1. Android TV:
Building apps with
Google’s Leanback Library

2. Joe Birch
Android Engineer @Buffer
@hitherejoe / hitherejoe.com

3. What is Android TV?

5. Build on Material

6. Build on Material Casual Consumption

7. Build on Material Casual Consumption
Cinematic Experience

8. Build on Material Casual Consumption
Cinematic Experience Simplicity

9. Navigation
Getting around

10. D-Pad controls

11. Focus based Navigation

13. Setting up
Getting your project ready

14. <uses-feature
android:name="android.hardware.microphone"
android:required="false"/>
<uses-feature
android:name="android.hardware.touchscreen"
android:required="false"/>
<uses-feature
android:name="android.software.leanback"
android:required="true"/>
<activity
android:name=“com.hitherejoe.vineyard.ui.main.LeanbackActivity”
android:label="@string/app_name"
android:theme="@style/Theme.Leanback">
<intent-filter>
<action android:name="android.intent.action.MAIN"/>
<category android:name="android.intent.category.LEANBACK_LAUNCHER"/>
</intent-filter>
</activity>

15. github.com/hitherejoe/vineyard
github.com/hitherejoe/bourbon

16. BrowseFragment
Display browsable content to the user

18. <fragment xmlns:android="http://schemas.android.com/apk/res/android"
android:name=“com.hitherejoe.vineyard.ui.fragment.BrowseFragment”
android:id="@+id/main_browse_fragment"
android:layout_width="match_parent"
android:layout_height="match_parent"/>

20. setBrandColor(ContextCompat.getColor(this,
R.color.fastlane_background));

21. Color color = ContextCompat.getColor(this, R.color.accent);
setSearchAffordanceColor(color);

22. Drawable badge = ContextCompat.getDrawable(
this, R.drawable.banner_shadow);
setBadgeDrawable(badge);

23. setHeadersState(HEADERS_ENABLED);

24. setHeadersState(HEADERS_HIDDEN);

25. setHeadersState(HEADERS_DISABLED);

28. Browse Fragment
Header Item
Presenter
Header Item
List Row
Array Object
Adapter
Post Adapter

29. Browse Fragment
Header Item
Presenter
Header Item
List Row
Array Object
Adapter
Post Adapter

30. public class IconHeaderItemPresenter extends RowHeaderPresenter {
@Override
public ViewHolder onCreateViewHolder(ViewGroup viewGroup) {
// inflate layout
}
@Override
public void onBindViewHolder(Presenter.ViewHolder viewHolder,
Object o) {
// set text, icons etc
}
@Override
public void onUnbindViewHolder(Presenter.ViewHolder viewHolder) {
// free resources
}
}

31. public class IconHeaderItemPresenter extends RowHeaderPresenter {
@Override
public ViewHolder onCreateViewHolder(ViewGroup viewGroup) {
// inflate layout
}
@Override
public void onBindViewHolder(Presenter.ViewHolder viewHolder,
Object o) {
// set text, icons etc
}
@Override
public void onUnbindViewHolder(Presenter.ViewHolder viewHolder) {
// free resources
}
}

32. <android.support.v17.leanback.widget.NonOverlappingLinearLayout
xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="match_parent"
android:layout_height=“match_parent"
android:orientation="horizontal">
<ImageView
android:id="@+id/header_icon"
android:layout_width="32dp"
android:layout_height="32dp"/>
<TextView
android:id="@+id/header_label"
android:layout_marginLeft="6dp"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:textColor="@color/white"
android:textSize=“@dimen/header_text”/>
</android.support.v17.leanback.widget.NonOverlappingLinearLayout>

33. public class IconHeaderItemPresenter extends RowHeaderPresenter {
@Override
public ViewHolder onCreateViewHolder(ViewGroup viewGroup) {
// inflate layout
}
@Override
public void onBindViewHolder(Presenter.ViewHolder viewHolder,
Object o) {
// set text, icons etc
}
@Override
public void onUnbindViewHolder(Presenter.ViewHolder viewHolder) {
// free resources
}
}

34. @Override
public void onBindViewHolder(Presenter.ViewHolder viewHolder,
Object o) {
HeaderItem headerItem = ((ListRow) o).getHeaderItem();
setIconDrawable(headerItem.getName(), viewholder.iconImage);
TextView label = viewHolder.headerText;
label.setText(headerItem.getName());
}

35. public class IconHeaderItemPresenter extends RowHeaderPresenter {
@Override
public ViewHolder onCreateViewHolder(ViewGroup viewGroup) {
// inflate layout
}
@Override
public void onBindViewHolder(Presenter.ViewHolder viewHolder,
Object o) {
// set text, icons etc
}
@Override
public void onUnbindViewHolder(Presenter.ViewHolder viewHolder) {
// release bitmaps if used
}
}

36. setHeaderPresenterSelector(new PresenterSelector() {
@Override
public Presenter getPresenter(Object o) {
return new IconHeaderItemPresenter();
}
});

37. Browse Fragment
Header Item
Presenter
Header Item
List Row
Array Object
Adapter
Array Object
Adapter

38. Header Item
List Row
Array Object
Adapter

39. ArrayObjectAdapter rowAdapter = new ArrayObjectAdapter(this);
rowAdapter.add(…);
HeaderItem header = new HeaderItem(headerPosition, tag);
mRowsAdapter.add(new ListRow(header, rowAdapter));

40. Browse Fragment
Array Object
Adapter

41. setOnItemViewClickedListener(mOnItemViewClickedListener);
setOnItemViewSelectedListener(mOnItemViewSelectedListener);

42. @Override
public void onItemClicked(Presenter.ViewHolder itemViewHolder,
Object item,
RowPresenter.ViewHolder rowViewHolder,
Row row) {
// Do stuff with clicked item object
}

43. @Override
public void onItemSelected(Presenter.ViewHolder itemViewHolder,
Object item,
RowPresenter.ViewHolder rowViewHolder,
Row row) {
// Do stuff with selected item object
}

46. BackgroundManager backgroundManager =
BackgroundManager.getInstance(getActivity());

47. BackgroundManager backgroundManager =
BackgroundManager.getInstance(getActivity());
backgroundManager.attach(getActivity().getWindow());

48. BackgroundManager backgroundManager =
BackgroundManager.getInstance(getActivity());
backgroundManager.attach(getActivity().getWindow());
backgroundManager.setBitmap(resource);

49. BackgroundManager backgroundManager =
BackgroundManager.getInstance(getActivity());
backgroundManager.attach(getActivity().getWindow());
backgroundManager.setBitmap(resource);
// Don’t forget to release!!
backgroundManager.release();

50. SearchFragment
Allow users to search for content

52. @Override
public boolean onQueryTextChange(String newQuery)
@Override
public boolean onQueryTextSubmit(String query)

53. Post Results
(Array Object Adapter)
Search Results
(Array Object Adapter)
Row Adapter
(Array Object Adapter)
Focused item triggers Post search

55. VerticalGridFragment
Display a grid of browsable content to the user

57. VerticalGridPresenter gridPresenter =
new VerticalGridPresenter();
gridPresenter.setNumberOfColumns(NUM_COLUMNS);
setGridPresenter(gridPresenter);

58. PlaybackActivity
Display media content on screen

60. mSession = new MediaSession(this, getString(R.string.app_name);
mSession.setCallback(new MediaSessionCallback());
mSession.setActive(true);
setMediaController(new MediaController(this,
mSession.getSessionToken());

61. PlaybackOverlayFragment
Display playback controls to the user

64. mMediaController = getActivity().getMediaController();
mMediaController.registerCallback(mMediaControllerCallback);
private class MediaControllerCallback extends MediaController.Callback {
@Override
public void onPlaybackStateChanged(@NonNull PlaybackState state) { }
@Override
public void onMetadataChanged(@NonNull MediaMetadata metadata) { }
}

65. ArrayObjectAdapter
(Row Adapter)
ArrayObjectAdapter
(Related Posts)
ArrayObjectAdapter
(Primary Actions)
ArrayObjectAdapter
(Secondary Actions)
PlayBackControlsRow
Meta Data

66. ControlButtonPresenterSelector presenterSelector =
new ControlButtonPresenterSelector();
mPrimaryActionsAdapter =
new ArrayObjectAdapter(presenterSelector);
mSecondaryActionsAdapter =
new ArrayObjectAdapter(presenterSelector);
mPlaybackControlsRow
.setPrimaryActionsAdapter(mPrimaryActionsAdapter);
mPlaybackControlsRow
.setSecondaryActionsAdapter(mPrimaryActionsAdapter);

67. public class Action {
private Drawable mIcons;
private CharSequence mLabel1;
private CharSequence mLabel2;
private ArrayList mKeyCodes;
…
}

68. mPlayPauseAction = new PlayPauseAction(getActivity());
mRepeatAction = new RepeatAction(getActivity());
mSkipNextAction = new SkipNextAction(getActivity());
mSkipPreviousAction = new SkipPreviousAction(getActivity());
mPrimaryActionsAdapter.add(mPlayPauseAction);
mPrimaryActionsAdapter.add(mSkipNextAction);
mPrimaryActionsAdapter.add(mSkipPreviousAction);
mSecondaryActionsAdapter.add(mRepeatAction);

69. playbackControlsRowPresenter.setOnActionClickedListener(new OnActionClickedListener() {
public void onActionClicked(Action action) {
if (action.getId() == mPlayPauseAction.getId()) {
togglePlayback(mPlayPauseAction.getIndex() == PlayPauseAction.PLAY);
} else if (action.getId() == mSkipNextAction.getId()) {
next(true);
} else if (action.getId() == mSkipPreviousAction.getId()) {
prev(true);
} else if (action.getId() == mRepeatAction.getId()) {
loopVideos();
}
if (action instanceof PlaybackControlsRow.MultiAction) {
notifyChanged(action);
}
}
});

70. mMediaController.getTransportControls().play();
mMediaController.getTransportControls().pause;
mMediaController.getTransportControls().skipToNext();
mMediaController.getTransportControls().skipToPrevious();
mMediaController.getTransportControls().fastForward;
mMediaController.getTransportControls().rewind();
mMediaController.getTransportControls()
.sendCustomAction(CUSTOM_ACTION_AUTO_LOOP, null);

71. Post item = (Post) mPlaybackControlsRow.getItem();
item.description = description;
item.username = username;
mPlaybackControlsRow.setTotalTime((int) duration);
mPlaybackControlsRow.setImageDrawable(resource);
mPlaybackControlsRow.setCurrentTime(currentTime);
mPlaybackControlsRow.setBufferedProgress(bufferedT

72. Post item = (Post) mPlaybackControlsRow.getItem();
item.description = description;
item.username = username;
mPlaybackControlsRow.setTotalTime((int) duration);
mPlaybackControlsRow.setImageDrawable(resource);
mPlaybackControlsRow.setCurrentTime(currentTime);
mPlaybackControlsRow.setBufferedProgress(bufferedTime);

73. ArrayObjectAdapter
(Adapter Rows)
ArrayObjectAdapter
(Related Posts)
ArrayObjectAdapter
(Primary Actions)
ArrayObjectAdapter
(Secondary Actions)
PlayBackControlsRow
Meta Data

74. GuidedStepFragment
Display a set of selectable options to the user

77. @Override
public GuidanceStylist.Guidance
onCreateGuidance(Bundle savedInstanceState) {
String title = getString(…);
String description = getString(…);
Drawable icon = getActivity().getDrawable(…);
return new GuidanceStylist.Guidance(
title, description, "", icon);
}

78. @Override
public void onCreateActions(
@NonNull List<GuidedAction> actions,
Bundle savedInstanceState) {
GuidedAction guidedAction = new GuidedAction.Builder()
.id(…)
.title(…)
.description(…)
.checkSetId(OPTION_CHECK_SET_ID)
.build();
guidedAction.setChecked(isChecked);
actions.add(guidedAction);
}

79. ErrorFragment
Display an error message to the user
(Because things don’t always go as planned)

81. ErrorFragment errorFragment =
new ErrorFragment();
errorFragment.setTitle(…);
errorFragment.setMessage(…);
errorFragment.setButtonText(…);
errorFragment.setButtonClickListener(…);

82. Custom Views
Because your app doesn’t have to look boring

83. Tag Card
Tag Card
View
Base Card
View
Text View
Image View

84. Tag Card
TagCardView cardView = new TagCardView(parent.getContext());
Tag post = (Tag) item;
TagCardView cardView = (TagCardView) viewHolder.view;
if (post.tag != null) {
cardView.setCardText(post.tag);
cardView.setCardIcon(R.drawable.ic_tag);
}

85. Icon Card
Icon Card
View
Base Card
View
Text View
Image View
Text View

86. Icon Card
IconCardView cardView = new IconCardView(parent.getContext());
Option option = (Option) item;
IconCardView cardView = (IconCardView) viewHolder.view;
if (option.tag != null) {
cardView.setCardIcon(R.drawable.ic_loop);
cardView.setTitleText(option.title);
cardView.setValueText(option.title);
}

87. Loading Card
Loading Card
View
Base Card
View
Progress Bar

88. Loading Card
LoadingCardView cardView = new LoadingCardView(parent.getContext());
IconCardView cardView = (IconCardView) viewHolder.view;
cardView.setIsLoading(true);

89. Live Card

90. Live Card
Live Card
View
Base Card
View
Preview Card
View
Looping Video
View
Progress Bar
Image View
View
(Transparent Overlay)
Video View

91. Live Card
LiveCardView cardView = new LiveCardView(parent.getContext());
Post post = (Post) item;
LiveCardView cardView = (LiveCardView) viewHolder.view;
if (post.videoUrl != null) {
cardView.setTitleText(post.description);
cardView.setContentText(post.username);
cardView.setVideoUrl(post.videoUrl);
Glide.with(cardView.getContext())
.load(post.thumbnailUrl)
.centerCrop()
.error(mDefaultCardImage)
.into(cardView.getMainImageView());
}

92. Leanback Cards
https://github.com/hitherejoe/LeanbackCards

94. Google Guidelines

96. Testing.

97. onView(withId(R.id.title_orb))
.perform(click());
onView(withId(R.id.browse_headers))
.perform(RecyclerViewActions
.actionOnItemAtPosition(i, click()));
onView(withItemText(post.description,
R.id.browse_container_dock))
.perform(click());
Dig deep and remember, everything has IDs!

98. Android N(utella?)

99. Picture-in-Picture

101. <activity android:name=“.ui.video.VideoActivity”
android:resizeableActivity="true"
android:supportsPictureInPicture="true"
android:configChanges=
“screenSize|smallestScreenSize|screenLayout|orientation" />

102. @Override
public void onActionClicked(Action action) {
if (action.getId() == R.id.lb_control_picture_in_picture) {
getActivity().enterPictureInPicture();
return;
}
}

103. @Override
public void onPictureInPictureChanged(boolean inPictureInPicture) {
if (inPictureInPicture) {
// Hide the controls in picture-in-picture mode.
} else {
// Restore the playback UI based on the playback status.
}
}

104. @Override
public void onPause() {
if (mInPictureInPicture) {
// Continue playback
}
// If paused but not in PIP, pause playback if necessary
}

105. TV Recording

106. Sharing Code

111. github.com/hitherejoe/bourbon

112. What’s next?

113. The future of TV

117. Resources
Official Android TV Documentation
github.com/hitherejoe/vineyard
Google Plus Android TV Community
github.com/hitherejoe/AndroidTvBoilerplate
github.com/hitherejoe/leanbackcards
medium.com/@hitherejoe
