The document discusses network programming in Java using the java.net package. It covers using TCP and UDP for network communication. TCP provides reliable, ordered streams between hosts using sockets, while UDP provides simpler datagram transmission that is unreliable but can be broadcast. The InetAddress class represents IP addresses, and sockets are used for both TCP clients/servers and UDP communication.

1. Network
Programming
in Java
JAVA.NET PACKAGE PROVIDE CLASSES FOR NETWORK
PROGRAMMING
BY((ASHOK HIRPARA))

2. Network Programming in
Java
 Java’s network support
 Addressing other machines
 Communicating using TCP/IP
 Communicating using UDP
 Broadcasting and multicasting

3. Network Programming in
Java
 Java distinguishes between UDP, TCP server & TCP
client sockets
 java.net.InetAddress class represents a single
IP address
 java.net.UnkownHostException thrown if DNS
system can’t find IP address for specific host

4. IP Addresses and Java
 Java has a class java.net.InetAddress
which abstracts network addresses
 Serves three main purposes:
 Encapsulates an address
 Performs name lookup (converting a host name into
an IP address)
 Performs reverse lookup (converting the address
into a host name)

5. java.net.InetAddress
 Static construction using a factory method
 InetAddress getByName(String hostName)
 hostName can be “host.domain.com.au”, or
 hostName can be “130.95.72.134”
 InetAddress getLocalHost()
 Some useful methods:
 String getHostName()
 Gives you the host name (for example “www.sun.com”)
 String getHostAddress()
 Gives you the address (for example “192.18.97.241”)
 InetAddress getLocalHost()
 InetAddress[] getAllByName(String hostName)

6. Using InetAddress objects
 import java.net.InetAddress;
 import java.net.UnknownHostExcepion;
 public static void main(String[] args)
 {
 try {
 InetAddress inet1 =
 InetAddress.getByName("asp.ee.uwa.edu.au");
 System.out.println(
 "HostAddress=" + inet1.getHostAddress());
 InetAddress inet2 =
 InetAddress.getByName("130.95.72.134");
 System.out.println("HostName=" + inet2.getHostName());
 if (inet1.equals(inet2))
 System.out.println("Addresses are equal");
 }
 catch (UnknownHostException uhe) {
 uhe.printStackTrace();
 }
 }

7. Transmission Control Protocol
 TCP is built on top of IP
 Provides the illusion of a continuous flow (or
stream) of data between sender and receiver
(rather like a telephone call)
 Splits up streams into strings of small datagrams
which are sent in succession
 Contains an error recovery mechanism to recover
datagrams which are lost
 These features make application development
simpler and so it is widely used

8. Two types of TCP Socket
 java.net.ServerSocket is used by servers
so that they can accept incoming TCP/IP
connections
 A server is a piece of software which advertises and
then provides some service on request
 java.net.Socket is used by clients who wish
to establish a connection to a (remote) server
 A client is a piece of software (usually on a different
machine) which makes use of some service

9. java.net.ServerSocket
 Listens on well-known port for incoming
connections
 Creates a dynamically allocated port for each
newly established connection
 Provides a Socket connected to the new port
 Maintains a queue to ensure that prospective
clients are not lost

10. java.net.ServerSocket
 Construction:
 ServerSocket(int port, int backlog)
 Allows up to backlog requests to queue
waiting for the server to deal with them
 Some useful methods:
 Socket accept()
 Blocks waiting for a client to attempt to
establish a connection
 void close()
 Called by the server when it is shutting down
to ensure that any resources are deallocated

11. java.net.Socket
 Provides access to TCP/IP streams
 Bi-directional communication between sender
and receiver
 Can be used to connect to a remote address
and port by using the constructor:
 Socket(String remoteHost, int port)
 Also used to accept an incoming connection
(see ServerSocket)

12. java.net.Socket
 Can obtain access to input and output streams
 Input stream allows reception of data from the
other party
 InputSteam getInputStream()
 Output stream allows dispatch of data to the
other party
 OutputStream getOutputStream()

13. How it all fits together
2037 80
2037 1583
2037 1583
Client (A) Server (B)
ServerSocket ss.
s = ss.accept()
s = new Socket
(“B”, 80)
Socket s
s.getInputStream()
s.getOuputStream()
s.getInputStream()
s.getOuputStream()

14. A sample TCP server
public static void main(String[] args)
{
try {
ServerSocket agreedPort =
new ServerSocket(AGREED_PORT_NUMBER, 5);
while (isStillServing()) {
Socket session = agreedPort.accept();
respond(session);
session.close();
}
agreedPort.close();
}
catch (UnknownHostException uhe) {
// Very unlikely to occur
}
catch (IOException ioe) {
// May occur if the client misbehaves?
}
}

15. A sample TCP client
public static void main(String[] args)
{
try {
InetAddress server = InetAddress.getByName(args[0]);
Socket connection =
new Socket(server, AGREED_PORT_NUMBER);
makeRequestToServer(connection);
getReplyFromServer(connection);
connection.close();
}
catch (UnknownHostException uhe) {
// arg[0] is not a valid server name or IP address
}
catch (IOException ioe) {
// The connection to the server failed somehow:
// the server might have crashed mid sentence?
}
}

16. What are datagrams?
 Datagrams are discrete packets of data
 Each is like a parcel that can be addressed and
sent to an recipient anywhere on the Internet
 This is abstracted as the User Datagram Protocol
(UDP) in RFC768 (August 1980)
 Most networks cannot guarantee reliable delivery
of datagrams

17. Why use datagrams?
 Good for sending data that can naturally be
divided into small chunks
 Poor for (lossless) stream based communications
 Makes economical use of network bandwidth (up
to 3 times the efficiency of TCP/IP for small
messages)
 Datagrams can be locally broadcast or multicast
(one-to-many communication)

18. Application using
datagrams
 UDP can be used for economical point-to-point
communications over LANs
 Datagrams can be used for one-to-many
communication:
 Local network broadcasting;
 Multicasting (MBONE)
 but there is no way to create one-to-many
streams using TCP/IP

19. java.net.DatagramPacket
(1)
 DatagramPackets normally used as short lived
envelopes for datagram messages:
 Used to assemble messages before they are
dispatched onto the network,
 or dismantle messages after they have been
received
 Has the following attributes:
 Destination/source address
 Destination/source port number
 Data bytes constituting the message
 Length of message data bytes

20. java.net.DatagramPacket
(2)
 Construction:
 DatagramPacket(byte[] data, int length)
 Some useful methods:
 void setAddress(InetAddress addr)
 InetAddress getAddress()
 void setPort(int port)
 int getPort()
 DatagramPackets are not immutable so, in principle
you can reuse then, but . .
 Experience has shown that they often misbehave
when you do -- create a new one, use it once, throw
it away!

21. java.net.DatagramSocket
(1)
 Used to represent a socket associated with a
specific port on the local host
 Used to send or receive datagrams
 Note: there is no counterpart to
java.net.ServerSocket! Just use a
DatagramSocket with a agreed port number so
others know which address and port to send their
datagrams to

22. java.net.DatagramSocket
(2)
 Construction:
 DatagramSocket(int port)
 Uses a specified port (used for receiving
datagrams)
 DatagramSocket()
 Allocate any available port number (for sending)
 Some useful methods:
 void send(DatagramPacket fullPacket)
 Sends the full datagram out onto the network
 void receive(DatagramPacket emptyPacket)
 Waits until a datagram and fills in emptyPacket
with the message
 . . . and a few more in the Javadoc

23. sea.datagram.DatagramSend
er
 This example sends datagrams to a specific host
(anywhere on the Internet)
 The steps are as follows:
 Create a new DatagramPacket
 Put some data which constitutes your message in
the new DatagramPacket
 Set a destination address and port so that the
network knows where to deliver the datagram
 Create a socket with a dynamically allocated port
number (if you are just sending from it)
 Send the packet through the socket onto the
network

24. sea.datagram.DatagramSen
der
byte[] data = “This is the message”.getBytes();
DatagramPacket packet =
new DatagramPacket(data, data.length);
// Create an address
InetAddress destAddress =
InetAddress.getByName(“fred.domain.com”);
packet.setAddress(destAddress);
packet.setPort(9876);
DatagramSocket socket = new DatagramSocket();
socket.send(packet);

25. sea.datagram.DatagramRecei
ver
 The steps are the reserve of sending:
 Create an empty DatagramPacket (and allocate a
buffer for the incoming data)
 Create a DatagramSocket on an agreed socket
number to provide access to arrivals
 Use the socket to receive the datagram (the thread
will block until a new datagram arrrives)
 Extract the data bytes which make up the message

26. sea.datagram.DatagramRecei
ver
// Create an empty packet with some buffer space
byte[] data = new byte[1500];
DatagramPacket packet =
new DatagramPacket(data, data.length);
DatagramSocket socket = new DatagramSocket(9876);
// This call will block until a datagram arrives
socket.receive(packet);
// Convert the bytes back into a String and print
String message =
new String(packet.getData(), 0, packet.getLength());
System.out.println("message is " + message);
System.out.println("from " + packet.getAddress());

27. But it’s never quite that
simple!
 Several of the constructors/methods throw
exceptions which I have omitted
 Each datagrams can only hold up to a maximum
of 64KB of data . .
 . . but the underlying transport layer may split the
message into smaller packets (for instance
Ethernet uses about 1500 bytes)
 Always remember that UDP is an unreliable
protocol: If any of the split datagrams are lost the
whole message will be lost
