About NetApp clustered Data ONTAP in Tech-Circle Event 2017/3/31

1. Ansible Module Topic
2017/3/31
TIS OSS 推進室
倉持健史

2. Ansible とは、
『 オートメーション（自動化）することができるソフトウェア 』
３つの特徴
Simple
Powerful
Agentless
Source : https://www.ansible.com/it-automation

3. Ansible の適用範囲
自動化出来るのは
サーバだけじゃない！

4. エンタープライズ志向なAnsible
 ネットワーク機器 の対応
Cisco、Juniper、F5、A10、・・・
 ストレージ機器 の対応
NetApp、INFINIDAT
 Windows の対応
 クラウド の対応
 Docker の対応

5. Source: docs.ansible.com

6. Author
 Sumit Kumar
 timuster（https://github.com/timuster）
 TME（テクニカルマーケティングエンジニア）
 NetApp, Inc. 所属

7. Requirement for NetApp cDOT Modules
 Ansible version
 v2.3（RC2）
 Python module
 netapp-lib（2015.9.25 <）
 latest version: 2016.10.14
 Target Storage OS version
 clustered DataONTAP 8.3
 Status
 preview

8. Readiness
# git clone git://github.com/ansible/ansible.git
# cd ansible/
# git checkout stable-2.3
# source ./hacking/env-setup
# ansible --version
ansible 2.3.0.0 (stable-2.3 af83d4d4df) last updated 2017/03/30 15:16:14 (GMT +900)
config file = /etc/ansible/ansible.cfg
configured module search path = Default w/o overrides
python version = 2.7.5 (default, Nov 20 2015, 02:00:19) [GCC 4.8.5 20150623 (Red Hat 4.8.5-4)]
# pip install netapp-lib

9. Playbook
---
- name: Test Playbook for NetApp cDOT Modules
hosts: localhost
gather_facts: no
vars:
netapp_hostname: 192.168.175.206
netapp_username: "admin"
netapp_password: “PASSWORD"
mysvm: "my_SVM"
svm_root_vol: "root_v01“
tasks:
- name: create SVM
na_cdot_svm:
state: present
name: "{{ mysvm }}"
root_volume: "{{ svm_root_vol }}"
root_volume_aggregate: "itc_aggr02"
root_volume_security_style: mixed
hostname: "{{ netapp_hostname }}"
username: "{{ netapp_username }}"
password: "{{ netapp_password }}"
tags: CREATE

10. Before
Console :
Clustered Data ONTAP

11. Run Playbook
# ansible-playbook -i hosts playbook.yml -t CREATE
PLAY [Test Playbook for NetApp cDOT Modules]
*****************************************************************************
TASK [create SVM]
*****************************************************************************
changed: [localhost]
PLAY RECAP
*****************************************************************************
localhost : ok=1 changed=1 unreachable=0 failed=0

12. After
Console :
Clustered Data ONTAP

13. Playbook (cont.)
- block:
- name: before destroy SVM make root vol offline
na_cdot_volume:
state: absent
name: "{{ svm_root_vol }}"
vserver: "{{ mysvm }}"
hostname: "{{ netapp_hostname }}"
username: "{{ netapp_username }}"
password: "{{ netapp_password }}"
- name: destroy SVM
na_cdot_svm:
state: absent
name: "{{ mysvm }}"
hostname: "{{ netapp_hostname }}"
username: "{{ netapp_username }}"
password: "{{ netapp_password }}"
tags: DESTROY

14. References
 Roadmap
Core 2.3 Target: Mid April 2017
https://github.com/ansible/ansible/blob/devel/docs/docsite/rst/roadmap/ROADMAP_2_3.rst
 Sample Playbook
https://github.com/timuster/netapp_ansible_playbooks
