The document describes experiments conducted to measure pressure-concentration isotherms (PCI) for two mischmetal-based hydrogen storage alloys (MmNi3.9Co0.6Al0.5 and MmNi4Al) using both static and dynamic methods. The effects of hydrogen flow rate on plateau pressure, enthalpy of formation, and entropy of formation were studied. For MmNi3.9Co0.6Al0.5, both the shape of the PCI curve and plateau pressure depended on the flow rate, but flow rate did not significantly affect plateau pressure for MmNi4Al. Both alloys showed variations in enthalpy of formation with flow rate due to reaction rate changes
