1. Apache Kafka Best
Practices
Manikumar Reddy
@omkreddy

2. 2 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Apache Kafka
 Core APIs
– The Producer API
– The Consumer API
– The Connector API
– The Streams API
 Broad classes of applications
– Building real-time streaming data pipelines
– Building real-time streaming applications
– core building block in other data systems

3. 3 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Key Concepts and Terminology

4. 4 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Component Layout

5. 5 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Hardware Guidance
Cluster Size Memory CPU Storage
Kafka Brokers 3+
24G+ (for small)
64GB+ (for large)
Multi- core
processors( 12 CPU+
core), Hyper
threading enabled
6+ x 1TB dedicated
disks( RAID or JBOD)
Zookeeper
3 (for small)
5 (for large)
8GB+ (for small)
24GB+ (for large)
2 core +
SSD for Transaction
logs

6. 6 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
OS Tuning
 OS Page Cache
– Ex: Allocate to hold all the active segments of the log.
 File descriptor limits : >100k
 less swapping
 Tcp tuning
 JVM Configs
– Java 8 with G1 Collector
– 6-8 GB heap

7. 7 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Disk Storage
 Use multiple disk spindles, dedicated to kafka
 JBOD vs RAID10
 JBOD
– Gives all the disk I/O
 JBOD Limitations
– any disk failure causes an unclean shutdown and requires lengthy recovery
– data is not distributed consistently across disks
– Multiple directories
 KIP-112/113
– necessary tools for users to manage JBOD
– Intelligent partition assignment
– On disk failure, broker can serve replicas on the good disks
– re-assign replicas between disks of the same broker

8. 8 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
RAID
 RAID10
– Can survive single disk failure
– Performance and protection
– balance load across disks
– Single mount point
– Performance hit and reduces the space
 File System
– EXT or XFS
– SSD
– Issues on NFS.
– SAN, NAS

9. 9 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Basic Monitoring
 CPU Load
 Network Metrics
 File Handle Usage
 Disk Space
 Disk I/O Performance
 Garbage Collection
 ZooKeeper Monitoring

10. 10 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Replication
 Partition has replicas – Leader replica, Follower replicas
 Leader maintains in-sync-replicas (ISR)
– replica.lag.time.max.ms, num.replica.fetchers
– min.insync.replica – used by producer to ensure greater durability
https://www.slideshare.net/junrao/kafka-replication-apachecon2013

11. 11 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Under Replicated Partitions
 Number of partitions which are not fully replicated within the cluster
 Mbean - kafka.server:type=ReplicaManager,name=UnderReplicatedPartitions
 ISR Shrink/Expand Rate
 Under Replicated Partitions
– Lost Broker?
– Controller Issues
– Zookeeper Issues
– Network Issues
 Solutions
– Tune the ISR settings
– Expand brokers

12. 12 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Controller
 Manages Partitions Life cycle
 Avoid controller's ZK session expires
– Soft failures – ISR Churn/Under replicated partitions
– ZK Server performance
– Long GC pauses on Broker
– Bad network configuration
 Monitoring
– Mbean : kafka.controller:type=KafkaController,name=ActiveControllerCount
– only one broker in the cluster should have 1
– LeaderElectionRate

13. 13 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Unclean leader election
 Enable replicas not in the ISR set to be elected as leader
 Availability vs correctness
– By-default kafka chooses availability
 Monitoring
– Mbean : kafka.controller:type=ControllerStats,name=UncleanLeaderElectionsPerSec
 Default will be changed in next release

14. 14 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Broker Configs
 log.retention.{ms, minutes, hours} , log.retention.bytes
 message.max.bytes, replica.fetch.max.bytes
 delete.topic.enable
 unclean.leader.election.enable = false
 min.insync.replicas = 2
 replica.lag.time.max.ms, num.replica.fetchers
 replica.fetch.response.max.bytes
 zookeeper.session.timeout.ms = 30s
 num.io.threads

15. 15 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Cluster Sizing
 Broker Sizing
– Partition count on each broker (<2K)
– Keep partition size on disk manageable (under 25GB per partition )
 Cluster Size (no. of brokers)
– how much retention we need
– how much traffic cluster is getting
 Cluster Expansion
– Disk usage on the log segments partition should stay under 60%
– Network usage on each broker should stay under 75%
 Cluster Monitoring
– Keep cluster balanced
– Ensure that partitions of a topic are fairly distributed across brokers
– Ensure that nodes in a cluster are not running out of disk and network

16. 16 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Broker Monitoring
 Partition Counts
– Mbean: kafka.server:type=ReplicaManager,name=PartitionCount
 Leader replica counts
– Mbean: kafka.server:type=ReplicaManager,name=LeaderCount
 ISR Shrink Rate/ISR expansion rate
– kafka.server:type=ReplicaManager,name=IsrExpandsPerSec
 Message in rate/Byte in rate/Byte out rate
 NetworkProcessorAvgIdlePercent
 RequestHandlerAvgIdlePercent

17. 17 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Topic Sizing
 No. of partitions
– Have at least as many partitions as there are consumers in the largest group
– topic is very busy – more partitions
– Keep partition size on disk manageable (under 25GB per partition )
– Take into account any other application requirements
– Special use cases – single partition
 Keyed messages
– enough partitions to deal with future growth
 expanding partitions
– whenever the size of the partition on disk is larger than threshold

18. 18 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Choosing Partitions
 Based on throughput requirements one can pick a rough number of partitions.
– Lets call the throughput from producer to a single partition is P
– Throughput from a single partition to a consumer is C
– Target throughput is T
– At least max (T/P, T/C)
 More Partitions
– More open file handles
– May increase unavailability
– May increase end-to-end latency
– More memory for clients

19. 19 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Quotas
 Protect from bad clients and maintain SLAs
 byte-rate thresholds on produce and fetch requests
 can be applied to (user, client-id), user or client-id groups.
 Server delays the responses
 Broker Metrics for monitoring – throttle-rate, byte-rate
 replica.fetch.response.max.bytes
– Limit memory usage of replica fetch response
 Limiting bandwidth usage during data migration
– kafka-reassign-partitions.sh -- -throttle option

20. 20 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Producer
 User new java based clients
 Test in your Environment
– kafka-producer-perf-test.sh
 Memory
 CPU
 Batch Compression
 Avoid large messages
– creates more memory pressure
– slows down the brokers

21. 21 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Critical Configs
 batch.size
– size based batching
– larger size -> high throughput, higher latency
 linger.ms
– time based batching
– larger size -> high throughput, higher latency
 max.in.flight.requests.per.connection
– Better throughput, affects ordering
 compression.type
– adding more user threads can help throughput
 acks
– Affects message durability

22. 22 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Performance tuning
 If throughput < network capacity
– Add more user threads
– Increase batch size
– Add more producers instances
– Add more partitions
 Latency when acks = -1
– Increase num.replica.fetchers
 Cross datacenter data transfer
– Tune socket buffer settings, OS tcp buffer settings

23. 23 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Producer Monitoring
 batch-size-avg
 compression-rate-avg
 waiting-threads
 buffer-available-bytes
 record-queue-time-max
 record-send-rate
 records-per-request-avg

24. 24 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Consumer
 Test in your Environment
– kafka-consumer-perf-test.sh
 Throughput Issues
– not enough partitions
– OS Page Cache - allocate enough to hold all the messages for your consumers for say, 30s
– Application/Processing logic
 Offsets topic
– __consumer_offsets
– offsets.topic.replication.factor
– offsets.retention.minutes
– Monitor ISR, topic size
 Slow offset commits
– commit async, manual commits

25. 25 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Consumer Configs
 fetch.min.bytes and fetch.max.wait.ms
 max.poll.interval.ms
 max.poll.records
 session.timeout.ms
 Consumer Rebalance
– check timeouts
– check processing times/logic
– GC Issues
 Tune network settings

26. 26 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Consumer Monitoring
 Whether or not the consumer is keeping up with the messages that are being produced
 Consumer Lag: Difference between the end of the log and the consumer offset
 Monitoring
– Metrics Monitoring - records-lag-max
– bin/kafka-consumer-groups.sh
– LinkedIn’s Burrow for consumer monitoring
 Decreasing Lag
– Analyze consumer - GC Issues, hung instance
– Add more consumer Instances
– increase the number of partitions and consumers

27. 27 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
No data loss settings
 Producer
– block.on.buffer.full=true
– retries=Long.MAX_VALUE
– acks=all
– max.in.flight.requests.per.connection=1
– close producer
 Broker
– replication factor >= 3
– min.insync.replicas=2
– disable unclean leader election
 Consumer
– disable auto.offset.commit
– Commit offsets only after the messages are processed

28. 28 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Authorizer - Ranger Auditing

29. 29 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Mirror Maker
 Tool to mirror a source Kafka cluster into a target (mirror) Kafka cluster

30. 30 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Mirror Maker
 Run multiple mirroring processes
– high fault-tolerance
– high throughput
 --num.streams option to specify the number of consumer threads
– no.of threads in num.streams

31. 31 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Kafka Mirror Maker
 Consumer and source cluster socket buffer sizes
– high value for the socket buffer size
– consumer's fetch size
– OS networking Tuning
 Source and Target Clusters are independent entities
– Can be different numbers of partitions
– offsets will not be the same.
– partitioning order is preserved on a per-key basis.
 Create topics in target cluster
 Monitor whether a mirror is keeping up
– Consumer Lag
 Running In Secure Clusters
– We recommend to use SSL
– We can run MM on source cluster

32. 32 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Open source Operational Tools
 Ambari Metrics
– https://docs.hortonworks.com/HDPDocuments/Ambari-2.4.2.0/bk_ambari-user-
guide/content/grafana_kafka_dashboards.html
 Removing brokers and rebalancing partitions in a cluster
– https://github.com/linkedin/kafka-tools
 Consumer Lag Monitoring
– Burrow (https://github.com/linkedin/Burrow)
 Kafka Manager - https://github.com/yahoo/kafka-manager

33. 33 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Apache Kafka 0.10.2 release
 Includes 15 KIPs, over 200 bug fixes and improvements
 The newest Java Clients now support older brokers (0.10.0 and higher)
 Separation of Internal and External traffic
 Create Topic Policy
 Security Improvements
– Support for SASL/SCRAM mechanisms
– Dynamic JAAS configuration for Kafka clients
– Support for authentication of multiple Kafka clients in single JVM
 Producer and Consumer Improvements
 Connect API & Streams API improvements

34. 34 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
Thank You

35. 35 © Hortonworks Inc. 2011 – 2017. All Rights Reserved
References
 http://kafka.apache.org/documentation.html
 https://community.hortonworks.com/articles/80813/kafka-best-practices-1.html
 https://www.slideshare.net/JiangjieQin/producer-performance-tuning-for-apache-
kafka-63147600
 https://www.slideshare.net/ToddPalino/tuning-kafka-for-fun-and-profit
 https://www.slideshare.net/JiangjieQin/no-data-loss-pipeline-with-apache-kafka-
49753844
 https://www.slideshare.net/ToddPalino/putting-kafka-into-overdrive
 https://www.confluent.io/blog/how-to-choose-the-number-of-topicspartitions-in-a-
kafka-cluster/
