecting the resources in your
racks and enclosures.
APC environmental solutions
monitor conditions in each rack
such as temperature, humidity,
and airflow. The scalable solutions
easily expand to monitor large
numbers of racks, and can be
customized with the appropriate
sensors deployed in strategic
locations for optimal monitoring.
The advanced policy engine
which resides on each monitoring
appliance accommodates
multiple thresholds per sensor,
sophisticated alert mechanisms,
and built-in alert escalation,
enabling you to receive immediate
notification when issues occur.
APC physical security solutions
for racks include access control
and IP-based video surveillance
appliances. Access control
solutions manage entry to individual
racks, ensuring that only authorized
personnel reach important
equipment and resources. Apply a
strict access schedule to specific
doors on individual enclosures,
providing even greater security.
IP-based video surveillance
appliances allow you to know who-
did-what-when on a rack-by-rack
basis. Couple NetBotz camera
pods or third-party closed-circuit
TV cameras with advanced motion
detection capabilities to create a
comprehensive video monitoring
solution. Recorded video can be
centrally accessed, searched, and
tagged for quick retrieval with the
NetBotz centralized management
platform, allowing for a scalable
solution and easy administration for
your enterprise deployments.
Security & Environmental
Solutions for RACKS
As the IP environment expands
to touch all aspects of your
business, important systems
and resources are often kept in
sub-optimal rooms and closets
that are usually unmanned.
This combination of distributed
resources and unoccupied
spaces is an ideal situation for the
introduction of physical threats.
APC environmental solutions
monitor conditions such as
temperature, humidity, and water
leaks in closets and rooms. Rack-
and wall-mount environmental
monitoring appliances and
low-profile sensors are
easily installed for seamless
incorporation into your rooms.
Deploying door sensors allows
for notification when doors to
remote and unmanned locales
are opened.
In addition to monitoring the
environmental conditions
of rooms, physical security
solutions for rooms includes
video monitoring, which captures
a visual record each time a
person accesses a remote room.
The video monitoring solution is
fully customizable, allowing for
configuration of specific days
and times when motion detection
and alarming is enabled or
disabled. Monitoring appliances
include an advanced policy
engine that can be configured
to provide multiple types of
notifications when thresholds
are reached. The APC physical
security solution can easily scale
from a small number of rooms
to a large number of rooms
via an intelligent centralized
management platform.
Security & Environmental Solutions
for ROOMS
17. ACCESSORIES COMPATIBILITY CHART
15For more information about APC’s Availability Solutions, visit www.apc.com
ENVIRONMENTAL
Protect your Network-critical Physical
Infrastructure from environmental threats
Wall- and rack-mount appliances
Protect against damage due to heat, humidity,
water, smoke, dust, and much more
Multiple thresholds for each sensor allowing
for notifications at the informational, warning
and critical levels
Various types of alert actions allow
notifications to be sent to SNMP managers,
email systems, and web servers phones,
pagers, etc.
SURVEILLANCE
Create a visual record of who enters secure
areas and what they do while there
Wall- and rack-mount appliances with cameras
Capture video in response to motion, door
opening, and more
Sort and search recorded clips by many criteria
Control frame rate and resolution to match
network and storage capabilities
ACCESS CONTROL
Network appliances enabling remote and local
authentication for your APC rack enclosure
Proximity-enabled rack access system
Audit trail allows for troubleshooting and
record-keeping
Local authentication for front and rear door of
rack
Access alarms based on remotely configurable
settings
ACCESSORIES
AND SENSORS
Extend the capabilities of your monitoring
appliances
Pods, external sensors, cables, and mounting
brackets
Position sensors at desired monitoring points
Support wide variety of analog and digital
sensors via dry contact, 4-20mA, 0-5V
Mounting and deployment hardware supports
flexible placement of appliances and pods
CENTRALIZED MANAGEMENT
Central server that enables management and
monitoring all of your NetBotz®
appliances
Standard and enterprise servers available
Centralized management, configuration and
administration gives you a 24x7 real-time view
into the status of your environment
For use in a single data center, multiple data
centers, or IDF/MDF closets
PHYSICAL THREAT
Security & Environmental
Monitoring Solutions
Address Multiple Risk Areas
Environmental
Disruption
The #1 physical cause of downtime at remote
locations, environmental problems go beyond
worries of fires and floods. Ventilation and
power are key points of exposure and become
more so as equipment density increases.
Human Error
We call this the "unspoken epidemic" because
no one likes to discuss human error and the
tremendous impact it can have on availability.
However, it’s the second greatest physical
cause of downtime in remote or unsupervised
locations because systems are often housed
in janitor closets, wiring closets, and other
less-than-optimal settings.
Physical Theft
As assets become smaller and more efficient,
they become more attractive targets to steal.
Physical attacks against digital assets are often
overlooked and are a source of real concern.
Sabotage
On everyone’s minds as a result of current
events, terrorism must be given due
consideration, regardless of cost.
There may be threats within your own building
from disgruntled employees who may strike
and, without any prevention, succeed.
SECURITY AND ENVIRONMENTAL
18. 16 For more information about APC’s Availability Solutions, visit www.apc.com
ACCESSORIES COMPATIBILITY CHART
NetShelter
Enclosure &
Rack Accessory
SKUs Description Color
Rack Enclosures Open Frame Racks
AR3100 AR3150 AR3107 AR3157 AR2105BLK
AR100 &
AR100HD
AR200 &
AR201
AR203&
AR204
AR7000 NetShelter SX 42U 600mm Wide Perforated Curved Door Black Black •
AR7007 NetShelter SX 48U 600mm Wide Perforated Curved Door Black Black •
AR7050 NetShelter SX 42U 750mm Wide Perforated Curved Door Black Black •
AR7057 NetShelter SX 48U 750mm Wide Perforated Curved Door Black Black •
AR7100 NetShelter SX 42U 600mm Wide Perforated Split Doors Black Black •
AR7107 NetShelter SX 48U 600mm Wide Perforated Split Doors Black Black •
AR7150 NetShelter SX 42U 750mm Wide Perforated Split Black •
AR7157 NetShelter SX 48U 750mm Wide Perforated Split Doors Black Black •
AR7201 NetShelter SX 600mm Wide x 1070mm Deep Standard Roof Black Black • •
AR7202 Roof Match Kit for SX to VX, 750mm Black • •
AR7203 Roof Match Kit for SX to VX, 600mm Black • •
AR7204 Grommet/Cover for Roof Openings on NetShelter SX Black • • • •
AR7209 NetShelter SX Roof Bridge to Facilitate Overhead Cabling Black • • • •
AR7251 NetShelter SX 750mm Wide x 1070mm Deep Standard Roof Black Black • •
AR7301 NetShelter SX 42U 1070mm Deep Split Side Panels Black Qty 2 Black • •
AR7371 NetShelter SX 48U 1070mm Deep Split Side Panels Black Qty 2 Black • •
AR7502 NetShelter SX 42U Vertical PDU Mount and Cable Organizer Black • •
AR7503 NetShelter SX 42U 600mm Wide Recessed Rail Kit Black •
AR7504 NetShelter SX 48U 600mm Wide Recessed Rail Kit Black •
AR7505 Cable Tree for NetShelter SX Black • • • •
AR7508 NetShelter SX 42U 750mm Wide Recessed Rail Kit Black •
AR7572 NetShelter SX 48U Vertical PDU Mount and Cable Organizer Black • •
AR7578 NetShelter SX 48U 750mm Wide Recessed Rail Kit Black •
AR7600 NetShelter SX 42U/48U Baying Trim Kit Black Black • • • •
AR7601 Baying Kit for 42U SX to VX or VS – 600mm centers Black • •
AR7602 Baying Kit for 42U SX to VX or VS – 24 inch centers Black • •
AR7700 NetShelter SX 600mm/750mm Stablilizer Plate Black Black • • • •
AR7701 NetShelter SX Bolt-Down Kit Black • • • •
AR7702 Cable Containment Brackets for Netshelter SX Black • • • •
AR7706 NetShelter SX 750mm Mounting Rail Brush Strips Black • •
AR7707 NetShelter SX Wide Cable Ring Set Black • •
AR7708 NetShelter SX Air Recirculation Prevention Kit Black • • • •
AR8005 #10-32 Hardware Kit (Qty-36) N/A • • • • • • AR203only
AR8006A Equipment Support Rails 600mm wide White-Zinc • • •
AR8008BLK Side Channel Cable Trough Black • • •
AR8010BLK Recessed Rail Kit for 600mm wide Black • •
AR8011BLK Dual PDU Mounting Brackets 600mm wide Black •
AR8013 HP Adapter Kit – L Class/RP54XX Series Black •
AR8013A NetShelter SX HP Adapter Kit – L Class/RP54xx Series Black • •
AR8014 HP Adapter Kit–N Class/RP7400 Series Black •
AR8014A NetShelter SX HP Adapter Kit–N Class/RP7400 Series Black • •
AR8015 M6 Hardware Kit (Qty-32) for AR203 Black AR203only
AR8016ABLK NetShelter SX Side Channel Cable Trough Black • •
AR8100 M6 Hardware Kit (Qty-32) N/A • • • • • • AR203only
AR8101BLK Blanking Panel Kit 19” Black (1U, 2U, 4U, 8U) Black • • • • • • • •
AR8105BLK Fixed Shelf 50lb/23kg Black Black • • • • • • • •
AR8108BLK 1U Blanking Panel Kit 19” Black Black • • • • • • • •
AR8112BLK Bolt-Down Bracket Kit Black Black •
AR8113A Cable Management Rings Black • • • • • • • •
AR8115ABLK Stabilizer Plate 600mm Wide Black Black •
AR8116BLK Cable Containment Brackets Black Black •
AR8122BLK Fixed Shelf 250lbs/114kg Black Black • • • • • AR203only
AR8123BLK Sliding Shelf 100lbs/45kg Black Black • • • • • •
AR8126ABLK 17” Keyboard Drawer Black Black • • • • • •
AR8127BLK 19” Rotating Keyboard Drawer Black Black • • • • • •
AR8128BLK Sliding Shelf 200lbs/91kg Black Black • • • • • •
AR8129 1U Cable Management Arm White-Zinc • • • • • •
AR8132A NetShelter SX-VX-VS Combination Door Lock Handle Black • • • • •
AR8136BLK 1U Plastic Blanking Panel Kit 19” Black (Qty–10) Black • • • • • AR203only
AR8136BLK200 1U Plastic Blanking Panel Kit 19” Black (Qty–200) Black • • • • • AR203only
AR8160ABLK PDU Shielding Trough 600mm wide Black Black • •
AR8161ABLK NetShelter Shielding Trough 600mm Wide Black Black • • •
AR8162ABLK Shielding Partition Solid 600mm Wide Black Black • • •
AR8163ABLK Shielding Partition Pass-Through 600mm Wide Black Black • • •
19. 17For more information about APC’s Availability Solutions, visit www.apc.com
NetShelter
Enclosure &
Rack Accessory
SKUs Description Color
Rack Enclosures Open Frame Racks
AR3100 AR3150 AR3107 AR3157 AR2105BLK
AR100 &
AR100HD
AR200 &
AR201
AR203&
AR204
AR8164AKIT Data Cable Ladder 6” (15cm) wide (Qty 1) Black • • • • • •
AR8164ABLK Data Cable Ladder 6” (15cm) wide w/ Bracket Kit Black • • • • • •
AR8165AKIT Power Cable Ladder 12” (30cm) wide (Qty 1) Black • • • • • •
AR8165ABLK Power Cable Ladder 12” (30cm) wide w/ Bracket Kit Black • • • • • •
AR8166ABLK Ladder Bracket Kit Black • • • • • •
AR8167BLK Trough End Cap Black (Qty-2) Black • • • • • •
AR8168BLK Ladder to Enclosure Connection Brackets Black • • • • • •
AR8169 Ladder Clamp Kit Black • • • • • •
AR8171BLK NetShelter Shielding Trough 750mm Wide Black Black • •
AR8172BLK Shielding Partition Solid 750mm Wide Black Black • •
AR8173BLK Shielding Partition Pass-Through 750mm Wide Black Black • •
AR8174BLK Shielding Trough Cover 600mm Wide Black (Qty-2) Black • • •
AR8175BLK Shielding Trough Cover 750mm Wide Black (Qty-2) Black • •
AR8176BLK 750mm Wide Trough Brackets Black • •
AR8177BLK 750mm Wide Partition Brackets Black • •
AR8178BLK PDU Shielding Trough 750mm Wide Black Black • •
AR8355 NetShelter WX Vented Gland Plate Black •
AR8359 NetShelter WX Caster Kit Black •
AR8390 Grounding Kit N/A •
AR8400 #12-24 Hardware Kit (Qty-24) Black • • AR204only
AR8410 NetShelter 4-Post Rack Baying Brackets 24” Centers Black •
AR8411 NetShelter 4-Post Rack Baying Brackets 600mm Centers Black •
AR8415 NetShelter 4-Post Rack PDU Mounting Brackets Black •
AR8416 NetShelter 4-Post Rack PDU Adapter Plates Black •
AR8417 NetShelter 4-Post Rack PDU Adapter Brackets Black •
AR8422 Double-Sided Fixed Shelf for 2-Post Rack 250lbs/114kg Black •
AR8425A 1U Horizontal Cable Organizer Black • • • • • • • •
AR8426A 2U Horizontal Cable Organizer Black • • • • • • • •
AR8427A 2U Patch Cord Organizer Black • • • • • • • •
AR8428 2U Patch Cord Organizer with Pass-Thru Black • • • • • • • •
AR8429 1U Cable Pass-Thru with Brush Strip Black • • • • • • • •
AR8440A 3” Vertical Cable Organizer Black • •
AR8441A 6” Vertical Cable Organizer Black • •
AR8442 Vertical Cable Organizer for NetShelter 0U Channel Black • • • • •
AR8445 3” Control Bracket Kit Black •
AR8446 6” Control Bracket Kit Black •
AR8450 NetShelter 4-Post Rack Roof Black •
AR8460 Ladder Attach Bracket 2 Post Rack Black •
AR8461 Ladder Corner Clamp Kit Black •
AR8462 Ladder Angle Clamp Kit Black •
AR8463 Ladder Stacking Kit Black •
AR8465 Ladder Wall Termination Kit 6” & 12” Wide Black •
AP9513 Door Switch Kit Grey • • • • •
Rack Cooling
SKUs Description Color
Open Frame Racks
AR3100 AR3150 AR3107 AR3157 AR2105BLK
AR100 &
AR100HD
AR200 &
AR201
AR203&
AR204
ACF001 RM Air Distribution Unit 120V Black • • • • •
ACF002 RM Air Distribution Unit 208/230V Black • • • • •
ACF003 RM Air Distribution Unit 100V Black • • • • •
ACF400 Rack Air Removal Unit 100-240V 50/60HZ for NetShelter SX 600 mm
Wide Rack
Black
• •
ACF402 Rack Air Removal Unit 100-240V 50/60HZ for NetShelter SX 750 mm
Wide Rack
Black
• •
ACF126 Rack Air Removal Unit SX Ducting Kit for 24” Black • • • •
ACF127 Rack Air Removal Unit SX Ducting Kit for 600mm Ceiling Tiles Black • • • •
ACF122 ARU Door Grille Kit Black • • • •
AR8206BLK NetShelter WX Fan Tray 120VAC Black Black •
AR8207BLK NetShelter WX Fan Tray 230VAC Black Black •
ACF501 Netshelter SX Roof Fan Tray 115 VAC Black • •
ACF502 Netshelter SX Roof Fan Tray 208-230 VAC Black • •
ACF503 Netshelter SX Roof Fan Tray 115 VAC 750mm Black • •
ACF504 Netshelter SX Roof Fan Tray 208-230 VAC 750mm Black • •
ACF201BLK Rack Side Air Distribution 2U 115V 60HZ Black • • • • •
ACF202BLK Rack Side Air Distribution 2U 208/230 50/60HZ Black • • • • •
