This document discusses the performance of concrete incorporating industrial and agricultural wastes. It describes adding sisal, flax, glass fiber, and carpet waste fibers at percentages of 0.5%, 1%, and 2% by volume to concrete mixes. Tests were performed on 234 concrete cubes to measure compressive strength, 39 beams for flexural strength, and 39 cylinders for indirect tensile strength. The results showed improvements in the mechanical and durability properties of concrete with the addition of glass fibers and waste fibers.
Physical and mechanical properties of concrete incorporating industrial and a...eSAT Journals
